CABINET PARTS
1
For Models: KBRS20ETWH00, KBRS20ETBL00, KBRS20ETSS00
(White) (Black) (Stainless Steel)
7−07 Litho In U.S.A. (tpm) Part No. W10153438 Rev. A
REFRIGERATOR

CABINET PARTS
2
For Models: KBRS20ETWH00, KBRS20ETBL00, KBRS20ETSS00
(White) (Black) (Stainless Steel)
W10153438
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10136388 Owners Manual
W10136377 Energy Tag
67006616 Tech Sheet
2 Cabinet (Not a
Servicable Part)
3 Plug, Button (3)
67001130 White
67001131 Black
5 67002227 Roller Assembly
6 12627302 Clip, Grille
7 67006642 Pin, Center Hinge
8 67006611 Bolt, Adjusting
(Rear)
9 67006521 Screw
10 12456801 Bracket, Roller
11 67006380 Screw
12 67006473 Screw
13 A3076901 Plug, Button
14 67006303 Screw
15 Hinge, Center
67006960 White
67007043 Black
16 67003868 Foot Brake
17 Cover, Corner
67003484 White
67003485 Black
18
12566604ED Hinge, Top
19 67007174 Bracket, Foot
20 67006473 Screw
21 Cover, Hinge
67001014 White
67001012 Black
22 Grille Assembly
(Includes Clips)
67006377 White
67006375 Black
25 67006425 Screw
27 67004098 Cover, Water Valve
28
12575101ED Cover, Unit
29 67007121 Power Cord
30 67003796 Insulation, Sound
31 67001066 Tube, Drain
32 67001067 Clip, Drain Tube
33 M0286708 Nut, Speed
34 67005127 Roller
35 M1205302 Pin
36 67006737 Screw
37 67006697 Bolt, Adjusting
(Rear)
40 B5759649 Gasket
42 67004092 Block, Filter
43 67006287 Screw
44 67003331 Cover, Water Line
45 67004102 Track, Water
46
W10137519 Elbow, Fill Tube
47 B5705307 Tube, Plastic
49 M0104106 Clip, Water Tube

FREEZER LINER PARTS
3
For Models: KBRS20ETWH00, KBRS20ETBL00, KBRS20ETSS00
(White) (Black) (Stainless Steel)
W10153438

FREEZER LINER PARTS
4
For Models: KBRS20ETWH00, KBRS20ETBL00, KBRS20ETSS00
(White) (Black) (Stainless Steel)
W10153438
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 67001291 Gasket, Foam
3 12002497 Gear (2)
(Includes RH & LH)
4 67003905 Cover, Light
5 67004017 Shaft
6 8170839 Socket, Light
7 67006407 Gear (RH)
8 67006737 Screw
9 A0282812 Bulb, Light
10 67001035 Housing, Frz. Light
11 67005873 Cover, Evaporator
12 67006425 Screw
13 Bracket, Door
67004732 Left
67004733 Right
14 67003906 Housing, Lighting
15 8208285 Clip, Evap. Motor
16 67005653 Switch, Light
17 8170922 Cover, Plug
18 Bracket, Basket
67004728 Left
67004729 Right
19 13031602 Slide, Drawer (2)
20 67002492 Gasket, Bottom
21 Bracket, Slide
67004971 Left
67004972 Right
22 13024802 Cover, Fan Shroud
23 67002777 Shroud, Evap.Fan
24 12217201 Fan, Evaporator
25 67002780 Grommet (2)
26 67003636 Motor, Evaporator
27 D7753903 Funnel, Drain
(Incl. # 28 & 29)
28 M0500703 Seal
29 B8381501 Gasket
30 12002355 Thermistor
31 67003924 Cover, Thermistor
32 67006406 Screw
33 67006530 Screw
Following Parts Not Illustrated
67006095 Harness, Lights
(Freezer)

REFRIGERATOR LINER PARTS
5
For Models: KBRS20ETWH00, KBRS20ETBL00, KBRS20ETSS00
(White) (Black) (Stainless Steel)
W10153438

