KLD CE User manual

KLD Guitar Effect Pedal
CE
Chorus Effect Pedal
Kailing Electronic co.Ltd
http://www.kldguitar.com

Congratulations
CongratulationsCongratulations
Congratulations : on purchasing the Kldguitar CE ! CE is chorus effect
pedal, based on classical electronic circuit. It's sound is warm, full and rich,
while avoiding the usual chorus pitfalls of muddiness or strange frequency
spikes. he tone is smooth and never grainy and its unmistakable warm analog
stereo chorus and vibrato have been heard on countless tracks--particularly on
guitars, bass.
NOTES
NOTES NOTES
NOTES
· unplug the instrument when not in use.
· You will hear some loss of level and distortion when the battery begins to run
down.
· When using external power source, we recommend you use our adapter.
· Do not remove the screws on bottom.
SPECIFICATIONS
· Accurate model of original CE chorus effect, 80's style sound.
· rue pitch shifting vibrato
· 100% analog circuit
· 100% hand made
· Input gain control
· “Classic Mode” or “Dual Mode” configuration with stereo tracks,
·Controls: EFFEC LEVEL, DEP H, RA E, CHOURSE /VIBRA O, WE
BASS/NORMAL,
·Strong virtually indestructible steel enclosure
·Heavy-duty, industrial footswitch
·Inside jacks
·Sloped face for easy stomping
·On/Off LED
· rue Bypass design
·Rubycon capacitors
·Military-spec glass-epoxy circuit board
·AC jack (power supply sold separately)
·No tools required; battery compartment
(9 volt not included).
· Input Impedance 500K ohms
· Output Impedance 10K ohms
· Maximum Output Level 0 dBm
· Maximum Gain +30 dB
· Equivalent Input Noise:-100 dBm (IHF-A)
·DIMENSIONS:5.5(W)x50(H)x12.3(L)CM (unpacked)
·Weight:0.7kg (unpacked)

OPERATION:
1 IN PUT:
Connect the input jack to your instrument or Send jack of amp which has FX
loop. he circuit is automatically turned on when a plug is inserted.
2 OUT:
Connect the output jack to your amp input or Return jack of amp which has FX
loop.
2. RATE:
he speed of chorus adjusts. urn CW to increase speed and deepen the effect.
3. DEPTH:
he depth of chorus adjusts. urn CW to increase depth.
4. LEVEL:
he volume adjusts. urn CW to increase volume.
5. WET BASS/NORMAL:
oggle switch is of effect on/off.
6. CHORUS/VIBRATO:
oggle switch is of Chorus/Vibrato.
7. LED of ON/OFF:
Indicator comes on when effect is on. If it is dim or does not light, replace the
battery.
8. EXT D.C. :
When using external D.C. supply, internal batteries are switched off.
For more information about our products, please look at our website
http://www.kldguitar.com
