Kontron CP342 User manual

P R E L I M A R Y
CP342
Dual Port Three Speed Ethernet Board
for Copper and Fiber Optic Applications
Doc.ID: 34938, Rev. 1.0
November 8, 2006
User Guide

Page ii Doc.ID: 34938, Rev 1.0
Preface CP342
CUSTOMER SPECIFIC
P R E L I M A R Y
Revision History
Imprint
Kontron Modular Computers GmbH may be contacted via the following:
MAILING ADDRESS TELEPHONE AND E-MAIL
Kontron Modular Computers GmbH +49 (0) 800-SALESKONTRON
Sudetenstraße 7 [email protected]
D - 87600 Kaufbeuren Germany
For further information about other Kontron products, please visit our Internet web site:
www.kontron.com
Disclaimer
Copyright © 2006 Kontron AG. All rights reserved. All data is for information purposes only and not guaranteed for
legal purposes. Information has been carefully checked and is believed to be accurate; however, no responsibility
is assumed for inaccuracies. Kontron and the Kontron logo and all other trademarks or registered trademarks are
the property of their respective owners and are recognized. Specifications are subject to change without notice.
Publication Title: CP342: Dual Port Three Speed Ethernet Board for Copper and
Fiber Optic Applications
Doc.ID: 34938
Rev. Brief Description of Changes Date of Issue
1.0 Initial issue 08-NOV-2006

Doc.ID: 34938, Rev 1.0 Page iii
CP342 Preface
CUSTOMER SPECIFIC
P R E L I M A R Y
Table of Contents
Revision History .........................................................................................................ii
Imprint ........................................................................................................................ii
Disclaimer ..................................................................................................................ii
Table of Contents ...................................................................................................... iii
List of Tables ..............................................................................................................v
List of Figures .......................................................................................................... vii
Proprietary Note ........................................................................................................ix
Trademarks ...............................................................................................................ix
Environmental Protection Statement .........................................................................ix
Explanation of Symbols .............................................................................................x
For Your Safety .........................................................................................................xi
High Voltage Safety Instructions ...........................................................................xi
Special Handling and Unpacking Instructions ......................................................xi
General Instructions on Usage ................................................................................ xii
Two Year Warranty .................................................................................................. xiii
1. Introduction ............................................................................. 1 - 3
1.1 System Overview .................................................................................... 1 - 3
1.2 Board Overview ....................................................................................... 1 - 4
1.2.1 Board Introduction .......................................................................... 1 - 4
1.2.2 Board Specific Information .............................................................. 1 - 4
1.3 Board Versions ........................................................................................ 1 - 5
1.3.1 CP342 ............................................................................................. 1 - 5
1.3.2 CP342-RIO ..................................................................................... 1 - 5
1.3.3 CP342-SFP ..................................................................................... 1 - 5
1.3.4 Optional CP-RIO3-42 RIO Module for CP342-RIO ......................... 1 - 5
1.3.5 System Considerations ................................................................... 1 - 5
1.4 System Relevant Information .................................................................. 1 - 6
1.5 Board Diagrams ...................................................................................... 1 - 6
1.5.1 Application System Interfacing ....................................................... 1 - 7
1.5.2 System Level Interfacing ................................................................ 1 - 8
1.5.3 Front Panels ................................................................................... 1 - 9
1.5.4 Board Layout ................................................................................ 1 - 10
1.6 Technical Specifications ........................................................................ 1 - 11
1.7 Applied Standards ................................................................................. 1 - 13
1.8 Related Publications ............................................................................. 1 - 13

