KITCHEN CREW 943353 User manual

Instruction manual
Bedienungsanleitung
Gebruiksaanwijzing
Istruzioni per l‘uso
Mode d‘emploi
Manual de instrucciones
Doppel-Induktionskochfeld
Dubbele inductiekookplaat
Induzione doppio
Induction double
Inducción dobles
Double induction hob

Impressum
Bedienungsanleitung KITCHEN CREW Doppel-Induktionskochfeld
A-Nr.: 943353
Stand: Januar 2020
Druck- und Satzfehler vorbehalten.
Copyright © 2020
Springlane GmbH
Reisholzer Wetstraße 25a
40589 Düsseldo, Germany
Telefon: [phone]
Telefax: [phone]
E-Mail: [e-mail]
Internet: www.springlane.de

Service-Hotline
Bei Fragen zum Gebrauch des Gerätes wende dich bitte an unseren
Kundendienst.
Kostenlose Hotline für Deutschland/Österreich: 0800 270 70 27
E-Mail: [e-mail]

4
INDEX
Instruction manual
Technical data 6
Safety information 6
Using a double induction hob 12
Cleaning and maintenance 16
Troubleshooting 17
Customer Service 19
Disposal/
Environmental Protection 19
Gebrauchsanweisung
Technische Daten 20
Sicherheitshinweise 20
Doppel-Induktionskochfeld
nutzen 26
Reinigung und Pflege 31
Fehler beheben 32
Kundenservice 34
Entsorgung/Umweltschutz 34
Gebruiksaanwijzing
Technische gegevens 35
Veiligheidsaanwijzingen 35
Dubbele inductiekookplaat
gebruiken 42
Reiniging en onderhoud 46
Fouten oplossen 47
Klantenservice 49
Afvalverwijdering/
Milieubescherming 49
Istruzioni per l‘uso
Dati tecnici 50
Informazioni di sicurezza 50
Uso dell piano cottura
a induzione 57
Pulizia e manutenzione 61
Risoluzione dei problemi 62
Servizio clienti 64
Smaltimento/Protezione
dell'ambiente 64

5
Mode d‘emploi
Caractéristiques techniques 65
Consignes de sécurité 65
Usage de la plaque de cuisson 71
Entretien et nettoyage 75
Corriger les problèmes 76
Service à la clientèle 78
Traitement des déchets/
Protection de l’environment 78
Manual de instrucciones
Datos técnicos 79
Advertencias de seguridad 79
Uso de la placa de inducción 86
Limpieza y cuidado 90
Resolución de problemas 91
Atención al cliente 93
Eliminación de residuos/
Protección del medio ambiente 93

6
Technical data
Type of appliance: Poable hob
Number of rings: 2
Heating method: Induction
Size of rings: Ø 26 cm
Total output: 3,500 W, 220-240 V 50/60 Hz
Output le/right hob: 200-2,000 W, 200-1,500 W
Dimensions (W/D/H): 60 x 36 x 4.5 cm
Weight: approx. 5 kg
Temperature range: 60-240 °C
Timer: 0-180 minutes
Feature: Ease of use ensured by touch function, 10 outputs
and 10 temperature levels, timer, child safety
feature and auto switch-off function
Changes and errors in features, technology, colours, and design are
excepted.
Safety information
Please read this manual before using the device for the
first time and keep the manual.
Intended use
The double induction hob is suitable for heating food and
liquids in induction-suitable cookware. The hob heats food-
stuff in a quick and energy-efficient manner using electro-
magnetic heat.

7
Explanation of symbols
This symbol warns of hazards that can damage the
appliance or cause injury.
This symbol warns of electrical hazards that could
damage the appliance or result in personal injury.
This symbol indicates a potential burns risk. Always
make sure to be particularly careful here.
This symbol indicates magnetic fields. They are a
potential hazard to persons with metal parts or
implants and may damage appliances and data carriers.
If you have an electronic implant, please consult your
specialist to find out whether your implant is susceptible
to magnetic interference.
General safety
• After unpacking the appliance, check that it is in
perfect condition and has not sustained any damage
that could impair its functional safety. Should you notice
any defects or if the appliance has fallen on the floor,
do not attempt to use it, but call our customer service.
• Improper repairs can lead to hazards for the user and
the warranty may be deemed void. If individual parts
are damaged, they must be replaced by the manufac-
turer, an authorized specialist company, or a similarly
qualified person.
• Store the appliance out of the reach of children.
• Children under the age of 8 should stay away from the
device or be under constant supervision.
• Children over the age of 8 and persons with reduced
physical, sensory, or mental abilities, or a lack of expe-
rience and/or knowledge of the appliance, should only

