KitchenAid KBSD602ESS-SS User manual

SIDE BY SIDE BUILT-IN REFRIGERATOR
Use & Care Guide
For questions about features, operation/performance, accessories or service, call: 1-800-422-1230
or visit our website at www.kitchenaid.com
In Canada call: 1800-807-6777 or visit our website at www.KitchenAid.ca
REFRIGERADOR EMPOTRADO DE DOS PUERTAS
Manual de uso y cuidado
Para consultas respecto a características, operación/desempeño, partes, accesorios o servicio, llame al: 1-800-422-1230
o visite nuestra página de internet www.kitchenaid.com
En Canadá, llame al: 1-800-807-6777 o visite nuestra página de internet www.KitchenAid.ca
RÉFRIGÉRATEUR ENCASTRÉ CÔTE À CÔTE
Guide d’utilisation et d’entretien
Au Canada, pour assistance, installation ou service composez le 1-800-807-6777 ou visitez notre site web à www.KitchenAid.ca
W10763009A
Table of Contents/Índice/Table des matières...................................................................................2

2
TABLE OF CONTENTS
REFRIGERATION SAFETY ....................................................... 3
Proper Disposal of Your Old Refrigerator.......................... 4
BEFORE USE............................................................................. 4
Water Supply Requirements................................................ 4
Water System Preparation................................................... 5
REFRIGERATOR USE............................................................... 5
Power On/Off Switch............................................................ 5
Using the Controls................................................................ 6
Sabbath Mode....................................................................... 7
Water and Ice Dispensers.................................................... 7
Ice Maker and Storage Bin .................................................. 9
Water Filtration System...................................................... 10
REFRIGERATOR FEATURES................................................. 11
Refrigerator Shelves........................................................... 11
Ingredient Care Center....................................................... 11
Crisper and Covers............................................................. 11
Wine Rack ........................................................................... 12
FREEZER FEATURES ............................................................. 12
Freezer Shelf ....................................................................... 12
Freezer Basket.................................................................... 12
DOOR FEATURES................................................................... 12
Utility Compartment ........................................................... 12
Door Bins............................................................................. 12
REFRIGERATOR CARE .......................................................... 13
Cleaning............................................................................... 13
Lights ................................................................................... 13
Power Interruptions............................................................ 13
Vacation Care...................................................................... 14
TROUBLESHOOTING ............................................................. 14
Refrigerator Operation....................................................... 14
Temperature and Moisture ................................................ 15
Ice and Water...................................................................... 15
ASSISTANCE OR SERVICE.................................................... 17
In the U.S.A.......................................................................... 17
In Canada ............................................................................ 17
ACCESSORIES........................................................................ 17
PERFORMANCE DATA SHEETS ........................................... 18
WARRANTY ............................................................................. 21
ÍNDICE
SEGURIDAD DEL REFRIGERADOR...................................... 22
Cómo deshacerse adecuadamente de
su refrigerador viejo ........................................................... 23
ANTES DE USAR..................................................................... 23
Requisitos del suministro de agua.................................... 23
Preparación del sistema de agua ..................................... 24
USO DE SU REFRIGERADOR................................................ 25
Interruptor de encendido/apagado................................... 25
Uso de los controles .......................................................... 25
Sabbath Mode (Modo de descanso)................................. 27
Despachadores de agua y hielo........................................ 27
Fábrica de hielo y depósito................................................ 29
Sistema de ltración de agua............................................ 30
CARACTERÍSTICAS DEL REFRIGERADOR......................... 31
Estantes del refrigerador ................................................... 31
Centro de cuidado de ingredientes .................................. 31
Cajones para verduras y tapas.......................................... 32
Portabotellas....................................................................... 32
CARACTERÍSTICAS DEL CONGELADOR............................ 32
Estante del congelador...................................................... 32
Canastilla del congelador .................................................. 32
CARACTERÍSTICAS DE LA PUERTA.................................... 33
Compartimiento utilitario................................................... 33
Recipientes de las puertas ................................................ 33
CUIDADO DE SU REFRIGERADOR ...................................... 33
Limpieza .............................................................................. 33
Luces ................................................................................... 34
Cortes de corriente ............................................................ 34
Cuidado durante las vacaciones....................................... 34
SOLUCIÓN DE PROBLEMAS................................................. 35
Funcionamiento del refrigerador ...................................... 35
Temperatura y humedad.................................................... 36
Hielo y agua......................................................................... 36
AYUDA O SERVICIO TÉCNICO.............................................. 38
En los EE.UU. ...................................................................... 38
En Canadá ........................................................................... 38
ACCESORIOS.......................................................................... 38
HOJA DE DATOS DEL RENDIMIENTO ................................. 39
GARANTÍA ............................................................................... 41
TABLE DES MATIÈRES
SÉCURITÉ DU RÉFRIGÉRATEUR ......................................... 43
Mise au rebut appropriée de votre vieux réfrigérateur... 44
AVANT L’UTILISATION........................................................... 44
Spécications de l’alimentation en eau ........................... 44
Préparation du système d’eau .......................................... 45
UTILISATION DU RÉFRIGÉRATEUR..................................... 46
Interrupteur d’alimentation On/Off (marche/arrêt).......... 46
Utilisation des commandes ............................................... 46
Sabbath Mode (mode sabbat) ........................................... 48
Distributeurs d’eau et de glaçons..................................... 48
Machine à glaçons et bac d’entreposage ........................ 50
Système de ltration d’eau................................................ 51
CARACTÉRISTIQUES DU RÉFRIGÉRATEUR ...................... 52
Tablettes du réfrigérateur.................................................. 52
Centre de soins des ingrédients ....................................... 52
Bac à légumes et couvercles ............................................ 53
Casier à vin.......................................................................... 53
CARACTÉRISTIQUES DU CONGÉLATEUR ......................... 53
Tablette de congélateur..................................................... 53
Panier du congélateur........................................................ 53
CARACTÉRISTIQUES DE LA PORTE.................................... 53
Compartiment utilitaire ...................................................... 54
Compartiments dans la porte............................................ 54
ENTRETIEN DU RÉFRIGÉRATEUR....................................... 54
Nettoyage ............................................................................ 54
Lampes ................................................................................ 55
Pannes de courant ............................................................. 55
Entretien avant les vacances............................................. 55
DÉPANNAGE ........................................................................... 56
Fonctionnement du réfrigérateur...................................... 56
Température et humidité ................................................... 57
Glaçons et eau .................................................................... 57
ASSISTANCE OU SERVICE.................................................... 59
ACCESSOIRES........................................................................ 59
FEUILLES DE DONNÉES SUR LA PERFORMANCE............ 60
GARANTIE................................................................................ 62

3
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
REFRIGERATOR SAFETY
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the State of California to cause cancer.
WARNING: This product contains one or more chemicals known to the State of California to cause birth defects or other
reproductive harm.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electric shock, or injury when using your refrigerator, follow these basic precautions:
SAVE THESE INSTRUCTIONS
■Plug into a grounded 3 prong outlet.
■Do not remove ground prong.
■Do not use an adapter.
■Do not use an extension cord.
■Disconnect power before servicing.
■Replace all parts and panels before operating.
■Remove doors from your old refrigerator.
■Use nonflammable cleaner.
■Keep flammable materials and vapors, such as gasoline,
away from refrigerator.
■Use two or more people to move and install refrigerator.
■Disconnect power before installing ice maker (on ice maker
kit ready models only).
■Use a sturdy glass when dispensing ice (on some models).
■Do not hit the refrigerator glass doors (on some models).