Page iv Doc.ID: 34938, Rev 1.0
Preface CP342
CUSTOMER SPECIFIC
P R E L I M A R Y
2. Functional Description ............................................................ 2 - 3
2.1 General Information .................................................................................2 - 3
2.2 Board-Level Interfacing Diagram .............................................................2 - 3
2.3 Interfaces .................................................................................................2 - 5
2.3.1 CompactPCI Bus Interface ..............................................................2 - 5
2.3.2 Gigabit Ethernet ..............................................................................2 - 8
2.3.3 SFP Cages ......................................................................................2 - 9
2.3.4 CP342-RIO ....................................................................................2 - 10
2.4 Remote Boot Operation .........................................................................2 - 10
3. Installation ................................................................................ 3 - 3
3.1 Safety Requirements ...............................................................................3 - 3
3.2 CP342 Installation Procedures ................................................................3 - 4
3.3 Standard Removal Procedures ................................................................3 - 5
3.4 Software Installation ................................................................................3 - 5
A. CP-RIO3-42 .............................................................................. A - 3
A.1 Overview ................................................................................................. A - 3
A.2 Front Panel ............................................................................................. A - 3
A.3 Board Layout .......................................................................................... A - 4
A.4 Gigabit Ethernet ...................................................................................... A - 5
A.5 Rear I/O Interface on J1 (CPCI rJ2) ....................................................... A - 6
A.6 Technical Specifications ......................................................................... A - 7
A.7 Applied Standards ................................................................................... A - 7

Doc.ID: 34938, Rev 1.0 Page v
CP342 Preface
CUSTOMER SPECIFIC
P R E L I M A R Y
List of Tables
1-1 System Relevant Information ................................................................... 1 - 6
1-2 Main Specifications ................................................................................ 1 - 11
1-3 Applied Standards .................................................................................. 1 - 13
1-4 Related Publications .............................................................................. 1 - 13
2-1 CompactPCI Bus Connector J1 Pinout .................................................... 2 - 6
2-2 Rear IO CompactPCI Bus Connector J2 Pinout (CP342-RIO only) ......... 2 - 7
2-3 Pinouts of J3A/B Based on the Implementation ....................................... 2 - 8
2-4 SFP Cage, J6 and J7, Pinout ................................................................... 2 - 9
A-1 Pinouts of J10A/B Based on the Implementation ..................................... A - 5
A-2 Rear IO J1 Pinout (CPCI rJ2) .................................................................. A - 6
A-3 Main Specifications .................................................................................. A - 7
A-4 Applied Standards .................................................................................... A - 7

Page vi Doc.ID: 34938, Rev 1.0
Preface CP342
CUSTOMER SPECIFIC
P R E L I M A R Y
This page has been intentionally left blank.

Doc.ID: 34938, Rev 1.0 Page vii
CP342 Preface
CUSTOMER SPECIFIC
P R E L I M A R Y
List of Figures
1-1 CP342 Application System Interfacing Diagram ...................................... 1 - 7
1-2 CP342 System Level Interfacing Diagram ............................................... 1 - 8
1-3 CP342, CP342-SFP, and CP342-RIO Front Panels ................................ 1 - 9
1-4 CP342 Board (Top View) ....................................................................... 1 - 10
1-5 CP342_SFP Board (Top View) .............................................................. 1 - 10
1-6 CP342_RIO Board (Top View) ............................................................... 1 - 11
2-1 CP342 Board Level Interfacing ................................................................ 2 - 4
2-2 CPCI Connectors J1/J2 ........................................................................... 2 - 5
2-3 Dual Gigabit Ethernet Connector J3A/B .................................................. 2 - 8
2-4 SFP Cages, J6 and J7, and Status LEDs ................................................ 2 - 9
A-1 CP-RIO3-42 Front Panel .......................................................................... A - 3
A-2 CP-RIO3-42 Board and J1 Connector Pin Layout ................................... A - 4
A-3 Dual Gigabit Ethernet Connector J10A/B ................................................ A - 5

Page viii Doc.ID: 34938, Rev 1.0
Preface CP342
CUSTOMER SPECIFIC
P R E L I M A R Y
This page has been intentionally left blank.

