Knox KN-BTAS15 User manual

KN-BTAS15 Speaker
Instruction Manual

Index
General Operation – page 1
Instructions – page 2
Specifications – page 2
Controls and Connections – page 3
General Operation
1. Reduce VOLUM level to lowest setting before turning KN-BTAS15
Speaker on.
2. Connect audio source to the appropriate INPUT jacks.
3. Plug KN-BTAS15 Speaker into wall outlet.
4. Turn on audio source, then power on KN-BTAS15 Speaker.
5. Set VOLUM /BASS/TR BL /GAIN/GRAPHIC QUALIZ R to desired
levels.
6. Pair your mobile device to the speaker via Bluetooth for wireless
audio streaming. If prompted for a password/passkey during the
pairing process, enter "0000".
Caution: To reduce the risk of electric shock, do not remove
unit’s cover or back panel. Unit must be grounded. Do not
attempt to repair or service unit yourself.

Safety Instructions
1. Keep away from open flames.
2. Only connect to grounded AC110V ~ 240V outlets.
3. For indoor use only. Humidity can damage the unit. If used outside, ensure
that the unit is kept free of moisture.
4. Do not place liquids on or near the unit.
5. Always unplug the unit during thunderstorms or when not in use.
6. Always make sure the unit is placed on a flat, stable surface.
7. Unit can be mounted. If mounting, insure that brackets used are approved
to support unit’s weight.
8. Never attempt to service or repair the unit yourself.
Model
KN
-
BTAS15
System
Active 2
-
way full range
Woofer
15”
Magnet
30 oz.
Voice Coil
1” KSV
Tweeter
1” resin film
Power RMS
100 watts
Impedance
4ohm
Frequency Range
100Hz
–
18KHz
Sensitivity
92dB (+/
-
2dB)
Connector
6.35mm/RCA/XLR
Mic Input Level
<5mV
Line Input/Output Level
250mV

1. SD/MMC card input
2. USB input
3. MP3 control
4. XLR MIC 1 input
5. 6.35mm MIC 2 input
6. 5-band Q control
7. RCA stereo (R+L) line input
8. RCA stereo (R+L) line output
9. MIC 2 volume control
10. MIC 1 volume control
11. Output level control
12. MIC cho control
13. Line/MP3 output level control
14. MP3/Line input switch
15. MIC input ON/OFF switch
16. Wireless MIC 1 output level control
17. Wireless MIC 2 output level control
18. DC power input
19. Wireless MIC 1 reception antenna
20. Wireless MIC 2 reception antenna
21. L D light ON/OFF switch
22. AC 115V/230V switch
23. Main POW R switch
24. Fused I C main input
