KISANKRAFT KK-BC2-JP30 User manual

Warranty Certificate
(DEALER COPY)
This warranty is null & void, if you fail to register the warranty with
KisanKraft by sending the KisanKraft Copy with dealer’s stamp.
KisanKraft Machine Tools Private Limited
: www.kisankraft.com : [email protected]om : +91.80. 22178200
Page 1 of 68
Product Brush Cutter KisanKraftTM
Invoice Date
Brand KisanKraft KisanKraftTM
Invoice No.
Model
KK-BC2-JP30
KK-BC2-JP45
KK-TC2-JP45
WARRANTY
PERIOD 6MONTHS
FOR THE SPECIFIED PERIOD FROM THE
DATE OF SALE OR DELIVERY WHICHEVER IS
EARLIER.
Dealer’s
Invoice Date Dealer’s Invoice
No.
Buyer’s Info (Name, Address, Phone, etc.):
Dealer’s Stamp (Address, Phone, TIN, etc.):
Buyer’s Sign Dealer’s Sign
What is covered: KisanKraft Machine Tools Private Limited and its manufacturers
warrant this product to be free from defects in material or workmanship. All parts
defective in material and workmanship are covered.
This warranty will only cover defects arising under normal usage.
This warranty is limited to repair or replacement by KisanKraft Machine Tools Private
Limited or its manufacturers at the premises of Authorized Dealers, of such parts as
appear to KisanKraft or its manufacturers, upon inspection, to be defective in material
and/or workmanship. KisanKraft or its manufacturers make no warranty with respect to
trade accessories not manufactured or sold by them.
What is not covered: The warranty shall become null and void and neither KisanKraft
Machine Tools Private Limited nor any of its manufacturers, nor its authorized dealers
assumes any responsibility, if the failure was caused by the following:
(1) Operation of product with incorrect fuel or lubricants, (2) Incorrect usage of machine
or misuse, (3) Lack of maintenance, (4) Negligence, (5) Accident or physical damage,
(6) Repairs made by unauthorized parties and/or with unauthorized parts, (7) Improper
set up, adjustments, tampering or altered products

Warranty Certificate
(DEALER COPY)
This warranty is null & void, if you fail to register the warranty with
KisanKraft by sending the KisanKraft Copy with dealer’s stamp.
KisanKraft Machine Tools Private Limited
: www.kisankraft.com : [email protected]om : +91.80. 22178200
Page 2 of 68
Important: (1) Normal maintenance and adjustments to the product is the responsibility
of the customer. (2) Normal wear and tear is not covered under warranty
(3) Rubber/plastic parts and consumables such as blades, clutch and clutch-bell, spark-
plugs, nylon line, air-filters, fuel-filters, oil seals etc. are not covered under the warranty.
No Warranty On Electrical Motor / Electrical Parts Etc.
Incidental / Consequential Loss: KisanKraft Machine Tools Private Limited or its
manufacturers will not be liable for general damages, including bodily injuries, or for
incidental or consequential damages including, but not limited to, loss of use, loss of
profits, loss of production, expense of substitute equipment or other commercial loss or
damage.
Limitation of Liability: This limited warranty is in lieu of all other express warranties,
obligations, or liabilities. Any implied warranties, obligations or liabilities, including, but
not limited to, any implied warranty of merchantability shall be limited in duration to the
applicable warranty period. Any action for breach of any warranties hereunder,
including, but not limited to, any implied warranty of merchantability must be brought
within the applicable warranty period.
Modifications of Warranty: No agent, representative, dealer, or employee of
KisanKraft Machine Tools Private Limited or any of its manufacturers has the authority
to increase or alter the obligations of this warranty.
Assignment / Transfer of warranty: The warranty cannot be assigned and shall not
transfer if the product is resold by the first buyer. The above warranties are extended to
the first end user (original purchaser), and no warranty is made, nor authorized to be
made assignable on resale by the first end user.
What you must do to obtain limited warranty service: To obtain performance of any
obligation under this warranty for failure during the applicable warranty period, deliver
the defective product, to the nearest Authorized Dealer. KisanKraft Machine Tools
Private Limited, its manufacturers and its dealers reserve the right to inspect the claimed
defective part(s) to determine if the malfunction is the result of a defect covered by this
warranty. Please note that the decision of KisanKraft Machine Tools Pvt Ltd with respect
to any warranty claim is final.
Receipt is required for availing warranty services
Jurisdiction: All disputes are subject to Bangalore court’s jurisdiction.
Our
Products
ChainsawsBrush Cutters and AccessoriesHarvesters
Engines and Water PumpsHand ToolsGarden Tools
Cultivators and AccessoriesSprayers and Accessories
Transplanter and Post Hole Digger Milking Machines

