1 Cabinet (Not A Serviceable Part)
3 2005004 Grommet, Tube Crossover
4 1112023 Roller, Front & Rear (4)
5 Support, Leveler Assembly
2004506 Refrigerator Side
2004505 Freezer Side
6 2005006 Grommet, Wiring
7 2005007 Grommet, Flexible
9 2004852 Mounting Stud, Grill
10 2005237 Wire Clip
11 1112849 Cap, Grommet
13 1113122 Grommet, Wiring
14 2004913 Wiring Harness, Cabinet
16 488946 Tube, Clamp
17 2005378 Screw, Door Stop
18 Hinge (Top)
2005252 Left Side
2005251 Right Side
19 2005294 Shim, Hinge Top
20 1112805 Guard, Wiring
21 2004994 Lock, Adjustable Bushing
22 2002903 Bushing
24 Spring, Door Closure
2004566 Refrigerator Side
2004567 Freezer Side
25 486194 Screw
26 2005008 Retaining Ring, Adjustable Bushing
27 1113227 Fastener (3)
28 2004867 Gap, Cover Assembly (Bottom)
29 Hinge (Bottom)
2004539 Freezer Side
2004507 Refrigerator Side
30 2005293 Bushing, Adjustable
31 3400207 Screw
33 2004516 Linkage, Door Closure
34 Grille Base, Front
2004532 Black
35 489238 Screw
36 2004512 Cover, Rear
37 1113123 Grommet, Wiring
39 2004595 Cup, Wiring
40 2004565 Bushing, Door Closure
41 1163283 Screw
42 2150347 Union
43 3400207 Screw (4)

1 2005256 Cabinet, Trim Right Side
2 2003857 Screw
3 1163283 Screw
4 2004538 Cabinet, Trim (Bottom)
5 486194 Screw
6 2003647 Cabinet, Trim Top
7 2005493 Cabinet, Trim Left Side

1 Liner (Not A Serviceable Part)
2 1113649 Bracket, Light
3 1113650 Lens
4 1112613 Light, Socket
5 548049 Light, Bulb
6 538533 Support Clip, Icemaker (2)
7 2000193 Grommet, Screw (2)
8 488552 Screw
12 486194 Screw
13 1112591 Spacer, Control Panel (3)
14 842534 Clip, Air Duct (4)
16 1112260 Support, Evaporator
17 2004068 Stud, Shelf (20)
18 487559 Screw

1 LINER (Not A Serviceable Part)
2 1112591 Spacer, Control Panel (3)
5 2001117 Ladder, Shelf (2)
6 520965 Screw Support, Ladder (8)
7 488357 Screw
8 486194 Screw
9 1112257 Hole Plug
10 2003579 Meat Pan, Air Duct Cover
11 2000337 Meat Pan, Air Duct
12 2003299 Inlay, Control Meat Pan
13 2001326 Seal, Air Duct
14 1112218 Damper Control, Meat Pan
15 2003811 Control Knob, Meat Pan
16 2003841 Retainer, Knob
17 2004484 Air Baffle Assembly
21 2001146 Seal
22 1116793 Cover, Thermistor
23 1116959 Thermistor
25 2003578 Air Baffle Cover
26 2003577 Guard, Air Return

1 1112642 Control Panel
2 2003303 Inlay, Control Panel
3 2004005 Circuit Board
4 2003842 Control Knob
5 2003841 Retainer, Knob
6 1118894 Switch, Rocker Arm
7 1113137 Seal, Control Panel
8 489260 Screw (3)
9 2000153 Hole Plug (3)
10 1113775 Shield, Control Panel
11 1112613 Socket, Light (2)
12 548049 Light Bulb (2)
13 486194 Screw
14 2003758 Wire, Light
15 2001141 Channel, Wiring
16 1115375 Clip, Wiring (2)

1 1113627 Control Panel
2 2003309 Inlay, Control Panel
3 1113466 Thermostat & Barrier Assembly
4 488974 Screw (2)
5 1115373 Switch, Rocker Arm
6 1113136 Seal, Control Panel
8 489260 Screw (3)
9 2000153 Hole Plug (3)
10 1113769 Shield, Control Panel
11 1112613 Socket, Light
12 486194 Screw
13 548049 Light Bulb
14 2001974 Channel, Wiring
16 2182112 Knob, Thermostat
17 1115375 Clip, Wiring

1 2174404 Frame, Shelf
2 2003377 Glass, Shelf
3 1112006 Reflector, Shelf
4 1113792 Gasket, Glass (2)
5 2179375 Rack, Wine
6 2169933 Egg Bin
7 2003327 Frame, Assembly Meat Pan
8 2164373 Egg Carrier
9 1112247 Cover, Crisper
10 2003380 Glass, Crisper (Includes #9)
11 2000742 Meat Pan, Connector
12 2169935 Cover
14 2003317 Crisper Pan (2)
15 2174388 Roller
16 2174478 Eyelet, Roller
17 2003478 Screw
20 2003322 Meat Pan
23 2002181 Retainer, Glass
25 2003411 Crisper Spacer, Right Side (2)
27 1113169 Stop, Roller
28 2003410 Crisper Spacer, Left Side (2)
29 486194 Screw

1 2003144 Solid Shelf
2 2003135 Front, Ice Compartment
3 1113638 Shelf, Fixed (2)
1112052 Shelf, Fixed-Deep
4 2001626 Basket (2)
5 2002727 Ice Container
6 2003045 Front Cover
7 Slide, Container
2002720 Right Side
2002721 Left Side
8 2003046 Hole Plug, Front
9 2003047 Hole Plug, Rear
13 2003114 Trim, Basket
15 2174388 Roller
16 2174478 Eyelet, Roller
17 2003478 Screw
18 488886 Screw
22 Basket Slide
2000061 Right Side
2000062 Left Side
24 1113169 Stop, Roller
25 486194 Screw

1 2005314 Top Grille Assembly
2 2005549 Cover, Unit
3 486194 Screw
4 2002484 Grille, Bracket
5 2001415 Screw
6 2005292 Nameplate
7 2005534 Guard, Compressor Wiring
9 2004333 Nut
10 2005485 Bracket, Trim Panel
11 2005483 Louver, Bracket
12 2005259 Vent, Louver
13 488649 Screw

1 2003872 Refrigerator Door Panel (Includes Insulation)
2 2005283 Door Skin
3 2005329 Hinge Assembly, Top
4 2004520 Spacer-Door, Top
5 489282 Screw
6 2004523 Hinge Assembly, Bottom
7 1112533 Gasket Retainer, Side (2)
8 1112542 Gasket Retainer, Top & Bottom
9 2001049 Door Gasket, Magnetic
10 2004447 Door Brace, Corner
11 2005290 Handle, Door
12 2005320 Spacer, Handle Side
13 2004549 Door, Spacer Bottom
14 2005327 Filler, Door
15 Screw
487052 Stainless Steel
16 90864 Screw
17 2005030 Spacer, Hinge Side
18 2005058 Insulation, Encapsulated
19 2005433 Spacer, Top
20 1113950 Panel, Interior Door
21 1113949 Ladder, Shelf (2)
22 1113948 Retainer, Shelf Ladder (2)
23 1112514 Back Up Plate (8)
24 486194 Screw
25 1113955 Gasket
26 2003465 Door, Utility Bin
27 2003132 Door Shelf (4)
28 2165792 Butter Tray
29 2004881 Retaining Ring, Door-Closure
30 2004935 Spacer-Door, Skin
