Koldfront WTC10001W User manual

V3.2-10132020
Through The Wall Air Conditioner
With Supplemental Heater
For more information on other great Koldfront products on the web, go to www.koldfront.com
To use the Koldfront self-diagnostic tool, go to https://support.edgestar.com
Owner’s Manual
WTC8001W / WTC10001W
WTC12001W / WTC14001W

i
Important Safety Information
Improper handling can cause serious damage to the appliance and/or to the user. Please read the
following safety information.
Warning: The water produced by the window AC is not potable or suitable for drinking.
Do not drink the water drained from the unit as it contains contaminates and could make you sick.
Electrical Safety
•Make sure your hands are dry and not wet before operating the unit.
•Do not wet the front housing or control panel.
•Do not directly spray water on this Air Conditioner.
•Do not pull the unit by the cord.
•Always turn the unit off and unplug it from the socket when cleaning.
•Unplug the unit if it is not going to be used for a long period of time.
•Do not operate the unit with a damaged or loose plug and / or socket.
•Use only the correct power supply with appropriate amperage.
•If the power cord is damaged, it must be replaced by the manufacturer, a service agent, or qualified
technician.
•Do not turn the unit off or on by inserting or pulling the power plug.
•Do not modify the power cord length or share the outlet with another appliance.
•Do not use this unit with an extension cord and / or adapter plug.
•Do not use this unit near flammable gases / combustibles or in close proximity to heating appliances.
•During operation do not remove any part of the outside casing.
General Safety
•Do not let people or pets sit or set an object directly in front of air flow.
•If a strange sound, smell, or smoke comes from the unit, turn it off and review the troubleshooting
page of this manual.
•Stop operation and unplug unit in the event of a severe storm.
•To ensure proper air flow and intake, make sure the air vents are not obstructed.
•See instructions for cleaning air filters and how often cleaning should occur.
•Do not use strong detergents when cleaning.
•Children should be supervised when operating this unit.
•Do not allow children to play with the controls or drop any objects into the air outlets or vents.
•Do not place objects or let any person sit on top of the unit.
•Route the power cord carefully to avoid a tripping hazard.
•This unit is intended for domestic home use only. Do not use the air conditioner for commercial or
industrial use. Any other use may invalidate the warranty.
•Use caution when unpacking and installing the unit as there may be some sharp edges.

ii
Operation of Safety Plug
Your air conditioner is supplied with a Leakage-Current Detection and Interruption (LCDI) safety
plug. This device provides protection to reduce the risk of fire due to arcing faults in the power
supply cord. Before using your air conditioner, follow the instructions below to ensure that the
LCDI plug is working properly:
1. Plug the power cord into a grounded outlet.
2. Press the TEST button on the LCDI plug. This should trip the plug and cut the power to the air
conditioner. If the plug does not trip and you are able to turn on the unit, please contact
EdgeStar support.
DO NOT USE YOUR AIR CONDITIONER IF THE TEST FAILS.
3. Press the RESET button to start using your air conditioner.
Note: Electrical products should not be disposed of with household waste. Please contact your
local recycling center for more information on how to recycle electronic waste.
Notes:
•Always make sure the “Reset” button is pushed in for proper operation.
•The power supply cord with LCDI plug must be replaced if it fails to reset.
•Do not use the TEST and RESET buttons as an ON/OFF switch.
•Please refer to the Specifications section of this document for additional information on the
correct LCDI Plug Type for your model.