BRUSH CUTTER
KK-BC2-JP30/JP45 , KK-TC2-JP45
: www.kisankraft.com
: [email protected]om : +91.80. 22178200
Page 3 of 68
Operation Manual
KisanKraft Machine Tools Pvt. Ltd.
Sri Huchhanna Tower, #4,1st Main,7-A Cross, Maruthi Layout, Dasarahalli,
HAF Post, Hebbal, Bangalore 560024,Karnataka,INDIA
♦Bangalore (HO) ♦ Ahmedabad ♦ Bhopal ♦ Bhubaneswar ♦ Coimbatore ♦
♦Ernakulam ♦ Guwahati ♦ Patna ♦ Hinudpur ♦ Hubli ♦ Hyderabad ♦
♦Jaipur ♦ Karnal ♦ Kolkata ♦ Lucknow ♦ Nagpur ♦ Pune ♦ Raipur ♦ Shimla ♦

BRUSH CUTTER
KK-BC2-JP30/JP45 , KK-TC2-JP45
: www.kisankraft.com
: [email protected]om : +91.80. 22178200
Page 4 of 68
CONTENTS
BEFORE GETTING STARTED .......................................................................7
SAFETY SYMBOLS ......................................................................................7
SAFETY INSTRUCTIONS..............................................................................8
PRODUCT OVERVIEW..............................................................................13
TECHNICAL SPECIFICATIONS....................................................................15
INSTALLATION –ASSEMBLY ....................................................................16
OPERATING INSTRUCTIONS ....................................................................18
SELECTION OF ROTARY CUTTER ..............................................................21
INSPECTION & MAINTENANCE ................................................................22
STORAGE.................................................................................................25
TROUBLESHOOTING................................................................................26
PARTS DIAGRAM & LIST (KK-BC-JP30) .....................................................27
PARTS DIAGRAM & LIST (KK-BC2 - JP45 & TC2 - JP45) .............................37
2-STROKE GASOLINE ENGINE-MANUAL...................................................51

Warranty Certificate
(CUSTOMER COPY)
This warranty is null & void, if you fail to register the warranty with
KisanKraft by sending the KisanKraft Copy with dealer’s stamp.
KisanKraft Machine Tools Private Limited
: www.kisankraft.com : [email protected]om : +91.80. 22178200
Page 5 of 68
Product Brush Cutter KisanKraftTM
Invoice Date
Brand KisanKraft KisanKraftTM
Invoice No.
Model
KK-BC2-JP30
KK-BC2-JP45
KK-TC2-JP45
WARRANTY
PERIOD 6MONTHS
FOR THE SPECIFIED PERIOD FROM THE
DATE OF SALE OR DELIVERY WHICHEVER IS
EARLIER.
Dealer’s
Invoice Date Dealer’s Invoice
No.
Buyer’s Info (Name, Address, Phone, etc.):
Dealer’s Stamp (Address, Phone, TIN, etc.):
Buyer’s Sign Dealer’s Sign
What is covered: KisanKraft Machine Tools Private Limited and its manufacturers
warrant this product to be free from defects in material or workmanship. All parts
defective in material and workmanship are covered.
This warranty will only cover defects arising under normal usage.
This warranty is limited to repair or replacement by KisanKraft Machine Tools Private
Limited or its manufacturers at the premises of Authorized Dealers, of such parts as
appear to KisanKraft or its manufacturers, upon inspection, to be defective in material
and/or workmanship. KisanKraft or its manufacturers make no warranty with respect
to trade accessories not manufactured or sold by them.
What is not covered: The warranty shall become null and void and neither KisanKraft
Machine Tools Private Limited nor any of its manufacturers, nor its authorized dealers
assumes any responsibility, if the failure was caused by the following:
(1) Operation of product with incorrect fuel or lubricants, (2) Incorrect usage of
machine or misuse, (3) Lack of maintenance, (4) Negligence, (5) Accident or physical
damage, (6) Repairs made by unauthorized parties and/or with unauthorized parts, (7)
Improper set up, adjustments, tampering or altered products.

