USER GUIDE
KOGAN 70” SMART HDR 4K UHD LED TV
SERIES 9 RU9310 (KALED70RU9310SUA)

2
Safety and warnings ............................02
Components..........................................04
Product overview...................................05
Inputs.................................................05
Assembly and installation...................06
Stand assembly ..............................06
Connect to antenna.......................06
Turning on.........................................06
Remote control..............................07 - 08
Power button..........................................08
First time setup......................................09
Basic operation ...................................... 10
Home Screen.....................................10
Channel..............................................10
Antenna..............................................10
Input Source...................................... 10
Network.............................................. 10
Navigating menus ........................... 10
Settings ..................................................... 11
Apps......................................................11
About....................................................11
Date & Time........................................11
11
Time......................................................
Language...........................................12
Keyboard............................................ 12
Inputs.................................................. 12
Power.................................................. 12
Picture................................................. 12
Sound.................................................. 13
Storage............................................... 13
Home screen..................................... 13
Retail Mode....................................... 13
Google Assistant.............................. 13
Chromecast Built-in........................ 13
Screen Saver..................................... 14
Location............................................. 14
Usege & Diagnostics....................... 14
Accessibility....................................... 14
Reset................................................... 14
Remote & Accessories.................... 14
PVR mode ............................................... 15
Media playback...................................... 16
Apps...........................................................17
Wall-mount installation........................18
Specifications.......................................... 19
Troubleshooting.....................................20
CONTENTS
Thank you for buying this Kogan product. Please read all safety instructions before using your TV.
• To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
• The apparatus shall not be exposed to dripping or splashing, and no objects filled with liquids,
(for example, vases), shall be placed on the apparatus.
• When discarding used batteries, always be mindful of the environment. Ensure you follow any
guidelines for recycling and safe disposal of batteries that apply in your local area. Don’t throw
used batteries in rubbish bin.
• When installing your TV, maintain a distance of at least 10 cm between the TV and other
objects (walls, cabinet sides, etc.) to ensure proper ventilation. Failing to maintain proper
ventilation may result in a fire or a problem with the product caused by an increase in its
internal temperature.
• The openings/slots on the back of the apparatus have been provided for necessary ventilation.
Ventilation should not be impeded by blocking these openings in any way (for example,
newspapers, table-cloths, curtains, etc.)
• No naked flame sources, such as lit candles, should be placed on the apparatus. To prevent
the spread of fire, keep candles or other open flames away from this product at all times.
• The device may malfunction when under electrostatic discharge. It can be manually resumed
• To avoid any injury caused by overturn of the product when installed with base stands, please
always ensure the whole product is placed horizontally within the supporting surface and that
the television is not overhanging the edge of the supporting furniture.
• If not using with base stands, use only a wall or ceiling mount which has been recommended
by the manufacturer of the television.
THIS USER GUIDE COVERS THE FOLLOWING MODELS
Kogan 70” SMART HDR 4K LED TV (Series 9 RU9310)
SAFETY AND WARNINGS
WARNING
Never place a television set in an unstable location. A television set may fall, causing serious
personal injury or death. Many injuries, particularly to children, can be avoided by taking
simple precautions such as:
• Using cabinets or stands recommended by the manufacturer of the television set.
• Only using furniture that can safely support the television set.
• Ensuring the television set is not overhanging the edge of the supporting furniture.
• Not placing the television set on tall furniture (for example, cupboards or bookcases) without
anchoring both the furniture and the television set to a suitable support.
• Not placing the television set on cloth or other materials that may be located between the
television set and supporting furniture.
• Educating children about the dangers of climbing on furniture to reach the television set or
its controls.
If your existing television set is being retained and relocated, the same considerations as
above should be applied.

