Kodak Miniloader 2000 P User manual

Publication No. II 3477-D
11/97
INSTALLATION INSTRUCTIONS
for the
KODAK Miniloader 2000 P Humidifier up to SN 5031
CAT. Number 7197007
and for the
KODAK Miniloader 2000 P Humidifier from SN 5032
CAT. Number 7192636
© KODAK AG STUTTGART, 1997
Kodak

PLEASE NOTE
The information contained herein is based on the experience and knowledge relating to the subject matter
gained by Kodak prior to publication. No patent license is granted by this information. Kodak reserves the
right to change this information without notice, and makes no warranty, express or implied, with respect to
this information. Kodak shall not be liable for any loss or damage, including consequential or special
damages, resulting from the use of this information, even if loss or damage is caused by Kodak’s
negligence or other fault.

TABLE OF CONTENTS
INTRODUCTION........................................................................................................................... 1-2
PACKING LIST............................................................................................................................. 1-3
INSTALLATION............................................................................................................................ 1-4
Part 1 ML2000 P up to SN5031...................................................................................... 1-4
Part 2 ML2000 P from SN 5032 ..................................................................................... 1-5
FINAL TEST.................................................................................................................................. 1-13
II 3477-D HUMIDIFIER ML2000 P INSTALLATION INSTRUCTIONS
KODAK AG, Stuttgart 1-1 11/1997

INTRODUCTION
The KODAK MINILOADER 2000 P HUMIDIFIER allows the relative humidity inside the
ML2000 P to be increased. The HUMIDIFIER should be set to 50%.
left-hand
INNER SIDE PANEL
PCB A16
HUMIDIFIER
COVER
OVERFLOW
TWIN WATER VALVE V1
HUMIDIFIER ASSY.
with FAN
WATER RESERVOIR
HUMIDITY SENSOR
HUMIDIFIER CONNECTOR
PRESSURE
HOSE
DRAIN
HOSE
CLAMP
CABLE DUCT
GROUND
WIRE
figure 1-1
INSTALLATION INSTRUCTIONS HUMIDIFIER ML2000 P II 3477-D
11/1997 1-2 KODAK AG, Stuttgart

PACKING LIST
PART
NUMBER DESCRIPTION QTY
II3477-D INSTALLATION INSTRUCTIONS 1
9318546 HUMIDIFIER COVER 1
9318746 OVERFLOW 1
9318666 BRACKET 1
9288426 HUMIDITY SENSOR 1
9318726 SENSOR CLAMP 1
9215636 CABLE DUCT 1
9198410 PCB A16 1
9183201 STANDOFF 4
9318516 HUMIDIFIER HARNESS 1
9318503 HUMIDIFIER ASSY with FAN 1
9318776 HOSE CLAMP 12.5 1
9318736 CLAMP 3
6081850 WIRE TIE 4
4500142 STAR WASHER 2
9318861 EXTERNAL DRAIN HOSE 1
9219131 HOSE CLAMP 40-25 1
9170182 HOSE CLAMP 16-25 1
9318791 DVGW LABEL 1
4283121 SCREW M4x10 24
4282801 SCREW M4x16 4
4480032 WASHER 4.3 mm 22
4480431 WASHER large (for CABLE DUCT) 2
500601 SELFADHESIVE SEAL 1
EXTERNAL PRESSURE HOSE ASSY consists of: 1
9198296 MANUAL VALVE 1
G9905358 ADAPTER 3/8 to ½ inch 1
G9904056 ADAPTER ¾ to ½ inch 1
G9906393 SEAL 1
9198031 T-ADAPTER 1
G9907057 PRESSURE HOSE with SEALS 1
The following PANELS are only needed up to SN 5031.
They are part of CAT. No. 7197007
9310916 OUTER RIGHT-HAND SIDE PANEL 1
9310536 INNER RIGHT-HAND SIDE PANEL 1
II 3477-D HUMIDIFIER ML2000 P INSTALLATION INSTRUCTIONS
KODAK AG, Stuttgart 1-3 11/1997