Warranty Certificate
(CUSTOMER COPY)
This warranty is null & void, if you fail to register the warranty with
KisanKraft by sending the KisanKraft Copy with dealer’s stamp.
KisanKraft Machine Tools Private Limited
: www.kisankraft.com : [email protected]om : +91.80. 22178200
Page 6 of 68
Important: (1) Normal maintenance and adjustments to the product is the
responsibility of the customer. (2) Normal wear and tear is not covered under
warranty.
(3) Rubber/plastic parts and consumables such as blades, clutch and clutch-bell,
spark-plugs, nylon line, air-filters, fuel-filters, oil seals etc. are not covered under the
warranty.
No Warranty On Electrical Motor / Electrical Parts Etc.
Incidental / Consequential Loss: KisanKraft Machine Tools Private Limited or its
manufacturers will not be liable for general damages, including bodily injuries, or for
incidental or consequential damages including, but not limited to, loss of use, loss
of profits, loss of production, expense of substitute equipment or other commercial
loss or damage.
Limitation of Liability: This limited warranty is in lieu of all other express warranties,
obligations, or liabilities. Any implied warranties, obligations or liabilities, including,
but not limited to, any implied warranty of merchantability shall be limited in duration
to the applicable warranty period. Any action for breach of any warranty hereunder,
including, but not limited to, any implied warranty of merchantability must be brought
within the applicable warranty period.
Modifications of Warranty: No agent, representative, dealer, or employee of
KisanKraft Machine Tools Private Limited or any of its manufacturers has the
authority to increase or alter the obligations of this warranty.
Assignment / Transfer of warranty: The warranty cannot be assigned and shall
not transfer if the product is resold by the first buyer. The above warranties are
extended to the first end user (original purchaser), and no warranty is made, nor
authorized to be made assignable on resale by the first end user.
What you must do to obtain limited warranty service: To obtain performance of
any obligation under this warranty for failure during the applicable warranty period,
deliver the defective product, to the nearest Authorized Dealer. KisanKraft Machine
Tools Private Limited, its manufacturers and its dealers reserve the right to inspect
the claimed defective part(s) to determine if the malfunction is the result of a defect
covered by this warranty. Please note that the decision of KisanKraft Machine Tools
Pvt Ltd with respect to any warranty claim is final.
Receipt is required for availing warranty services
Jurisdiction: All disputes are subject to Bangalore court’s jurisdiction.
Our
Products
ChainsawsBrush Cutters and AccessoriesHarvesters
Engines and Water PumpsHand ToolsGarden Tools
Cultivators and AccessoriesSprayers and Accessories
Transplanter and Post Hole Digger Milking Machines

BRUSH CUTTER
KK-BC2-JP30/JP45 , KK-TC2-JP45
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 7 of 68
BEFORE GETTING STARTED
You are now the proud owner of a KisanKraft product. It is made of the finest materials and
under a rigid quality control system. It will give you long and satisfactory service. To obtain
the best use of our products, please read this manual carefully
It will help you become familiar with the operation of the product and contains many useful
hints about the product maintenance. It is KisanKraft’s policy to utilize as quickly as possible
every advance in our research. The immediate use of new techniques in the manufacture
of products may cause some small parts of this manual to be outdated. KisanKraft
distributers and dealers have the most up-to-date information. Please do not hesitate to
consult them.
SAFETY SYMBOLS
This symbol, the industry’s “Safety Alert Symbol” is used
throughout this manual and on labels on the machine itself
to warn of the possibility of personal injury. Read these
instructions carefully. It is
essential that you read the
instructions and safety regulations before you attempt to
assemble or use this unit.
Read the operation manual carefully
Always wear eye and ear protectors when using this unit
When transporting, checking or adjusting the unit be sure the
engine is stopped.
Keep people out of the danger zone. This is a circle of 15
meter radius around the unit and operator.
This is the safety alert symbol. When you see this symbol in this manual, be
alert and avoid personal injury.
When accompanied by the words “CAUTION” & “WARNIRNG”, it calls your
attention to items or operations which can lead to serious injury.