8
use it in its intended normal operating position, under
supervision, or after they have been instructed in its
safe use and understand the dangers involved. Children
over the age of 8 should not connect, clean, or service
the appliance. This appliance is not a toy. Children
should be supervised to ensure that they do not play
with the appliance.
• Position the appliance on a free and level surface.
• The appliance is only intended for use in the household
or other similar uses such as
• in kitchenettes in shops, offices, or other workplaces,
• on farms,
• for use by guests in accommodation establishments
(hotels, motels) private guest houses, or holiday
homes.
• Never heat food in sealed containers such as tins, coffee
pots or other pressurized containers. Risk of explosion!
• To ensure full functionality of the appliance and to
avoid injury, never heat empty cookware.
• Do not cover the appliance and do not place items
weighing more than 8 kg on it. Too much weight can
cause damage.
• Do not move the appliance while cooking utensils are
on it.
• Avoid direct contact with sharp objects that could
damage the hob. Should the surface be damaged,
switch the unit off immediately and have the glass
ceramic stove top repaired by an authorized technician.

9
Electrical safety
WARNING! RISK OF ELECTRIC SHOCK
This product may only be opened for necessary
service work by an authorised technician.
WARNING!
Induction works through magnetic fields. They are
a potential hazard to persons with metal parts or implants
and may damage appliances and data carriers. If you have
an electronic implant, please consult your specialist to find
out whether your implant is susceptible to magnetic inter-
ference.
• Connect the appliance only to alternating current as in-
dicated on the type plate. Connect the mains plug only
to an earthed socket.
• Uncoil the power cable completely before use.
• Disconnect the mains plug as soon as you have finished
using the appliance. Do not pull the power cable itself,
as it could cause damage.
• Switch off the machine before plugging in or unplug-
ging it.
• The appliance must not be operated with an external
timer or a separate remote control system.
• Always disconnect the mains plug after use, before
cleaning, or in the event of possible malfunctions during
operation.
• Do not submerge the appliance in water or any other
liquid. Protect the power cable, plug and mains adaptor
from moisture.
• The appliance is not dishwasher-safe.
• Never place or use the appliance and power cable on or
near a hot surface.
• The cable must not hang over the edge of the work
surface.

10
• Do not use the appliance outdoors.
• Ensure that the appliance's ventilation slots are not
blocked at any time.
• Never insert body parts or metallic objects into ventila-
tion slots, there is a risk of injury.
• Do not leave paper between the cookware and the hob.
It could catch fire.
• Do not leave the hob and cookware unsupervised when
in use. If supervision is not possible for a short time,
ensure that there is always enough liquid/content in the
cookware.
• Never use the device near gas stoves. Metal parts could
unintentionally become heated by the magnetic field.
• Except for cookware, do not heat any other metallic
parts on the hob and only use cookware suitable for
induction.
• Do not use the hob as a storage area for paper, fabric
in the form of cleaning rags, metallic objects such as
knives, forks, cans and aluminium foil, as well as other
unsuitable items and highly flammable materials.
• The hob is not suitable for indirect heating. Use suitable
cookware exclusively on the hob without additional aids.
• Keep the device away from heat sources. Do not place
the device on hot surfaces or near open flames.
• The device should be set up a good distance away from
objects that are sensitive to electromagnetic fields
(such as radios, televisions etc.).
• Caution: hot parts! Wait for the device to have cooled
down before touching it with your hands. The surface be-
comes hot during use and may still hold residual heat from
the cookware when the appliance has been turned off.
• Only use the appliance on heat-resistant surfaces.
• Allow the appliance to cool completely before attaching
or removing accessories and before cleaning them.

11
Suitable cookware
WARNING!
Only use cookware that is mentioned in this instruction
manual: flat bottom pots/pans with 16-26 cm base dia-
meter – must be made of steel, stainless steel, cast iron
or enamelled iron. The pans should lie flat on the hob and
the bottom of the pan should not be deformed or bent.
Thinner pan bases are better suited to induction than thick
sandwich bases. Using thinner pan bases highlights the
positive qualities of cooking with induction: short warm-up
phase, fast and controllable frying.
Unsuitable cookware is that which has a rounded bottom
edge or a diameter smaller than 16 cm and is made of the
following materials: glass, ceramic, copper or aluminium.
Before first use
• Remove all parts related to packaging and transport
safety. Make sure that these parts are also kept away
from children - they pose a risk of suffocation!
• Before initial operation and after prolonged periods of
non-use, the appliance should be cleaned. When doing
so, please make sure to note our instructions on cleaning
and care.
• Place the appliance on a level and dry surface.

