KODAK EKTASOUND Projector Case
To close the case,
be^ sure that -
1.
Power cord is removed from Projector
and stored in storage compartment.
2.
Takeup reel is removed From Projector
and placed on reel retainer in case to
prevent scratching the dust cover.
3.
The holding tabs for the lamp and
the microphone are extended across
the openings.
4.
The elevation wheel on the projector
is fully retracted.
5.
Small objects aren't placed in the
opening for the microphone cord be
-
cause they might slip down into the
case and
be difficult to retrieve
easily.
J~ ..j([(:;<::?= :[{(:;:;. . x., .: MOVIE
- -
0. *. . :. .. -...
A .:.::<::$[::. .
.:+.::: .. '. .:::'::
.:::;[:[:[($.:: a.
.:==':. . :;[([:.--: "
\
CORD MICROPHONE LAMP
1 NOTE: Equipment shown not supplied with case. STORAGE
KODAK and EXTASOUND are trademarks.

I KODAK
welcome to the world of super 8 sound movies! As a
companiou to the KODAK EKTASOUNDMovie Cameras,.
your projector brings new enjoyment to home movies.
1
1
Relivetheexcitementof abirthday party,concert,grad-
uation,or other event just
as it occurred - the projector
playsback
~nllnt-1 " in sync " with thescreen image.
EKTASOUND -2351 ha rn
movie projector t
Equipment subjectta minor appearance changes.
'34 .
the shelf. Or with
g the projectorcontrols
the rear of the pro
your projector
reading the KODAKPhoto Book listed derAuxiliary,
Equipment.
'L ' .

If you need help or advice on using your projector,
please write to our staff of photographic experts' at
Eastman Kodak Company, Photo Information, Depart -
ment 841, Rochester, New York 14650. (Should your
projector ever require service, the warranty and in
-
structions for obtaining service are printed at the back
of thismanual.)

1
Placetheprojectionscreen in the best locationfor your
9
Remove the DUST C O V E R by graspingitat thelower cor-
audience and for the size and shape of the room. Posi -
ners and p&ng it away from the projector.
tion the projector on a table or other firm support
I
(such asa bookshelf or mantle) at a distance from the
screen that allows you to project
an image to fill the
screen.
If convenient, use a support that is about as
high as the center of thescreen.
(By movingthe P R O J E C T I O N -OR 90°, YOU can pro -
P RO J E C T IO N M I R RO R
ject in the opposite direction.)
!
To Fill 40 - inch Wide Projection Screen
Approximate
Lens Projector
- to - ScreenDistance
22mm f 11.5 14 feet
15-30mm f 11.3 Zoom 9.5 to 18.5 feet
NOTE: If you have a zoom lens, slowly turn the front
silver portionof thelens
until theimage fills thescreen.
PROJECTION MIRROR I
- DUST
COVER

7"--7 --
Set the PRO J E C TI O N C O N T R O L at OFF'/'EEXCAD and the Remove the
POWER CORD from its storage area in the
V O L U M E C O N T R O L fully counterclockwise. back of the projector. Insert one end into the
P O W E R
R E C E P T A C L E on the back of the projector and the other
end into a120
- volt,60 Hz power outlet only. If you plug
your projector into a different electrical source, you
may damage theprojector.
:
SPEAKER/HEADPHONE
I
PROJECT~N C O N T RO L
VOLUME CONTROL
ELEVATION
'1 WHEEL
POWER
RECEPTACLE

threading
The T A K E - U P R E E L has been placed on the projector at
the factory.Be sure this reel is seated securely on the
TAKE - UP SPINDLE.
NOTE: The R E E L B R A K E prevents film from " spilling " by
pressing against the flat edge of the supplied take - up
reel. Since other take
- up reels may not operate as
well, be sure to use only the KQDAK 400 Movie Reel
supplied.
(400
- foot maximum) of film, perforated '
.
you, onto the S~PLY S P IN D L E
TAKE - UP REEL TAKE-UPSPINDLE SUPPLY SPINDLE

Draw off approximately 2 feet of LE~ER. With$he right
hand, grasp the leader near the supply reel. Sweep the
a film intoand through the T H R E A D I N G C H A N N E L , asshown.
THREADING CHANNEL LEADER
THREADING CHANNEL
3
Insert the end of the leader securely into the s-shapea
SLOT in the take - upreel. Rotatethe take - upreel clock -
h
wise to removeany slack.
SLOT

