KonNad C2000-B2-SIE0101-BB1 User manual
Last updated: 2020-11-26
C2000-B2-SIE0101-BB1
User Manual
Ethernet ⇋ 1 * RS485/422
Serial-to-Ethernet Device — Serial Device Server
SinoCon Co., Ltd.
Copyright Notice
©2000 - 2020 SinoCon Co., Ltd. All Rights Reserved.
Trademarks
The KonNaD logo is a registered trademark of SinoCon Co., Ltd. All other trademarks or registered marks in
this manual belong to their respective manufacturers.
Disclaimer
This document only provides information about KonNaD products. No license to any intellectual property
rights is granted by this document, including any intellectual property licenses, expressed or implied, or by
any means. SinoCon assumes no responsibility other than the liability stated by SinoCon in the terms and
conditions of sale of its products and SinoCon makes no warranties regarding the sale or use of KonNaD
products, including the suitability for the specific use of the products, and marketability, and SinoCon doesn't
guarantee that it won't infringe any patent, copyright or other intellectual property rights, etc.
Information in this document is subject to change without notice and does not represent a commitment on
the part of SinoCon.
Contact US
SinoCon Co., Ltd.
Address: 16th Floor, Tower A, Zhongyin Building, Caitian Road, Futian District, Shenzhen, China
Web: www.sinoconsys.com
Tel: +86 0755-88865168
C2000-B2-SIE0101-BB1 User Manual
3 / 11
SinoCon Co., Ltd. www.sinoconsys.com
C2000-B2-SIE0101-BB1 User Manual
4 / 11
SinoCon Co., Ltd. www.sinoconsys.com
1. Hardware Description
1.1. Specifications
Classification Parameter Specification
Ethernet No. of Ports 1
Bandwidth 10/100M
Communication Distance 100m
Protocol Mode Support TCP Server/TCP Client/UDP
Mode
Max. No. of TCP Connections 1
Downstream Serial
Port
Serial Standard RS485/422
No. of Ports 1
Connector Terminal block
Cascade Connection/Transparent
Transmission
Bidirectional transparent
transmission
Baud Rate 300~115200bps
Communication Distance 1200m
Power Power Connector Dual power inputs
Input Voltage 9~27VDC
Current 80mA @ 12VDC
Physical
Characteristics
Dimensions 75*105*30mm
Installation Din-rail or wall
Environmental
Limits
Operating Temperature -40℃ ~ 85℃
Storage Temperature -60℃ ~ 125℃
Ambient Relative Humidity 5% ~ 95% RH, non-condensing
C2000-B2-SIE0101-BB1 User Manual
5 / 11
SinoCon Co., Ltd. www.sinoconsys.com
1.3. Indicators
Classification Indicator Description Meaning
Ethernet LINK Network status
indicator
Steady on：Network connection enabled
Flashing：Transmit or receive data
Off：The network port is not plugged into the
network cable
SPD 10/100Mbps
indicator
Steady on：100M network connected
Off：Not connected to the 100M network
Power PWR Power indicator Steady on：Normal power supply
Off：No power or abnormal power supply, please
check if the voltage range is 9~27VDC
Downstream
Serial Port
RXD RS485/RS422
data receive
indicator
Steady on：RS485/RS422 line fault，please check if
the positive and negative poles of 485/422 line are
reversed
Flashing：RS485/RS422 receiving data
Off：RS485/RS422 no receiving data
TXD RS485/RS422
data transmit
indicator
Flashing：RS485/RS422 transmitting data
Off：RS485/RS422 no transmitting data
C2000-B2-SIE0101-BB1 User Manual
7 / 11
SinoCon Co., Ltd. www.sinoconsys.com
1.4. Port Description
Classification Port Description Recommended
wiring
Ethernet Ethernet RJ45 Ethernet port CAT-5e
Power Input V+、V- Power supply input positive, power supply input
negative
RVV 2*1.0
PE Used for reliable grounding of the device, surge
protection
RVV 2*0.5
㊉ → ㊀Power supply input positive, power supply input
negative
RVV 2*1.0
Parameter
Settings
ON、
OFF
Turn WP to ON: You can force the converter to work
with the default network settings. At this time, the IP
address of the converter defaults to 10.1.1.10, the
password is invalid, and the converter works in TCP
client mode and makes a TCP connection to the 8000
port of the server 10.1.1.1<br/> Turn WP to OFF:
The settings will take effect and the converter will go
into operation (The factory default setting is OFF)
-
ON、
OFF
Turn Setup to ON: The save settings are in the write-
protected state, and the save settings data cannot
be changed at this time<br/> Turn Setup to OFF:
Allows settings for the device (The factory default
setting is OFF)
-
Downstream
Serial Port
R-、
R+、
GND、
T-、T+
R-、R+、GND、T-(485-)、T+(RS485+) (downward) RVSP 2*0.5
C2000-B2-SIE0101-BB1 User Manual
8 / 11
SinoCon Co., Ltd. www.sinoconsys.com
3. Warranty Policy
In the normal use of the products you purchased, free warranty service will be provided from the date of
purchase whenever the quality problems caused by raw materials or production process are concerned.
However, due to the user's failure to install, disassemble or improperly use the product according to the
requirements of this product manual, the company provides maintenance services, but charges appropriate
maintenance fees. The warranty period is as follows:
Product category Warranty Period
Shelled product 6years
Unshelled product 3years
Note: Accessories are not covered by warranty.
Warranty Terms:
1. From the date of purchase, in the case of normal use (determined by the company's authorized
technicians), the failed product will be repaired free of charge during the warranty period.
2. Products that have been repaired or modified by a maintenance personnel other than our company
during the warranty period, or that have been improperly installed, incorrectly input voltage,
improperly used, accidental events or natural disasters, etc., are not covered by the warranty.
3. Before accepting the warranty service, the customer is required to prove the date of purchase of the
product by presenting the warranty card or purchasing the invoice. Otherwise, the warranty cannot
be guaranteed.
4. For all warranty or repair products, the customer bears the risk of shipping and shipping costs.
5. If the product exceeds the warranty period or does not meet the warranty requirements, the
company will provide charge maintenance.
6. The warranty terms for customized and ODM products should be defined in the contract.
7. Other verbal commitments that conflict with this warranty would be executed with reference to this
warranty.
8. Our company's responsibility for the manufacture, sale and use of the products shall not exceed the
original cost of the products. The company does not assume any joint responsibility.
9. The right to interpret this clause belongs to the company.