4
Proper Disposal of Your Old Refrigerator
WARNING
Suffocation Hazard
Remove doors from your old refrigerator.
Failure to do so can result in death or brain damage.
IMPORTANT: Child entrapment and suffocation are not
problems of the past. Junked or abandoned refrigerators are still
dangerous, even if they will sit for “just a few days.” If you are
getting rid of your old refrigerator, please follow these instructions
to help prevent accidents.
Before You Throw Away Your Old Refrigerator or Freezer:
■Take off the doors.
■Leave the shelves in place so that children may not easily
climb inside.
Important information to know about disposal of
refrigerants:
Dispose of refrigerator in accordance with Federal and Local
regulations. Refrigerants must be evacuated by a licensed,
EPA certified refrigerant technician in accordance with
established procedures.
BEFORE USE
Remove the Packaging
■Remove tape and glue residue from surfaces before turning
on the refrigerator. Rub a small amount of liquid dish soap
over the adhesive with your fingers. Wipe with warm water
and dry.
■Do not use sharp instruments, rubbing alcohol, flammable
fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your refrigerator. For
more information, see “Refrigerator Safety.”
■Dispose of/recycle all packaging materials.
After you remove all of the packaging materials, clean the inside
of your refrigerator before using it. See the cleaning instructions
in “Refrigerator Care.”
Important information to know about glass shelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
Tempered glass is designed to shatter into many small,
pebble-size pieces. This is normal. Glass shelves and covers
are heavy. Use both hands when removing them to avoid
dropping.
Water Supply Requirements
Read all directions before you begin.
IMPORTANT:
■When your refrigerator was installed, the water connection
from the water source should have been connected to your
refrigerator. If your refrigerator is not connected to a water
source, see “Connect to Water Line” in the Installation
Instructions. If you have any questions about your water
connection, see “Troubleshooting” or call a licensed, qualified
plumber.
Clean Before Using
Water Pressure
A cold water supply with water pressure between 30 and 120 psi
(207 and 827 kPa) is required to operate the water dispenser and
ice maker. If you have questions about your water pressure, see
“Troubleshooting” or call a licensed, qualified plumber.
Reverse Osmosis Water Supply
IMPORTANT: The pressure of the water supply coming out of
a reverse osmosis system going to the water inlet valve of the
refrigerator needs to be between 30 and 120 psi (207 and
827 kPa).
If a reverse osmosis water filtration system is connected to your
cold water supply, the water pressure to the reverse osmosis
system needs to be a minimum of 40 psi (276 kPa).
If the water pressure to the reverse osmosis system is less than
40 psi (276 kPa):
■Check to see whether the sediment filter in the reverse
osmosis system is blocked. Replace the filter if necessary.
■Allow the storage tank on the reverse osmosis system to refill
after heavy usage.
■If your refrigerator has a water filter, it may further reduce
the water pressure when used in conjunction with a reverse
osmosis system. Remove the water filter. See “Water Filtration
System.”
If you have questions about your water pressure, call a licensed,
qualified plumber.
■If you turn the refrigerator on before the water line is
connected, turn the ice maker Off. See “Ice Maker and
Storage Bin.”
■All installations must meet local plumbing code requirements.

5
Water System Preparation
Please read before using the water system. Follow the directions
specific to your model.
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or
after the system.
NOTE: If your model has a base grille filter system, make sure
the base grille filter is properly installed and the cap is in the
horizontal position.
1. Open the freezer door and turn off the ice maker. The On/
Off switch is located on the top right side of the freezer
compartment. Move the switch to the OFF (right) setting as
shown.
2. Use a sturdy container to depress and hold the water
dispenser lever for 5 seconds, then release it for 5 seconds.
Repeat until water begins to flow. Once water begins to
flow, continue depressing and releasing the dispenser lever
(5 seconds on, 5 seconds off) until a total of 3 gal. (12 L)
has been dispensed. This will flush air from the filter and
water dispensing system and prepare the water filter for use.
Additional flushing may be required in some households.
NOTE: As air is cleared from the system, water may spurt out
of the dispenser.
3. Open the freezer door and turn on the ice maker. Move the
switch to the ON (left) position.
NOTES:
■Allow 24 hours to produce the first batch of ice.
■Discard the first three batches of ice produced.
■Allow 3 days to completely fill ice container.
■Depending on your model, you may want to select the
maximum ice feature to increase the production of ice.
Style 2 (Non-Dispenser Models)
IMPORTANT: After connecting the refrigerator to a water source
or replacing the water filter, fill and discard two full containers of
ice to prepare the water filter for use, before using the ice.
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or
after the system.
NOTE: If your model has a base grille filter system, make sure
the base grille filter is properly installed and the cap is in the
horizontal position.
1. Turn on the ice maker. Lower the wire shutoff arm as shown.
Please refer to “Ice Maker and Storage Bin” for further
instructions on the operation of your ice maker.
NOTES:
■Allow 24 hours to produce the first batch of ice.
■Allow 3 days to completely fill ice container.
■Depending on your model, you may want to select the
maximum ice feature to increase the production of ice.
REFRIGERATOR USE
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.
Power On/Off Switch
If you need to turn the power to your refrigerator On or Off,
you must remove the top grille assembly to access the power
switch. Turn the power to the refrigerator Off when cleaning your
refrigerator or changing light bulbs.
To Remove Top Grille:
1. Grasp both ends of the top grille.
Style 1 (Dispenser Models)
IMPORTANT: After connecting the refrigerator to a water source
or replacing the water filter, follow the steps below to make sure
that the water system is properly cleaned. This will flush air from
the filter and water dispensing system, and prepare the water
filter for use.

6
2. Push the top grille straight up, then pull straight out. Lay the
grille on a soft surface.
B BA
A. Top grille
B. Cabinet side trims
To Replace To Grille:
1. Insert top grille hooks (located on the back of the top grille)
onto mounting bolts on the side trim.
2. Pull grille down slightly to lock into place.
Turn Power On or Off:
1. Remove top grille.
2. Press Power switch to the ON or OFF position.
3. Replace top grille.
IMPORTANT: Be sure the power switch is set to the ON position
after cleaning refrigerator or changing light bulbs.
A
A. Power switch
Using the Controls
IMPORTANT:
■The refrigerator control adjusts the refrigerator compartment
temperature. The freezer control adjusts the freezer
compartment temperature.
■Wait 24 hours after you turn on the refrigerator before you put
food into it. If you add food before the refrigerator has cooled
completely, your food may spoil.
NOTE: Adjusting the refrigerator and freezer controls to a
lower (colder) setting will not cool the compartments any
faster.
■If the temperature is too warm or too cold in the refrigerator
or freezer, first check the air vents to be sure they are not
blocked before adjusting the controls.
■The preset settings should be correct for normal household
usage. The controls are set correctly when milk or juice is as
cold as you like and when ice cream is firm.
■The actual temperature may differ from the display when a
door is open for an extended period of time.
NOTE: The factory recommended set points are 0°F (-18°C) for
the freezer and 37°F (3°C) for the refrigerator.
Turning Refrigerator On and Viewing Set Points
■Press the Cooling (ON/OFF) touch pad.
NOTE:
■After the refrigerator is turned on, the Over Temperature audio
alarm and indicator light may activate every 1¹⁄₂ hours until the
refrigerator and freezer temperatures are below 48°F (9°C) and
15°F (-9°C), respectively, or until the alarm is turned off. To
turn off the audio alarm and indicator light, see “Master Alarm
Reset.”
■The Cooling ON/OFF touch pad on the control panel shuts
down refrigerator functions such as cooling, lighting, fans and
compressors. To turn the power off completely, use the power
ON/OFF switch located behind the top grille. See “Power On/
Off Switch.”
Viewing the Celsius Temperatures
■Press the F/C touch pad. To redisplay degrees Fahrenheit,
press F/C again.
NOTE: If the freezer temperature is below zero, the negative sign
next to the freezer display will light up. This is normal.
Adjusting Controls
NOTE: Wait at least 24 hours between adjustments. Recheck the
temperatures before other adjustments are made.
To Adjust Set Point Temperatures:
■Press the refrigerator or freezer PLUS (+) or MINUS (-) touch
pad until the desired temperature is reached.
■Press the Set To Recommended touch pad to reset the set
points to the factory recommended temperatures.
NOTE: The set point range for the freezer is -5°F to 3°F (-21°C
to -16°C). The set point range for the refrigerator is 34°F to
42°F (1°C to 6°C).
CONDITION/REASON: TEMPERATURE
ADJUSTMENT:
REFRIGERATOR too cold
Not set correctly for conditions
REFRIGERATOR Control
1° higher
REFRIGERATOR too warm
High use or room very warm
REFRIGERATOR Control
1° lower
FREEZER too cold
Not set correctly for conditions
FREEZER Control
1° higher
FREEZER too warm/too little ice
High use or heavy ice use
FREEZER Control
1° lower

