Knaack 118-01 User manual

Werner Co. 724-588-2000
93 Werner Rd. 888-523-3371 toll free/ llamada gratuita
Greenville, PA 16125 888-456-8458 fax
118-01 DATAVAULT
118-02 DATAVAULT - BARE
INSTALLATION MANUAL
JOBSITE STORAGE SOLUTIONS
ALWAYS ON THE JOB™

Page 2
ENGLISH
NOTICE
ATTENTION: PLEASE READ AND UNDERSTAND ALL INSTRUCTIONS
AND WARNINGS BEFORE ASSEMBLING, INSTALLING OR USING THIS
PRODUCT.
Tools Required
• 9/16” SOCKET
• 9/16” WRENCH
• 5/16” SOCKET
• 7/16” SOCKET
• 7/16” WRENCH
• SCREWDRIVER, STRAIGHT BLADE
• SCREWDRIVER, PHILLIPS HEAD
Parts List
• MODEL 500 POWER CREW * QTY. 1
• MODEL 497 LIFT BRACKETS* QTY. 1
• BRACKETS, SCREEN MTG. QTY. 2
Bolt Kit #32-1180
• BOLT, M4 X18MM PHILLIPS HEAD QTY. 4
• BOLT, M4 X30MM PHILLIPS HEAD QTY. 4
• Bolt, M6 x 12MM PHILLIPS HEAD QTY. 4
• BOLT, M6 x 30MM PHILLIPS HEAD QTY. 4
• BOLT, M8 x 35MM PHILLIPS HEAD QTY. 4
• WASHER, LOCK ¼” QTY. 4
• WASHER, FLAT 1/4 QTY. 4
• WASHER, LOCK 5/16” QTY. 4
• BOLT, 1/4-20 x 5/8 HEX HD QTY. 6
• NUT, WHIZ 1/4-20 QTY. 6
• SHIM, HORSESHOE 1/16” THICK QTY. 12
• SHIM, HORSESHOE ¼” THICK QTY. 4
* NOTE: FOR INSTALLING BOTH THE MODEL 500 POWER CREW, AND THE 497
LIFT BRACKETS, REFER TO THE INSTRUCTION SHEETS INSIDE EACH KIT.
TV Specications (not included in 118-02 but must meet these specs)
• 40” TV
• MINIMUM OF 2 HDMI PORTS

Data Vault
USER INSTRUCTIONS
Page 3
ENGLISH
Contents
I. INSTALLING A LARGE SCREEN...................................................................... 4
II. 3 POSITION HATCH FEATURE........................................................................ 6
a. Working Position ......................................................................................................6
b. Open Position ..........................................................................................................6
c. Closed Position........................................................................................................6
III. LOCKABLE HATCH......................................................................................... 7
IV. INSTALLING A PRINTER ................................................................................ 8
V. INSTALLING USB SWITCH.............................................................................. 8
VI. INSTALLING POWER STRIPS........................................................................ 9
VII. INSTALLING A COMPUTER .......................................................................... 9
a. Tower Computer .......................................................................................................9
b. Laptop.....................................................................................................................10
c. Tablet .......................................................................................................................10
VIII. DRAWER ADJUSTING:................................................................................10
a. Drawer Removal and Installation..........................................................................10
b. Drawer Slide Install................................................................................................10
c. Drawer Retention ...................................................................................................10
IX. INSTALLING STRAPS:...................................................................................11

Page 4
ENGLISH
CAUTION
Any modication or unintended use of this product shall immediately
void all manufactures warranties. Manufacture disclaims all liability
for injuries to persons or property resulting from any modication to,
or unintended use of this product.
CAUTION
Prior to drilling to keep debris out of your eyes, always wear protective
eye wear. Failure to heed may result to death or serious injury.
I. Assembly of TV/Monitor and TV/Monitor Protector
a. Take the TV/monitor from the shipping packaging
b. Place TV on the at surface(preferably
on the carpet or use the TV box as the
working surface to avoid any scratching
of the TV)
c. Locate the mounting hardware inside
the TV box
d. Remove the mounting plate from the
TV mount by removing the screw(need
to reuse the screw so place it in safe
place)
e. Place 4 plastic spacers (from the
mounting hardware bag included in TV
box) and place them on the back of the
TV (FIG. 1).
f. Mount the mounting plate to back of
the TV (FIG. 2)

Data Vault
USER INSTRUCTIONS
Page 5
ENGLISH
g. Remove the Velcro straps from the TV
protector
h. Slide the TV protector onto the TV
i. Tighten the Velcro straps down
(FIG. 3)
j. Lift the TV/Protector assembly
k. Place TV, mounting plate to mounting
plate holder
l. Assemble the bolt to the back of the
mount (FIG. 4)
m. Connect the HDMI cables, on the left
side of the TV (FIG. 5)
n. Connect the power cable, on the right
side of the TV
HDMI
CONNECTIONS

Page 6
ENGLISH
o. Pull the TV mount out and push to one
side to be able to access the mounting
plate holder
p. Adjust the mounting plate to vertical
position and tighten the two nuts on
each side (FIG. 6).
II. 3 Position Hatch Feature
The keyboard hatch can be positioned in 3
places, working, open and closed.
a. Working Position
With the rod placed fully forward,
the keyboard will be level, while still
providing a at work surface above.
b. Open Position
With the rod placed in notch, the hatch
will be held open allowing you a larger
access to items stored under the hatch.

