KOHO Kp90s User manual

0
Pico Projector
User Manual
Kp90s

1
Contents
1. Brief Introduction ............................................................................................... 2
2. Important safety Instructions ............................................................................. 3
3. Standard accessory........................................................................................... 6
4. FCC Information................................................................................................ 6
5. Location of parts and controls ........................................................................... 8
6. Projector installation place .............................................................................. 10
7. The distance between the projector and screen.............................................. 10
8. Charging the Projector .................................................................................... 11
9. Start up the projector....................................................................................... 11
10. Video play ..................................................................................................... 11
11. Trouble shooting ........................................................................................... 13
12. Specification.................................................................................................. 14


2
1. Brief Introduction
This product use TI 0.3 inch DMD chip, cooperate with RGB LED display
technology.
LED light source, using LED RGB trichromatic LED chips, the life up to
20000 hours, in terms of 6 hours watching TV every day, life is about 10
years, much higher than general projector bulb lamp life 3000 hours. Its
brightness to 80 lumens, making the products in the field of video, games,
entertainment and mobile commerce, have got well.
The projector with micro SD card input interface, with built-in speakers
and infrared receiver control, users only need to insert micro SD card, for
the most part can decipher the format of the video.
When you buy the projector, please read the user manual, it is the
foundation of you are familiar with and master and operate the projector, I
wish you a happy to use!

3
2. Important safety Instructions
All of the safety and operating instructions should be read, adhered to
and followed before the unit is operated.
CAUTION
•TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER. THERE ARE NO SERVICEABLE PARTS INSIDE.
•TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE.
The lightning flash with arrow-head symbol within an
equilateral triangle is intended to alert the user to the
presence of uninsulated "dangerous voltage" within the
unit's enclosure that may be of sufficient magnitude to
constitute a risk of electric shock.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the unit.
Avoidstaring/facingdirectlyintotheprojectorbeam
atalltimes

4
DANGER
To reduce the risk of electric shock, burns, fire or injury:
1. Do not use while bathing or in a shower.
2. Do not place or store unit where it can fall or be pulled into a tub or sink.
3. Do not place in, drop or submerge in water or other liquid.
4. Do not reach for unit that has fallen into water. Unplug it immediately.
5. Care should be taken so that objects do not fall and liquids are not spilled onto
the unit.
WARNING
1. Close supervision is necessary when this appliance/product is used by or near
children or mentally disabled individuals.
2. Use this unit only for its intended use as described in this manual.
3. Unplug this unit during lightning storms or when unused for long periods of time.
4. Never drop or insert an object into any opening.
5. Protect the adapter cord from being walked on or pinched, particularly at plug
outlets, convenience receptacles and the point where it exits the unit.
6. Do not allow adapter cord to touch hot surfaces. Wrap cord loosely around the
unit when storing.
7. The unit should be situated away from direct sunlight or heat sources such as
radiators, electric heaters, heat registers, stoves, or other units (including

5
amplifiers) that produce heat. Avoid placing on top of stereo equipment that
radiates heat.
8. Never block the air openings of the unit with materials such as clothing, plastic
bags or papers, or place it on a soft surface such as a bed or couch, where the
air openings may be blocked.
9. Do not overload electrical outlet. Use only the power source as indicated.
10. Do not carry this unit by cord or use cord as handle.
11. Never operate this unit if it has a damaged cord or plug, if it is not working
properly, or if it has been dropped or damaged, or dropped into water. If the
unit's power supply cord or plug is damaged, do not attempt to fix it yourself.
12. To avoid the risk of electric shock, do not disassemble or attempt to repair the
unit. Incorrect repair can cause risk of electric shock or injury to persons when
unit is used.
13. Do not operate in the presence of explosive and/or flammable fumes.
14. Never remove the plug from the socket by pulling the power cord.
15. Clean only with dry cloth.
16. Don't stick alcohol such as detergent to clean with wet cloth lens

6
WARNING!
this product contains A rechargeable battery
•Do not store this product in high temperatures, damp areas or in direct sunlight.
•Never disassemble the product.
•Never dispose of the product in fire or water, which may result in explosion
and/or injury.
•Keep product out of reach of children.
•Do not touch product with damp hands.
•Dispose of the product properly.
• The product must not be discarded with ordinary household waste.
•Contact your local recycling center for proper disposal.
3. Standard accessory
Projector 1 PC Power Adapter 1 PC
User Manual 1 PC

4. FCC Information
This device complies with Part 15 of the FCC Rules. Operation is subject

7
to the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received including interference
that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This unit generates, uses, and can radiate radio frequency
energy and if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try and
correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment to an outlet on a circuit different from that to which
the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.