7
Water Filter Indicator and Reset
See “Water Filter Indicator” section.
Max Cool
The Max Cool feature assists with periods of heavy ice usage, full
grocery loads, or temporarily warm room temperatures.
■Press MAX COOL to turn on the Max Cool feature. The Max
Cool indicator light will remain on for 24 hours unless manually
turned off.
NOTE: The temperature display will remain at 34°F (1°C) and
-5°F (-21°C) for the refrigerator and freezer compartments,
respectively, while the Max Cool feature is enabled. After 24
hours, the refrigerator returns to the previous temperature set
points.
Alarm Functions
Master Alarm Reset
Pressing Alarm Reset once will turn off the audio alarm and
indicator light. The audio alarm will not sound again for the
current condition that caused the alarm until a new condition
occurs or until a Master Alarm Reset is performed.
A Master Alarm Reset can be performed by pressing Cooling
(ON/ OFF) twice or by turning the power to the refrigerator off and
on again. See “Power On/Off Switch.” After performing a Master
Alarm Reset, the indicator light will reactivate if the condition that
caused the alarm is still present. See “Over Temperature,” “Call
Service,” or “Door Open.”
Door Open
The Door Open indicator light will flash, an alarm will sound
and the interior lights will turn off when a door has been open
for longer than 10 minutes. When the door is closed, the audio
alarm will reset and turn off, but the Door Open indicator light
will continue to flash until the temperature is equal to or below
45°F (7°C) and 15°F (-9°C) for the refrigerator and freezer
compartments, respectively.
NOTE: To deactivate the audio alarm and indicator light, see
“Master Alarm Reset.”
Over Temperature
IMPORTANT: If the Over Temperature Alarm activates, your
food may spoil. See the “Power Interruptions.” Minimize door
openings until temperatures return to normal.
The Over Temperature feature is designed to let you know when
either the refrigerator temperature rises above 48°F (9°C) or
the freezer temperature rises above 15°F (-9°C) for longer than
1¹⁄₂ hours. The audio alarm will shut off automatically when the
temperature returns to normal, but the indicator light will continue
to flash until the Alarm is pressed to let you know that an over
temperature condition has occurred.
If the over temperature condition is still present when an Over
Temperature Reset is performed, the indicator light will continue
to reactivate every 1¹⁄₂ hours until refrigerator and freezer
temperatures are below 48°F (9°C) and 15°F (-9°C), respectively.
NOTE: The audio alarm will be disabled for subsequent
occurrences of over temperature alarm condition. To enable the
audio alarm, see “Master Alarm Reset.”
Sabbath Mode
The Sabbath Mode feature is designed for the traveler or for
those whose religious observances require turning off the lights
and ice maker. By selecting this feature, the temperature set
points and Deli Pan settings remain unchanged, the ice maker
will be disabled and the interior lights will turn off. For most
efficient refrigerator operation, it is recommended to exit the
Sabbath Mode when it is no longer required.
To fully activate Sabbath Mode, you must follow the instructions
below for both the control panel and dispenser panel (on some
models).
IMPORTANT: If you do not activate Sabbath Mode in both ways
listed below, some functions you wish to disable will remain
active.
Control Panel
In Sabbath Mode, the temperature set points remain unchanged
and the interior lights turn off.
■Press SABBATH MODE to turn on Sabbath Mode.
■Press SABBATH MODE again to turn off Sabbath Mode.
Dispenser Panel Holiday Mode (on some models)
In Holiday Mode, the dispenser levers are disabled and the
dispenser lights turn off.
■To turn on Holiday Mode, press and hold ICE, LIGHT and
LOCKOUT at the same time for 3 seconds. When the feature
turns on, the indicator light around the LOCKOUT button will
blink and “HOL” will appear on the dispenser display.
■To turn Holiday Mode off, press and hold ICE, LIGHT and
LOCKOUT at the same time for 3 seconds again.
NOTE: If the Max Cool feature has been selected prior to
turning on the Holiday Mode feature, then the set points will
remain at 34°F (1°C) and -5°F (-21°C) for the refrigerator and
freezer compartments, respectively, until the Max Cool feature
times out. The refrigerator will then return to the previous
temperature set points chosen prior to the selection of the
Max Cool feature, but the lights and ice maker will remain off
until the Holiday Mode is pressed again.
Water and Ice Dispensers
(on some models)
IMPORTANT:
■After connecting the refrigerator to a water source or replacing
the water filter, flush the water system. Use a sturdy container
to depress and hold the water dispenser lever for 5 seconds,
then release it for 5 seconds. Repeat until water begins to
flow. Once water begins to flow, continue depressing and
releasing the dispenser lever (5 seconds on, 5 seconds off)
until a total of 3 gal. (12 L) has been dispensed. This will flush
air from the filter and water dispensing system, and prepare
the water filter for use. Additional flushing may be required in
some households.
NOTE: As air is cleared from the system, water may spurt out
of the dispenser.
■Allow 24 hours for the refrigerator to cool down and chill
water.

8
■Allow 24 hours to produce the first batch of ice. Discard the
first three batches of ice produced.
■The dispensing system will not operate when the freezer door
is open.
■Depending on your model, your water and ice dispensers may
have one or more of the following features: a dispenser tray,
a special light that turns on when you use the dispenser, or a
lock option to avoid unintentional dispensing.
Water Dispenser
To Dispense Water:
1. Press a sturdy glass against the water dispenser pad.
NOTES:
■While dispensing water and for 3 seconds after
dispensing has stopped, the digital display will show how
many ounces of water have been dispensed.
■To switch from ounces to cups, press and hold ICE and
LOCK at the same time until the dispenser beeps after 3
seconds. To switch from cups to liters, press and hold the
buttons for another 3 seconds. To switch back to ounces,
repeat the process a third time.
2. Remove the glass to stop dispensing.
NOTE: Water may have an off-flavor if you do not use the
dispenser periodically. Dispense enough water every week to
maintain a fresh supply.
Ice Dispenser
Ice dispenses from the ice maker storage bin in the freezer when
the dispenser pad is pressed. The dispensing system will not
operate when the freezer door is open. To turn off the ice maker,
see “Ice Maker and Storage Bin.”
Your ice maker can produce both crushed and cubed ice. The
display screen reads “CRUSHED” or “CUBED,” indicating which
type is selected. To change the setting, press the ICE button
before dispensing ice.
For crushed ice, cubes are crushed before being dispensed. This
may cause a slight delay when dispensing crushed ice. Noise
from the ice crusher is normal, and pieces of ice may vary in size.
When changing from crushed to cubed, a few ounces of crushed
ice will be dispensed along with the first cubes.
To Dispense Ice:
1. Press the button to select the desired type of ice.
Cut Hazard
Use a sturdy glass when dispensing ice.
Failure to do so can result in cuts.
WARNING
2. Press a sturdy glass against the ice dispenser pad. Hold
the glass close to the dispenser opening so ice does not fall
outside of the glass.
IMPORTANT: You do not need to apply a lot of pressure to
the pad in order to activate the ice dispenser. Pressing hard
will not make the ice dispense faster or in greater quantities.
3. Remove the glass to stop dispensing.
NOTE: Ice may continue to dispense for up to 10 seconds
after removing the glass from the pad. The dispenser may
continue to make noise for a few seconds after dispensing.
Dispenser Tray (on some models)
Some models have a tray at the bottom of the dispenser area.
The tray is designed to catch small spills and is removable for
easy emptying and cleaning.
NOTE: There is no drain in the tray.
Dispenser Light (on some models)
When you use the dispenser, the light will automatically turn on.
If you want the light to be on continuously, you may choose either
ON or AUTO.
ON: Press LIGHT to turn the dispenser light on.
AUTO: Press LIGHT a second time to select AUTO mode. The
dispenser light will automatically adjust to become brighter as the
room brightens and dimmer as the room darkens.
OFF: Press LIGHT a third time to turn the dispenser light off.
The dispenser lights are LEDs that cannot be changed. If it
appears that your dispenser lights are not working, be sure
that the light sensor is not blocked (in AUTO mode). See
“Troubleshooting” for more information.
Dispenser Lock (on some models)
The dispenser can be turned off for easy cleaning or to avoid
unintentional dispensing by small children and pets.
NOTE: The lock feature does not shut off power to the product,
to the ice maker, or to the dispenser light. It simply deactivates
the ice and water dispensers. To turn off the ice maker, see “Ice
Maker and Storage Bin.”
■Press and hold LOCK for 3 seconds to lock the dispenser.
While the dispenser is locking, “LOCKING” will appear on the
display screen and the blue indicator light around the LOCK
button will flash. When the dispenser is locked, the indicator
light will change to red for a few seconds, then turn off.
■Press and hold LOCK a second time to unlock the dispenser.
While the dispenser is unlocking, “UNLOCKING” will appear
on the display screen and the red indicator light around the
LOCK button will flash. When the dispenser is unlocked, the
indicator light will change to blue for a few seconds, and then
turn off.
Water Filter Status Light (on some models)
The water filter status light and display screen help you know
when to change your water filter. Press the FILTER button to
check the status of your water filter.
If the filter is new:
You must press FILTER to view the filter’s status. For a few
seconds, the status light will be blue and the display screen will
show what percentage of your filter’s life remains.