Doc.ID: 34938, Rev 1.0 Page ix
CP342 Preface
CUSTOMER SPECIFIC
P R E L I M A R Y
Proprietary Note
This document contains information proprietary to Kontron. It may not be copied or transmitted
by any means, disclosed to others, or stored in any retrieval system or media without the prior
written consent of Kontron or one of its authorized agents.
The information contained in this document is, to the best of our knowledge, entirely correct.
However, Kontron cannot accept liability for any inaccuracies or the consequences thereof, or
for any liability arising from the use or application of any circuit, product, or example shown in
this document.
Kontron reserves the right to change, modify, or improve this document or the product de-
scribed herein, as seen fit by Kontron without further notice.
Trademarks
This document may include names, company logos and trademarks, which are registered
trademarks and, therefore, proprietary to their respective owners.
Environmental Protection Statement
This product has been manufactured to satisfy environmental protection requirements where
possible. Many of the components used (structural parts, printed circuit boards, connectors,
batteries, etc.) are capable of being recycled.
Final disposition of this product after its service life must be accomplished in accordance with
applicable country, state, or local laws or regulations.

Page x Doc.ID: 34938, Rev 1.0
Preface CP342
CUSTOMER SPECIFIC
P R E L I M A R Y
Explanation of Symbols
Caution, Electric Shock!
This symbol and title warn of hazards due to electrical shocks (> 60V)
when touching products or parts of them. Failure to observe the pre-
cautions indicated and/or prescribed by the law may endanger your
life/health and/or result in damage to your material.
Please refer also to the section “High Voltage Safety Instructions” on
the following page.
ESD Sensitive Device!
This symbol and title inform that electronic boards and their compo-
nents are sensitive to static electricity. Therefore, care must be taken
during all handling operations and inspections of this product, in
order to ensure product integrity at all times.
Please read also the section “Special Handling and Unpacking
Instructions” on the following page.
Warning!
This symbol and title emphasize points which, if not fully understood
and taken into consideration by the reader, may endanger your health
and/or result in damage to your material.
Note ...
This symbol and title emphasize aspects the reader should read
through carefully for his or her own advantage.

Doc.ID: 34938, Rev 1.0 Page xi
CP342 Preface
CUSTOMER SPECIFIC
P R E L I M A R Y
For Your Safety
Your new Kontron product was developed and tested carefully to provide all features necessary
to ensure its compliance with electrical safety requirements. It was also designed for a long
fault-free life. However, the life expectancy of your product can be drastically reduced by im-
proper treatment during unpacking and installation. Therefore, in the interest of your own safety
and of the correct operation of your new Kontron product, you are requested to conform with
the following guidelines.
High Voltage Safety Instructions
Special Handling and Unpacking Instructions
Do not handle this product out of its protective enclosure while it is not used for operational pur-
poses unless it is otherwise protected.
Whenever possible, unpack or pack this product only at EOS/ESD safe work stations. Where
a safe work station is not guaranteed, it is important for the user to be electrically discharged
before touching the product with his/her hands or tools. This is most easily done by touching a
metal part of your system housing.
It is particularly important to observe standard anti-static precautions when changing piggy-
backs, ROM devices, jumper settings etc. If the product contains batteries for RTC or memory
back-up, ensure that the board is not placed on conductive surfaces, including anti-static plas-
tics or sponges. They can cause short circuits and damage the batteries or conductive circuits
on the board.
Warning!
All operations on this device must be carried out by sufficiently skilled
personnel only.
Caution, Electric Shock!
Before installing your new Kontron product into a system always
ensure that your mains power is switched off. This applies also to the
installation of piggybacks.
Serious electrical shock hazards can exist during all installation,
repair and maintenance operations with this product. Therefore,
always unplug the power cable and any other cables which provide
external voltages before performing work.
ESD Sensitive Device!
Electronic boards and their components are sensitive to static elec-
tricity. Therefore, care must be taken during all handling operations
and inspections of this product, in order to ensure product integrity at
all times.