3
• Keep small accessories out of reach of children so they are not mistakenly swallowed.
CAUTION: Connecting the power cord
Most appliances recommend they be placed upon a dedicated circuit; that is, a single outlet
circuit which powers only that appliance and has no additional outlets or branch circuits.
Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension
cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these
conditions could result in electric shock or fire. Periodically examine the cord of your appliance,
and if appearance indicates damage or deterioration, immediately discontinue use of the
appliance until the cord is replaced with an exact replacement part by an authorized servicer.
Protect the power cord from physical or mechanical abuse, such as being twisted, kinked,
pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the
point where the cord exits the appliance.
The MAINS plug is used as the disconnect device, and the disconnect device shall remain
readily operable.
Operating Temperature: 5°C to 35°C
Operating Humidity: ≤80%
Storage Temperature: -15°C to 45°C
Storage Humidity: ≤90%
CAUTION
Do not attempt to modify this product in any way without written authorization from supplier.
Unauthorized modification could void the user’s authority to operate this product.
It is not recommended to keep a certain still image displayed on the screen for a long time as
well as displaying extremely bright images on screen.
from actual product appearance. Product design and specifications may be changed without
notice.
SAFETY AND WARNINGScont’d
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE
COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO
QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated “dangerous voltage”
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the appliance.
Class II product: This symbol indicates that a safety connection to electrical
earth (ground) is not required. If this symbol is not present on a product with a
mains lead, the product MUST have a reliable connection to protective earth
(ground).
~AC voltage: Rated voltage marked with this symbol is AC voltage.
⎓DC voltage: Rated voltage marked with this symbol is DC voltage.
Caution. Consult instructions for use: This symbol instructs the user to consult
the user manual for further safety related information.
Refer to the table below as a guide to the symbols and warnings which may be on your TV.

4
COMPONENTS
NOT INCLUDED
Phillips head screwdriver, antenna
cable, broadband internet connection.
A
70
N6y29nn!tdsfx!)y7*

5
TV back panel
3 Inputs/Ports
4 Power button
TV front panel
1 Kogan UHD LED display screen
2 Remote sensor / Standby light
PRODUCT OVERVIEW Inputs
Composite video input.Video and YPbPr
share one audio channel
Component
video input
Composite
video input
Component video input.
Three cables (“Y,” “Pb” and “Pr”) provide a
higher quality connection than the single-
wire composite cable (“Y”) commonly
HDMI
Connect an HDMI cable between the
HDMI port on the TV and the HDMI port
on the DVD player/Set-Top Box.
Ports marked ‘ARC’ also support Audio
Return Channel.
USB 2.0
MICRO SD
US
MICRO SD card storage devices can be
inserted to record and pause live TV in PVR
mode, or to watch media files stored on
device in media mode.
B storage devices can be inserted to
record and pause live TV in PVR mode, or
to watch media files stored on device in
media mode.
ANT
For free-to-air TV, use an antenna cable
(not supplied) to connect to a working
antenna, either via an antenna wall
socket, or directly.
LAN
For a wired internet connection via a
broadband modem or router, connect an
Ethernet cable to the LAN port.
Digital
audio out
(optical)
Audio out for digital audio devices. Port
and cable may look di erent depending
on an optical or coaxial input. Please use
the cable appropriate for your device.
3.5mm
audio out
Line audio out port for use with
headphones, amplifier, soundbar or any
other audio device via an AUX cable (not
supplied).
2
1
43

6
BEFORE YOU GET STARTED
Spread cushioning flat to lay the TV on. This will help to prevent damage.
1. Stand assembly
a. Attach first stand to base of TV, ensuring R and L stands are on correct
side. You can install either one first.
b. Insert three 18mm screws and use Phillips head screwdriver
(not supplied) to tighten.
c. Repeat these steps for second stand.
ASSEMBLY AND INSTALLATION
2. Connect to antenna
a. Connect an antenna cable (not supplied) via the ‘ANT’ input port at the
back of the TV.
b. Ensure the antenna cable is also connected to a working antenna, either
via an antenna wall socket in your home, or directly.
3. Turning TV on
a. Plug the power cord into a suitable power outlet. The standby will display
a light, showing that the TV is receiving power.
b. Press the POWER ( ) button (either on your remote control or the lower
side of the back panel on the TV – see page 8) to turn the TV on. The
TURNING TV OFF
Press the POWER ( ) button on the remote control to enter standby mode.
To power down the TV completely, unplug the power cord from the power
outlet.
Do not leave your set in standby mode for long periods of time. If you will not
use the TV for a long time, it is recommended to unplug the set from both the
power outlet and aerial.
Standby mode
Red light on
3a
TV on
3b