BRUSH CUTTER
KK-BC2-JP30/JP45 , KK-TC2-JP45
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 8 of 68
UNDERSTAND SIGNAL WORDS AND FOLLOW SAFETY INSTRUCTIONS
WARNING: To avoid serious injury
You should pay special attention to the above “WARNINIG” signal text given in this manual
as failure to do so could result in injury or death to the operator.
CAUTION: To avoid serious injury
You should pay special attention to the above “CAUTION” signal text given in this manual
as failure to do so could result in mechanical damage or failure.
NOTE: This symbol refers to an area or subject of special merit emphasizing either the
products capabilities, common errors in operation, maintenance and instructions which are
of special interest.
A circular band with a diagonal slash means whatever is shown is
prohibited.
SAFETY INSTRUCTIONS
Read the operator’s manual carefully.
Be familiar with the controls and the
proper use of the unit.
How to turn the unit off, and how to
unhook the harness quickly in an
emergency.
Dress:
WARNING: To avoid serious injury
1. There is a great risk to eyes from thrown objects.
Always wear proper eye protection in
accordance with standards
2. Dress in long pants and wear boots or safety shoes. Wear leg guards when cutting
large or thorny material
3. DO NOT wear open-
toed shoes or go baraefoot or
barelegged.DO NOT wear loose or dangling clothing,
neckties, scarfs,or jewellwey which could be caught in eh unit
or the vegetaion
4. Secure hair under hat.

BRUSH CUTTER
KK-BC2-JP30/JP45 , KK-TC2-JP45
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 9 of 68
Environmental Precautions:
1.
Never allow children to operate or play with the
machine.
Never allow anyone without proper instruction to use
the unit.
WARNING: To avoid serious injury
2. Keep people out of the danger zone. This is a circle of
15m radius around the unit and operator
3. Operate only where firm footing is assured. DO NOT
operate from a ladder or any other place where use of
hands would ordinarily be necessary to prevent falls.
4. DO NOT operate under the influence of alcohol,
drugs, medications or substances which can affect
your vision, dexterity or judgment. You must be
healthy physically and mentally in order to operate
safely.
5. DO NOT operate in unventilated areas. Exhaust gas
is highly poisonous.
Strictly No Fire:
WARNING: Handle petrol with care. It is highly flammable
.
1. Move at least three meters away
from the fueling point before
starting engine.
2. DO NOT remove the fuel cap
when engine is still warm or
running.
3. Eliminate all sources of sparks or
flame (including smoking, open
flames, or work that could cause
sparks) in the areas where fuel is
mixed, poured, or stored.

BRUSH CUTTER
KK-BC2-JP30/JP45 , KK-TC2-JP45
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 10 of 68
4. Always stop the engine to refuel the tank.
5. Handle in a clean and dry place away from fire.
6. DO NOT smoke while handling fuel.
7. Always store petrol in an approved container.
8. DO NOT refuel a hot engine. Wait until the
engine has cooled down.
9. Avoid spilling of fuel or oil. Spilt fuel should
always be wiped off.
10.
Mix, pour, and store petrol in an approved
marked container and in a well-ventilated area.
Checks before Starting:
1. Adjust the handle to a position for comfort and
keep good balance as recommended in this
manual.
2. Make sure the unit is assembled properly.
3. Always use a harness if provided with the unit.
Balance the unit as recommended by
adjusting the position of the harness
WARNING: To avoid serious injury
4. Hold the unit down firmly so that
you may not lose control while
cranking. If not held down
properly, the engine could pull
you off balance or swing the
cutting line into an obstruction or
your body.
5. DO NOT cut with dull, cracked
or damaged metal blade.
6. Keep the unit and attachments in good working condition. Tighten fastening
parts at regular intervals. Check the cutting head assembly before using each
time.