1
Table of Contents
IMPORTANT SAFETY INFORMATION.............................................................................................................................................I
OPERATION OF SAFETY PLUG.....................................................................................................................................................II
TABLE OF CONTENTS....................................................................................................................................................................1
INTRODUCTION...............................................................................................................................................................................2
PARTS IDENTIFICATION.................................................................................................................................................................3
Air Conditioner Unit ...........................................................................................................................................................................3
Wall Sleeve .......................................................................................................................................................................................3
PREPARATIONS FOR INSTALLATION ..........................................................................................................................................4
Tools You May Need.........................................................................................................................................................................4
Parts Supplied:..................................................................................................................................................................................4
INSTALLATION INSTRUCTIONS ....................................................................................................................................................5
Basic Installation Steps .....................................................................................................................................................................5
Before Getting Started.......................................................................................................................................................................5
Preparing the Wall Sleeve.................................................................................................................................................................5
Attach Seals and Support Blocks to Wall Sleeve...............................................................................................................................6
Prepare Ground Wire ........................................................................................................................................................................8
Install Air Conditioner Unit into Wall Sleeve ......................................................................................................................................9
Completing Installation....................................................................................................................................................................10
Alternate and Supplemental Installation Instructions.......................................................................................................................11
Install the Rear Louver Panel / Grille into the NEW Wall Sleeve.....................................................................................................11
Preparation of Previously Installed Wall Sleeve ..............................................................................................................................11
Rear Louver Panel / Grille Installation into Wall Sleeve Diagram....................................................................................................12
Install Rear Louver Panel / Grille Directly on Back of Air Conditioner..............................................................................................13
Non-Koldfront Wall Sleeve Types....................................................................................................................................................13
CONTROL PANEL OPERATIONS.................................................................................................................................................14
To Turn the Unit on:.........................................................................................................................................................................14
To Change the Temperature:..........................................................................................................................................................14
To Adjust Fan Speeds:....................................................................................................................................................................14
To Select Operating Mode:..............................................................................................................................................................15
To Operate in Cool Mode:...............................................................................................................................................................15
To Operate in Heat Mode:...............................................................................................................................................................15
To Operate in Auto Mode:...............................................................................................................................................................15
To Operate in Fan Only:..................................................................................................................................................................16
To Operate in Dry Mode:.................................................................................................................................................................16
To Use the Energy Saver Feature:..................................................................................................................................................16
To Use the Sleep Feature: ..............................................................................................................................................................16
To Use the Timer (Auto Start/Stop) Feature:...................................................................................................................................16
To Use the Check Filter Feature:.....................................................................................................................................................16
Digital Display:.................................................................................................................................................................................17
Error Codes.....................................................................................................................................................................................17
AIR DIRECTIONAL LOUVERS: .....................................................................................................................................................17
REMOTE OPERATIONS ................................................................................................................................................................18
Additional Notes on Remote Operations .........................................................................................................................................19
MAINTENANCE..............................................................................................................................................................................20
Air Filter Cleaning............................................................................................................................................................................20
Cabinet Cleaning.............................................................................................................................................................................20
NORMAL SOUNDS ........................................................................................................................................................................21
ENERGY SAVING GUIDE ..............................................................................................................................................................21
TROUBLESHOOTING TIPS...........................................................................................................................................................22
SPECIFICATIONS ..........................................................................................................................................................................24
EDGESTAR LIMITED WARRANTY ...............................................................................................................................................25

2
Introduction
Thank you for purchasing this Koldfront by EdgeStar air conditioner. We hope that this purchase
will be the beginning of a lasting and rewarding relationship between you and EdgeStar. We will
provide the customer support and exemplary products necessary to nurture that relationship.
This manual contains important information regarding the proper installation, use, and
maintenance of your air conditioner. Following this manual will ensure that your product will work
at its peak performance, efficiency, and safety.
Please save the original product packaging in case you need to safely transport your air
conditioner.
For Your Records:
Please write down the model number and serial number below for future reference. Both
numbers are located on the ratings label on the back of your unit and are needed to obtain
warranty service. You may also want to staple your receipt to this manual as it is the proof of
your purchase, and is also needed for service under your warranty.
Model Number:
Serial Number:
Date of Purchase:
For a more efficient experience, please do the following before contacting customer service:
•If you received a damaged product, immediately contact the dealer that sold you the
product.
•Read and follow this instruction manual carefully to help you install, use, and maintain your
air conditioner.
•Read the troubleshooting section of this manual as it will help you diagnose and solve
common issues.
•Visit us on the web at www.koldfront.com for product guides, additional troubleshooting
resources and up-to-date information. You can also find an interactive self-diagnostic tool
at https://support.edgestar.com. If you need service, our friendly customer service
representatives are available via email at se[email protected].