9
If it is almost time to change the filter:
The status light will automatically illuminate and will remain on,
appearing yellow. The words “ORDER FILTER” will appear on
the display screen. Press FILTER to see what percentage of your
filter’s life remains. You should order the appropriate replacement
filter. See “Accessories.”
If it is time to change the filter:
The status light will remain on, changing to red. The words
“REPLACE FILTER” and “HOLD BUTTON TO RESET” will appear
on the display screen until the filter has been changed and the
status light has been reset.
To reset the water filter status light:
After changing the filter, reset the status light by pressing and
holding the FILTER button for 3 seconds. The status light will
blink red and change to blue, and then turn off when the system
is reset.
Ice Maker and Storage Bin
(on some models - Accessory)
IMPORTANT: Flush the water system before turning on the
ice maker. See “Water and Ice Dispensers.” Allow 24 hours to
produce the first batch of ice. Discard the first three batches of
ice produced. Allow 3 days to completely fill the ice container.
Style 1
To Turn the Ice Maker On/Off:
The On/Off switch for the ice maker is a wire shutoff arm located
on the side of the ice maker.
1. To turn the ice maker on, simply lower the wire shutoff arm.
NOTE: Your ice maker has an automatic shutoff. As ice is
made, the ice cubes will fill the ice storage bin and the ice
cubes will raise the wire shutoff arm to the OFF (arm up)
position.
2. To manually turn the ice maker off, lift the wire shutoff arm to
the OFF (arm up) position and listen for the click to make sure
the ice maker will not continue to operate.
To Remove and Replace the Ice Bin:
1. Flip up the covering panel.
A
A. Ice maker cover
2. Lift the wire shutoff arm so it clicks into the OFF (up) position.
Ice can still be dispensed, but no more can be made.
3. Lift up the front of the storage bin and pull the ice bin forward.
4. Replace the bin by pushing it in all the way or the dispenser
will not work. Push the wire shutoff arm down to the ON
position to restart ice production. Make sure the door is
closed tightly.
Style 2
To Turn the Ice Maker On/Off:
The On/Off switch is located on the top right side of the freezer
compartment.
1. To turn the ice maker on, slide the control to the ON (left)
position.
NOTE: Your ice maker has an automatic shutoff. The ice
maker sensors will automatically stop ice production, but the
control will remain in the ON (left) position.
2. To manually turn the ice maker off, slide the control to the OFF
(right) position.
To Remove and Replace the Ice Storage Bin:
1. Hold the base of the storage bin with both hands and press
the release button to lift the storage bin up and out.
NOTE: It is not necessary to turn the ice maker control to
the OFF (right) position when removing the storage bin. The
sensor cover (“flipper door”) on the left wall of the freezer
stops the ice maker from producing ice if the door is open or
the storage bin is removed.
2. Replace the storage bin on the door and push down to make
sure it is securely in place.
Clean the Ice Storage Bin
NOTE: It is normal for ice to stick together in the ice bin. Ice may
be dispensed or used more frequently which will break up the ice.
It is recommended that the ice container be emptied and cleaned
as needed.
To clean the ice storage bin:
1. Empty the ice container. Use warm water to melt the ice if
necessary.
NOTE: Do not use anything sharp to break up the ice in the
bin or bucket. This can cause damage to the ice container
and the dispenser mechanism.
2. Wash ice bin with a mild detergent, rinse well and dry
thoroughly. Do not use harsh or abrasive cleaners or solvents.

10
Remember
■Allow 24 hours to produce the first batch of ice. Allow 3 days
to completely fill ice container.
■Discard the first three batches of ice produced to avoid
impurities that may be flushed out of the system.
■The quality of your ice will be only as good as the quality of
the water supplied to your ice maker.
■Avoid connecting the ice maker to a softened water supply.
■Water softener chemicals (such as salt) can damage parts of
the ice maker and lead to poor quality ice. If a softened water
supply cannot be avoided, make sure the water softener is
operating properly and is well maintained.
■It is normal for the ice cubes to be attached at the corners.
They will break apart easily.
■For Style 1 ice maker, do not force the wire shutoff arm up or
down.
■Do not store anything on top of the ice maker or in the ice
storage bin/bucket.
Water Filtration System
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or
after the system.
Water Filter Indicator (on some models)
The water filter indicator, located on the control panel, will help
you know when to change the water filter.
A new water filter should display a reading of 99%. The reading
in the display will decrease as the filter life is used. A replacement
water filter should be ordered when “Order Filter” is displayed. It
is recommended that you replace the filter when “Change Filter”
is displayed or when water flow to your water dispenser and/or
ice maker decreases noticeably. See “Changing the Water Filter”
later in this section.
NOTE: Dispenser models have a filter reset on the freezer
compartment door. Non-Dispenser models have a Good/Order
Filter/Replace Filter indicator.
After changing the water filter, press and hold RESET for
2 seconds until the status display changes to 99%.
Changing the Water Filter
The water filter is located in the base grille below the freezer
compartment door. It is not necessary to remove the base grille
to remove the filter.
1. Remove the filter by pressing the eject button and pulling
straight out on the filter cap.
NOTES:
■Avoid twisting the cap when removing the filter because
this could cause the cap to come off. If this occurs,
replace the cap and pull the filter straight out.
■There will be water in the filter. Some spilling may occur.
A
B
A. Eject button
B. Filter cap
2. Remove the cap by turning it counterclockwise until it stops.
IMPORTANT: Do not discard the cap. It is part of your
refrigerator. Keep the cap to use with the replacement filter.
3. Align the ridge on the cap with the arrow on the new filter, and
turn the cap until it snaps into place.
A
B
A. Cover
B. O-rings
4. Remove the covers from the O-rings. Be sure the O-rings are
still in place after the covers are removed.
5. Place the cap (removed in Step 2) on the new filter. Align the
ridge on the cap with the arrow on the filter. Turn the cap
clockwise until it snaps into place.
A
B
C
A. Eject button
B. Arrow on filter
C. Ridge on cap
6. Push the new filter into the opening in the base grille. As the
filter is inserted, the eject button will depress. The eject button
will pop back out when the filter is fully engaged.
7. Pull gently on the cap to check that the filter is securely
in place.
8. Flush the water system. Depending on your model, see
“Water and Ice Dispensers” or “Ice Maker and Storage Bin.”

11
Using the Ice Maker Without a Water Filter
You can operate the ice maker without a water filter. Your ice will
not be filtered.
1. Remove the filter by pressing the eject button and pulling on
the cap. See “Changing the Water Filter” earlier in this section.
2. Remove the cap by turning it counterclockwise until it stops.
IMPORTANT: Do not discard the cap. It is part of your
refrigerator. Keep the cap to use with the replacement filter.
3. With the cap in a horizontal position, insert the cap into the
base grille until it stops.
4. Turn the cap counterclockwise until the cap slips into the
attachment slot. Then, turn the cap clockwise until it is in a
horizontal position.
NOTE: The cap will not be even with the base grille.
REFRIGERATOR FEATURES
Refrigerator Shelves
Important information to know about glass shelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
Tempered glass is designed to shatter into many small,
pebble-size pieces. This is normal. Glass shelves and covers
are heavy. Use both hands when removing them to avoid
dropping.
The shelves in your refrigerator are adjustable to meet your
individual storage needs.
Storing similar food items together in your refrigerator and
adjusting the shelves to fit different heights of items will make
finding the exact item you want easier. It will also reduce the
amount of time the refrigerator door is open and help save
energy.
Shelves and Shelf Frames
To remove and replace a shelf/frame:
1. Remove the shelf/frame by tilting it up at the front and lifting it
out of the shelf supports. Pull shelf straight out.
2. Replace the shelf/frame by guiding the rear shelf hooks into
the shelf supports. Tilt the front of the shelf up until the rear
shelf hooks drop into the shelf supports.
3. Lower the front of the shelf and check that the shelf is
securely in position.
Ingredient Care Center
The control for the Ingredient Care Center adjusts the storage
temperature of the pan. Cold air flows into the pan through the air
duct between the freezer and the refrigerator. Setting the controls
allows more or less cold air through the air duct.
To Adjust the Ingredient Care Center
1. Choose a setting based on the item to be stored in the pan.
2. Push the button that corresponds to that setting.
3. The indicator light for that setting will illuminate to verify that
the pan is ready to be loaded.
Remove and Replace the Ingredient Care Center Cover
1. Remove food from Ingredient Care Center cover. Pull drawer
out about 4” (10.16 cm). Reach under the glass shelf with both
hands and lift gently upward until back of shelf is free. Tilt the
shelf at an angle and remove the shelf from the refrigerator. Be
sure not to bump the glass.
2. Replace the cover by holding the glass shelf firmly with both
hands, tilt the shelf at an angle and position it above the
support rails. Place shelf gently on support rails on side wall.
Meat Storage Guide
Store most meat in original wrapping as long as it is airtight and
moisture-proof. Rewrap if necessary. See the following chart for
storage times. When storing meat longer than the times given,
freeze the meat.
Fresh fish or shellfish......................... use same day as purchased
Chicken, ground beef, variety meat (liver, etc.) ................ 1-2 days
Cold cuts, steaks/roasts .................................................. 3-5 days
Cured meats................................................................... 7-10 days
Leftovers - Cover leftovers with plastic wrap, aluminum foil, or
plastic containers with tight lids.
Crisper and Covers
To remove and replace the crispers:
1. Slide the crisper drawer straight out to the stop. Lift the front
of the drawer with one hand while supporting the bottom of
the drawer with your other hand and slide the drawer out the
rest of the way.
2. To replace the crisper drawer, place the drawer onto slides
and push the drawer back until securely in position.