12
Using a double induction hob
Product description
Hob
3 4
2
1
1. Hob
2. Fans (exhaust)
3. Left control panel with control buttons
4. Right control panel with control buttons
Left control panel
1 2 3 4 3 5 6
1. Timer button
2. Temperature button
3. +/- buttons / locking function
4. Display
5. Output button
6. On/off button

13
Right control panel
1 2 3 4 3 5
1. Timer button
2. Temperature button
3. +/- button / locking function
4. Display
5. Output button
General instructions for use
• Insert the mains plug into the wall
socket.
• Place the cookware in the middle
of the respective ring.
• Press the on/off button to turn
the appliance on. "OFF" will
appear on the left-hand display.
• Adjust the appliance according to
your cooking requirements.
• After use, press the on/off button
to place the appliance on standby.
• Immediately disconnect the mains
plug from the wall outlet.
• Allow the appliance to cool
completely.
• The buttons on the control panel
are touch-sensitive. This means
that there is no need to press
them down firmly. Use your finger-
tips, not your fingernails, to type.
• Always keep the buttons clean
and dry. Do not cover them with
objects such as cloths, potholders
or other cooking utensils. Even a
thin film of water can impair the
function of the buttons.
• Always keep ventilation openings
unobstructed.
• Only use cookware that contains
food or liquid and always place it
in the middle of the hob.

14
• For your safety, the double hob
will turn off after 2 hours of
inactive use, meaning no buttons
are pushed to change the temp-
erature, the output or the time.
• The double hob is equipped
with overheating protection. If
the cookware becomes too hot,
the appliance switches off auto-
matically and the message "E6"
appears on the display. Wait a few
minutes and let the hob cool down
if the appliance gets too hot. The
appliance is then free to be used
again without problem.
Do not touch the hot surfaces during and after use. The hob heats up
intensely and reaches high temperatures – it poses a burn risk.
Power mode for cooking
Use power mode when cooking dishes with a lot of liquid, e.g. pasta,
sauces, or soup.
The left hob can be set from 200 W to 2.000 W, the right hob can be set from
200 W to 1.500 W.
• Press the output button. The watt indicator will light up. “1200” will appear
on the display to the left. “1000” will appear on the display to the right if
you have placed suitable cookware on the hob.
• Touch the +/- buttons to increase or decrease the output.
Output levels
in watts
(left hob) 200 400 600 800 1000 1200 1400 1600 1800 2000
Temperature mode for frying
Use temperature mode when roasting or heating up fat, e.g. sautéing
or deep-frying. Otherwise you may trigger the overheat protection,
which automatically switches off the hob.

15
The hobs can be set from 60 °C to 240 °C.
• Press the temperature button. The temperature indicator will light up. “240”
will appear on the display when suitable cookware is placed on the hob.
• Touch the +/- buttons to increase or decrease the temperature.
Temperature
levels in °C 60 80 100 120 140 160 180 200 220 240
Setting the timer
• Press the timer button. The timer indicator will light up. "0:00" will appear
on the display.
• Touch the +/- buttons to increase or decrease the time set by the timer.
Press and hold the button to increase or decrease the time in 10-minute
increments.
• Press the timer button to confirm.
• When the countdown is over, an acoustic signal sounds and the appliance
switches to standby mode.
To cancel the function:
• Press the on/off button to put the appliance into standby mode. The timer
display will go out.
• Press and hold the timer button to resume operation at the set output or
temperature setting. The timer display will go out.
Locking the appliance
The appliance can be locked to prevent it being operated unintentionally.
• Press and hold + and - keys simultaneously to lock the output button, the
temperature button and the timer button. An acoustic signal will sound.
To cancel the function:
• Press the + and - buttons simultaneously to unlock the appliance.
The locking indicator will stop being lit up. An acoustic signal will sound.