3
Parts Identification
Air Conditioner Unit
Wall Sleeve
(purchased or provided separately)

4
Preparations for Installation
Before you begin, make sure you have all the parts and tools necessary for installation.
Tools You May Need:
• Flat Screwdriver or Putty Knife • Phillips Screwdriver • Tape Measure • Level • Drill
Parts Supplied:
Note: You may need to contact an electrician if your room’s circuit is not able to power your unit.
Note: To avoid risk of injury and / or product / property damage, please take the following
precautions:
•Two or more people are needed to properly handle and install the unit.
•Use proper lifting and carrying techniques.
•Before installation, make sure to inspect the installation location to ensure it is able to handle
the weight and size of this unit.
•Wearing protective gloves will help to avoid injury from sharp edges.
The parts below are intended to be used in conjunction with a Koldfront branded Wall
Sleeve (WTCSLV).
Part Name
Size
Qty Included
Horizontal Insulation Seals
1” x 3/8” x 25”
1
Vertical Insulation Seals
1” x 3/8” x 14”
2
Horizontal Insulation Seals
1” x 3/4” x 14”
2
Foam Support Blocks
1” x 1 1/2” x 14”
2
Tapered Support Blocks
1” x 1” x 17” (tapered to ¾”)
2
Main Insulating Seal (stuffer seal)
1” x 1 1/2” x 84”
1
Trim Frame (sides)
2
Trim Frame (top / bottom)
2
Ground Wire (green)
1
Toothed washers for grounding screw
2
Grounding Screw
1
Rear Louver Panel / Grille (aluminum)
1
Nuts (plastic)
4
Washers (for screws)
4
Screws
4
Additional and / or duplicate parts noted below have been included to allow for installation
into non-Koldfront branded Wall Sleeves or to accommodate non-standard installation
scenarios. Any unused parts may be discarded at your discretion.
Part Name
Size
Qty Included
Centering / Support Blocks
4 1/2” x 3 1/2” x1 1/2”
4
Plastic Divider
1/8” x 4 1/2” x 14 1/2”
2
Horizontal Insulation Seals
1” x 3/8” x 25”
2
Horizontal Insulation Seals
1” x 1 1/2” x 25”
3

5
Installation Instructions
Basic Installation Steps
•Prepare the Wall Sleeve.
•Install the rear Louver Panel / Grille into the Wall Sleeve.
•Attach Seals inside the Wall Sleeve.
•Prepare the Grounding Wire
•Insert the Air Conditioner Unit into the Wall Sleeve and attach the Ground Wire.
•Insert the Main Seal.
•Attach the Front Frame pieces.
Before Getting Started
Your Koldfront though the wall air conditioner is designed to be installed in conjunction with a wall
sleeve. If you are installing your new Koldfront air conditioner into an existing wall sleeve, please
check to confirm that the wall sleeve is in sound structural condition and that is sized
appropriately to accommodate your Koldfront air conditioner. For reference, your new Koldfront
Air Conditioner is 24 1/4" x 20 3/8”x 14 1/2”
Note: When choosing your installation location make sure power supply cord is within 4 feet of a
grounded 3-prong outlet.
Important: When installation is complete, the unit MUST have a rearward slope as shown in the
image below to ensure proper drainage. This is accomplished by using the Tapered Support
Blocks as noted in the “Attach Seals” section of this document.

6
Note: The Koldfront Through the Wall Air Conditioner Sleeve (Model: WTCSLV) is designed
specifically for Koldfront’s line of through the wall air conditioners and makes installation simpler
than using non-Koldfront branded sleeves. The WTCSLV can be purchased from an authorized
retailer or the dealer from which you purchased your Koldfront air conditioner.
Preparing the Wall Sleeve
Your Koldfront Through The Wall Air Conditioner unit is intended to be installed into a compatible
wall sleeve enclosure. A wall sleeve provides the proper support and enclosure for your air
conditioner and allows for the wall opening to be properly sealed prior to final installation.
To properly install your new Koldfront Through The Wall Air Conditioner into a wall sleeve, it is
required that you use the Rear Louver Panel / Grille that was shipped with your new air
conditioning unit. This will ensure proper air flow from the back of the unit. If your installation
utilizes a previously installed wall sleeve, please replace the Rear Louver Panel / Grille with the
one provided with your new air conditioner.
Attach Seals and Support Blocks to Wall Sleeve
With the wall sleeve properly assembled, it is now time to prepare the wall sleeve enclosure
for the air conditioner unit. The process involves positioning seals and foam support blocks
inside of the wall sleeve enclosure in order to enable a proper fit for the air conditioning unit.
Important: The below instructions are to be used in conjunction with the Koldfront Wall Sleeve
model WTCSLV. Instructions for other compatible wall sleeves can be found in the “Alternate
and Supplemental Installation Instructions” section.