BRUSH CUTTER
KK-BC2-JP30/JP45 , KK-TC2-JP45
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 11 of 68
NOTE:
7. Thoroughly inspect the area where the unit
is to be used and remove all stones, sticks,
wire and other objects that could cause
injury if thrown at high speeds.
8. Never operate the unit without proper guards, shields or other safety protective
devices in place and properly connected. Inspect to determine that these safety
devices are installed properly, are in good condition and operate properly. If the
condition or operation of the devices are abnormal, they must be repaired or
replaced before using the unit.
9. Make sure the cutting head stops turning when the throttle trigger is released and
the engine runs at idle speed.
10. DO NOT use any accessory or attachment other than those supplied by the
manufacturer for use with this particular unit.
11. Use only for jobs mentioned in this manual.
12. Inspect the entire unit before using each time for worn, loose, or damaged parts.
DO NOT use until the unit is in proper working order.
13. DO NOT attach any blade to a unit without proper installation of all required parts.
Cautions during Operation:
1. If necessary to cut where people or cars could be hit
by thrown objects, cut at reduced (slow) throttle speed
to reduce the speed of the cutting head.
CAUTION: To avoid serious injury
2. Shut down immediately if the unit starts to shake or
vibrate. This could be a sign of danger from a broken
part or missing fasteners.
3. Disconnect spark plug wire before you work on the
unit or leave it unattended.

BRUSH CUTTER
KK-BC2-JP30/JP45 , KK-TC2-JP45
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 12 of 68
4. Always keep both hands on the control handles. DO
NOT operate one-handed. DO NOT hold material
you are cutting.
WARNING: To avoid serious injury
5. After shutting down the engine, keep fingers and
feet away from the cutting head until all rotation
stops.
6. Never use wire in place of nylon monofilament
cutting lines. The wire tip can break off during
cutting and become a dangerous missile.
7. DO NOT put hands or feet near or under rotating
parts while engine is running.
8. BLADE THRUST may occur when the spinning
blade contacts a solid object in the critical area. A
dangerous reaction may occur causing the entire
unit and operator to
be thrust violently. This
reaction is called BLADE THRUST. As a result the
operator may lose control of the unit which may
cause serious or fatal injury. BLADE THRUST is
more likely to occur in areas where it is difficult to
see the material to be cut.
9. To avoid hitting small stones or other debris, do
not cut too close to the ground.
10. Keep cutting attachment below waist level.
11. After striking a foreign object or if the unit vibrates
abnormally, stop the engine, disconnect and
secure the spark plug wire. Inspect the unit for any
damage and repair it if necessary.
12. Cover the blade when storing or during transport.
13. The muffler side of the engine should be away
from your body. This is necessary to avoid arm
burns.

BRUSH CUTTER
KK-BC2-JP30/JP45 , KK-TC2-JP45
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 13 of 68
Precautions after Operation:
WARNING:
1. Do not store the unit with fuel in the tank, because a fuel leak could start
a fire. Allow the engine to cool before storing in any enclosure.
2. Before cleaning, repairing or inspecting, make certain
cutting head has stopped. Disconnect and secure the
spark plug away from plug to prevent accidental
starting
3. Use only recommended, genuine replacement parts to avoid creating a hazard
and/or voiding your warranty.
4. Store in a dry area out of reach of children.
PRODUCT OVERVIEW
KK-BC2-JP30:
1. Nylon cutter
2. Gear case
3. Cutting attachment guard
4. Shaft tube
5. Handle
6. Harness
7. Suspension eyelet
8. Throttle trigger
9. Engine switch
10. Clutch case
11. Throttle wire
12. Lead wire
13. Engine
14. Main grip