Page xii Doc.ID: 34938, Rev 1.0
Preface CP342
CUSTOMER SPECIFIC
P R E L I M A R Y
General Instructions on Usage
In order to maintain Kontron’s product warranty, this product must not be altered or modified in
any way. Changes or modifications to the device, which are not explicitly approved by Kontron
and described in this manual or received from Kontron’s Technical Support as a special han-
dling instruction, will void your warranty.
This device should only be installed in or connected to systems that fulfill all necessary techni-
cal and specific environmental requirements. This applies also to the operational temperature
range of the specific board version, which must not be exceeded. If batteries are present their
temperature restrictions must be taken into account.
In performing all necessary installation and application operations, please follow only the in-
structions supplied by the present manual.
Keep all the original packaging material for future storage or warranty shipments. If it is neces-
sary to store or ship the board please re-pack it as nearly as possible in the manner in which it
was delivered. In the event that the original packaging material is not available for storage or
warranty shipments, packaging which complies with the standards indicated in section 1.8 may
be used to ensure the proper protection of this product.
Special care is necessary when handling or unpacking the product. Please, consult the special
handling and unpacking instruction on the previous page of this manual.

Doc.ID: 34938, Rev 1.0 Page xiii
CP342 Preface
CUSTOMER SPECIFIC
P R E L I M A R Y
Two Year Warranty
Kontron grants the original purchaser of Kontron’s products a TWO YEAR LIMITED HARDWARE
WARRANTY as described in the following. However, no other warranties that may be granted or
implied by anyone on behalf of Kontron are valid unless the consumer has the express written
consent of Kontron.
Kontron warrants their own products, excluding software, to be free from manufacturing and
material defects for a period of 24 consecutive months from the date of purchase. This warranty
is not transferable nor extendible to cover any other users or long-term storage of the product.
It does not cover products which have been modified, altered or repaired by any other party
than Kontron or their authorized agents. Furthermore, any product which has been, or is sus-
pected of being damaged as a result of negligence, improper use, incorrect handling, servicing
or maintenance, or which has been damaged as a result of excessive current/voltage or tem-
perature, or which has had its serial number(s), any other markings or parts thereof altered, de-
faced or removed will also be excluded from this warranty.
If the customer’s eligibility for warranty has not been voided, in the event of any claim, he may
return the product at the earliest possible convenience to the original place of purchase, togeth-
er with a copy of the original document of purchase, a full description of the application the
product is used on and a description of the defect. Pack the product in such a way as to ensure
safe transportation (see our safety instructions).
Kontron provides for repair or replacement of any part, assembly or sub-assembly at their own
discretion, or to refund the original cost of purchase, if appropriate. In the event of repair, re-
funding or replacement of any part, the ownership of the removed or replaced parts reverts to
Kontron, and the remaining part of the original guarantee, or any new guarantee to cover the
repaired or replaced items, will be transferred to cover the new or repaired items. Any exten-
sions to the original guarantee are considered gestures of goodwill, and will be defined in the
“Repair Report” issued by Kontron with the repaired or replaced item.
Kontron will not accept liability for any further claims resulting directly or indirectly from any war-
ranty claim, other than the above specified repair, replacement or refunding. In particular, all
claims for damage to any system or process in which the product was employed, or any loss
incurred as a result of the product not functioning at any given time, are excluded. The extent
of Kontron liability to the customer shall not exceed the original purchase price of the item for
which the claim exists.
Kontron issues no warranty or representation, either explicit or implicit, with respect to its prod-
ucts’ reliability, fitness, quality, marketability or ability to fulfil any particular application or pur-
pose. As a result, the products are sold “as is,” and the responsibility to ensure their suitability
for any given task remains that of the purchaser. In no event will Kontron be liable for direct,
indirect or consequential damages resulting from the use of our hardware or software products,
or documentation, even if Kontron were advised of the possibility of such claims prior to the pur-
chase of the product or during any period since the date of its purchase.
Please remember that no Kontron employee, dealer or agent is authorized to make any modi-
fication or addition to the above specified terms, either verbally or in any other form, written or
electronically transmitted, without the company’s consent.