7

8
Prepare Ground Wire
To properly ground the air conditioner unit, the ground wire must be secured to the frame of the
wall sleeve. When the air conditioner unit is placed inside of the wall sleeve, this ground wire will
be attached to the air conditioner frame to allow for proper grounding of the air conditioner unit.
1. Locate the following parts:
•Grounding Screw (1)
•Toothed Grounding Screw Washer
•Ground Wire
2. As needed, use a drill and 1/8” bit to drill a hole for the grounding screw. The hole needs to be
approximately 1” from the bottom and 3” from the front edge of the wall sleeve on the left side.
3. Attach one end of ground wire using 1 (one) Toothed Washer and 1 (one) Grounding Screw.
Note: This step may require the use of a drill with a 1/8” drill bit. If your wall sleeve has been
previously installed, there may be no requirement to drill a new hole for the grounding screw. If
using the Koldfront wall sleeve (model WTCSLV), the hole should be pre-drilled for you.
Also, please note that additional fastener types may have been included and may be used to suit
your particular installation setup.

9
Install Air Conditioner Unit into Wall Sleeve
With the wall sleeve fully prepared, you are now ready to insert the air conditioner unit into the
wall sleeve. Two or more people may be required for this step.
1. Remove the CENTER cabinet screw on the left lower side of the air conditioner cabinet. Set
aside and / or discard the plastic washer.
2. The ground wire will be attached to the air conditioner cabinet using the screw you just
removed along with a Toothed Washer.
3. Gently slide the air conditioner cabinet into the Wall Sleeve. With the cabinet screw hole still
exposed, attach the ground wire to the cabinet using the cabinet screw making sure that the
Toothed Grounding Screw Washer is pressed against the cabinet.

10
4. Slide air conditioner completely to the rear of the wall sleeve unit ensuring that all seals and
foam support blocks create snug fit for the unit. Please be sure that the ground wire does not
become entangled when the unit is pushed back into the wall sleeve.
Completing Installation
With the air conditioner installed into the Wall Sleeve and the ground wire properly attached, it is
time to complete installation by inserting the Main Insulating Seal (stuffer seal) and attaching the
Trim Frame.
1. Locate the Main Insulating Seal (stuffer seal) included with the installation kit. This is the
longest seal and measures 1” X 11/2” X 84”. Using a putty knife or flathead screwdriver, insert
the seal into the gap between the air conditioner cabinet and the Wall Sleeve frame. Trim seal
as needed.
2. Locate the 4 (four) trim kit components that were packaged with your installation kit. Snap the
pieces together as shown in the image below.

11
3. Pull the power cord through the Trim Kit frame and then slide the Trim Kit Frame over the unit
until it is flush with the wall.
Alternate and Supplemental Installation Instructions
The below instructions may be referenced for scenarios in which the standard installation
procedures cannot be followed.
Install the Rear Louver Panel / Grille into the NEW Wall Sleeve
Assemble and install your new wall sleeve according to the manufacturer’s instructions. Basic
instructions are as follows:
1. Prepare and install the new wall sleeve according to the manufacturer’s instructions.
Ensure that the wall sleeve is properly fastened to the wall a minimum of 4” from any
heating source and that high-grade sealant / caulking has been used to prevent air and
water infiltration.
2. Place the Rear Louver Panel / Grille included with your new air conditioner towards the
rear of the sleeve.
3. Mark the mounting hole positions.
4. Drill through the sleeves flanges with a 1/8”drill bit.
5. Attach the Rear Louver Panel / Grille included with your new air conditioner unit with self-
threading screws and washers. (See following page.)
Preparation of Previously Installed Wall Sleeve
To install the rear louver panel / grille provided with your new air conditioner unit into an existing
wall sleeve installation:
1. Remove the existing Rear Louver Panel / Grille.
2. Clean the interior and exterior of the wall sleeve and verify that all seals are in proper
condition. Replace seals if needed with the seals that have been provided with this unit.
3. Place the Rear Louver Panel / Grille included with your new air conditioner towards the
rear of the sleeve.
4. Mark the mounting hole positions.
5. Drill through the sleeves flanges with a 1/8”drill bit.
6. Attach the Rear Louver Panel / Grille included with your new air conditioner unit with self-
threading screws and washers. (See following page.)
7. Most existing decorative exterior grilles may be left in place as long as the proper interior
air direction grille is installed.