7
REMOTE CONTROL OVERVIEW

8
1. Remote control assembly
a. Open the battery compartment cover on the back side.
b. Insert two 1.5V AAA size batteries, making sure to match the polarity
markings (+ / -) of the batteries with the diagram inside
the compartment.
c. Replace battery compartment cover.
1a 1b 1c
USING REMOTE CONTROL / POWER BUTTON
WARNING
BUTTON
3. BUTTON
S
• If you do not intend to use the remote controller for a long period of time,
remove them to avoid damage due to leakage.
• Do not use old and new batteries together.
• The batteries (battery pack or batteries installed) shall not exposed to
excessive heat such as sunshine, fire or the like.
TIPS
Do not block the path between the sensor
and the remote control.
2. Using remote control
Point the remote towards the sensor at the front of
Ensure the distance between the remote control
and the TV is no greater than 8 metres, at an angle
of no more that 30 degrees on either side (2a).
2a
3a
C
VOL
H+/ -
+/-
MENU
Menu button to open the menu.
Standby or switch on the TV.
Selecting channel.
Adjusting volume.
CIick once to call up the MENU, double
click to call up the SOURCE interface.
SOURCE
SOURCE

9
FIRST TIME SETUP
The first time you turn on your TV,
the Setup Wizard will guide you
through setting up basic settings.
Please according to the Text Tip to
First Time Setup.
Connect your Android phone to your TV,
select “Continue” to continue the
connection, and choose “Skip” to skip
this step.
This function is used for the remote
successful, you can use the Bluetooth
remote control to operate the TV.
Press ▲, ▼ to select the system
language and press OK to confirm the
language.
Press ▲, ▼ to select the Wifi to
1. Your device is powered by Android
TV and press the ▶ button to select
the browing feature.
2. You can get more apps from Google
Play and press the ▶ button to go to the next screen.
3. Transfer photos and other content
to the TV via the built-in chromecast,
press OK to complete the browsing.
connect, press OK and enter the
password to confirm the connection is
successful.
By accepting the Google Terms of
Service to improve the product
experience, select “Accept” to accept
this condition.
Agree to Google to get the location
information of your device to get more
features, choose “Yes” to accept.
By agreeing to automatically send
diagnostic information to Google to
improve discriminative power, choose
“Yes” to accept.
Press ▲,▼ to select the country of your
device and press OK to confirm.
Press up and down to select the time
zone you want, and press OK to select.
For selecting the mode, press ▲,▼ key
to select Home mode and press OK to
confirm.
Confirm the selected mode again,
select “Yes” to confirm the selected
mode, and select “No” to return to the
previous step.
available features of Chromecast.
Press ▲,▼ to select whether to search,
select “Scan” to search, select “Skip
Scan” to skip the search.
Used to set your device’s password to
ensure security and privacy.
and use the remote control to enter the
4-digit password automatically jump
to the next interface.
Confirm the password again and keep
it consistent. Use the remote control
the password and complete the
password confirmation.
Press OK to complete the setup.
NOTE
The IOT system is working support to wards a more connected IOT based
home applicances, the simplicity of voice control will allow the smart TV
to act as the central access point of the modern smart home under the
standard language & words.