Data Vault
USER INSTRUCTIONS
Page 7
ENGLISH
c. Closed Position
Lift rod out of the notch and hold rod in
location shown, slide the rod rearward
to allow the hatch to close.
III. Lockable Hatch
Hatch can be locked to protect valuables while momentarily away.
Simply attach any padlock through the locking tab and loop of the rod.
IV. Installing A Printer (printer not included in 118-02)
a. Install lose drawer into pre-installed drawer slides. Refer to drawer
removal instructions on page 10.
b. Plug the power cord and USB
connection into back of printer and
place printer on upper shelf in left
compartment. Route the power cable
through center dividing walls into
compartment on right side. Plug
power into UPS in the surge protector
without battery backup.

Page 8
ENGLISH
V. Installing USB Switch
(not included in 118-02)
Install USB switch in central compartment.
Attach 2 USB-BM cables into switch.
a. Install USB hub, connecting USB hub
computer port/connector into USB
switch.
b. Plug USB-AM cable (from
printer) into USB hub.
c. Other computer USB devices
such as a keyboard and
mouse may be installed at
this time.

Data Vault
USER INSTRUCTIONS
Page 9
ENGLISH
VI. Installing Power Strips
(not included in 118-02)
a. Install both power strips into the
118-01. Place one in the central
compartment and route the cord
through the cable channel to the lower
compartment. Place the second in the
lower compartment.
b. Prior to installing the UPS power
system, it needs to be charged for
several hours.
c. Install UPS device into right lower compartment on shelf.
d. Plug the UPS power system into one of the GFCI slots in the
powerstrip.
e. Plug both power strips into UPS power system power backup and
surge protection slots.
VII. Installing a Computer
a. Tower Computer
Install tower computer on the lowest
shelf in the left lower compartment.
Route power cable through hole in the
middle panel and plug into power strip.
Connect USB and HDMI or VGA cable.
b. Laptop
To use laptop, connect the HDMI and USB cables.
c. Tablet
To use tablet, connect any necessary adapter to HDMI and connect
to tablet.

Page 10
ENGLISH
VIII. Drawer Adjustment:
If you need to move any of the bottom drawers, to t your printer or
computer, follow these instructions:
a. Drawer Removal and Installation
1. To remove a drawer (FIG. 8), pull
the drawer out till it stops. Notice
the locking levers located inside the
track that is attached to the drawer.
Lift lever (A) while pressing down on
the right lever (B). Pull drawer clear
of the sides.
2. To replace a drawer, simply insert
the drawer slide into the cabinet slide
and close the drawer completely.
The mechanism will automatically
latch.
b. Drawer Slide Install
1. Take one slide (FIG. 9) and insert
the clips (inset) into the front and
rear notches of the drawer support
panel. Push the slide to the rear and
down. Secure the slide through the
end access hole in the slide.
2. Remove #6X1/2 screws to adjust
locations of drawers.

Data Vault
USER INSTRUCTIONS
Page 11
ENGLISH
c. Drawer Retention
1. Install 14-20 x 5/8” hex head bolt
on inside of the front, 2 places each
drawer. Fasten with 1/4-20 whiz nut.
2. This will prevent the drawer
from bouncing out when being
transported.
IX. Installing Straps C
Straps have been provided to secure
printer and power supply. Simply route strap through slots and pull
until snug.
CAUTION
Pull out only one drawer at a time to avoid sudden tipping of product
which could cause serious personal injury or property damage. For
optimal weight distribution of unit, install large drawers in lower
positions.
Notice: Any modication or unintended use of this product shall
immediately void all manufacture’s warranties. Manufacturer
disclaims all liability for injuries to persons or property resulting from
any modications to, or unintended use of this product.
DRAWER
SLIDE
1/4-20 WHIZ NUT
1/4-20 x 5/8” BOLT
DRAWER

PN14-0056 ©2016 Werner Co. Rev E 7/16
KnaackLLC
ATTN:Warranty Claims
420 E. Terra Cotta Avenue Crystal Lake, IL 60014
www.knaack.com
If you have any questions, please call toll free at 1-800-456-7856.
©2013 Knaack LLC