INSTALLATION
Part 1 ML2000 P up to SN5031
NOTE
This series of ML2000 P is not prepared by manufacturing for the HUMIDIFIER installation. For this reason
new inner and outer SIDE PANELS for the right-hand side are needed.
1. Switch off the ML2000 P.
2. Take off the inner and outer right-hand SIDE PANELS. Discard both.
3. Place the new inner right-hand Side Panel on a flat surface.
4. Continuewithstep4ofPart2.
outer right-hand
SIDE PANEL
inner right-hand
SIDE PANEL
figure 1-2
INSTALLATION INSTRUCTIONS HUMIDIFIER ML2000 P II 3477-D
11/1997 1-4 KODAK AG, Stuttgart

Part 2 ML2000 P from SN 5032
1. Switch off the ML2000 P.
2. Take off the outer right-hand SIDE PANEL.
3. Take off the inner right-hand SIDE PANEL and place it on a flat surface.
1. Remove the 2
COVER PLATES
2. Remove these
SCREWS and
discard them
figure 1-3
II 3477-D HUMIDIFIER ML2000 P INSTALLATION INSTRUCTIONS
KODAK AG, Stuttgart 1-5 11/1997

4. Remove all SCREWS (marked with a Hex-head on figure 1-3) and discard them.
5. Remove the 2 COVER PLATES (see figure 1-3) and discard them.
6. Fix the ceramic RESISTOR from the HUMIDIFIER HARNESS with the CLAMP to the
HUMIDIFIER.
7. Connect the 2 small FLAT TAB CONNECTORS to the FAN. (white to -, red to +)
WARNING
If the white wire is connected to + and the red wire to -, the FAN does not run. Q3 on PCB A16 will be-
come hot and will eventually burn out.
CLAMP
RESISTOR
(ceramic)
figure 1-4
-+
figure 1-5
INSTALLATION INSTRUCTIONS HUMIDIFIER ML2000 P II 3477-D
11/1997 1-6 KODAK AG, Stuttgart

8. Place the HUMIDIFIER PARTS from the KIT on the new inner right-hand PANEL.
Mount them as shown. Mount the CABLE DUCT first. The other parts can be
mounted in any sequence. For mounting the GROUND WIRE and PCB A16 see
step 9 and 10.
NOTE
All threads needed for mounting the HUMIDIFIER parts to the right-hand INNER SIDE PANEL are pre-
pared with SCREWS (removed in step 4). The purpose of these SCREWS is to make the SIDE PANEL light-
tight as long as no HUMIDIFIER is installed.
PCB A16
HUMIDIFIER
ASSEMBLY
CABLE DUCT
GROUND
WIRE
DRAIN
HOSE
PRESSURE
HOSE
TWIN WATER
VALVE
CONNECTOR
A4X31
CLAMP
CLAMP
CLAMP
CLAMP
HUMIDITY
SENSOR
100 mm
HOSE CLAMP
12.5
figure 1-6
II 3477-D HUMIDIFIER ML2000 P INSTALLATION INSTRUCTIONS
KODAK AG, Stuttgart 1-7 11/1997

9. MounttheGROUNDWIRE.UseaSCREWM4x8andaSTARWASHER.
10. MountPCBA16.Use4SCREWSM4x16and4STANDOFFS.
GROUNDWIRE
STAR WASHER
SCREW
STAR WASHER
figure 1-7
PCB A16
A4X31
ML2000P HARNESS
Connect the HUMIDITY
SENSOR to the small
CONNECTOR
figure 1-8
INSTALLATION INSTRUCTIONS HUMIDIFIER ML2000 P II 3477-D
11/1997 1-8 KODAK AG, Stuttgart