12
3. Test the crisper drawer to make sure it has been replaced
properly.
To clean crisper covers:
1. To clean the top crisper cover, remove the Ingredient Care
Center located above it.
2. To clean the bottom crisper cover, first remove the top
crisper drawer.
Wine Rack
To remove and replace the wine rack:
1. Remove the rack by pulling it straight out from the shelf.
2. Replace the rack by sliding it in between the shelf and the wall
of the refrigerator.
FREEZER FEATURES
Freezer Shelf
To remove and replace the shelf:
1. Remove the shelf by lifting it up and pulling it straight out.
2. Replace the shelf by putting it over the supports and lowering
it into place.
Frozen Food Storage Guide
Storage times will vary according to the quality and type of
food, the type of packaging or wrap used (should be airtight and
moisture-proof), and the storage temperature. Ice crystals inside
a sealed package are normal. This simply means that moisture in
the food and air inside the package have condensed, creating
ice crystals.
Put no more unfrozen food into the freezer than will freeze within
24 hours (no more than 2 to 3 lbs of food per cubic foot
[907 to 1,350 g per 28 L] of freezer space). Leave enough space
in the freezer for air to circulate around packages. Be sure to
leave enough room for the door to close tightly.
For more information on preparing food for freezing, check a
freezer guide or reliable cookbook.
Freezer Basket
The freezer basket can be used to store bags of frozen fruits and
vegetables that may slide off freezer shelves.
To remove and replace the freezer basket:
1. Pull the basket straight out to the stop.
2. Lift the front of the basket and slide it out the rest of the way.
3. Replace the basket by positioning it on the side wall guide
rails. Lift the basket front slightly while pushing it past the
guide rail stops and slide basket in the rest of the way.
DOOR FEATURES
The utility compartment can be placed in any position on the
refrigerator door.
To remove and replace the utility bin:
1. Remove utility compartment by grasping both ends and lifting
compartment up and out.
2. Replace the bin by sliding it in above the desired support and
pushing it down until it stops.
Utility Compartment
(on some models)
Door Bins
Large door bins hold gallon containers and the smaller door bins
hold 2-liter bottles. The door bins are adjustable and removable
for easy cleaning and adjusting.
Gallon Door Bin
To install gallon door bin:
NOTE: The gallon door bin can only be placed on the
lower support.
1. Position gallon door bin above lowest door adjustment slot.
2. Push down to secure bin.
3. Adjust other bins, as necessary to allow for milk or beverage
container height.

13
Door Bins
To remove and replace the door bins:
1. Remove the bin by lifting it up and pulling it out.
2. Replace the bin by sliding it in above the desired support and
pushing it down until it stops.
REFRIGERATOR CARE
Cleaning
WARNING
Explosion Hazard
Use nonflammable cleaner.
Failure to do so can result in death, explosion, or fire.
Both the refrigerator and freezer sections defrost automatically.
However, clean both sections about once a month to avoid
build-up of odors. Wipe up spills immediately.
To Clean Your Refrigerator:
1. Remove the top grille. See “Power On/Off Switch.”
2. Press power switch to OFF.
3. Remove all removable parts from inside, such as shelves,
crispers, etc.
4. Hand wash, rinse, and dry removable parts and interior
surfaces thoroughly. Use a clean sponge or soft cloth and a
mild detergent in warm water.
■Do not use abrasive or harsh cleaners such as window
sprays, scouring cleansers, flammable fluids, cleaning
waxes, concentrated detergents, bleaches or cleansers
containing petroleum products on plastic parts, interior
and door liners or gaskets. Do not use paper towels,
scouring pads, or other harsh cleaning tools. These can
scratch or damage materials.
■To help remove odors, you can wash interior walls with a
mixture of warm water and baking soda (2 tbs to 1 qt
[26 g to 0.95 L] of water).
5. Wash stainless steel and painted metal exteriors with a clean
sponge or soft cloth and a mild detergent in warm water. Do
not use abrasive or harsh cleaners, or cleaners containing
chlorine. Dry thoroughly with a soft cloth.
NOTE: To keep your Stainless Steel refrigerator looking like
new and to remove minor scuffs or marks, it is suggested that
you use the manufacturer’s approved Stainless Steel Cleaner
and Polish.
IMPORTANT: This cleaner is for Stainless Steel parts only!
Do not allow the Stainless Steel Cleaner and Polish to come into
contact with any plastic parts such as the trim pieces, dispenser
covers or door gaskets. If unintentional contact does occur,
clean plastic part with a sponge and mild detergent in warm
water. Dry thoroughly with a soft cloth. To order the cleaner, see
“Accessories.”
6. Clean the condenser coils located behind the top grille
ventilation panel regularly. Coils may need to be cleaned as
often as every other month. This may help save energy.
■Use a vacuum cleaner with an extended attachment to
clean the condenser coils when they are dusty or dirty.
7. Press the power switch to ON.
8. Replace the top grille. See “Power On/Off Switch.”
Lights
The lights in both the refrigerator and freezer compartments
are LEDs which do not need to be replaced. If the lights do not
illuminate when the door is opened, call for assistance or service.
In the U.S.A., call 1-800-422-1230. In Canada call 1-800-807-
6777.
Power Interruptions
If the power will be out for 24 hours or less, keep the door or
doors closed (depending on your model) to help food stay cold
and frozen.
If the power will be out for more than 24 hours, do one of the
following:
■Remove all frozen food and store it in a frozen food locker.
■Place 2 lbs (907 g) of dry ice in the freezer for every cubic foot
(28 L) of freezer space. This will keep the food frozen for 2 to
4 days.
■If neither a food locker nor dry ice is available, consume or
can perishable food at once.
REMEMBER: A full freezer stays cold longer than a partially filled
one. A freezer full of meat stays cold longer than a freezer full of
baked goods. If you see that food contains ice crystals, it may be
refrozen, although the quality and flavor may be affected. If the
condition of the food is poor, dispose of it.
Vacation Care
Your refrigerator is equipped with the Sabbath Mode feature,
which is designed for the traveler who wishes to turn off the lights
and ice maker. By selecting this feature, the temperature set
points remain unchanged, the ice maker will be disabled and the
interior lights will turn off. For most efficient refrigerator operation,
it is recommended to exit Sabbath Mode when it is no longer
required.
If You Choose To Leave the Refrigerator On While
You’re Away:
1. Use up any perishables and freeze other items.
2. Press SABBATH.
3. If your refrigerator has an automatic ice maker, shut off water
supply to the ice maker.
4. Empty the ice bin.
5. When you return from vacation, press SABBATH to return to
normal operation.