10
BASIC OPERATION
Home Screen
you can watch TV and go to the
home screen
Open the Google assistant or start
a voice search.
Among the applications installed on the TV, the icons for the favourite
applications are shown inside here. (Favourite applications can be
added / deleted / changed its order by users.)
Apps: Click to jump to Apps screen where all the installed applications
are listed.
Notification: Display the notifications.
Inputs: Icon to select an input source.
Network & Interent: Icon to set up Network, such as wifi.
Settings: Various settings can be configured here.
For detaiks on the settings, see the next explanation.
Input Source
1. In the Home interface, press ▲,▼,
select the “Inputs” icon, press OK to open
◀,▶ to
the input source list, then press up to
highlight an input and press OK to switch.
2. Under live TV, press the SOURCE
button to display the list of input
source. You can select the desired source.
2. Press ▲,▼ button to select what you
want set.
3. Press OK to enter setting.
Navigating the on-Screen Menu
1. There are two ways to enter.
First, in live TV, press the menu button
to display TV options, press ▲,▼,◀,▶
to select the settings menu and press
OK to confirm. Second, in the Home
interface, press the ▶ key to select the
icon of the circular settings menu, press
OK to confirm.
Press BACK to return to the previous
menu. If the main menu is displayed,
pressing BACK will close the on screen
menu.
1. Press ▲,▼ button to select what you
want set.
2. Press OK button to adjust.
save and return to the previous menu.
OK button to
Channel- Display the scan sub-menu
modes.
Auto Channel Update- Press OK button to choose ON / OFF.
When selecting ON, the system will automatically scan
standby.
Parental controls- Press ▲,▼ button to select the option then
press OK button to enter the sub- menu.
Audio Channel- Press ▲,▼ button to select the option then
press OK button to enter the sub-menu.
Open source licenses- Press ▲,▼ button to select the option
then press OK button to enter the sub-menu.
1. Menu - Settings - Channel - Channel Installation Mode enter,
choose Antenna.
2. Enter Menu - Settings - Channel - channels.
Channel
Network
Picture Mode Display Mode
Channel
Channels
Channel Installation Mode
Auto Channel Update
Parental Controls
Audio Channel
Open Source Licenses
Version
2.28.5 build 18321512
Antenna
Antenna
Channel
Channels
Auto Channel Update
Parental Controls
Audio Channel
Open Source Licenses
Version
2.28.5 build 18321512
Channels
Channel Scan
Update Scan
Analog Manual Scan
Single RF Scan
Default
LCN
Channel Scan Type
All
Channel Store Type
Favorite Metwork Select
All

3. Channel Scan directly enters the
ATV+DTV automatic search platform
interface of Antenna.
Update Scan: Re-automatically search
for frequency points outside the station.
In this menu, you can set the App permissions, and read
the app lists.
1. Press ▲,▼ button to select what you want set.
2. Press OK button to adjust.
return to the previous menu.
BACK button to
Automatic date & time- Press ▲,▼ button to select
the option then press OK button to enter the sub-menu.
(Optional: Use network-provided time,
NOTE
Manually adjusting date & time settings will automatically
change the Automatic date & time to .
Time
Set date - Press ▲,▼ button to select the option then
press OK button to enter the sub-menu.
Set time - Press ▲,▼ button to select the option then
press OK button to enter the sub-menu.
Set time Zone - Press ▲,▼ button to select the option
then press OK button to enter the sub-menu.
Use 24-hour format - Press ▲,▼ button to select the
option then press OK button to choose ON / OFF.
In this menu, you can read the information and
settings of TV.
1. Press ▲,▼ button on select what you want set.
2. Press OK button to adjust.
press BACK button
to return to the previous menu.
Accounts & Sign in
Apps
Date & Time
Device Preferences
About
Analog Manual Scan: Manual ATV
frequency point, you can select up or down
search station.
Single RF Scan: DTV manual search,
directly OK search.
About
System update
Device Name
Production Name
Restart
Status
Legal information
Model
Version
Network, serial numbers and other information
9
Timer
Power On Time Type
Auto Power On Time
SETTINGS
11
Power On Time Type - Press ▲,▼
button to select the option then press
OK button to choose ON/OFF/ONCE.
Power On Time - Press ▲,▼ button to select the option then press OK button
to enter the sub-menu.
Press ▲,▼ button to select the option then press OK
button to choose ON/OFF/ONCE.
Press ▲,▼ button to select the option then press OK button
to enter the sub-menu.

