Kintec Digital Technology KDS‐0702 User manual

1
Digital Signage
KDS‐0702, KDS‐1003, KDS‐1004
Built in Motion Sensor
Operating Instructions
Before operating the unit, please read this manual thoroughly and retain it for future
reference.
2011 By Kintecdigital
Motion Sensor
Speakers
SD Card Slot
Power
USB Port
Vesa Hole
Volume Control Button
Motion sensor switch button
Stand
LCD

2
Specifications:
General
Panel Size/Type LCD Panel
Resolution/Aspect Ratio KDS0702: 7”, 800x480/16:9,
KDS1003: 9.7”, 1024x768/4:3
KDS1004: 10.1”, 1024X600/16:9
DSP F1C100
Function 720p HD Video & Picture Mix Playback, Scroll text
Storage
Internal Memory Optional (Support 128MB~2GB)
Flash Card SD/SDHC/MMC up to 32GB
Support Format
Video Mpeg‐1/2,DIVX,XVID,WMV9/VC‐1,RMVB,H.263,H.264,FLV
all format up to 720P@30fps
Audio MP3,AAC
Images JPEG,BMP,GIF,PNG,Maximum 16M pixels
User Interface
Motion Sensor 3~4m/120° Human body infrared sensor
Hardware Keys 4 Buttons (Power/ Menu /Vol‐/vol+)
USB Interface USB 2.0 Host
Stereo Speaker 2Wx2
Brightness 300 nits
Contrast 600
Lifetime 20000 hr
Dimension/Weight/Condition
Dimension 243x227x26mm
Weight 780g
Operation Condition 0℃~40℃
Storage Condition ‐20℃~55℃
Power
AC/DC Adapter DC 5V‐2A, Φ3.5mm,Center PIN 1.2mm

3
Content‐Delivery Method: Removable Devices: USB Drives
Prepare a SD card for content storage, and use a USB drive for content delivery.
Content can be also updated directly from a SD card.
Video, and image management:
The Image and video files on a SD card display sequence according to ASCII code. Ex.
1.JPG, 2.JPG, 3.AVI, 4.JPG.
Rolling text management:
Caption.txt: Rolling text input
Setting.txt: Define rolling text message size, color, and speed.
Font TTF: Define font size.
Ex.
Font: 48
Text color: 65280
BG color: 255
Alpha: 48
Speed: 1
Step 1:
Option 1: USB drives
Option 2: SD card
Step 1:
Create content on your PC
and save it onto a USB
drive
Step 2:
Remove a USB drive from your PC by Inserting a USB
drive to signage, and later content will be
automatically updated.
Step 1:
Create content on your SD
card by dragging and
dropping videos & images
Step 2:
Insert a SD card into signage that content can be
played directly from a SD card.

4
Description：
Font: 48 Font size value from 16 to 48
Text color 65280 Rolling text color, edited by hexadecimal. Each R, G, B accounts
for 8bit to combine into a color value. Value range starts with
0~0xFFFFFF. Ex. 0xFFFFFF represents in white color，0xFF0000
represents in red color，0x00FF00 represents in green color，
0x0000FF represents in blue color.
BG color 255 Rolling text background color，edited by hexadecimal. Each R,
G, B accounts for 8bit to combine into a color value. Value
range starts with 0~0xFFFFFF. Ex. 0xFFFFFF represents in white
color，0xFF0000 represents in red color，0x00FF00 represents in
green color，0x0000FF represents in blue color.
Alpha 48 Rolling text background transparence, value from 0 to 255，
0=transparence, 255=completely opaque
Speed 1 Rolling text speed
Motion sensor operating principle:
Detecting range: 120 degree, 3 to 4M.
Sound is automatically switched on while detecting any object enters the detection
range. Sound is switched off after 45 sec, but monitor will continue to play video, even
if no movement is detected.
Youcanalsofindmotionsensorsetupoptioninmenusetup.Whilemotionsensor
function is set off, the monitor will function normally with sound.
Key Functions:
Power/Exit: long press to turn power on/off. Short press to exit.
Menu/Enter: press menu to access below setups:
‐Volume+, Volume‐adjustment.
‐Language: current language availability only in English and Chinese.
‐Sensor: Set motion sensor on/off.
‐Date/Time: Date and time adjustment.
‐Default setting.
‐Setup options
Content updating methods:
1. Copy videos, images, Caption.txt, Font.TTF, Setting.txt, and Update.txt to a USB drive. The
image is shown as below:

5
2. Insert a USB drive into USB host, and reboot the device. The screen will be shown “update
in process” as below:
3. Remove a USB, once update is completed. Please note that the device will automatically
reboot itself while update is completed. The screen is shown as below:
Firmware upgrading:
1. Format your SD card before copy all updated files to a SD card.
2. Ensure file name is FWUPDATE.IMG.
3. Insert SD card into SD slot and reboot the device. The screen is shown “FW update in

6
process” as blow:
Notes:
‐Once FW upgrade is completed, the screen will automatically switch off and switch on.
Please unplug power, otherwise the device will keep upgrading the firmware.
-Do not power off, while updating. The device may cause a crash while removing power
during updating process.
‐Different signage models need to map the corresponding signage Firmware. Please consult
an original manufacturer for firmware upgrade.