14
TROUBLESHOOTING
Try the solutions suggested here first in order to avoid the cost of an unnecessary service call.
Refrigerator Operation
The refrigerator will not operate
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
■Power cord unplugged? Plug into a grounded 3 prong outlet.
■Is outlet working? Plug in a lamp to see if the outlet
is working.
■Household fuse blown or circuit breaker tripped? Replace
the fuse or reset the circuit breaker. If the problem continues,
call an electrician.
■Are controls on? Make sure the refrigerator controls are on.
See “Using the Controls.”
■Is refrigerator defrosting? Your refrigerator will regularly run
an automatic defrost cycle. Recheck in 30 minutes to see if it
is operating.
■New installation? Allow 24 hours following installation for the
refrigerator to cool completely.
NOTE: Adjusting the temperature controls to coldest setting
will not cool either compartment more quickly.
The motor seems to run too much
Your new refrigerator may run longer than your old one due to
its high-efficiency compressor and fans. The unit may run even
longer if the room is warm, a large food load is added, doors are
opened often, or if the doors have been left open.
The refrigerator is noisy
Refrigerator noise has been reduced over the years. Due to
this reduction, you may hear intermittent noises from your new
refrigerator that you did not notice from your old model. Below
are listed some normal sounds with an explanation.
■Buzzing - heard when the water valve opens to fill the ice
maker
■Pulsating - fans/compressor adjusting to optimize
performance
■Rattling - flow of refrigerant, water line, or from items placed
on top of the refrigerator
■Sizzling/Gurgling - water dripping on the heater during
defrost cycle
■Popping - contraction/expansion of inside walls, especially
during initial cool-down
■Water running - may be heard when water melts during the
defrost cycle and runs into the drain pan
■Creaking/Cracking - occurs as ice is being ejected from the
ice maker mold.
There is no audible door open alarm
Has the door been open less than 10 minutes? The door open
alarm will only flash when the door has been open for 10 minutes.
The audible alarm will sound the first time the door is left open
for more than 10 minutes. Subsequent door open alarms will only
flash. You must reset the audible alarm each time. See “Using the
Control(s).”
The doors will not close completely
■Door blocked open? Move food packages away from door.
■Bin or shelf in the way? Push bin or shelf back in the
correct position.
If You Choose To Turn the Refrigerator Off Before You Leave:
1. Remove all food from the refrigerator.
2. If your refrigerator has an automatic ice maker:
■Turn off the water supply to the ice maker at least one day
ahead of time.
■When the last load of ice drops, raise the wire shutoff arm
to the OFF (up) position.
3. Depending on your model, turn the Thermostat Control (or
Refrigerator Control) to OFF. See “Using the Controls.”
4. Clean refrigerator, wipe it, and dry well.
5. Tape rubber or wood blocks to the tops of both doors to prop
them open far enough for air to get in. This stops odor and
mold from building up.

15
The doors are difficult to open
WARNING
Explosion Hazard
Use nonflammable cleaner.
Failure to do so can result in death, explosion, or fire.
■Are the gaskets dirty or sticky? Clean gaskets with mild
soap and warm water.
The lights do not work
■Is the refrigerator in Sabbath Mode? See “Using the
Controls.”
■Has the door been open more than 10 minutes? See “Using
the Controls.”
Temperature and Moisture
Temperature is too warm
■New installation? Allow 24 hours following installation for the
refrigerator to cool completely.
■Door(s) opened often or left open? Allows warm air to enter
refrigerator. Minimize door openings and keep doors fully
closed.
■Large load of food added? Allow several hours for
refrigerator to return to normal temperature.
■Controls set correctly for the surrounding conditions?
Adjust the controls a setting colder. Check temperature in
24 hours. See “Using the Controls.”
■Refrigerator not cooling? For models with digital controls,
turn the refrigerator off and then on to reset. If this does not
correct the problem, call for service.
■Air vents blocked? Remove any item from in front of the
air vents.
There is interior moisture buildup
NOTE: Some moisture buildup is normal.
■Humid room? Contributes to moisture buildup.
■Door(s) opened often or left open? Allows humid air to enter
refrigerator. Minimize door openings and keep doors fully
closed.
Ice and Water
The ice maker is not producing ice or not enough ice
■Refrigerator connected to a water supply and the supply
shutoff valve turned on? Connect refrigerator to water
supply and turn water shutoff valve fully open.
■Kink in the water source line? A kink in the line can reduce
water flow. Straighten the water source line.
■Ice maker turned on? Make sure wire shutoff arm or switch
(depending on model) is in the ON position.
■New installation? Wait 24 hours after ice maker installation
for ice production to begin. Wait 72 hours for full ice
production.
■Large amount of ice recently removed? Allow 24 hours for
ice maker to produce more ice.
■Ice cube jammed in the ice maker ejector arm?
Remove ice from the ejector arm with a plastic utensil.
■Reverse osmosis water filtration system connected to
your cold water supply? This can decrease water pressure.
See “Water Supply Requirements” in either the Installation
Instruction booklet or the Use & Care Guide.
The ice cubes are hollow or small
NOTE: This is an indication of low water pressure.
■Water shutoff valve not fully open? Turn the water shutoff
valve fully open.
■Kink in the water source line? A kink in the line can reduce
water flow. Straighten the water source line.
■Reverse osmosis water filtration system connected to
your cold water supply? This can decrease water pressure.
See “Water Supply Requirements.”
■Questions remain regarding water pressure? Call a
licensed, qualified plumber.
Ice is sticking together in the ice storage bin
■It is normal for frost to be on top of the ice storage bin due to
normal opening and closing of the freezer.
■It is normal for ice to stick together when it is not dispensed or
used frequently. It is recommended that the ice storage bin be
emptied and cleaned as needed. See “Ice Maker and
Storage Bin.”
Off-taste, odor or gray color in the ice
■New plumbing connections? New plumbing connections
can cause discolored or off-flavored ice.
■Ice stored too long? Discard ice. Wash ice bin. Allow
24 hours for ice maker to make new ice.
■Odor transfer from food? Use airtight, moisture proof
packaging to store food.
■Are there minerals (such as sulfur) in the water? A water
filter may need to be installed to remove the minerals.
■Is there a water filter installed on the refrigerator? Gray
or dark discoloration in ice indicates that the water filtration
system needs additional flushing.

16
The ice dispenser will not operate properly
■Freezer door closed completely? Close the door firmly. If
it does not close completely, see “The doors will not close
completely.”
■Ice bin installed correctly? Be sure the ice bin is firmly
in position.
■New installation? Wait 24 hours after ice maker installation
for ice production to begin. Wait 72 hours for full
ice production.
■Ice stuck in the delivery chute? Use a plastic utensil to clear
the delivery chute.
■Has the wrong ice been added to the bin? Use only cubes
produced by the current ice maker.
■Has the ice melted around the auger (metal spiral) in the
ice bin? Empty the ice container. Use warm water to melt the
ice if necessary.
Cut Hazard
Use a sturdy glass when dispensing ice.
Failure to do so can result in cuts.
WARNING
■Is the ice dispenser stalling while dispensing “crushed”
ice? Change the ice button from “crushed” to “cubed.”
If cubed ice dispenses correctly, depress the button for
“crushed” ice and begin dispensing again.
■Has the dispenser arm been held in too long? Ice will stop
dispensing when the arm is held in too long. Wait 3 minutes
for dispenser motor to reset before using again.
The water dispenser will not operate properly
■Freezer door closed completely? Close the door firmly. If it
does not close completely, see “The doors will not
close completely.”
■Refrigerator connected to a water supply and the supply
shutoff valve turned on? Connect refrigerator to water
supply and turn water shutoff valve fully open.
■Is the water pressure at least 30 psi (207 kPa)? The water
pressure to the home determines the flow from the dispenser.
See “Water Supply Requirements.”
■Kink in the home water source line? Straighten the water
source line.
■New installation? Flush and fill the water system.
■Water filter installed on the refrigerator? The filter may be
clogged or incorrectly installed.
■Is a reverse osmosis water filtration system connected to
your cold water supply? See “Water Supply Requirements”
in either the Installation Instructions or the Use & Care Guide.
Water is leaking from the dispenser
NOTE: One or two drops of water after dispensing is normal.
■Glass not being held under the dispenser long enough?
Hold the glass under the dispenser 2 to 3 seconds after
releasing the dispenser lever.
■New installation? Flush the water system. See “Prepare the
Water System” or “Water and Ice Dispensers.”
■Recently changed water filter? Flush the water system. See
“Prepare the Water System” or “Water and Ice Dispensers.”
The dispenser water is not cool enough
NOTE: Water from the dispenser is chilled to only 50°F (10°C).
■New installation? Allow 24 hours after installation for the
water supply to cool completely.
■Recently dispensed large amount of water? Allow 24 hours
for water supply to cool completely.
■Water not been recently dispensed? The first glass of water
may not be cool. Discard the first glass of water.
■Refrigerator connected to a cold water pipe? Make sure
the refrigerator is connected to a cold water pipe. See “Water
Supply Requirements.”
ASSISTANCE OR SERVICE
If You Need Service
Please refer to the warranty page in this manual
If You Need Replacement Parts
If you need to order replacement parts, we recommend that
you use only factory specified parts. Factory specified parts will
fit right and work right because they are made with the same
precision used to build every new KITCHENAID® appliance.
To locate factory specified parts in your area, call us or your
nearest designated service center.
In the U.S.A.
Call the KitchenAid Customer eXperience Center toll free
1-800-422-1230, or visit our website at www.kitchenaid.com.
Our consultants provide assistance with:
■Features and specifications on our full line of appliances.
■Referrals to local KitchenAid brand dealers.
■Installation information.
■Use and maintenance procedures.
■Accessory and repair parts sales.
■Specialized customer assistance (Spanish speaking, hearing
impaired, limited vision, etc.).