12
Language - Press ▲,▼ button to select the option
then press OK button to enter the select language.
Current keyboard - Press ▲,▼ button to select the
option then press OK button to enter the sub-menu.
Gboard settings - Press ▲,▼ button to select the
option then press OK button to enter the sub-menu.
Manage keyboards - Press ▲,▼ button to select the
option then press OK button to enter the sub-menu.
Inputs - Press ▲,▼ button to select the option then
press OK button to enter the sub-menu.
HDMI control - Press ▲,▼ button to select the option
then press OK button to choose ON/OFF.
Press ▲,▼
button to select the option then press
OK button to choose ON/OFF.
TV auto power on - Press ▲,▼ button
to select the option then press OK
button to choose ON/OFF.
HDMI EDID Version -
Show EDID
Version.
CEC Device List -Press ▲,▼ button to
select the option then press OK button
to enter the sub-menu.
Sleep Timer - Press ▲,▼ button to select the option then
press OK button to enter the sub-menu.
30 minutes, 40 minutes,
50 minutes, 60 minutes, 90 minutes, 120 minutes).
Press ▲,▼ button to select the option then
press OK button to choose ON/OFF.
Press ▲,▼ button to select the option
then press OK button to enter the sub-menu.
90 minutes, 120 minutes, 150 minutes, 180 minutes, 210 minutes,
240 minutes).
Press ▲,▼ button to select the option then press
OK button to enter the sub-menu.
15 minutes, 30 minutes, 60 minutes).
Picture Mode - Press ▲,▼ button to select the option, button to enter the
sub-menu. (Optional: User, Standard, Vivid, Sport,Movie, Game, Energy saving).
Backlight/Brightness/Cintrast/Saturation/HUE/Sharpness - Press ▲,▼
button to select the option, Press ◀ to decrease the parameter. Press
increase the parameter. ▶ to
Gamma - Press ▲,▼ button to select the option then press OK button to enter
the sub-menu. (Optional: Dark, Middle,Bright).
Color Temperature - Press ▲,▼ button to select the option then press OK
button to enter the sub-menu.
HDR - Press ▲,▼ button to select the
option then press OK button to enter
Advanced Video - Press ▲,▼ button
to select the option then press OK
button to enter the sub-menu.
Reset to Default - Reset all settings
to the factory defaults.
Language
Keyboard
Inputs
Power
SETTINGS
Koyboard
Current keyboard
Gboard
Gboard Settngs
Manage keyboards

13
Sound
Storage
Retail Mode
Chromecast Built-in
Sound style - Press ▲,▼ button to
select the option then press OK button
to enter the sub-menu. (Optional: User,
Standard, Vivid, Sports, Movie, Music,
News).
Balance/Bass/Treble - Press ▲,▼
button to select the option. Press ◀ to
decrease the parameter. Press ▶ to increase the parameter.
Sound Surround - Press ▲,▼ button to select the option then press OK button
to choose ON/OFF.
Equalizer Detail - Press ▲,▼ button to select the option then press OK button
to enter the sub-menu.
Speakers - Press ▲,▼ button to select the option then press OK button to
enter the sub-menu. (Optional: TV Speaker, External Audio System).
Digital Output - Press ▲,▼ button to select the option then press OK button
to enter the sub-menu. (Optional: Auto,
Bypass, PCM, Dolby Digital Plus, Dolby
Digital).
Spdif Delay- Press ▲,▼ button to select the option. Press ◀ to decrease
the parameter. Press ▶ to increase the parameter.
Auto Volume Control - Press ▲,▼ button to select the option then press
OK button to choose ON/OFF.
Downmix Mode - Press ▲,▼ button to select the option then press OK button
to enter the sub-menu. (Optional: Stereo, Surround).
Reset to Default - Reset all settings to the factory defaults.
Internal Shared Storage - Press ▲,▼ button to
select the option then press OK button to enter
the sub-menu.
Removable Storage - Press ▲,▼ button to select
the option then press OK button to enter the
sub-menu. (Note: Show external devices if available)
SETTINGS Home Screen
In this menu, you can set channels, apps, open source licenses.
1. Press ▲,▼ button to select what you want set.
2. Press OK button to adjust.
3. Ater finishing your adjustment, press BACK
button return to the previous menu.
In this menu, you can set searchable
words, open source licenses.
1. Press ▲,▼ button to select what you want set.
2. Press OK button to adjust.
3. Ater finishing your adjustment, press BACK button
return to the previous menu.
In this menu, you can read the infor- mation and settings of Chromecast.
1. Press ▲,▼ button to select what you want set.
2. Press OK button to adjust.
3. Ater finishing your adjustment, press BACK button
return to the previous menu.
Retail Mode - Press ▲,▼ button to select the option then press OK
button to choose ON/OFF.
Retail Messaging - Press ▲,▼ button to select the option then press OK
button to enter the sub-menu. (Note: bottom).
PQ Demo - Press ▲,▼ button to select the option then press OK button to
Right).
Google Assistant