BRUSH CUTTER
KK-BC2-JP30/JP45 , KK-TC2-JP45
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 14 of 68
KK-BC2-JP45:
1. Nylon cutter
2. Gear case
3. Cutting attachment guard
4. Shaft tube
5. Handle
6. Harness
7. Suspension eyelet
8. Throttle trigger
9. Engine switch
10. Clutch case
11. Throttle wire
12. Lead wire
13. Engine
KK-TC2-JP45:
1. Blade
2. Gear case
3. Cutting attachment guard
4. Shaft tube
5. Handle
6. Harness
7. Suspension eyelet
8. Throttle trigger
9. Engine switch
10. Clutch case
11. Throttle wire
12. Lead wire
13. Engine
14. protector

BRUSH CUTTER
KK-BC2-JP30/JP45 , KK-TC2-JP45
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 15 of 68
TECHNICAL SPECIFICATIONS
Model KK-BC2-JP30 KK-BC2-JP45 KK-TC2-JP45
Drive System Auto Centrifugal Clutch Spiral Bevel Gear
Reduction Ratio 13:19 14:19 16:19
Drive shaft (mm)
3937
3362
3327
Engine (Mitsubishi) TU26 TU43
Engine type 2 –Stroke
Engine Displacement 26 CC 43 cc
Standard blades
(rpm) Nylon cutter:10000 (max)
Metal balde:255
mmx25.4
mm/10000 (max)
Size (LxWxH) 1770x620x470 1807x620x500 1537x615x415
Fuel Tank Capacity 600 ml 1100 ml
Rated blade speed
(rpm)
5100 4,800 5470
Max output (kw/rpm) 0.67 / 7500 1.27 / 6500
Handle type Double handle
Weight (2 Kgs) 5. 7.6 8.1
Fuel mixture 40ml (2T) oil per 1 Litre of Petrol
Spark plug (mm) 0.6-0.7< gap of electrodes>
Fuel Consumption 400 ml / hour 600 ml / hour
NOTE: The Company reserves the right to change the specifications without prior notice.

BRUSH CUTTER
KK-BC2-JP30/JP45 , KK-TC2-JP45
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 16 of 68
INSTALLATION –ASSEMBLY
Installation of Handle (Double handle):
Insert the handle into the handle joint and fix it
securely using 4 bolts.
Installation of cutting attachment
guard:
Position the cutting attachment guard so that it
contacts the edge of the gear case. Fix in place with
the spacer, bracket and bolts (x2), as shown in the
figure.
NOTE:
For your own safety, be sure to keep the cutting
attachment guard attached during operation.
WARNING: To avoid serious injury
For safety, stop the engine and then attach or detach the blade
.Installation of Blade:
Caution : To avoid serious injury
Blade is sharp, please handle carefully to prevent injury.
Affix parts in the following order: holder
A(2), blade (3), holder B (4), stabilizer (5),
and blade-fastening nut (6).
In order to lock the rotation of the spline
shaft, align holes of gear case (1), and
holder A and insert bar wrench (7).

BRUSH CUTTER
KK-BC2-JP30/JP45 , KK-TC2-JP45
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 17 of 68
Rotate blade-fastening nut with plug box
wrench (8) in counterclockwise direction
until securely tightened.
Installation of Nylon Cutter:

In case of affixing the nylon
cutte
r (9), put parts in the
following order: holder A (2),
holder B (4), and nylon cutter.
As in the case of affixing the
blade, insert bar wrench (7) to
lock the rotation of the spline
shaft.

Rotate nylon cutter in
counterclockwise direction unit
securely tightened
Harness-To-Shaft:
Hold harness remembering the side of
catcher
Work your arms through the straps in
the manner illustrated above (the way
you wear a coat)
Connect the buckle with the catcher
positioned properly. (The buckle can be
engaged by
simple insertion of the
tongue). Then hang the brush cutter to
it and adjust the band length.
Adjust the fit so that the blade lays
almost flat on the ground.
Harness with quick release device:
Use this harness to protect yourself from the unit
in case of emergency (fire in the engine, etc.)
In an emergency, pull the release belt (1) strongly
upward, and you can detach the machine from
you. Be extremely careful to maintain control of
the machine at this time. Do not allow the
machine to be deflected toward you or anyone in
the work vicinity.