#
>
Your projectorcan projectsound and silent filmsat18or 24 fps (frames - per - second).
Films made with
KODAK EKTASOUND Movie Cameras are18 fps. Commercial sound films are
usually
24 fps. The projector's dust cover can be installed and the projector operated with the
. .
* cover in position. Replace the dust cover by guiding its top edge under the top edge of the
.
projector and pushinginatthebottom.
I
I
forward projection
Move the projection control from OFF/THREAD to
2
Adjust the V O L U M E C O N T R O L to the desired listening
PROJECT. Rotate the
FOCUS W HE E L uxitil the screen level. (Forsilent movies turn the volume control fully
image is sharp. counterclockwise.)
Use the
F R A M E W HE E L to center one complete picture
onthescreen. Turnthe
E L E V A T I O N WH E E L , located atthe
FOCUS WHEEL
rear of theprojector, to raise or lower theimage on the
screen. While the projector
is running, movethe FILM-
S P E E D C O N T R O L to the required speed (18 or 24 fps).
(Moving the lever to the left changes the speed
to 24
fps; to the right changes thespeed to18 fps.)
VOLUME CONTROL
FRAM
EEL FILM - SPEED CONTROL

ill projd~i
luring proj~_--~nyou wish to show a singleframe of film,
we theprojectioncontrol to STILL. (A specialheat shield
moves into the light path between the projection lamp and
the film
to protect your film from heat whiie you show a
single frame. The screen image will be slightly darker than
normal.)
After you make
all adjustments (filmspeed,volume,focus,
frame), move the projection control to
REWIND to return
the film to the supply reel, stopping before the leader comes
off the take
- up reel.
I
STILL
during b- -,ecti---, -- want to get to a certain scene quick-
, move the projection control to FAST FORWARD.
To go back quickly to a certain scene,s
jection control to REWIND.
FAST FORWARD
ly move the pro -
REWIND

Attach the end of the
When all the
film has
film to the supply reel
reached the take
- up by guiding it over the
3 4
After the film is com -
reel, move the projec-
LENS C O V E R . Rotate the pletely rewound, move
1 tion control to OFF/ supply reel a few turns Slide theprojectioncon - the control to OFF'/
THREAD or STILL. counterclockwise. trol to REWIND. THREAD.
LENS COVER
after the show
When you have shown and rewound all the reels of film,
move the projection control to OFFITHREAD, unplug
bothendsof the power cord,and put it in thestoragearea.
Replace the dust cover by guidingits top edge under the
top edge of the projector and pushing in atthe bottom.
\
REWIND
&
NOTE: You can also re -
wind the film onto the
supply reel through the
threading channel. To
A
eliminate rethreading
film to the supply reel,
attach a section of the
leader to the film end.
Movetheprojectioncon
-
trol toREWIND just be -
foreyou reach theendof
the film on the supply
reel.
8
-L
A
6

operating tips
The perforations in the film should be toward you as the
film comesoff the supply reel clockwise.If they are not, the
fXm has not been rewound or was twisted while being re -
wound.
If thepictureisunsteady, itcan
be duetotornperforations
in the
film.
If you are not getting any sound while projecting a
magnetic
- stripedsound film, check to make sure:
Film is wound correctly on supply reel.
Volume control is set at a listening level.
If the sound is distorted,check to make sure:
Speed control is set at the proper
film speed (18 or 24
ames per second).
Volume is not too
high.
The P L A Y B A C K H E A D is self - cleaning (see illustration under
" Cleaning Projection Lens, " page10).The movement of film
acrossthe head is sacienttokeep itclean.
1
Also, your projector mechanism has bearings that require
no oiling.
replacing lamp
Your projector is equipped with an 80 - watt, 30 - volt, code
DFE projectionlamp witha rated life of 15 hours. It's a good
idea to keep a spare projectionlamp on hand. You can pur
-
chase lamps from your photo dealer.
If the lamp should burn out during projection, accelerate
lampcooling by running the projector in the.STILLposition.
After cooling,turn offthe projector and proceed asfollows:
1. Disconnect the power plug from the wall outlet.
2. Grasp the top edge of the LAMP WOR, located at the rear
of the projector, and pull it away from the projector.
3. Pull the LAPKP-RELEASE L E V E R toward you. (This releases
the
P R O JE C T I O N L A M P from the socket.) Lift out the lamp.
4. Installa newlamp (80 - watt,30 - volt, code DFE) by hold -
ing it so that the shiny side of the reflector in the lamp is
toward the lens (away from you). Place the center post of
the lamp
in the center hole of the socket. Rotate the lamp
slightly
until the key on the lamp center post drops in the
socket slot.
5. Press the lamp down all the way.
LAMPRELEASE
LAMP POOR (see page 3) PROJECTION LAMP LEVER