REFRIGERATOR LINER PARTS
6
For Models: KBRS20ETWH00, KBRS20ETBL00, KBRS20ETSS00
(White) (Black) (Stainless Steel)
W10153438
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2
Y67003896 Bracket, Control
and Lights
3 67005628 Overlay
4 67005444 Housing,
Electronic Control
5 67005397 Electronic Control
6 C3680310 Switch, Light
7 67003897 Cover, Light
8 67003901 Housing, Light
9 A0282812 Bulb, Light (2)
10 8170839 Socket, Light (2)
11 67003900 Insert,
Damper Cover
12 67006602 Screw
13 67003899 Cover, Damper
14 67006604 Insulation
15
W10127429 Control, Damper
18 67001668 Plate
19 67004091 Tank, Water
20 67002979 Dispenser
21 67006400 Screw
22 B8390302 Clip
23 67006524 Housing, Filter
Head
24 12568001 Cover, Filter
25 67006470 Filter, Water
26 12664501 Head, Filter
Bypass
27 67002742 Plate, Switch
28 67006287 Screw
29 67005674 Cover
30 12575501 Switch, Limit
31 61006182 Union
32 67002816 Clip, Water
33 67002743 Guide, Water
Following Parts Not Illustrated
8208197 Harness,
Damper Control
67005644 Harness, Controls
(Refrigerator)
(Includes # 16)

REFRIGERATOR DOOR PARTS
7
For Models: KBRS20ETWH00, KBRS20ETBL00, KBRS20ETSS00
(White) (Black) (Stainless Steel)
W10153438

REFRIGERATOR DOOR PARTS
8
For Models: KBRS20ETWH00, KBRS20ETBL00, KBRS20ETSS00
(White) (Black) (Stainless Steel)
W10153438
Illus. Part
No. No. DESCRIPTION
1 Refrigerator Door
(w/ Insulation)
67004804 White
67004803 Black
W10136411 Stainless Steel
2 Plug, Vent
67001130 White
67001131 Black
3 67003819 Door, Compartment
4 67001279 Tray, Dairy
5 67005724 Bin, Shelf (1)
(Medium)
6 Plug, Handle Hole
67001130 White
67001131 Black
8 Gasket, Door
Magnetic
W10133418 White
W10133881 Black
9 Handle, Door
2319727W White
2319727B Black
2319727S Stainless Steel
10 67002935 Screw
11 Closure, Door
67003638 White
67003639 Black
12 67005464 Bin, Shelf (3)
(Large)
13 Bushing
8208208 White
8171213 Black
14 67003027 Trim, Door Shelf
15 67006287 Screw
17 Stop, Door
67003779 White
67003780 Black
18 67004790 Stud, Handle
19 67005626 Caddy, Can
20
W10136387 Bin, Egg
22 Plug, Button
10712401 White
67004838 Black
23 Nameplate
W10046670 White
W10046640 Black
W10046610 Grey

UNIT PARTS
9
For Models: KBRS20ETWH00, KBRS20ETBL00, KBRS20ETSS00
(White) (Black) (Stainless Steel)
W10153438

UNIT PARTS
10
For Models: KBRS20ETWH00, KBRS20ETBL00, KBRS20ETSS00
(White) (Black) (Stainless Steel)
W10153438
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 67006425 Screw
2 67004952 Blade, Fan
3 67005889 Base
4 67006433 Screw
5 67004954 Screw
6 67005421 Cover, Box
7 67005679 Harness,
Evap. Heater
8 67007175 Drain Pan
9 61004743 Grommet (3)
10 67002493 Evaporator Heater
11 Capacitor
(See Item #12)
12 67005560 Overload/Relay
(Capacitor Incl.)
13 61003210 Gasket
14 67003426 Bi−Metal
15 67005680 Grommet (8)
16 67006550 Screw
17 67007052 Clip, Capacitor
18 67006131 Condenser
19 67004700 Tube, Discharge
20 67002490 Tray, Drip
21 67005719 Spacer, HV Box
22 12002041 Evaporator
23 Dam
67001084 Right Side
67001083 Left Side
24 67004432 Motor, Fan
25 10428101 Clip, Heater
26 13060201 Harness, Unit
27 2317845 Drier (Service)
28 12002634 Compressor
(Includes Items
11, 12, 17,
27 & 35)
29 12782027 Control Board
30 12972902 Harness, HV Board
31 12575305 Shroud
32 67004953 Bracket, Fan Motor
33 67005718 Box, Control
34 10547003 Clip, Drier
35 67003493 Grommet (4)
36 10623002 Clip, Evaporator
37 67006737 Screw
38 67006432 Screw
39 67006573 Screw
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.00 Ozs.
(R−134A)

SHELF PARTS
11
For Models: KBRS20ETWH00, KBRS20ETBL00, KBRS20ETSS00
(White) (Black) (Stainless Steel)
W10153438