12
Rear Louver Panel / Grille Installation into Wall Sleeve Diagram
Important: Please ensure that the Rear Louver Panel / Grille is installed correctly to ensure
proper airflow and performance. Please note the direction and alignment of the louvered fins.
If you are unable to secure the Rear Panel Louver / Grille to the wall sleeve, it may be attached
directly to the rear of the air conditioning unit.

13
Install Rear Louver Panel / Grille Directly on Back of Air Conditioner
If your installation scenario does not allow you to attach the Rear Louver Panel / Grille to the
Wall Sleeve you may carefully secure the Panel directly to the rear of the Air Conditioner unit.
1. Attach 1” x 3/8” x 14” seal pieces.
2. Position Grille over rear or air conditioner ensuring that:
- The double set of screw holes are on the bottom.
- The Grille fins are pointed away from unit.
3. Align the top of the Grille with the top of the air conditioner unit.
- Holes should be pre-drilled, but if required, carefully pre-drill 4 (four) 1/8” holes through
the Grille and into the side flange of the air conditioner cabinet frame approximately
1 ½” – 2” from the top and bottom.
4. Attach Grille to unit with 4 (four) self-tapping screws.
5. Install unit into sleeve.
Non-Koldfront Wall Sleeve Types
The below diagrams may be used as a reference when installing your Koldfront Through The
Wall Air Conditioner into a non-Koldfront branded Wall Sleeve. Regardless of brand, please
ensure your wall sleeve is securely installed into the wall opening and is properly sealed.
Additionally, as noted previously, please ensure that your air conditioner is installed with a
slight rearward tilt to allow for proper drainage.

14
Control Panel Operations
Using the Control Panel
To Turn the Unit on:
Press the On/Off button.
Auto-Restart: If power to the unit is interrupted, the air conditioner will restart itself in its last
used mode and settings once power is restored. The compressor will restart after 3 minutes.
To Change the Temperature:
Press or hold either Up or Down button until desired temperature is seen on the
digital display. This temperature will be automatically maintained anywhere between 62 °F
(17° C) and 86° F (30° C).
The unit is capable of displaying the temperature in degrees Fahrenheit or degrees Celsius.
To convert from one to the other, press and hold the Up and Down Temp / Timer buttons at
the same time for 3 seconds.
To Adjust Fan Speeds:
To select the speed of the fan press Fan Speed which cycles through four steps- Auto,
Low, Medium, or High. Each time the button is pressed the fan speed mode is shifted.
On/Off
Energy Saver
Timer
Mode
Check Filter
Fan Speed
Sleep
Temp/Timer Up
Temp/Timer Down
Note: The fan speed is not adjustable in Dry, Auto or Heat modes. It is controlled automatically.

15
To Select Operating Mode:
To choose the operating mode press Mode . Each time you press the button a mode is
selected in a sequence that goes from Auto, Cool, Heat, Dry, to Fan. The indicator light
beside the mode button will be illuminated and remain on once the mode is selected.
To Operate in Cool Mode:
•When the unit is set to “Cool” mode it will cool the room to maintain the desired set
temperature.
•When the desired temperature has been reached, the unit will automatically maintain the
temperature.
•Press the Up and Down buttons to adjust the desired temperature and press the Fan
button to adjust the fan speed.
•The “Cool” mode has an automatic 3 minute delay if the unit it turned off and on quickly
to prevent overheating of the compressor and possible circuit breaker tripping. The fan
will continue to run during this time.
To Operate in Heat Mode:
•When the unit is set to “Heat” mode it will heat the room to maintain the desired set
temperature.
•When the desired temperature has been reached, the unit will automatically maintain the
temperature.
•The Fan speed is not adjustable in heat mode.
To Operate in Auto Mode:
AUTO Mode is a setting that allows the unit to automatically switch between COOL, FAN and
HEAT in order to achieve and maintain the desired set temperature.
•When set to “Auto” mode, the unit will automatically select cooling, heating or fan only
operation depending on the temperature selected and the current room temperature.
•Once the temperature you selected is achieved the unit will automatically maintain the
room temperature by switching between modes as needed.
•While in AUTO Mode, the fan speed cannot be adjusted manually.
•When operating in AUTO MODE, the control panel display will NOT illuminate to indicate
any change between Cool/Fan/Heat. The AUTO indicator will remain illuminated.
Note: Heat function is intended to provide supplemental heating in addition to an existing heat source. The
heat function has a lower BTU rating than the cool mode and therefore does not treat the same square
footage. The maximum heating capacity of the unit is 15°F above the ambient room temperature.
Note: The unit’s temperature sensor is located on the front of the unit near the air intake port. As such, a
temperature reading taken manually on the opposite side of the room may read differently than what the
unit is detecting. Please make note of this when operating your unit.
Also, the unit does not constantly take temperature readings. The unit will take a temperature reading
periodically while operating in AUTO mode, or immediately upon adjustment of the desired set
temperature. As such, it is important to understand that when operating in AUTO MODE the unit may not
switch between Cooling, Heating, and Fan Mode at the exact moment when a temperature change occurs.

