CyberData VoIP Desktop Intercom User manual

CyberData Corporation 2555 Garden Road Monterey, California 93940
[phone] [phone] www.cyberdata.net
CyberData Corporation
VoIP Desktop Intercom
VoIP Desktop Intercoms
SpeakerLoudspeaker Amp
Typical Installation
Generic PoE Hub
IP PBX ServerIP Phone
1 2 3 4 5 6 7 8
VoIP Desktop Intercom
Features
 PoE 802.3af enabled (Powered-over-Ethernet)
 SIP support
 Dual-speed Ethernet 10/100 Mbps
 Push-to-talk option
 Adaptive full-duplex voice operation
 Network web management
 Network adjustable speaker volume
 Network adjustable mic sensitivity
 Network downloadable firmware
 Doubles as a paging speaker
 Tamper-proof design
 Activity LED
 Wall-mount option
 Cable cover
The CyberData SIP-enabled VoIP Intercom is a
desktop version of our VoIP Intercom. The
intercom is compatible with most SIP-based IP
PBX servers that comply with SIP RFC 3261.
Ethernet I/F 10/100 Mbps
Dimensions
2 years limitedWarranty
010xxxPart Number
VoIP Desktop Intercom Specifications
Power Input PoE 802.3af compliant
or +5 volts at 1000mA
Regulatory Compliance FCC Class A, UL 60950
Protocol SIP RFC 3261 Compatible
G711, A-law and µ-lawPayload Types
Typical Applications
 Dedicated use phone
 Door entry phone
 Emergency phone
 Mass notification
930239A/080908CyberData Corporation 2555 Garden Road Monterey, California 93940
[phone] [phone] www.cyberdata.net
CyberData Corporation
CyberData Corporation
1.9” x 4.25” x 5.33” (H x W x D)
