CONTROL BOARD PARTS
1
For Models: KHMS2056SWH0, KHMS2056SBL0, KHMS2056SSS0
(White) (Black) (Stainless Steel)
11−07 Litho In U.S.A. (rek) Part No. W10144495 Rev. A
MICROWAVE
HOOD
COMBINATION
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10117076 Use & Care Guide
8205288 Tech Sheet
8205744 Quick Reference
2 8206039 Support, Cavity
(Left)
3 8206040 Plate, Protection
(Left)
4 8206608 Control Board,
(Relay)
5 8206061 Plate, Protection
(Right)
6
W10113785 Plate, Chassis
7 8206065 Support, Cavity
(Right)
8 8206493 Board, Relay
9 8206053 Holder,
Microcomputer
10 8206062 AC Line Filter
11 8206060 Holder, Filter
12
W10113782 Resistor (50W)
13
W10113783 Resistor (25W)
14
W10113784 Spacer (6)
15 8169499 Glass, Lamp
16 8169646 Frame, Glass
17
W10143955 Seal, Foam

DOOR PARTS
2
For Models: KHMS2056SWH0, KHMS2056SBL0, KHMS2056SSS0
(White) (Black) (Stainless Steel)
W10144495
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Handle
8206501 White
W10110267 Black
W10116265 Stainless Steel
3 8206528 Outer Door Glass
4 8206635 Control Panel
5 Outer Door Frame
8206518 White
8206519 Black
8206521 Stainless Steel
6
W10116269 LCD Frame
7
W10143961 Board, User
(Interface)
8
W10143962 LCD Module
9 8206511 Cntrl Panel Plate
10 8206512 Cntrl Panel Cover
11 8206527 Cable Cover, Door
12
W10143965 Clip,Hinge Screw
13 Logo
8206514 White
8206515 Black
8206517 Stainless Steel
14 8206513 Screw (2)
15 Spacer, Side (6)
8206522 White
8206523 Black
8206525 Stainless Steel
16 8206215 Screw (6)
17 8206178 Spacer, Bottom (2)
18 8206179 Screw (2)
19 8206529 Cover, Choke
20
W10112215 Door Plate Assy
21
W10143963 Hinge Screw
22
W10143964 Dr Innr Frm Assy

VENTILATION PARTS
3
For Models: KHMS2056SWH0, KHMS2056SBL0, KHMS2056SSS0
(White) (Black) (Stainless Steel)
W10144495

VENTILATION PARTS
4
For Models: KHMS2056SWH0, KHMS2056SBL0, KHMS2056SSS0
(White) (Black) (Stainless Steel)
W10144495
Illus. Part
No. No. DESCRIPTION
1 8206092 Housing, Blower
(Left)
2
W10143957 Reflector, Lamp
3 8204670 Lamp (2)
4
W10143958 Socket, Lamp (2)
(Left)
7 Frame, Glass
W10113788 Left
W10113789 Right
8 8206097 Plate, Separator
(Left)
9 8206497 Plate, Bottom
11
W10143960 Reflector, Lamp
12 8206103 Cover, Terminal
13 8206104 Diffuser
14 8206105 Cover, Duct
15 8206106 Connector, Duct
16 8206107 Holder, Duct
17 8206498 Shield
18 8206212 Support & Base
Thermostat Assy
19 8206263 Connector Shaft
20 8206499 Spring
21 8206112 Housing, Blower
(Right)
22
W10120840 Filter, Charcoal
23
W10120839 Filter, Grease
24
W10113792 Spring, Hook
25
W10143951 Air Guide,
Center Hood
26
W10110862 Mounting Nut (2)

