KitchenAid KEWS105SPA03 User manual

CONTROL, DOOR AND DRAWER PARTS
1
For Models: KEWS105SSS03, KEWS105SPA03
(Stainless) (Panel Ready)
03−09 Litho in U.S.A. (amd) (eeb) Part No. W10260356 Rev. A
30" ELECTRIC
BUILT−IN
WARMING DRAWER

CONTROL, DOOR AND DRAWER PARTS
2
For Models: KEWS105SSS03, KEWS105SPA03
(Stainless) (Panel Ready)
W10260356
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10064720 Tech Sheet
W10162186 Use & Care Guide
9763140 Installation
Instructions
2 8273277 Rack, Warming
3
W10162376 Slide, Vent
4
W10162374 Panel, Front
5
W10164998 Gasket, Drawer
6 9763646 Drawer Assembly
7 4449743 Screw
8
W10139505 Door, Panel
Stainless Only
9
8303774SS Handle, Drawer
Stainless Only
10
8304603SS Badge
Stainless Only
11 4455984 Knob, Thermostat
12
W10080130 Light, Indicator
13 Lens, Light
4456314 Stainless
9763644 Custom Wood,
Panel Only
14
W10139494 Rail, Pan (2)
15 9763125 Grip, Vent
16
W10035910 Magnet
17 3196537 Screw (2)
18 4456862 Clip, Lens
Retainer
19 4456861 Spacer, Lens

INTERNAL WARMING DRAWER PARTS
3
For Models: KEWS105SSS03, KEWS105SPA03
(Stainless) (Panel Ready)
W10260356

INTERNAL WARMING DRAWER PARTS
4
For Models: KEWS105SSS03, KEWS105SPA03
(Stainless) (Panel Ready)
W10260356
Illus. Part
No. No. DESCRIPTION
1 9762305 Wrapper
2 313806 Screw (1)
3
W10188461 Slide Assembly
4 Wall
9762307 Right
9762308 Left
5 311865 Screw
6
W10121337 Control
7
W10117362 Gasket, Control
8 9763126 Thermal Fuse
9 9763122 Enclosure,
Electric
10 9763121 Cover, Enclosure
11
W10117363 Gasket,Enclosure
12 9762329 Element, Heating
13 3196537 Screw
14
W10118049 Seal, Heating
Element
15
W10118113 Seal, Switch
16
W10118073 Heat Shield
FOLLOWING PARTS
NOT ILLUSTRATED
WIRING HARNESS PARTS
W10129043 Harness, Main
W10129023 Power Cord
W10131847 Sensor, Sealed
4452601 Strain Relief
3400015 Screw, Ground
Power Cord
ACCESSORY PARTS
Front Panel
Assembly, Includes
Handle & Badge
8212671 Black
8212672 White
