KIRON 30 – 80MM F/3.5 – 4.5
PART
NUMBER
REF
NUMBER
PART DESCRIPTION QUANTITY
N
M
C
K
O
P
K56001
800515
1
RING, NAME
1
1
1
1
1
Z75905B
760520
2
SETSCREW, 1.4 x 1.5
4
4
4
4
4
K56002
800515
3
RING. FRONT
1
1
1
1
1
Z75918B 760520 4 SETSCREW, 1.4 x 2.0 4 4 4 4 4
K56912 800515 5 RING, FABRIC A 1 1 1 1 1
K56902
800515
6
SPACER, FRONT FOCUSING 1.0mm
1
1
1
1
1
K17900B
790203
7
SCREW, PANHEAD 1.7 x 2.5
7
7
7
7
7
K56032
800515
8
GRIP
1
1
1
1
1
K56003 800515 9 RING, ZOOM DRIVE 1 1 1 1 1
K80935 771115 10 WASHER 5 5 5 5 5
K54900
800110
11
ROLLER
2
2
2
2
2
K54901
800110
12
SHAFT, ROLLER
2
2
2
2
2
K56004
800515
13
RING, FOCUSSING INDEX
1
1
1
1
1
K56913
800515
14
RING, FABRIC B
1
1
1
1
1
K56012 800515 15 RING, FOCAL LENGTH INDICATOR 1 1 1 1 1
Z579963B 760520 16 SCREW, FLATHEAD 1.4 x 2.5 3 6 6 3 6
K54910
800110
17
SPACER, 4
TH
GROUP 0.3mm
1
1
1
1
1
K56907
800515
18
SPACER, REAR FOCUSING 1.0mm
2
2
2
2
2
V82905
770718
19
PIN, GUIDE
1
1
1
1
1
K56022
800515
20
RING
, 1
st
/2
nd
ELEMENT RETAINING
1
1
1
1
1
G00331 800515 21 LENS, 1st ELEMENT 1 1 1 1 1
G00332 800515 22 LENS, 2
nd
ELEMENT 1 1 1 1 1
K56023
800515
23
HOUSING, 1
st
LENS GROUP
1
1
1
1
1
G00333
800515
24
LENS, 3
rd
ELEMENT
1
1
1
1
1
K56024
8005
15
25
RING, 4
th
ELEMENT RETAINING
1
1
1
1
1
G00334 800925 26 LENS 4th ELEMENT 1 1 1 1 1
K56025 800925 27 HOUSING, 2nd LENS GROUP 1 1 1 1 1
G00335
800515
28
LENS, 5
th
ELEMENT
1
1
1
1
1
G00336
800515
29
LENS, 6
th
ELEMENT
1
1
1
1
1
K56044
801205
30
HOUSING, 7
th
/8
th
LENS ELEMENT
1
1
1
1
1
G00337
801205
31
LENS, 7
th
ELEMENT
1
1
1
1
1
G00338 801205 32 LENS, 8TH ELEMENT 1 1 1 1 1
K56010 800515 33 RING, CAM STOPPER 1 1 1 1 1
K56008
800515
34
RING, CAM
1
1
1
1
1
Z75933B
760520
35
SCREW, PANHEAD 1.7 x 3.0
2
2
2
2
2
K80914B
771115
36
SCREW,
PANHEAD
1.7
x 4.0
4
4
4
4
4
K
56006
800515
37
RING, MIDDLE
1
1
1
1
1
K56007 800515 38 RING, RETAINING 1 1 1 1 1
Z75927B
760520
39
SCREW, FLATHEAD 1.7 x 3.0
3
3
3
3
3
K56019
800515
40
RING, 2
nd
LENS GROUP
1
1
1
1
1
K54903
800110
41
ROLLER
B
3
3
3
3
3
K54902
800110
42
ROLLER
A
3
3
3
3
3
K54904 800110 43 SHAFT, ROLLER 3 3 3 3 3
K56009 800515 44 HELECOID, INNER 1 1 1 1 1
K56020 800515 45 RING, 3
rd
LENS GROUP 1 1 1 1 1
K56005
800515
46
HELECOID, OUTER
1
1
1
1
1
K56011
800515
47
RING, HELECOID STOPPER
1
1
1
1
1
K56914
800515
48
SETSCREW 1.4 x 1.5
2
2
2
2
2
K56723 800515 49 PLATE, HELECOID GUIDE 1 1 1 1 1
K54922B 800110 50 SCREW, PANHEAD 1.7 x 2.5 2 2 2 2 2
K56013
800515
51
RING, FOCUSING LIMIT
1
1
1
1
1
K56702
800515
52
PLATE, HELECOID GUIDE
1
1
1
1
1
N
M
C
K
O
P