11. Connect the HUMIDITY SENSOR to the small CONNECTOR on PCB A16. See
figure 1-8.
12. Connect the brown PLUG from the WATER LEVEL SWITCH to the brown PLUG of
the HUMIDIFIER HARNESS.
13. Connect the 2 large FLAT TAB CONNECTORS from the HUMIDIFIER HARNESS to
the outer TWIN WATER VALVE.
NOTE
Only 1 side of the TWIN WATER VALVE is used. The other one must be closed properly. To store less spare
parts, the TWIN WATER VALVE from the XML300 is used in the ML2000P too.
This side of the TWIN WATER VALVE
must be closed.
Connect the 2 large
FLAT TAB CONNECTORS
to the outer TWIN WATER VALVE
figure 1-9
II 3477-D HUMIDIFIER ML2000 P INSTALLATION INSTRUCTIONS
KODAK AG, Stuttgart 1-9 11/1997

14. Mount the right-hand INNER SIDE PANEL to the ML2000P.
15. Locate CONNECTOR A4x31 in the ML2000 P Harness. Plug in A4X31 from the
HUMIDIFIER. See figure 1-8.
16. Route the HUMIDIFIER HARNESS through the CABLE DUCT and close the DUCT.
17. Mount the parts shown in DETAIL A figure 1-10 to the fresh WATER INPUT of the
HUMIDIFIER
18. Mount the parts shown in DETAIL B figure 1-10 to the fresh WATER INPUT of the
PROCESSOR. If there is a PLASTIC ADAPTER at the PROCESSOR WATER IN, take it
out and discard it.
To avoid leakage, carefully seal the threads of the ADAPTER (3/8 to 1/ in.),
T-ADAPTER and MANUAL VALVE with PIPE THREAD TAPE TL2190 (PN 952960)
19. Connect the other end of the T-ADAPTER to the WATER SUPPLY.
NOTE
The PRESSURE HOSE for the WATER SUPPLY is not supplied with the HUMIDIFIER KIT.
INSTALLATION INSTRUCTIONS HUMIDIFIER ML2000 P II 3477-D
11/1997 1-10 KODAK AG, Stuttgart

1/2 in.
3/4 in.
ADAPTER
PRESSURE
HOSE to
MANUAL VALVE
MANUAL
VALVE
T-ADAPTER
3/8 in.
1/2 in.
PRESSURE
HOSE to
HUMIDIFIER
from WATE
R
SUPPLY
PROCESSOR
WATER IN
DETAIL A
DETAIL B
ADAPTER
SEAL
SEAL
SEAL
**
**
**
**
To avoid leakes,
use PIPE THREAD
TAPE TL2190
(PN 952960).
**
figure 1-10
II 3477-D HUMIDIFIER ML2000 P INSTALLATION INSTRUCTIONS
KODAK AG, Stuttgart 1-11 11/1997

20. Connect the EXTERNAL DRAIN HOSE to the HUMIDIFIER DRAIN. Use a HOSE
CLAMP 40-25
21. Mount the OVERFLOW and the BRACKET to the lower right-hand corner of the
HUMIDIFIER COVER. Use 2 SCREWS M4x10 with WASHERS.
22. Fix the self adhesive SEAL to the BASE of the ML2000 P.
HUMIDIFIER COVER
OVERFLOW
BRACKET
SCREW M4x10
with WASHER
SCREW M4x10
with WASHER
figure 1-11
selfadhesive
SEAL
figure 1-12
INSTALLATION INSTRUCTIONS HUMIDIFIER ML2000 P II 3477-D
11/1997 1-12 KODAK AG, Stuttgart

FINAL TEST
1. Ensure that the second output of the TWIN WATER VALVE is closed.
NOTE
Only 1 side of the TWIN WATER VALVE is used. The other one must be closed properly.
2. With WATER ON, check that all HOSE CLAMPS and all ADAPTERS are tight.
3. Switch on the ML2000 P.
4. Connect the DVM to TEST POINTS TP5 (Plus) and to TP2 (Gnd) of the SENSOR
PCB A16. See the drawing on the next page.
5. Adjust R5 until the voltage reading is 5 VDC. This is equal to a relative humidity
of 50 % RH.
6. If the relative humidity is below 50% the HUMIDIFIER FAN will start. and the WATER
RESERVOIR is filled.
This side of the TWIN WATER VALVE
must be closed.
figure 1-13
II 3477-D HUMIDIFIER ML2000 P INSTALLATION INSTRUCTIONS
KODAK AG, Stuttgart 1-13 11/1997