16
Overheat protection
• As a protective measure, the double induction hob automatically switches
off when the temperature sensor detects overheating.
• Please note that overheat protection varies depending on your choice of
operating mode.
• Make sure that you're using power mode to heat up food containing liquid.
Use temperature mode for heating up fat and frying food.
Cleaning and maintenance
Das Gerät sollte nach jeder Nutzung wie folgt gereinigt und getrocknet
werden. Mangelnde oder unsachgemäße Pflege des Geräts kann die Funkti-
onstüchtigkeit des Geräts beeinträchtigen.
• Before performing cleaning or maintenance, turn off the appliance, dis-
connect the mains plug from the wall socket and wait until the appliance has
completely cooled down.
• Never use scouring agents or solvents.
• Do not immerse the appliance in water or other liquids.
• Do not attempt to repair the appliance yourself. If it does not work properly,
replace it with a new one.
• Clean the exterior of the appliance with a soft damp cloth. Use a small
amount of neutral detergent if necessary. Dry the appliance thoroughly with
a dry clean cloth.
• Dry-clean the ventilation opening with a soft brush

17
Troubleshooting
If the appliance is not working properly, please follow these steps:
1. Check that you have followed the operating instructions precisely and
correctly.
2. Check whether the table below offers a feasible solution.
3. Check that all fuses are intact.
Error
code
Problem Solution
After plugging in the mains
plug and using the on/off
button to turn the appliance
on, the display and symbols
are not lighting up.
Make sure that the buttons, cable
connection, power supply and fuse
are not damaged and that the po-
wer cord is properly plugged into
the wall outlet.
The flow of heat stops during
cooking.
The appliance's overheat protecti-
on may have been activated. Dis-
connect the hob from the power
supply, then reconnect the power
supply and restart the appliance.
The appliance must not be cont-
inuously operated for more than
2 hours. The ventilation openings
must not be blocked or dirty. Make
sure that the ambient temperature
is not too high.
E0
There is no cookware on the
hob or the cookware is not
suitable for use with the
induction hob.
Place suitable cookware on the
hob.

18
E2
The temperature sensor
under the hob is defective
or there has been a short
circuit.
Remove the plug from the outlet
and contact customer service.
E3 The hob is receiving too
much voltage.
Make sure the hob is plugged into
a 220-240 V, 50-60 Hz outlet.
E4 The hob is not receiving
enough voltage.
Make sure the hob is plugged into
a 220-240 V, 50-60 Hz outlet.
E5,
E6 The hob has overheated.
Remove the plug from the outlet
and let the hob cool down. If the
problem persists, please contact
customer service.
Ensure that you're using tempe-
rature mode for sautéing and
heating up fat.
If you have any other issues with your double induction hob please contact
our customer service or a professional repair service. Do not try to repair the
machine yourself.

19
Customer Service
In principle, our products have a legal warranty duty of 2 years. Further claims
can only be processed in conjunction with a proof of purchase. Wearing parts
exclude any warranty claims, when usual abrasion has occurred. The durability
is determined by the respective handling and use of the products and is thus
variable.
Free hotline for Germany/Austria only: 0800 270 70 27
From other EU countries: [phone] (Different costs may apply.)
E-Mail: [e-mail]
Disposal/Environmental Protection
Our products are manufactured to high quality standards and are
designed for a long service life. Regular maintenance and care will help
to extend service life. If the appliance is defective and can no longer be
repaired, it must not be disposed of in the normal household waste.
The device must be disposed via your municipal collection center for electrical and
electronic devices. By the appropriate disposal and recycling, you are making an
important contribution to the protection of our environment.
This device applies with the WEEE regulation 2002/96/EG on the Return and
Recycling of Electrical and Electronic Appliances.

20
Technische Daten
A des Geräts: Tragbares Kochfeld
Anzahl der Kochzonen: 2
Heiza: Induktion
Größe der Kochzonen: Ø 26 cm
Leistung gesamt UK: 3500 W, 220-240 V 50/60 Hz
Leistung linkes/rechtes Kochfeld UK: 200-2000 W, 200-1500 W
Maße (B/T/H): 60 x 36 x 4,5 cm
Gewicht: ca. 5 kg
Temperaturbereich: 60-240 °C
Timer: 0-180 Minuten
Ausstaung: Einfache Bedienung durch
Touch-Funktion, 10 Leistungs- und
10 Temperaturstufen, Timer,
Kindersicherung und automatische
Abschaltung
Änderungen und Irümer in Ausstaungsmerkmalen, Technik, Farben und
Design vorbehalten.
Sicherheitshinweise
Bitte lies dir die Gebrauchsanweisung vor Inbetriebnahme
sorgfältig durch und bewahre diese auf.
Verwendungszweck
Das Doppel-Induktionskochfeld eignet sich, um Lebens-
mittel und Flüssigkeiten in induktionsgeeignetem Koch-
geschirr durch elektromagnetische Hitze schnell und
energieeffizient zu erwärmen.