8
5. Location of parts and controls
FRONT
1 LENS （lamp）
2 General Switch
3 Spring Switch
4 DC IN
5 Micro SD card slot
6 Fan (Out talk)
7 Speaker

9
Left
1 Focus adjustment 2 USB port
3 RESET 4 UPDATE BUTTOM

10
6. Projector installation place
1. To install, after a vote of the geometry distortion in image will not appear in
trapezoidal state, the projector should be placed in a horizontal position (e.g.,
flat on the table), and perpendicular to the center of the screen (90° right-angle
direction).
2. The Projector can display media just about anywhere! However, for the best
quality, we suggest you find a light colored wall (preferably smooth and white)
and place the Projector with its lens facing the location. The Projector can show
media up to 80 ", just move the projector towards and away from the wall to
adjust the size of the picture. Dimming room lights will also add to viewing
quality.
7. The distance between the projector and screen
screen diagonal size Projection distance
37.8 inch 100cm, 39.37 inch
50 inch 132cm, 51.97 inch
60 inch 159cm, 62.6 inch
80 inch 211cm,83.07 inch

11
8. Charging the Projector
1. The projector is charged using the included AC Adapter.
2. The LED Indicator Light will illuminate Red to indicate that the projector is
currently charging and then revert to blue when the projector is fully charged.
Important: It takes approximately 3 to 5 hours to fully charge the projector for the
first use, and the approximate working time is 3~4 hours.
3. A low battery icon will show on the screen when the projector battery is low. Use
the included AC Adapter to charge your projector. If the battery is too low, the
projector will automatically shut off.
9. Start up the projector
1. Will POWER switch to the ON position，Press the Power button to turn the
projector on
2. When the picture is not clear, through focus adjustment knob make clear picture
10. Video play
Play video from micro SD card
1. Insert micro SD card into the corresponding slot.
2. Will POWER switch to the ON position，Press the Power button to turn the

12
projector on.
3. Automatically play video in TF card
4.Spring switch is closed to stop the projection, spring began to projection when
switch on.
Video format support:
MP4，AVI,MKV,MPEG2，ASF,DIVX,H264，MJPEG,RMVB ---

13
11. Trouble shooting
Q. The Projector will not show the video on the wall.
A. Recharge your device's battery. Also, check to see if the HDMI cable is fully
inserted into the Projector and your device.
Q. The video showing on my wall is blurry.
A. Adjust the Focus Wheel on the Projector to fine-tune the picture. It may also
depend on the surface on which you are attempting to show your video. Try
moving to a location with a smoother wall surface.
Q. I cannot get my device to work at all with the Projector and its battery is fully
charged.
A. Make sure the cables are inserted into the correct ports and test connections.
Q. No signal - I am getting no input from my device.
A. Make sure your device is on - and fully charged.

14
12. Specification
Native Resolution 854 - 480 (WVGA) (Support Maximum 1920*1080P)
Display Technology TI DLP,0.3’’DMD EM
LED Brightness 50 ANSI Lumens
LED Lamp Life Approximately 20000 hours
Contrast Ratio 1000:1
Image Size 100inch
Screen Aspect Ratio 16:9
Throw Ratio 1.19:1
Color Gamut (typical) 100% of NTSC
Uniformity 85%
Speaker 1W*2 Speakers
Power 7.4V 2000 MAH Rechargeable Battery
Battery Life ≥3Hours (Fully Charged)
DC IN 12V/1.5A
Unit Dimensions 40*60*110mm

15
FCC NOTE：
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO
OR TV INTERFERENCE CAUSED BY UNAUTHORIZED
MODIFICATIONS OR CHANGE TO THIS EQUIPMENT. SUCH
MODIFICATIONS OR CHANGE COULD VOID THE USER’S
AUTHORITY TO OPERATE THE EQUIPMENT.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause

16
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