6. Replace the lamp door by first resting its bottom edge on
the
L A M P - A CC E SS O P E N I N G ; then push the top of the door to -
ward theprojector until it snaps in place.
cleaningoutside of projector
You can maintain the heappearance of your projector by
proper care.
Clean the wooden parts of your projector with a good
-
quality furniture polish. Wipe the black areas and the dust
cover with a soft, damp, lintless cloth.
cleaningprojectionmirror
For the brightest, clearest pictures keep the P R O J E C T I O N
M I R R O R free of dust, dirt, and fingerprints. Clean the mirror
with a soft, lintless cloth or
KODAK Lens Cleaning Paper. If
PROJECTION MIRROR
you need moisture, breathe on the mirror surface or use a
drop of
KODAK Lens Cleaner on the paper or cloth.
cleaningprojection lens
To project a bright, clear picture, keep the P R O J E C T I O N L E N S
free of dust, dirt, and fingerprints.
If you need to clean the lens, proceed as follows:
1. Remove the take - up reel.
2. Move the mirror to the position shown.
3. Slide the LENS C O V E R toward the T A K E - U P S P I N D L E and
remove the cover.
4. Carefully lift out the P R O J E C T I O N LENS . Blow any dust and
dirt from the lens surfaces.
With
KODAK Lens Cleaning Paper or a soft, lintless cloth,
gently wipe the front and rear surfaces or use a drop of
KODAK Lens Cleaner on the paper or cloth.
5. Replace the lens by setting it in its housing, moving the
lens all the way to the right; make sure the smaller end of
the lens barrel is facing the supply reel.
6. Grasp the lens cover and place it so that the S P R I N G C L I P S
on the back of the lens cover line up with the G U I D E S on the
lenshousing.Then press thelens cover against thelenshous
-
ing and at the same time slide the cover toward the supply
spindle. You will hear a
" click, " indicating that the lens
cover is in place.
NOTE: Thezoom lens is removed thesame way. To install the
lens,set it in the lens housing as shown,with its front flange
against the housing. Refer to the two illustrations showing
thezoom lens.

LENS COVER
LENS COVER
TAKE
- UP (moved toward
S P I N D L E take - UD soindle)
f/1.5 22mm
SERIAL NUMBER PROJECTION LENS
1
PROJECTION MIRROR PLAYBACK HEAD
-
&l&" , ?* 4
cleaningpressurepad
f/1.3 15-30mm
f/1.3 15-3omm andaperture
SPRING ZOOM PROJECTION LENS ZOOM PROJECTION LENS
The P R E SS U R E P A D and A P E R T U R E
are not removable. To clean
them, first move projection
control to OFF/THREAD,
then remove the lens cover
and the projection lens as de
-
scribed under " Cleaning Pro-
jection Lens, " page 10. Then
remove any foreign particles
from the pressure pad and
i
L E N S C O V E R
aperture by blowing lightly in
the area, or by dusting the
area with a small, soft brush.

specifications auxiliary equipment
Dimensions - 10x 21% x 6%inches You can extend your movie enjoyment withtheprojectionaids
described below. See your photo dealer for these and others.
Reel Size
- accepts50 - through 400 - footsuper 8 reels
Weight
- 14 Ibs
PowerService Required
- 120volts, 60 Hz
K O D A K EKTASOUND
ProjectorCase
K O D A K P RESSTAPE
UniversalSplicer
Brown molded - plastic carry Easy - to - use drysplicer for super
case. Will accommodate projec
- 8, 8mm, and 16mm films. Uses
Projection Lamp-ANSI Code DFE 80-watt, 30-volt with in-
tor, spare lamp, and two indi -
pressure - sensitive tape to make
vidually retained reels. film splices.
tegral reflector, 15 - hour rating
K O D A K PRESSTAPES
L~~S~S-KODAKProjection Lens, 22mm f11.5 or Vario- Ko~~~AuxiliarySpeaker
Thin, durable, pressure - sensitive
Kiptagon Zoom Lens,15 to 30mm f11.3
Matching wood speaker cabinet tapes for easy dry splices.
(10 x 6 x 3% inches) with 8 - ohm
Projection Speeds - 18 or 24 frames per second plus still pro -
speaker.
KODAK Photo Book
jection for either sound or silent film
Sound
- Picture Separation - 18 frames (ANSI Standard
PH22.164)
Auxiliary SpeakerIHeadphone Jack
- Switches sound from
built
- in speaker to an 8 - to 16 - ohm auxiliary speaker or
headphones having a %-inch phone plug
Amplifier
- Transistorized 2 - watt poweroutput
Serial Number
- The serial number for your projector is lo -
cated just above the lens housing. You can see it by remov -
ing the lenscover (see " Cleaning Projection Lens, " page10).
Make a record of this number and keep it in a safe place.
The serial number and exact name of your projector should
be included in any correspondence about the projector.
K O D A K 400 Movie Reel
(super 8,8mm)
Makes possible long, uninter -
rupted showings. The reel fea -
tures an " easy - load " slot. A stor -
age box protects your film from
dust, and the box can be marked
for ready identification and
stored neatly.
K O D A K Projection Screen
(40 x40 inches)
A high - quality beaded screen for
home movie showings. It's easy
to set up and easy to store.
To help you make movies you
and your friends will enjoy see
-
ing over and over again, Kodak
publishes many fascinating idea
books, such as the one described
here. See your photo dealer for
other Kodak publications.
How to Make Good
Sound Movies,
AD - 2
The book has 100 pages, with
more than 165 color pictures to
illustrate such topics as: Equip
-
ment, Films, Sound - Recording
Techniquesfor Movies, and Edit
-
ing and Splicing Your Sound
Movies.

