OWNER’S MANUAL
42" ANIMATED GRAZING DOE (105LT)
Product code: 0-03431354-4
UPC code: 029944491736
Date of purchase: _____/ _____/ _____

42 IN ANIMATED GRAZING DOE
ITEM NUMBER: M16(42)-105L-M
A. Ears-1pair
B.Headandneck
Qty：1pc
C.Body
Qty：1pc
D.Pin
Qty：1pc
E. Ground stake
Qty：4pcs
ASSEMBLY INSTRUCTIONS
STEPS:
(1) Take out all the parts of the product and place them on a flat surface; If there are any
plastic covers to protect the end of metal rod tips, remove the covers before assembly;
(2) Carefully remove the ears, head, and neck from inside the body.
(3) Unfold the four legs. Insert the four hooks at the bottom of the body into the
corresponding holes on the inner side of each leg .(See diagram 1,2)
(4) Unfold the front legs. Insert the metal hook on one front leg into the metal loop on the
other front leg to secure them in position; (See Diagram 1).
(5) There is a pair of hooks on the rear neck and another pair of hooks on the forefront of the
body. Hang the rear neck's hooks onto the hooks on the front of the body. (See Diagram 3)
(6) Turn the motor set to vertical position. Insert the metal hook on the body side to the
corresponding hole on the motor standing frame.(See Diagram 3)
(7) Insert the end of the balance metal bar into the hole on top of the rear end of the neck and
secure them with the Pin (Part #4) .(See Diagram 3)
(8) Insert the two metal rods at the bottom of the ears into the holes on the top of the head.
(See Diagram 4)
(9) Take the item outside and secure to ground by using the stakes provided.
(10) Plug in.
