KODA LM030241 User manual

Please lay out all parts and read the instructions prior to installation.
PACKAGE CONTAINS:
4 x Solar LED Pathway
Bollard Light
4 x Stake
2
43
Solar LED Pathway
Bollard Light (4 PACK)
IMPORTANT INFORMATION.
PLEASE READ CAREFULLY AND RETAIN FOR FUTURE REFERENCE
Model: LM030241
For assistance with assembly, installation, parts or customer service,
please contact us:
[e-mail]
1-866-294-9244, Monday to Friday, 8am to 5pm Pacific Time
2975 Red Hill Ave., Suite 100, Costa Mesa, CA 92626, USA
•Regular and consistent use of the device aids in the longevity of the battery lifespan.
•Remove the battery from the product when not in use for an extended period of time.
•Position the battery in proper polarity when replacing.
•Clean the surface of the fixture with a soft and dry or slightly dampened cloth. Never use
a cleaner with chemicals, solvents, or harsh abrasives to clean the product.
•Please dispose of the used battery properly according to local laws and regulations
regarding the disposal of hazardous waste. Improper disposal of the battery could
cause serious injury from fire or explosion.
•This product is intended for use with AA 1.2V 900mAh Ni-MH battery.
•Place the light in an area that is clean and well-lit for optimal performance.
•Make sure the light is secured into the ground to avoid injuries.
•For outdoor use only.
•Inspect the product before using for any visual damage or deflects. Do not use if the
product has been damaged.
INSTALLATION PROCEDURE:
Please read the following safety information before use.
MAINTENANCE:
CLEANING:
1. Select a flat surface for the Bollard Light,
then secure the Stake into the ground.
2. Once the Stake is firmly in the ground,
attach the Bollard Light onto the Stake.
3. Set the Bollard Light to ON and allow
the battery to charge in direct sunlight for
at least 8 hours before first use.
4. Adjust the orientation of the Solar Panel
by turning the Bollard Light to receive
maximum sunlight.
5. Upon being fully charged, the Bollard
Light will automatically turn on at night.
BATTERY REPLACEMENT INSTRUCTIONS:
When replacing the Battery, be sure to:
•Use a rechargeable battery only.
•Match the replacement battery specifications with the battery that have been
removed.
•IMPORTANT: Dispose of the Lithium ion battery in accordance with local, state
and federal regulations.
•Swallowing the batteries may lead to serious injury or death. Seek immediate
medical attention if batteries are ingested.
•Clean batteries and the battery contacts before inserting if necessary with a
clean, dry cloth.
•Always match the replacement battery specifications with the specifications of
the original batteries.
•Ensure the batteries are installed correctly with regard to polarity (+ and -).
Wrongly inserted batteries may cause battery leakage and cause damage to the
device or other harmful.
•Remove batteries when they are not used for an extended period of time.
•Remove old and used batteries promptly to reduce the risk of battery leakage.
•Keep batteries out of children’s reach.
•Do not charge, dismantle, throw into fire, or short-circuit the batteries.
•If a battery has leaked, avoid contact with skin, eyes, and mucous membranes.
Promptly rinse any affected area with water and seek medical assistance.
•Do not mix old and new batteries.
•Always use the same type of batteries. Do not mix alkaline, standard
(Carbon-Zinc), or rechargeable (Nickel Cadmium) or (Nickel Metal Hydride)
batteries.

PRODUCT SPECIFICATIONS: TROUBLESHOOTING:
Operating Voltage: 1.2V
Wattage: 0.06W
Solar Panel: 2V/200ma
Light Output: 12 lumens
Color Temperature: 3000K
Operating Temperature: -20°C to 55°C / -4°F to 131°F
Battery Run Time: Up to 8 hours on a full charge
Problem Possible Cause Solution
The light is turned o. Press the power button to
turn the light on.
Dirty or obstructed Solar Panel. Clean the Solar Panel.
The light does not
light up.
The light does not
light up at night or
stays on during
daytime.
The Solar Panel is obscured or
interfered by other light
sources, such as street light.
Relocate the light to an open
area where the Solar Panel
can receive direct sunlight.
The battery cannot be recharged. Wipe the battery contact with
dry cloth or replace the battery.
6
87
5
Warranty:
This KODA product carries an 18-month warranty against defects in workmanship and
materials subject to the conditions and additional warranty information available at:
www.kodabuilt.com/warranty
DISCLAIMER OF WARRANTIES, INCLUDING WARRANTY OF MERCHANTABILITY AND
WARRANTY OF FITNESS FOR PARTICULAR PURPOSE: EXCEPT AS SPECIFICALLY SET
FORTH HEREIN, NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, IS MADE
AS TO THE SOLAR ROSE PETAL BOLLARD LIGHT. KODA AND/OR ITS AFFILIATES
EXPRESSLY DISCLAIMS, WITHOUT LIMITATION, ANY STATUTORY WARRANTIES AND ALL
IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE.
MADE IN VIETNAM
Solar LED Pathway
Bollard Light (4 PACK)
Model: LM030241
Responsible Party:
KODA
Address: 2975 Red Hill Ave., Ste. 100, Costa Mesa, CA 92626, USA
Tel: [phone]
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
3.74 IN / 9.50 CM
20.4IN / 51.8CM
15.4IN / 39.2CM
3.74 IN / 9.50 CM
ML-030241_V1
Have a comment or question? Email us at [e-mail]
or visit us online at www.KodaBuilt.com
