KLINGER EMXN1025 User manual

EMXN1025
Manual
v_1.0

Specifications
CAMERA
Components and Accessories
Camera part name
Camera bass
Mountbase
Camera guard
Camera
DC12V cable
2.5mm
“L’wrench 5mm “L’wrench
Focus/Zoom
Adjustment Tool
Manual
Manual
Fixing Screw
S5X25(4EA)
Anchor
φ4X30(4EA)
“T’ Block
EMXN1025
1/3" Sony Super HAD CCD
Color - 600TV lines / B&W - 700TV lines
NTSC 768(H)x494(V) / PAL 753(H)x582(V)
2:1 Interlace
Internal
0.1Lux @ F1.2(Normal mode)
0.0002Lux @ F1.2(Sens-up x 256)
52 dB (AGC Off/Weight ON)
1Vp-p Composite 75Ω
NTSC 15.734KHz(H)/ 60HZ (V) / PAL 15.625KHz (H) / 50Hz (V)
NTSC 1/60 ~ 1/120,000sec / PAL 1/50 ~ 1/100,000
ATW1/ATW2/AWC/Manual
ON / OFF (54 ea / 2 line)
ON / OFF (Level setting)
x2 ~ x256
ON / OFF (Aera setting)
LOW / HIGH / OFF selectable
ON /OFF
ON /OFF (8 zone)
ON /OFF
ON /OFF
ON /OFF
ON /OFF (Level adjustable)
ON / OFF ( x 10)
COLOR / BW / AUTO / EXT
f = 6~50mm Aspheric AI LensStandard
mm11~8.2noitpO
DC12V(±10%) / AC24V(±10%) regulated
700mA Max.
-30°C ~ +50°C
30% ~ 90% RH
)AE84-eip5DELRI(m04roodnI
Outdoor
Camera
Package
30m ( IR LED 5pie - 48EA )
Weight
1,730g
2,000g
120(W) X 140(H) X 254(D)mm
Lens
Sharpness
Power Source
Scanning Frequency
Power Consumption
Operating Temperature
Electronic Shutter Speed
Operating Humidity
Visible Range
(LED on)
Dimensions (HxDmm)
Scanning System
Synchronization
S/N ratio
Horizontal Resolution
Min.lllumination (LED off)
MODEL
Video Output
CCD
Effective Pixels
Digital Zoom
Sens-up
DNR
AGC
Motion Detection
Day & Night
DIS
Privacy Function
Camera ID
BLC
White Balance
Mirror(H-rev)
Flip(V-res)

PAN 360°
PAN 360°
ROTATE 360°
ROTATE 360°
TILT 90°
TILT 90°
Camera bracket function
Dimension
45°
45°
∅5
133
87
95
120
140
42
254
FRONT
SIDE
MOUNT BASE

[PIC 2]
[PIC 1]
1. ZOOM/FOCUS ADJUST MENT
2.CAMERA SETTING
Camera setting
5mm
“L”wrench
2.5mm
“L”wrench
Fixing Screw
Camera installation
1. Make desired viewing angle by using Focus/Zoom adjustment tool clockwise
or conunter clockwise as [PIC 1]
Video Jack
(BNC/RCA)
Cable Jack Setting
Video Signal
Video GND
Video Jack
DC/AC Switched
Without
Nega(-)/Posi(+)
1. On the ceiling(or wall), make the hole for Anchor and put the Anchor into
the hole completely.
Use Fixing Screw to settle (Anchor size : Φ4 / Lengh 30mm)
2. After settle the Bracket Base, use “L”wrench to settle the Camera Body
and Bracket Head
Camera bass
Mountbase
Camera guard
Termial
Block
Extra Service Preview
Video output
Joystick
Push
Menu / Enter
1. According to [PIC 2], open Control Panel cover to change the setting.
2. If necessary, change OSD setting for desired performance, at camera control
panel
* The extra service preview video out put can be used for installation with the
Portable monitor. ( For the camera setting, please check the OSD manu)
* Push the OSD joystick little more than 1sec., OSD manu will be appeared.
* Move the OSD joystick for change the setting.
* Push the OSD joystick for Enter and Set the setting.
3. After changing OSD setting, lock the control panel cover completely.
Focus/Zoom
Adjustment Tool
Control Panel cover
Control Panel cover
UP
DOWN
RIGHT
LEFT
Zoom
Focus
N
∞
TW