BRUSH CUTTER
KK-BC2-JP30/JP45 , KK-TC2-JP45
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 18 of 68
NOTE:
Use hook to connect and disconnect the band from the hunger of the unit. Don’t work the
quick release device with the exception of emergency.
OPERATING INSTRUCTIONS
(Starting & Stopping the Engine)
Preparation before starting the engine:
CAUTION: To avoid serious injury.
Using the fuel with incorrect mixture ratio may cause insufficient
output power or malfunction of the engine.
Wipe off completely any spilled petrol (gasoline). It may soil clothes
or cause a fire.
Fill the fuel tank with the correct mixture of regular automobile petrol (gasoline) and 2 Stroke
engine oil.
Petrol (gasoline) : oil
40:1
Adjustment of the Throttle Wire:
Adjust the play of throttle wire to 0. To 1.0 mm.
Excessive play will cause a starting failure.
Starting the Engine:
Release the throttle trigger (1).
Set the engine switch (2) to the “I” (start) position.
Slowly press the priming pump (3) several times until fuel comes out of the
overflow tube (4). (More than 10 times)
NOTE:
Fuel that overflows by pressing the priming pump is returned by design
to the fuel tank.
Press the priming pump a sufficient number of times to start the engine
as there is no possibility of flooding the engine.
Move the choke lever (5) to the fully closed position ( mark side).

BRUSH CUTTER
KK-BC2-JP30/JP45 , KK-TC2-JP45
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 19 of 68
When fuel is remaining and the engine is warm, move the choke lever to the fully
open position ( mark side).
CAUTION: To avoid serious injury.
Do not pull the recoil starter rope out completely. This can damage
the unit.
Do not let the recoil starter grip snap back. This can cause bodily
injury or damage the unit.
Place the unit on the ground.
Check that the cutting tool is not touching the ground or any other obstacles.
Hold the unit with your left hand and press it down firmly.
Pull the recoil starter grip (6) slowly with your right hand until you feel it engage
and then give it brisk strong pull.
After starting, watch the engine condition and move the choke lever slowly to the
full open position (mark side),
NOTE:
When the explosion sound is heard, but the engine does not start, move the choke lever
the full open position and again pull the starter knob rapidly.
CAUTION: To avoid serious injury.
Do not increase the engine speed immediately after starting as the
lubrication oil is not yet evenly distributed to every part.
When the throttle is in fully open position, the engine speed
becomes considerably high, and that not negatively affects the
engine life but it also can cause engine failure. Do not race the
engine (high revving with the engine at idle), and also avoid
unnecessary high-speed operation.
Release the throttle trigger. Warm up the engine at the idling speed for a few
minutes.
NOTE:
As the engine becomes warm, smooth acceleration is obtained.

BRUSH CUTTER
KK-BC2-JP30/JP45 , KK-TC2-JP45
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 20 of 68
Perform cutting work by setting the throttle trigger to the required RPM.
CAUTION: To avoid serious injury.
Do not stop the engine suddenly during high-speed operation as
this can cause engine damage.
Stopping the Engine:
Release the throttle trigger (1).
Move the engine switch (2) to
the “0” (stop) position.
NOTE:
Storing for short period: Fill the fuel tank until full and store the unit in a dry place
until it is used again in order to prevent condensation.
Storing for long period: Drain the fuel from the fuel tank.
Restart and continue operating the engine until it stops.
WARNING: To avoid serious injury.
Be careful that the inner packing of fuel tank cap is not submerged
in the fuel as shown in the figure, during the summer months when
the unit is not used. If the air hole is submerged in the fuel may leak
due to the increased internal pressure in the fuel tank.
Do not touch the muffler and other parts of the engine when hot.
Doing so could result in serious burn injury. The muffler and other
parts are hot during operation and for some time after stopping the
engine.
