KitchenAid KCMS2055SSS0 User manual

DOOR PARTS
1
For Models: KCMS2055SSS0
(Stainless)
08−07 Litho in U.S.A. (rek) Part No. W10160568 Rev. A
MICROWAVE OVEN
2.0 CUBIC FOOT
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10114100 Guide, U & C
W10160564 Tech Sheet
W10114101 Cook Guide Label
2
W10160566 Front Screen
3
W10160543 Door Frame Asm
4 8205777 Choke Cover
5
W10160562 Tape, Seal
6 8184263 Latch
7 8183882 Spring, Latch
8
W10160561 Panel, Door
9
W10160557 Door Assembly

CONTROL PANEL PARTS
2
For Models: KCMS2055SSS0
(Stainless)
W10160568
Illus. Part
No. No. DESCRIPTION
1 W10160560 Button, Release
2 8184272 Spring, Button
3
W10160556 Membrane/Panel
4
W10160555 Microcomputer
5 8205451 Lever, Release
6 4358883 Screw

OVEN CAVITY PARTS
3
For Models: KCMS2055SSS0
(Stainless)
W10160568
Illus. Part
No. No. DESCRIPTION
1 8184278 Canopy
2
W10160554 Outer Case
3
W10160544 Tray, Glass
4
W10160542 Turntable Support
5 8184375 Motor, Synchronous
6 4358188 Screw
7 4358829 Screw
8 8171862 Screw
9
W10160547 Sensor, Humidity
10 8205457 Guide, Sensor
11 4358376 Screw
12 4358489 Screw

LATCH BOARD PARTS
4
For Models: KCMS2055SSS0
(Stainless)
W10160568
Illus. Part
No. No. DESCRIPTION
1 Latch Board Assembly
(Non−Serviceable)
2 8185271 Latch Board
3 8183561 Switch Micro
Primary/Secondary
4 8183562 Switch, Micro
Monitor
5 4358271 Screw

OVEN INTERIOR PARTS
5
For Models: KCMS2055SSS0
(Stainless)
W10160568
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8205458 Propeller
2 8205456 Guide, Suction
3 8205462 Motor, Fan
4 8185272 H.V. Capacitor
5 8184288 H.V.C Bracket
6
W10160549 Leadwire Assembly
7
W10160548 H.V. Diode Cable
8 8206281 Power Cord
9
W10160550 Thermostat
10 8171810 Lamp, Baseless
11
W10160545 Duct, Air
12 8205460 Magnetron
13 4359794 Holder
14 4359781 Damper
15 8183507 Fuse
16 8206270 Filter, Noise
17 8205509 Insulator
18 4358190 Screw
19 4358489 Screw
20 4358381 Screw
21 4358271 Screw
22
W10160553 Screw

BASE PLATE PARTS
6
For Models: KCMS2055SSS0
(Stainless)
W10160568
Illus. Part
No. No. DESCRIPTION
1 W10160551 Base Plate (L)
2
W10160552 Base Plate (R)
3 8184385 Leg
4
W10160546 Transformer
5 4358192 Screw
6 4358489 Screw