INTERIOR AND AIR FLOW PARTS
5
For Models: KHMS2056SWH0, KHMS2056SBL0, KHMS2056SSS0
(White) (Black) (Stainless Steel)
W10144495
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8206075 Fan Motor Assy
2 8206076 Housing, Fan
3 8206077 Plate, Divider
4 8206078 Thermistor,
Magnetron
5 8206079 Magnetron
6 8206080 Motor, Capacitor
7 8206081 Housing, Valve
8
W10113786 Cam Plate (Upper)
11 8206085 Cover, Inverter
12 8206086 Ferrite Ring
13 8206087 Inverter
14 8206035 Thermostat,
Base Assembly
15 8206089 Holder, Inverter
16 8206494 Air Guide,
Magnetron
17
W10143956 Support, Interlock
18 8206091 Spring, Interlock
19 8206345 Switch, Micro
(Secondary)
20 8184312 Holder, Fuse
21 4393308 Fuse
22 8206347 Switch, Micro
(Monitor)
23 8206352 Switch, Micro
(Primary)
24 8206026 Humidity Sensor
& Thermostat Assy
25 8206031 Support, Air Guide
26 8206477 Protector, Wire
27 8206037 Clip, Saddle
28 8206038 Clip, Round
29 8206209 Support, Interlock
30 8206210 Piston Assembly
31
W10113787 Cam Plate (Lower)

RACK AND TURNTABLE PARTS
6
For Models: KHMS2056SWH0, KHMS2056SBL0, KHMS2056SSS0
(White) (Black) (Stainless Steel)
W10144495
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
2 8206117 Rack
3 8206118 Hook, Rack (4)
4 8204670 Lamp, Cavity
5
W10113781 Holder, Lamp
6 8205980 Deflector, Air
12 8205996 Plate, Crisp
13 8205992 Turntable
14 8206222 Ring, Turntable
15 8205994 Driver, Turntable
16
W10106520 Handle
17 8206034 Clip, Cavity Lamp
18 8206101 Spacer
19
W10143959 Motor, Turntable
20 4393832 Screw
23 8206116 Spacer
24 8206066 Cover, Inlet
25 8206476 Lid, Lamp

CABINET AND INSTALLATION PARTS
7
For Models: KHMS2056SWH0, KHMS2056SBL0, KHMS2056SSS0
(White) (Black) (Stainless Steel)
W10144495

CABINET AND INSTALLATION PARTS
8
For Models: KHMS2056SWH0, KHMS2056SBL0, KHMS2056SSS0
(White) (Black) (Stainless Steel)
W10144495
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Case, Outer
W10143952 White
W10143953 Black
W10143954 Apollo Grey
2 8206442 Damper
3 8184897 Lid, Power Cord
4 4393472 Screw
5 8206475 Vent Screen
(Middle)
6 Support,
Vent Screen
8206011 White
W10143735 Black
W10116263 Stainless
7 8206207 Vent Screen
(Left)
8 8206051 Plate, Back
9 8206319 Plate, Mounting
10 8206182 Cord, Power
21 Bracket, Upper
11 4393836 Screw
12 8206206 Vent Screen
(Right)
13 Panel, Side
W10143968 White, Left
W10143991 White, Right
W10143969 Black, Left
W10143992 Black, Right
W10143975 Stainless, Left
W10143993 Stainless, Right
14
W10143976 Side Panel Sup.(2)
15 Panel, Front
W10143977 White, Left
W10143986 White, Right
W10143978 Black, Left
W10143987 Black, Right
W10143979 Stnls. Left
W10143988 Stnls. Right
16 Button
W10143980 White
W10143981 Black
W10143982 Stainless
17
W10143983 Hood/Light Switch
Board
18 Bracket
W10143984 Lower Left
W10143990 Lower Right
19 Plate (Co.)
W10143985 Bottom, Left
W10143989 Bottom, Right
20 Plate, Back
W10143994 Right
W10143996 Left
21 Bracket, Upper
W10143995 Right
W10143997 Left
Miscellaneous
W10128803 Hardware, Install
8205274 Template, Upper
W10113776 Harns−Wire,#70 RCB
W10113062 Main Harness
8206185 Ground Wire
8206186 Ground Wire (Mag)
W10143999 Harns−Wire, Cooktp
W10112290 Harns−Wire,#71 RCB
W10113777 Harns−Wire,
RCB − Inverter
8206189 Hood/Light Control
Harns−Wire #74
W10113778 Hood/Light Control
Harns−Wire #73
W10113779 Harns−Wire #75
P64 RCB
W10113780 Harns−Wire #76
P2 RCB
8206468 Harns−Wire #77
P3 LCD to UIB