SHELF PARTS
12
For Models: KBRS20ETWH00, KBRS20ETBL00, KBRS20ETSS00
(White) (Black) (Stainless Steel)
W10153438
Illus. Part
No. No. DESCRIPTION
1 67003037 Ladder, Side
2 67006415 Screw
3 67003036 Ladder, Center
4 67006360 Screw
5 67005625 Housing, Control
6 67005676 Shelf, Glide (4)
7 67006655 Glass, Crisper
8 67006185 Frame, Crisper
9 67002329 Gasket, Pantry
Crisper Drawer
10 67005864 Slide,
Humidity Control
11 Track, Pantry
67005862 Left
67005860 Right
12 67006400 Screw
13 67002488 Support,
Crisper Frame
14 67005675 Trim, Crisper
15 67002659 Pan, Crisper (2)
16 67004988 Basket, Freezer
(Upper)
17 67007026 Glide, Pantry
18 67004127 Divider,
Upper Basket
19 67006608 Screw
20 67006026 Basket, Freezer
(Lower)
21 67004812 Divider,
Lower Basket
22 67002332 Glass, Pantry
23 67001056 Frame, Pantry
24 67002005 Gasket, Pantry
25 67002004 Air Duct, Pantry
26 67002330 Brace, Pantry
27 67003793 Slide,
Pantry Control
28 67003794 Rod,Temperature
Control
29 67006010 Support, Glass
30 67003530 Drawer, Pantry
32 67001719 Track, Pantry
33 67003791 Knob, Temperature
34 67002321 Divider, Pantry
36 67005930 Lid Assembly
Drawer

FREEZER DOOR PARTS
13
For Models: KBRS20ETWH00, KBRS20ETBL00, KBRS20ETSS00
(White) (Black) (Stainless Steel)
W10153438
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Freezer Door
(w/ Insulation)
67004810 White
67004808 Black
W10136412 Stainless Steel
2 Handle, Door
2319727W White
2319727B Black
2319727S Stainless Steel
3 67006408 Screw
4 Gasket, Door
W10133249 White
W10131754 Black
5 67002935 Screw
7 Plug, Vent (2)
10712401 White
67004838 Black
9 67004790 Stud, Handle

ICEMAKER PARTS
14
For Models: KBRS20ETWH00, KBRS20ETBL00, KBRS20ETSS00
(White) (Black) (Stainless Steel)
W10153438
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Mold & Heater
Assembly
(Not Available
Order D7824706Q)
2 67004028 Arm, Shutoff
3 628356 Cup, Fill
4 627843 Ejector
5 2182124 Ice Stripper
6 2195914 Support & Motor
Assembly
7 2315522 Retainer,
Thermostat
8 Thermostat
(Not Available
Order 4317943)
9 681249 Screw (2)
10 67006531 Pan, Ice
11 67004101 Bracket, Tube
Support
12 67006531 Valve, Water
Inlet
13 A3223101 Insert, Tube
14 B5705307 Tubing, Plastic
15 67006614 Harness, Icemaker
16 625910 Bracket
17 67006662 Screw
18 67004710 Cover
19 Module Assembly
(Not Available
Order D7824706Q)
20 67006287 Screw
100
D7824706Q Complete Icemaker
Following Parts Not Illustrated
18001005 Icemaker Install
Kit

OPTIONAL PARTS (NOT INCLUDED)
15
For Models: KBRS20ETWH00, KBRS20ETBL00, KBRS20ETSS00
(White) (Black) (Stainless Steel)
W10153438
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
72032 Black
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
350939 Black
350942 Primer, White
Important: The spray paint is
not to be used where the paint
may make contact with the door
gaskets.
PAINT, BULK (1 qt.)
799344 White (Uncut)
799340 Black (Uncut)
Miscellaneous
212643 Sealer, Gum
(4 Feet)
479502 Tape, Vinyl
(3/4 x 108")
505587 Sealer, Mastic
(1 Qt.)
503695 Cork, Sealer
(1/4 Pound)
542638 Grease, Silicone
(1/2 Oz.)
542639 Cement,
Alumilastic
(1−1/4 Oz.)
799833 Kit, Evaporator
Repair
(Aluminum Epoxy)
833938 Kit, Terminal
Connector
TORX SCREW WRENCH
1117510 Torx Key
FIELD INSTALLABLE
ICE MAKER
D7824706Q Complete Icemaker
ACCESSORIES
2217192 Cleaner,
Stainless Steel
