OVEN PARTS
1
For Models:KEBC247KBL0, KEBC247KWH0
(Black) (White)
9−02 Litho in U.S.A.(cre) Part No. 8185910
24" BUILT−IN ELECTRIC
DOUBLE OVEN
THERMAL CONVECTION
SELF−CLEAN

OVEN PARTS
2
For Models:KEBC247KBL0, KEBC247KWH0
(Black) (White)
8185910
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 Literature Parts
LIT8300656 Installation
Instructions
LIT8300886 Use & Care Guide
LIT4449066 Cookbook
(T/C Oven)
LIT4451879 Tech Sheet
LIT4449264 Easy Set Guide
LIT3191638 Safer Cooking Tips
2 Trim, Side
4455426 RH Black
4455375 RH White
4455427 LH Black
4455374 LH White
8281236 Screw
3 Hinge, Receiver
4455605 Left Hand
4455606 Right Hand
4 4448520 Bumper, Door
5 4452490 Spacer, Foam
6 4452199 Divider, Vent
4449809 Screw
7 4455863 Top Chassis
4449809 Screw
8 Deflector,
Vent Box
4455807 Black
4452489 Stainless Steel
9 4452158 Tube, Vent
3196176 Screw
10 4452163 Lens, Light
11 4448972 Oven Light Assy
4449748 Screw
12 4452164 Bulb, Light
13 8300825 Insulation,
Bottom Vent
3400832 Screw
14 4455610 Frame, Front
4449040 Screw
4450118 Nut
15 4455380 Gasket, Door
16 4452152 Bracket, Mounting
19 4451476 Support, Insulation
4449809 Screw
20 4451605 Cap, Spacer
21 Rail, Side
4450581 Right Side
4450582 Left Side
4448444 Grommet
4449154 Screw
22 4451896 Latch Assy
23 4452224 Solenoid
24 4452312 Micro Switch N.C.
4449154 Screw
25 4455641 Side, Chassis
(R.H. & L.H.)
4449809 Screw
26 4452232 Back, Chassis
4449809 Screw
27 Liner, Oven
(Not serviceable)
28 4451426 Micro Switch
29 4455636 Sensor
4449154 Screw
30 4451537 Spring, Latch
33 8300880 Deflector, Vent
34 4452265 Vent, Center
37 4452223 Thermostat (TOD)
4449809 Screw
43 4450525 Base, Chassis
4449809 Screw
49 4448933 Retainer, Gasket
4449154 Screw
50 4451747 Cover, Back
4449809 Screw
51 Trim, Bottom
8300828 Black Model
8300829 White Model
3400832 Screw
53 4449845 Support, Bracket
4449809 Screw
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
4449314 Insulation, Wrap
4450363 Insulation, Back
4455375 RH White
694091 Screw

CONTROL PANEL PARTS
3
For Models:KEBC247KBL0, KEBC247KWH0
(Black) (White)
8185910
Illus. Part
No. No. DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 Panel, Control
8300815 Black Model
8300816 White Model
3400832 Screw
2 Switch, Membrane
8300842 Black
8300845 White
3400832 Screw
3 4453379 Microcomputer
3400406 Screw
4 4452248 Insulation, Board
5 4452249 Insulation, Board
Support

OVEN DOOR PARTS
4
For Models:KEBC247KBL0, KEBC247KWH0
(Black) (White)
8185910
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 4455616 Liner, Door
2 Hinge, Door
8300569 R.Side
8300570 L.Side
4449743 Screw
3 4449247 Glass, Inner
4 4451720 Insulation, Door
5 8300776 Retainer, Glass
4449809 Screw
7 4449251 Glass, Inner
12 Door Glass, Assy
8300836 Black Model
8300837 White Model
13 Door Handle
4452498 Black Model
4452499 White Model
14 Bracket, Handle
4452959 R.Side
4452960 L.Side
4451040 Screw
19 4450360 Shield, Heat
4449809 Screw
20 4451668 Retainer, Glass
4449809 Screw
21 4451672 Seal, Door Top
23 Retainer, Clip
8300853 Black Model
4450864 White Model
24 4455255 Glass, Inner

INTERNAL OVEN PARTS
5
For Models:KEBC247KBL0, KEBC247KWH0
(Black) (White)
8185910
Illus. Part
No. No. DESCRIPTION
2 4452156 Element, Broil
4449154 Screw
3 3147563 Grill, Broiler
4 3147845 Pan, Broiler
5 3181534 Rack, Roasting
6 4448716 Rack, Oven
7 4452155 Element, Bake
8 4448881 Nut, Hex
9 4451583 Convection Motor
4449154 Screw
10 4452226 Blade, Fan
11 4448882 Washer, Lock
12 4452227 Nut
13 4451355 Jack, Meat Probe
14 4448948 Probe, Meat
15 4455035 Tray, Bake
17 4450039 Cover, Bake Tray
4449809 Screw
20 4452157 Element,
Convection
4449154 Screw
21 4448418 Cover, Fan
4449154 Screw

TOP VENTING PARTS
6
For Models:KEBC247KBL0, KEBC247KWH0
(Black) (White)
8185910
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 4451759 Vent, Exhaust
2 4451758 Foam, Block
3 Blower
6610168 45MM Lower Oven
4455334 60MM Upper Oven
4455352 Bracket, Blower
4449809 Screw
5 6610122 Transformer,
(Lights)
4449809 Screw
7 4451789 Plate, Mounting
8 8300642 Transformer, Control
4449809 Screw
9 4455178 Elbow, Vent−Top
10 4455177 Elbow, Vent−Bottom
11 4449868 Block, Terminal
3400080 Screw
13 4448547 Vent,
(Control Panel)
4450038 Screw
14 Side, Control Top
4451597 Right
4451598 Left
4449809 Screw
4449154 Screw
15 4452244 Back, Control
4449809 Screw
16 4450549 Cover, Top Rear
4449809 Screw
17 4448664 Clamp
4449809 Screw
112432 Nut
18 4452365 Cover, Top Front
4449809 Screw
4452260 Spacer, Foam
19 4451985 Suppressor,
Transient
4455191 Plate, Service

MISCELLANEOUS PARTS
7
For Models:KEBC247KBL0, KEBC247KWH0
(Black) (White)
8185910
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
261869 Cord Brown
72032 Black
PAINT, SPRAY
350930 White
261900 Citrine White
830864 Black
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
SPLICING WIRES−−25FT.
LENGTH
242828 Wire (12 Ga.
150 c Black)
242820 Wire (14 Ga.
150 c Black)
242821 Wire (14 Ga.
150 c Blue)
242822 Wire (14 Ga.
150 c Brown)
242830 Wire (14 Ga.
200 c Brown)
242823 Wire (14 Ga.
150 c Green)
242824 Wire (14 Ga.
150 c Orange)
242829 Wire (12 Ga.
150 c Red)
242825 Wire (14 Ga.
150 c Red)
242831 Wire (14 Ga.
200 c Red)
242826 Wire (14 Ga.
150 c White)
242827 Wire (14 Ga.
150 c Yellow)
242832 Wire (14 Ga.
200 c Yellow)
WIRING HARNESS PARTS
4451926 Harness, Wire
(Latch)
4455726 Harness, Wire
(Main)
4450953 Conduit, Double
4450800 Screw, Ground
4448664 Clamp
4449809 Screw
112432 Nut
4452222 Spacer, Harness
4454835 Tie, Cable
4451761 Support, Wiring
4454842 Tie, Cable
4454835 Tie, Cable
313438 Harness Clip
Miscellaneous
814381 Pin Hinge Kit
4448950 Screw, Install (4)