Page xiv Doc.ID: 34938, Rev 1.0
Preface CP342
CUSTOMER SPECIFIC
P R E L I M A R Y
This page has been intentionally left blank.

Doc.ID: 34938, Rev 1.0 Page 1 - 1
CP342 Introduction
CUSTOMER SPECIFIC
P R E L I M A R Y
Introduction
Chapter 1
1

Page 1 - 2 Doc.ID: 34938, Rev 1.0
Introduction CP342
CUSTOMER SPECIFIC
P R E L I M A R Y
This page has been intentionally left blank.

Doc.ID: 34938, Rev 1.0 Page 1 - 3
CP342 Introduction
CUSTOMER SPECIFIC
P R E L I M A R Y
1. Introduction
1.1 System Overview
The CompactPCI board described in this manual operates with the PCI bus architecture to sup-
port additional I/O and memory-mapped devices as required by various industrial applications.
For detailed information concerning the CompactPCI standard, please consult the complete
Peripheral Component Interconnect (PCI) and CompactPCI Specifications. For further informa-
tion regarding these standards and their use, visit the home page of the PCI Industrial Comput-
er Manufacturers Group (PICMG).
Many system-relevant CompactPCI features that are specific to Kontron Modular Computers
CompactPCI systems may be found described in the Kontron CompactPCI System Manual.
Please refer to the section “Related Publications” at the end of this chapter for the relevant or-
dering information.
The CompactPCI System Manual includes the following information:
• Common information that is applicable to all system components, such as safety infor-
mation, warranty conditions, standard connector pinouts etc.
• All the information necessary to combine Kontron’s racks, boards, backplanes, power
supply units and peripheral devices in a customized CompactPCI system, as well as con-
figuration examples.
• Data on rack dimensions and configurations as well as information on mechanical and
electrical rack characteristics.
• Information on the distinctive features of Kontron CompactPCI boards, such as function-
ality, hot swap capability. In addition, an overview is given for all existing Kontron Com-
pactPCI boards with links to the relating data sheets.
• Generic information on the Kontron CompactPCI backplanes, such as the slot assign-
ment, PCB form factor, distinctive features, clocks, power supply connectors and signal-
ling environment, as well as an overview of the Kontron CompactPCI standard backplane
family.
• Generic information on the Kontron CompactPCI power supply units, such as the input/
output characteristics, redundant operation and distinctive features, as well as an over-
view of the Kontron CompactPCI standard power supply unit family.

Page 1 - 4 Doc.ID: 34938, Rev 1.0
Introduction CP342
CUSTOMER SPECIFIC
P R E L I M A R Y
1.2 Board Overview
1.2.1 Board Introduction
The CP342 board is a CompactPCI three speed Ethernet LAN controller for multiple server-to-
client networking functions. It provides dual independent Gigabit / Fast Ethernet interfaces.
Both interfaces are based on the Intell® Gigabit Ethernet PCI Bus LAN Controller 82546GB
with integrated physical layer interface (PHY).
CP342 is a 3U CPCI Ethernet board suitable for both 10Base-T, 100Base-TX, and 1000Base-
TX interfacing and includes all necessary features for auto-negotiation. Thus, 10/100/1000
Mbit/s transfer rates are supported by the board. In fact, provided that the network has the
speed capability, the CP342 switches automatically. Additionally, if the addressed network sta-
tion is compatible, it switches automatically to full-duplex mode.
The 3.3V signalling, 5V tolerant, board is designed to permit a very high PCI data bandwidth,
which is achieved thanks to a MAC with dual 64 kB configurable Transmit and Receive buffers.
The board does not have any jumpers and, therefore, does not require hardware configuration.
To make installation, repairs and updates easier, a PXE Boot allows the system to be started
from a different operating system via network provided the optional Boot Flash is installed.
Three versions of the board are available: the CP342 with a dual front panel RJ45 connector;
the CP342-RIO with no front panel connectors (signals are routed to J2 for rear IO capability);
the CP342-SFP with two Small Form-factor Pluggable (SFP) interfaces on the front panel. For
the CP342-RIO, there is a RIO module (CP-RIO3-42) with a dual RJ45 connector available.
1.2.2 Board Specific Information
Major board components of the CP342 board are:
• dual independent Gigabit Ethernet controller: Intel® 82546GB
• a Boot Flash (optional)
• a configuration EEPROM
• Magnetics (CP342, CP342-RIO)
• dual RJ45 connector (CP342)
• two SFP (small format pluggable) fiber optic connectors (CP342-SFP)
Other board features are:
• multiple server-to-client networking
• three speed operation: 10/100/1000 Mbit/s (the CP342-SFP supports only 1000 Mbits/s)
• auto-negotiation
• 64 kB Transmit and Receive buffers
• galvanic de-coupling
• optional rear IO capability (CP342-RIO plus CP-RIO3-42)