Location
Usege & Diagnostics
Reset
Remote & Accessories
Accessibility
Screen Saver
Screen saver
Screen saver
Backdrop
When to start
After 5 minutes of inactivity
Put device to sleep
After 30 minutes of inactivity
Start now
14
SETTINGS
Screen Saver - Press ▲,▼ button to select the option
then press OK button to enter the sub-menu.
(Optional: Turn screen o, Backdrop, Colors).
When to Start - Press ▲,▼ button to select the
option then press OK button to enter the sub-menu.
(Optional: 5 minutes, 10 minutes, 30 minutes, 1 hour,
2 hours).
Put device to sleep - Press ▲,▼ button to select the
option then press OK button to enter the sub-menu. (Optional: 30 minutes, 1
hour, 3 hours, 6 hours, 12 hours, Never).
Start now - Press ▲,▼ button to select the option then press OK button to
enter screen saver.
Location status- Press ▲,▼ button to select the
option then press OK button to enter the sub-menu.
(Optional: Use Wi-Fi to estimate location, O).
Usege & Diagnostics- Press ▲,▼ button to select
the option then press OK button to choose ON/OFF.
Press OK button to enter the sub-menu.
Reset-Erase everything.
Audio Description - Press ▲,▼button to select the
option then press OK button to choose ON/OFF.
Visually Impaired - Press ▲,▼button to select the
option then press OK button to enter the sub-menu.
(Need: Audio Description ON).
Hearing Impaired - Press ▲,▼button to select the
option then press OK button to choose ON/OFF.
Captions - Press ▲,▼button to select the option
then press OK button to enter the sub-menu.
High contrast text - Press ▲,▼button to select the
option then press OK button to choose ON/OFF.
In this menu, you can pair Bluetooth
devices.
1. Press the “RED” and “BLUE” buttons
at the bottom of the remote control for
5 seconds.
2. When the LED starts to flash, release
it. The remote controller will send the
pairing signal to the TV and display the
information fo the remote control on the
right side of the screen.
3. Press the OK button to display the
pairing. If the paired is displayed, the connection is successful.
4. If the couldn’t pair appears, the connection fails. Wait 30 seconds and then
press the “RED” and “BLUE” buttons at the bottom of the remote control for
5 seconds to repeat the previous steps.
6. Press BACK button return to the previous menu.