16
To Operate in Fan Only:
•Use this function only when cooling is not desired, such as for room air circulation. You
can choose any speed you prefer.
•During this function the display will show the actual room temperature as in the cooling
mode.
•In Fan Only mode, the temperature is not adjusted.
To Operate in Dry Mode:
•In this mode, the air conditioner will operate as a dehumidifier. Because the conditioned
space is closed or sealed, some degree of cooling will continue to occur.
To Use the Energy Saver Feature:
To start the Energy Saver feature, press the Energy Saver button. This feature is
available on “Cool”, “Dry”, and “Auto”. The fan continues to run for 3 minutes after the
compressor shuts off. The fan then cycles on for 2 minutes at 10 minute intervals until the
room temperature is above the set temperature, at which point the compressor turns back on
and cooling starts.
To Use the Sleep Feature:
To initiate, press the Sleep button. In this mode the selected temperature will increase
(cooling) or decrease (heating) by 2°F (1°C) 30 minutes after the mode is selected. The
temperature will then increase (cooling) or decrease (heating) by another 2°F (1°C) after an
additional 30 minutes. This new temperature will be maintained for 6 hours before it returns to
the originally selected temperature. This ends the Sleep mode and the unit will continue to
operate as originally programmed. The Sleep Mode program can be cancelled at any time
during operation by again pressing the Sleep button.
To Use the Timer (Auto Start/Stop) Feature:
•When the unit is on or off, press the Timer button and the “Timer On” indicator light
illuminates. It indicates that the Auto Start/Stop program is initiated.
•To switch to off press the Timer button again and the “Timer Off” indicator light
illuminates. It indicates that the Auto Stop program is initiated.
•Press or hold the Up or Down button to change the Auto Time by ½ hour
increments up to 10 hours or 1 hour increments up to 24 hours. The control will count
down the time remaining until start.
•The selected time will display for five (5) seconds and then will automatically revert back to
display the previous temperature setting or room temperature when the unit is on.
(Note-when the unit is off there is no display.)
•Turning the unit ON or OFF at any time or adjusting the timer setting to 0.0 will cancel the
Auto Start/Stop program.
To Use the Check Filter Feature:
This feature is a reminder to clean the Air Filter for more efficient operation. The LED light will
illuminate after 250 hours of operation. To reset after cleaning the filter, simply press the
Check Filter button and the light will go off.

17
Digital Display:
This component displays the set temperature in “F” or “C” and the Auto-Timer settings. While
on Fan only mode it shows the room temperature.
Error Codes
AS - Room temperature sensor error
✓Unplug the unit and plug it back in.
✓If the error repeats call for service.
✓Note- In Fan only mode it will display “LO” or “HI”.
- Evaporator temperature sensor error
✓Unplug the unit and plug it back in.
✓If the error repeats, call for service.
HS - Electric Heating sensor error
✓Unplug the unit and plug it back in.
✓If the error repeats, call for service.
Air Directional Louvers:
The 4-way air directional louvers allow you to direct the air flow Up, Down, Left, and Right
throughout the room as needed. To adjust the air directional louvers side to side use the center
handles as you move side to side. To pivot the louvers, press with your fingers until the desired
airflow direction is obtained.
