Kopul CMX-1-V2 User manual

Thank you for choosing Kopul.
The CMX-1-V2 is a compact, camera-mountable
two-channel audio mixer ideal for shooting
videos with a DSLR camera or camcorder. It
features mono inputs for two separate
microphones and a stereo input for a stereo mic.
The levels of the left and right channels are
controlled with the dual trim control knobs.
Set the mono/stereo switch to mono (M) to send
the signal from a mono microphone to both left
and right channels. Select stereo (S) to record
with one stereo microphone or two mono
microphones. The mixed levels are output to the
mic input on your camera with the enclosed
coiled cable. The CMX-1-V2 features three
integrated shoe mounts for use with
microphones, wireless receivers, or other
mountable accessories.
DSLR Solutions
2-CHANNEL
MINI MIXER
with Shoe Bracket
CMX-1-V2

CMX-1-V2
Overview
Stereo Input
Stereo
output
Shoe mounting foot
Shoe mount
locking wheel
Mono
inputs

Mounting
shoes
Mono/
stereo
switch
Dual trim
control
knobs

Input Level
Frequency response
Dimensions (W × D × H)
Weight
-35 dBu minimum
20 Hz to 20 KHz (± 0.5 dB)
3
˝ × 2.3 ˝ × 2.2 ˝ (7.5 × 5.9 × 5.6 cm)
5.4 oz. (153 g)
Specications

One-Year Limited Warranty
This KOPUL product is warranted to the original purchaser to be free from defects in materials
and workmanship under normal consumer use for a period of one (1) year from the original
purchase date or thirty (30) days after replacement, whichever occurs later. The warranty
provider’s responsibility with respect to this limited warranty shall be limited solely to repair or
replacement, at the provider’s discretion, of any product that fails during normal use of this
product in its intended manner and in its intended environment. Inoperability of the product or
part(s) shall be determined by the warranty provider. If the product has been discontinued, the
warranty provider reserves the right to replace it with a model of equivalent quality and function.
This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration,
abuse, improper installation or maintenance. EXCEPT AS PROVIDED HEREIN, THE WARRANTY
PROVIDER MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES,
INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. This warranty provides you with specic legal rights,
and you may also have additional rights that vary from state to state.
To obtain warranty coverage, contact the Kopul Customer Service Department to obtain a return
merchandise authorization (“RMA”) number, and return the defective product to Kopul along with
the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s
own risk and expense.
For more information or to arrange service, visit www.kopulcables.com or call Customer Service
at 212-594-2353.
Product warranty provided by the Gradus Group.
www.gradusgroup.com
KOPUL is a registered trademark of the Gradus Group. © 2017 Gradus Group LLC. All Rights Reserved.