Doc.ID: 34938, Rev 1.0 Page 1 - 5
CP342 Introduction
CUSTOMER SPECIFIC
P R E L I M A R Y
1.3 Board Versions
1.3.1 CP342
This is the standard version of the CP342. It has a dual RJ45 connector on the front panel with
two LEDs integrated in each connector.
1.3.2 CP342-RIO
This version of the CP342 provides the basis for rear IO output. Both Ethernet channel signals
are routed to the J2 connector for rear IO capablility on backplanes which support rear IO.
There are no front panel connectors with this version, however, there are three operational
status LEDs for each channel available on the front panel. To support standard CompactPCI
rear IO, there is an optional rear IO module available, the CP-RIO3-42.
1.3.3 CP342-SFP
This version of the CP342 provides two SFP (small form-factor pluggable) cages at the front
panel for use with SPF transceivers (fiber optic or RJ45 type modules). In addition, there are
three operational status LEDs available for each channel.
1.3.4 Optional CP-RIO3-42 RIO Module for CP342-RIO
This optional module is designed for use with the CP342-RIO. It provides two rear IO Ethernet
channels with RJ45 interfacing (copper only)
Refer to Appendix A for further information on the CP-RIO3-42 module.
1.3.5 System Considerations
Within any given CompactPCI system there may be more than one CP342 board installed. The
mixing of different versions within a system is also permitted. Use of the CP342-RIO version
requires a backplane which supports rear IO. This may be a standard CPCI backplane with rear
IO slots or may be a customized backplane.
Note ...
This version of the CP342 is supplied only with SFP cages as receptacles for
SFP transceiver modules.
SFP transceiver modules are not a part of this product.

Page 1 - 6 Doc.ID: 34938, Rev 1.0
Introduction CP342
CUSTOMER SPECIFIC
P R E L I M A R Y
1.4 System Relevant Information
The following system relevant information is general in nature but should still be considered
when developing applications using the CP342.
1.5 Board Diagrams
The following diagrams provide additional information concerning board functionality and com-
ponent layout.
Table 1-1: System Relevant Information
SUBJECT INFORMATION
System Configuration The CP342 may be used in any CompactPCI system.
Master/Slave Functionality The CP342 can operate as a peripheral board (bus master capable).
Board Location in the System The CP342 board may be installed anywhere in a system except in the system slot
of a CompactPCI backplane. The CP342-RIO requires a rear IO capable slot for
use.
Hot Swap Compatibility The CP342 is not Hot Swap capable.
Operating Systems The CP342 can operate under the following operating systems:
Microsoft®Windows®XP
Microsoft®Windows®XP Embedded
Linux
VxWorks®
Please contact Kontron for further information concerning other operating sys-
tems.
LEGEND FOR FIGURE 1-2
CPCI CompactPCI
GbE Gigabit Ethernet
SFP Small Form-factor Pluggable
TSE Three Speed Ethernet (10/100/1000 Mbits/s)
TXRX Transceiver