uo lu!p~oDaae seq leql wry padpp
-a!lau%eurelu!paFoad aae no6 aans ayeEy
-
'PUnOfiW 7OU ur[!d
I 'UMOPapjsdn uaaaasuo saanlau
I
-yae.qpunos ON 1
wogsanb xnod 0% JaMSUE arfl St?y d~qt?qold
1~01q vqaaqyaay;, 'uaddeq ppoqs s!q $1 'xnaaosaqamosswa~qoxdBqexado pus 'asno$ds~a s! ~o$oa[oxdxnod qnorfl~
s~u!y ~n~dly

I
specifications
Dimensions-10 x 21% x 6% inches You canextend your movieenjoyment with theprojectionaids
described below.
See your photo dealer for these and others.
Reel Size
- accepts50 - through 400 - footsuper 8reels
Weight
- 14 lbs
K O D A K EKTASOUND KODAK PRESSTAPE
Projector Case
UniversalSplicer
PowerService Required
- 120volts, 60 Hz
L
Projection Lamp - ANSI Code DFE 80 - watt, 30 - volt with in -
vidually retained reels.
film splices.
tegral reflector,15 - hour rating
KODAK P RESSTAPES
Lenses-KODAKProjection Lens, 22mm f11.5 or Vario- Koo~~AuxiliarySpeaker
Thin, durable,pressure - sensitive
Kiptagon Zoom Lens,15 to 30mm f 11.3
Matching wood speaker cabinet
tapes for easy dry splices.
(10 x 6 x 3% inches) with 8 - ohm
Projection Speeds - 18 or 24 frames per second plus still pro -
speaker.
KODAK Photo Book "
jection for either sound or silent film
To help you make movies you
KODAK 400 Movie Reel
and your friends will enjoy see-
Sound-Picture Separation - 18 frames (ANSI Standard (super
PH22.164)
I
headphones having a % - inchphone plug
Sound Movies, AD - 2 &- - -
The book has 100 pages, with
RoDlr~Projection Screen
Amplifier-'I'ransistorized 2 - watt power output
(40 x 40 inches)

service facilities
Kodrkhrtghm.rknthrslanmdrtknHMlhrpmdud~
aU ttp(ll1I*tfUCfkns h thkwmWCIpt thbastnrwhmd
t@PlJWWltda~to:yb~lrq~~I~lfywshwtdmOLdtcbl(p
WS@W~,~CIWI,~*R~~~#~TC~)~. -
W.wMI~irpwPPOJK;tDfatmdk~~nomyw
twawm4utpm/rdknErmpwld
drw ~u#d by brn w CJnum- byond Kadrk'r
'
mtd, Thls wsmrdyapgdfblOlZly tD Zlw pftW%rh and' Kodrk
can- b nrpondh tbr other bmmf dimw at ry ldnd
.
nrum@ faom aqulpmm trihm.
Exmptornrcnt~rbwn,m,othe~nramnly.~or
hnplkd, lpplkr to thh proirsbot.
FW mtttw~~m~~g ~p, mttcr b~ Eutmtn ~#dlk ~kpny,
-
PhoM InformWn, Dlpt. 841, Roo)nstrr, MCw York LMW.
~ar .rrvfcr on pur pmMr during or rPkj ~wr warnutty
p.rrkd,aantKtywrdsrkrinKodrkpmductswcmsofthe
lkdrk~o~urnar~lr~t*nfor lid#ama;eirmdpwpmja3
wbauolth.~adrk~i~*-~**r.thtdhrr
hnakmdwdWbthth~pmont@~drtrlls8ndddh
afpurcSIIIlwlllhslpurgetitbrck20yw~-