17
In Canada
For Further Assistance
If you need further assistance, you can write to KitchenAid with
any questions or concerns at:
KitchenAid Brand Home Appliances
Customer eXperience Center
553 Benson Road
Benton Harbor, MI 49022-2692
Please include a daytime phone number in your correspondence.
Call the KitchenAid Canada LP Customer eXperience Centre toll
free 1-800-807-6777 or visit our website at www.kitchenaid.ca.
Our consultants provide assistance with:
■Scheduling of service. KitchenAid® appliances designated
service technicians are trained to fulfill the product warranty
and provide after-warranty service anywhere in Canada.
■Features and specifications on our full line of appliances.
■Referrals to local KitchenAid brand dealers.
■Use and maintenance procedures.
■Accessory and repair parts sales.
For Further Assistance
If you need further assistance, you can write to KitchenAid
Canada LP with any questions or concerns at:
KitchenAid Brand Home Appliances
Customer eXperience Centre
200 – 6750 Century Ave.
Mississauga, Ontario L5N 0B7
Please include a daytime phone number in your correspondence.
ACCESSORIES
To order accessories, call 1-800-442-9991 and ask for the
appropriate part number listed below or contact your authorized
KitchenAid brand dealer. In Canada, call 1-800-807-6777.
affresh® Stainless Steel Cleaner:
In U.S.A., order Part #W10355016
In Canada, order Part #W10355016B
affresh® Stainless Steel Wipes:
In U.S.A., order Part #W10355049
In Canada, order Part #W10355049B
affresh® Kitchen & Appliance Cleaner:
In U.S.A., order Part #W10355010
In Canada, order Part #W10355010B
Replacement Water Filter:
In U.S.A., order Part #4396841 (T2RFWG2)
In Canada, Order Part #4396841B (T2RFWG2)

18
PERFORMANCE DATA SHEETS
Base Grille Water Filtration System
Model T2WG2L/T2RFWG2 Capacity 200 Gallons (757 Liters)
Model T2WG2/T2RFWG2 Capacity 200 Gallons (757 Liters)
This system has been tested according to NSF/ANSI Standards 42 and 53 for the reduction of the substances listed below. The
concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the
permissible limit for water leaving the system, as specified in NSF/ANSI Standards 42 and 53.
Te
st Parameters: pH = 7.5 ± 0.5 unless otherwise noted. Flow = 0.85 gpm (3.2 Lpm). Pressure = 60 psig (413.7 kPa).
Te
mp. = 68°F to 71.6°F (20°C to 22°C). Rated service capacity = 200 gallons (757 liters).
It is essential that operational, maintenance, and filter
replacement requirements be carried out for the product to
perform as advertised.
Use replacement filter T2RFWG2, part #4396841.
Model T2WG2L: Style 1 – When the filter indicator reads 10%,
order a new filter. When the indicator reads 0%, it is
recommended that you replace the filter.
Style 2 – When the filter indicator changes from green to yellow,
order a new filter. When the indicator changes from yellow to red,
it is recommended that you replace the filter.
Style 3 –When the water filter status display changes from
“GOOD” to “ORDER,” order a new filter. When the filter indicator
reads “REPLACE,” it is recommended that you replace the filter.
Style 4 – Press FILTER to check the status of your water filter. If
the filter indicator light is yellow, order a new filter. If the filter
indicator light is red, it is recommended that you replace the filter.
Model T2WG2: Change the water filter cartridge every 6months.
If the water flow to the water dispenser or ice maker decreases
noticeably before 6months have passed, replace the water filter
cartridge more often.
These contaminants are not necessarily in your water supply.
While testing was performed under standard laboratory
conditions, actual performance may vary.
The product is for cold water use only.
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or after the
system.
Refer to the “Warranty” section for the Manufacturer’s name,
address and telephone number.
Refer to the “Warranty” section for the Manufacturer’s limited
warranty.
Application Guidelines/Water Supply Parameters
System tested and certified by NSF International against NSF/ANSI
Standard42 for the reduction of Chlorine Taste and Odor, Particulate
ClassII*; and against NSF/ANSI Standard 53 for the reduction of Mercury,
Benzene, Toxaphene, O-dichlorobenzene, and Carbofuran.
Substance Reduction
Aesthetic EffectsNSF Reduction Requirements Average Influent Influent Challenge Concentration Maximum Effluent Average Effluent Minimum % ReductionAverage % Reduction
Chlorine Taste/Odor
Particulate Class II*50% reduction
85% reduction 2.0182 mg/L 1333333 #/mL 2.0 mg/L ± 10% At least 10,000 particles/mL 0.06 mg/L 6600 #/mL** 0.0536 mg/L 2325 #/mL 97.03 99.51 97.34 99.83
Contaminant
Reduction NSF Reduction Requirements Average Influent Influent Challenge Concentration Maximum Effluent Average Effluent Minimum % ReductionAverage % Reduction
Lead: @ pH 6.5***
Lead: @ pH 8.5*** 0.010 mg/L 0.010 mg/L 0.1533 mg/L 0.1400 mg/L 0.15 mg/L ± 10% 0.15 mg/L ± 10%0.0005 mg/L 0.0007 mg/L 0.0005 mg/L 0.0006 mg/L 99.67 99.5099.67 99.57
Mercury: @ pH 6.5
Mercury: @ pH 8.5 0.002 mg/L 0.002 mg/L 0.0058 mg/L 0.0059 mg/L 0.006 mg/L ± 10% 0.006 mg/L ± 10% 0.0002 mg/L 0.0005 mg/L 0.0002 mg/L 0.0003 mg/L 96.54 91.57 96.54 94.92
Benzene 0.005 mg/L 0.0154 mg/L 0.015 mg/L ± 10% 0.0012 mg/L 0.0006 mg/L 92.22 96.34
O-Dichlorobenzene 0.6 mg/L 1.7571 mg/L 1.8 mg/L ± 10% 0.0250 mg/L 0.0066 mg/L 98.58 99.63
Toxaphene 0.003 mg/L 0.015 mg/L 0.015 mg/L ± 10%0.001 mg/L 0.001 mg/L 93.33 93.33
Carbofuran 0.04 mg/L 0.0819 mg/L 0.08 mg/L ± 10%0.0400 mg/L 0.0213 mg/L 51.13 74.00
Water Supply
Water Pressure
Water Temperature
Service Flow Rate
City or Well
30 - 120 psi (207 - 827 kPa)
33° - 100°F (0.6° - 37.8°C)
0.85 gpm (3.2 Lpm) @ 60 psi
*
**
***
Class II particle size: 1 um to <5 um
Test requirement is at least 100,000 particles/mL of AC Fine Test Dust.
Compliant for Lead reduction requirements under NSF/ANSI Standard 53 as tested by Pace Analytical Services, Inc.
® NSF is a
registered trademark of NSF International.