15
PVR MODE
Recording controls
Media playback controls
OK Confirm / Play / Pause
/ / / Navigation
OK
Hold to start recording
Play Record List Mode,
Hold to Play/Pause
Hold to Stop recording
PVR (PERSONAL VIDEO RECORDER)
To access RECORDING menu, (PVR)
1. While watching Live TV, press “MENU” on remote control.
2. “TV Options” will appears, Press “DOWN” arrow on remote control to go to
“RECORD” menu (as image shown below)
IMPORTANT - You must have a USB Drive inserted into the USB Port of the TV to in order to
use any of these “RECORD” functions. (Must be FAT32 format)
Start Recording - Select “Start Recording” to start recording the channel you are
currently viewing on Live TV.
Record List - Select “Record List” to view all previous recordings.
Device Info - Select “Device Info” to view information about your
storage device.
Schedule Li st - Select “Schedule Li st” to see future programs you have
scheduled to record.
TimeShift Mode - Select “TimeShift Mode” and switch on to enable
Pause/rewind/play of Live TV.
Channels
TV options
Record List Device Info Schedule List
Start Recording
Record
NOTE
• Don’t connect or disconnect any USB device while in USB playback mode.
• Ensure all personal data is backed up before inserting USB device into TV.
We assume no liability for any loss of data due to malfunction or misuse.
• USB device should have capacity at least 512MB.
• USB device must support USB 2.0 high-speed specification.
• Use only USB storage devices formatted to FAT32.
• You cannot change channels while recording.
• If the signal is interrupted while recording, the recording will stop until signal is
regained.
• While in time-s ode,

1. In the Home interface, select the + icon in the APP conlumn to add the
application, and click OK. Press up and down to select the Multi Media Player
applicaiton, and clich OK to add it to the Home interface.
2. Select OK key to enter Multi Media Player and display Video, Photo, Audio.
USB flash drive.
MEDIA PLAYBACK
16
MEDIA MODE SETTINGS
Alongside flashdrives, the TV’s USB port is also capable of reading from
devices such as digital cameras and USB hard disks.
Recordings saved in PVR mode will also be playable.
Video
OK Confirm / Play / Pause
MENU
MENU
MENU
/Rewind / fast forward function.
Play previous / next video
.
Exit playback, return to previous menu.
Submenu can be called out to make related settings.
OK Confirm / Play / Pause
Rewind / fast forward operation possible.
Play previous / next music.
Exit music playback, return to the previous menu.
Submenu can be called out to make related settings.
OK Confirm / Play / Pause
Play previous / next picture.
Back key: Exit picture playback, return to the previous menu.
Submenu can be called out to make related settings.
Audio
/
/
/
/
/

17
Press the Home ( ) button on the remote to display the main interface.
Use the directional buttons on your remote control to navigate through the pages,
and press the OK button to launch selected app. For Netflix and YouTube, you can
launch the apps directly using the remote control hotkeys.
Netflix
Sign into your Netflix account to browse by genre, search for titles, manage your
Instant Queue and review Netflix recommendations all from your TV. If you do not
already have a Netflix account, you will need to sign up to use this feature. For
more information, visit netflix.com
YouTube
Enjoy the videos and music you love, upload original content, and share it all with
friends, family, and the world on YouTube.
9NOW
Enjoy the videos and music you love, upload original content, and share it all with
friends, family, and the world on 9NOW.
Google Play Movies&TV
Apps
Google's integrated Chrome-based application provides relevant entertainment
experience
Some of the many streaming applications on the Smart TV Apps portal
APPS
Click to jump to Apps screen where all the installed applications are listed.

18
WALL MOUNTING
A Mounting bracket (x2)
M8(x4)B
C M8 x 45mm sc
NOTE: PIease refer to the actual product for the screw size.
rew (x4)
D M6 x 60mm self-tapping
screw (x4)
E Wall anchor (x4)
A B C D E
Wall mount kit not included. Steps below are provided as an optional
alternative to the supplied base-mounts.
NOTE:
Only use wall-mounts that match the same size screws and fittings as those
listed on this page. Other methods of wall-mounting have not been tested for
this model and can not be guaranteed to safely support the TV.
It is recommended that two people perform step 4h together to ensure the
sleeves are properly aligned before the TV is lowered onto the brackets.
5. Optional wall-mounting installation
a. Measure and double-check the distance of threaded holes on the back
panel of the TV before creating any holes in the wall.
b. Use 45mm screws (C) (B) within the four threaded
holes on the back panel of the TV.
c. Use a mounting bracket (A) as a guide to mark the positions for the four
holes on the wall with a pencil.
d. Using a drill, create holes in the marked positions on the wall.
e. Insert the four wall anchors (E) into the screw holes in the wall.
f. Place the mounting brackets against the wall, aligned with the wall
anchors, ensuring the directional arrow is facing upwards.
g. Fix the mounting brackets with the 60mm self-tapping screws.
h.
into the larger openings of the brackets, then lowering the TV so that the
4b
4g 4h
Wall
TV
Wall
E
A
D
4f
C
B