R1
10k
R2
1.13k
R3
10.2k
R4
27k
R6
10k
TP5
TP4
R7
1M
R8
5.6k
R9
5.6k
R10
1k
R12
1k
R11
560k
VDR
TP1
TP7
TP2
TP8
TP3 TP6
R5
10k
C8
100nF
C1
10nF
78L05
U3
W1
U1
TESTPOINTS
C5
680pF
C3
100nF
C2
330nF
Q1
Q2
Q3
BC547
BC547
BC637
C6
10nF
78L12
C7
330nF
U2
EG
1
4
2
3
GND PE
HUMIDIFIER
FAN
+24V
1
2
3
not used
U2
SSR DP 2110
16
1
10
8
- +
9
10 8
U1
11
47
5 6-
+
U1
812437 56
5.0V
SENSOR+
SENSOR GND
1
2
3
SENSOR
A16X1
A16X3
C4
100nF
2
1
27R
56R
Twin Water
Valve V1
Level Sensor
PCB A16
A16X2 A16P2A16P1
figure 1-14
INSTALLATION INSTRUCTIONS HUMIDIFIER ML2000 P II 3477-D
11/1997 1-14 KODAK AG, Stuttgart

7. If the relative humidity is above 50% the HUMIDIFIER FAN will not start. For test
purposes set the voltage to a higher value until the FAN starts.
8. Mount the HUMIDIFIER COVER.
9. Test the OVER FLOW of the HUMIDIFIER.
NOTE
It is a legal requirement that this test is done.
To test it, close the HUMIDIFIER DRAIN HOSE and hold down the WATER LEVEL
SENSOR. The WATER RESERVOIR will fill up and will eventually overflow.
HUMIDIFIER
COVER
figure 1-15
WATER LEVEL
SENSOR
HUMIDIFIER
OVERFLOW
figure 1-16
II 3477-D HUMIDIFIER ML2000 P INSTALLATION INSTRUCTIONS
KODAK AG, Stuttgart 1-15 11/1997

10. Release the WATER LEVEL SENSOR and open the DRAIN HOSE.
11. If you had to change the voltage in step 5, set it back to 5VDC.
12. Mount the outer right-hand SIDE PANEL.
13. Inform the customer that to minimise biological growth, the HUMIDIFIER FILTER
CARTRIDGEmustbereplacedduringPMsoraminimumoftwiceayear
NOTE
The replacement of the HUMIDIFIER FILTER CARTRIDGE must only be done by SERVICE PERSONAL
authorised by KODAK.
14. Open the HUMIDIFIER ACCESS PANEL.
15. Insert slowly the HUMIDIFIER FILTER CARTRIDGE to prevent spilling water inside
the ML2000 P and to prevent water from flowing over electrical components.
16. Mount the HUMIDIFIER ACCESS PANEL.
WARNING
With the HUMIDIFIER ACCESS PANEL off, the ML2000 P is not light-tight.
HUMIDIFIER
ACCESS PANEL
HUMIDIFIER
FILTER CARTRIDGE
figure 1-17
INSTALLATION INSTRUCTIONS HUMIDIFIER ML2000 P II 3477-D
11/1997 1-16 KODAK AG, Stuttgart

NOTE
For installations in Germany do step 17.
17. PlacetheDVGWLABELclosetotheDATAPLATEoftheML2000P.
II 3477-D HUMIDIFIER ML2000 P INSTALLATION INSTRUCTIONS
KODAK AG, Stuttgart 1-17 11/1997

Kodak AG
Hedelfinger Str. 54-60
70327 Stuttgart
Germany