19
PERFORMANCE DATA SHEETS
Base Grille Water Filtration System
Model T2WG2L/T2RFWG2 Capacity 200 Gallons (757 Liters)
Model T2WG2/T2RFWG2 Capacity 200 Gallons (757 Liters)
This system has been tested according to NSF/ANSI Standards 42 and 53 for the reduction of the substances listed below. The
concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the
permissible limit for water leaving the system, as specified in NSF/ANSI Standards 42 and 53.
Test Parameters: pH = 7.5 ± 0.5 unless otherwise noted. Flow = 0.85 gpm (3.2 Lpm). Pressure = 60 psig (413.7 kPa).
Temp. = 68°F to 71.6°F (20°C to 22°C). Rated service capacity = 200 gallons (757 liters).
It is essential that operational, maintenance, and filter
replacement requirements be carried out for the product to
perform as advertised.
Use replacement filter T2RFWG2, part #4396841.
Model T2WG2L: Style 1 – When the filter indicator reads 10%,
order a new filter. When the indicator reads 0%, it is
recommended that you replace the filter.
Style 2 – When the filter indicator changes from green to yellow,
order a new filter. When the indicator changes from yellow to red,
it is recommended that you replace the filter.
Style 3 –When the water filter status display changes from
“GOOD” to “ORDER,” order a new filter. When the filter indicator
reads “REPLACE,” it is recommended that you replace the filter.
Style 4 – Press FILTER to check the status of your water filter. If
the filter indicator light is yellow, order a new filter. If the filter
indicator light is red, it is recommended that you replace the filter.
Model T2WG2: Change the water filter cartridge every 6months.
If the water flow to the water dispenser or ice maker decreases
noticeably before 6months have passed, replace the water filter
cartridge more often.
These contaminants are not necessarily in your water supply.
While testing was performed under standard laboratory
conditions, actual performance may vary.
The product is for cold water use only.
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or after the
system.
Refer to the “Warranty” section for the Manufacturer’s name,
address and telephone number.
Refer to the “Warranty” section for the Manufacturer’s limited
warranty.
Application Guidelines/Water Supply Parameters
System tested and certified by NSF International against NSF/ANSI
Standard42 for the reduction of Chlorine Taste and Odor, Particulate
ClassII*; and against NSF/ANSI Standard 53 for the reduction of Mercury,
Benzene, Toxaphene, O-dichlorobenzene, and Carbofuran.
Substance Reduction
Aesthetic EffectsNSF Reduction Requirements Average Influent Influent Challenge Concentration Maximum Effluent Average Effluent Minimum % ReductionAverage % Reduction
Chlorine Taste/Odor
Particulate Class II*50% reduction
85% reduction 2.0182 mg/L 1333333 #/mL 2.0 mg/L ± 10% At least 10,000 particles/mL 0.06 mg/L 6600 #/mL** 0.0536 mg/L 2325 #/mL 97.03 99.51 97.34 99.83
Contaminant
Reduction NSF Reduction Requirements Average Influent Influent Challenge Concentration Maximum Effluent Average Effluent Minimum % ReductionAverage % Reduction
Lead: @ pH 6.5***
Lead: @ pH 8.5*** 0.010 mg/L 0.010 mg/L 0.1533 mg/L 0.1400 mg/L 0.15 mg/L ± 10% 0.15 mg/L ± 10%0.0005 mg/L 0.0007 mg/L 0.0005 mg/L 0.0006 mg/L 99.67 99.5099.67 99.57
Mercury: @ pH 6.5
Mercury: @ pH 8.5 0.002 mg/L 0.002 mg/L 0.0058 mg/L 0.0059 mg/L 0.006 mg/L ± 10% 0.006 mg/L ± 10% 0.0002 mg/L 0.0005 mg/L 0.0002 mg/L 0.0003 mg/L 96.54 91.57 96.54 94.92
Benzene 0.005 mg/L 0.0154 mg/L 0.015 mg/L ± 10% 0.0012 mg/L 0.0006 mg/L 92.22 96.34
O-Dichlorobenzene 0.6 mg/L 1.7571 mg/L 1.8 mg/L ± 10% 0.0250 mg/L 0.0066 mg/L 98.58 99.63
Toxaphene 0.003 mg/L 0.015 mg/L 0.015 mg/L ± 10%0.001 mg/L 0.001 mg/L 93.33 93.33
Carbofuran 0.04 mg/L 0.0819 mg/L 0.08 mg/L ± 10%0.0400 mg/L 0.0213 mg/L 51.13 74.00
Water Supply
Water Pressure
Water Temperature
Service Flow Rate
City or Well
30 - 120 psi (207 - 827 kPa)
33° - 100°F (0.6° - 37.8°C)
0.85 gpm (3.2 Lpm) @ 60 psi
*
**
***
Class II particle size: 1 um to <5 um
Test requirement is at least 100,000 particles/mL of AC Fine Test Dust.
Compliant for Lead reduction requirements under NSF/ANSI Standard 53 as tested by Pace Analytical Services, Inc.
® NSF is a registered trademark of NSF International.
Base Grille Water Filtration System
Model T1WG2L/T2RFWG2 Capacity 200 Gallons (757 Liters)
Model T1WG2/T2RFWG2 Capacity 200 Gallons (757 Liters)
This system has been tested according to NSF/ANSI Standards 42 and 53 for the reduction of the substances listed below. The
concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the
permissible limit for water leaving the system, as specified in NSF/ANSI Standards 42 and 53.
Te
st Parameters: pH = 7.5 ± 0.5 unless otherwise noted. Flow = 0.5 gpm (1.9 Lpm). Pressure = 60 psig (413.7 kPa).
Te
mp. = 68°F to 71.6°F (20°C to 22°C). Rated service capacity = 200 gallons (757 liters).
It is essential that operational, maintenance, and filter
replacement requirements be carried out for the product to
perform as advertised.
Use replacement filter T2RFWG2, part #4396841.
Model T1WG2L: Style 1 – When the filter indicator reads 10%,
order a new filter. When the indicator reads 0%, it is
recommended that you replace the filter.
Style 2 – When the filter indicator changes from green to yellow,
order a new filter. When the indicator changes from yellow to red,
it is recommended that you replace the filter.
Style 3 –When the water filter status display changes from
“GOOD” to “ORDER,” order a new filter. When the filter indicator
reads “REPLACE,” it is recommended that you replace the filter.
Style 4 – Press FILTER to check the status of your water filter. If
the filter indicator light is yellow, order a new filter. If the filter
indicator light is red, it is recommended that you replace the filter.
Model T1WG2: Change the water filter cartridge every 6months.
If the water flow to the water dispenser or ice maker decreases
noticeably before 6months have passed, replace the water filter
cartridge more often.
These contaminants are not necessarily in your water supply.
While testing was performed under standard laboratory
conditions, actual performance may vary.
The product is for cold water use only.
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or after the
system.
Refer to the “Warranty” section for the Manufacturer’s name,
address and telephone number.
Refer to the “Warranty” section for the Manufacturer’s limited
warranty.
Application Guidelines/Water Supply Parameters
System tested and certified by NSF International against NSF/ANSI
Standard42 for the reduction of Chlorine Taste and Odor, Particulate
ClassII*; and against NSF/ANSI Standard 53 for the reduction of Mercury,
Benzene, Toxaphene, O-dichlorobenzene, and Carbofuran.
Substance Reduction
Aesthetic Effects NSF Reduction Requirements Average Influent Influent Challenge Concentration Maximum Effluent Average Effluent Minimum % ReductionAverage % Reduction
Chlorine Taste/Odor
Particulate Class II*50% reduction
85% reduction 2.0182 mg/L 1333333 #/mL 2.0 mg/L ± 10% At least 10,000 particles/mL 0.06 mg/L 6600 #/mL** 0.0536 mg/L 2325 #/mL 97.03 99.5197.34 99.83
Contaminant
Reduction NSF Reduction Requirements Average Influent Influent Challenge Concentration Maximum Effluent Average Effluent Minimum % ReductionAverage % Reduction
Lead: @ pH 6.5***
Lead: @ pH 8.5***0.010 mg/L 0.010 mg/L 0.1533 mg/L 0.1400 mg/L 0.15 mg/L ± 10% 0.15 mg/L ± 10%0.0005 mg/L 0.0007 mg/L 0.0005 mg/L 0.0006 mg/L 99.67 99.5099.67 99.57
Mercury: @ pH 6.5
Mercury: @ pH 8.5 0.002 mg/L 0.002 mg/L 0.0058 mg/L 0.0059 mg/L 0.006 mg/L ± 10% 0.006 mg/L ± 10%0.0002 mg/L 0.0005 mg/L 0.0002 mg/L 0.0003 mg/L 96.54 91.5796.54 94.92
Benzene 0.005 mg/L 0.0154 mg/L 0.015 mg/L ± 10% 0.0012 mg/L 0.0006 mg/L 92.22 96.34
O-Dichlorobenzene 0.6 mg/L 1.7571 mg/L1.8 mg/L ± 10% 0.0250 mg/L 0.0066 mg/L 98.58 99.63
Toxaphene 0.003 mg/L 0.015 mg/L 0.015 mg/L ± 10%0.001 mg/L 0.001 mg/L 93.3393.33
Carbofuran 0.04 mg/L 0.0819 mg/L 0.08 mg/L ± 10%0.0400 mg/L 0.0213 mg/L 51.1374.00
Water Supply
Water Pressure
Water Temperature
Service Flow Rate
City or Well
30 - 120 psi (207 - 827 kPa)
33° - 100°F (0.6° - 37.8°C)
0.5 gpm (1.9 Lpm) @ 60 psi
*
**
***
Class II particle size: 1 um to <5 um
Test requirement is at least 100,000 particles/mL of AC Fine Test Dust.
Compliant for Lead reduction requirements under NSF/ANSI Standard 53 as tested by Pace Analytical Services, Inc.
® NSF is a
registered trademark of NSF International.

20