19
SPECIFICATIONS
Audio
Speakers 2 x 10W
Connectivity
Ethernet (RJ45) Yes
HDMI 4 x 2.0
HDMI-ARC Yes | HDMI 4
HDMI-CEC Yes
USB 2 x USB 2.0
Wi-Fi
Bluetooth
Yes
Yes (5.0)
Dimensions
Without Stand 1576 x 78 x 886mm
With Stand 1576 x 302 x 952mm
VESA Wall Mount Pattern 400 x 200
WNet eight 25.1 kg
Display
Colours 1.07G
6Frequency 0Hz
Contrast Ratio 5000:1
Native Aspect Ratio 16:9
Refresh Rate 60Hz
Resolution 3840 x 2160
Response Time 9.5ms
Size 70”
Viewing Angle 178°/178°
Features
EPG Yes
HDR Yes (HDR 10)
HDCP Yes
TV Resolution 4K UHD
USB Media Playback Yes
USB Media Playback Formats JPG, JPEG, PNG, BMP, MP3, DD, DD+, AAC,
MPG, MPEG4, H.265, VP9 (4K @ 60P)
Inputs
Composite (AV)
Component (YPbPr)
1
1
HDMI 4
Outputs
3.5mm Stereo Audio 1
Optical Audio Out 1
Performance
CPU
GPU
OS
A55*4@1.2GHz
Mail470MP3 (OpenGLEL)
Android
RAM 1.5G Byte DDR3
Storage Capacity 8G Byte Flash
Power
Average Consumption 280W
Energy Consumption 660 kWh per year
Energy Rating 4Star
Tuning And Signal
Tuner Type DVB-T
Note:
• Design and specifications are subject to change without notice.
• Weight and dimension shown are approximate.
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo
are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

20
TROUBLESHOOTING
Please make these simple checks before calling service. These tips
may save you time and money since charges for receiver installation
and adjustements of customer controls are not covered under your
warranty.
“Ghost” Or double image
This may be caused by obstruction to
the antenna may improve the picture.
No power
• Check if the TV’s AC power cord is
plugged into the outlet.
• Unplug the TV, wait for 60 seconds.
Then reinsert plug into the outlet and
turn on the TV again.
No picture
• Check antenna connections at the rear
of the TV to see if it is properly
connected to the TV.
• Possible broadcast station trouble. Try
another channel.
• Adjust the contrast and brightness
settings.
• Check the closed captions control.
Some TEXT modes could block the
screen.
Good picture but no sound
• Increase the volume level by pressing
VOL+ button on the remote control or on
the TV side control panel.
• Press the MUTE button on the remote
control to ensure mute is o.
Good sound but poor color
Adjust the contrast, color and
brightness settings
Poor Picture
Poor picture quality may occur when an
activated S-VHS camera or camcorder is
connected to your TV and other
peripherals at the same time. Switch o
one of the peripherals.
Snowy picture and noise
Check the antenna connection
Horizontal dotted line
This may be caused by electrical
interference (e.g. hair dryer, nearby neon
lights, etc.) Turn o the equipment.
TV not responding to remote control
• Check whether the batteries are working.
Replace if necessary.
• Clean the remote control sensor lens on
the TV.
• You can still use the buttons on the side
of your TV.
Pixels (dots) that are always dark or
always lit
Your TV is precision-manufactured using
an extremely high level if technology.
However, sometimes pixels may not
display correctly.
These types of occurrences are inherent to
this type of product and do not constitute
a defactive product.
For our full TV troubleshooting guide,
head online to help.kogan.com
