HD-TVI XSEE932
SEE932Full HD Covert PIR Camera (TVI/AHD/CVI/CVBS)
Menu Description
The following menu description gives more in depth information about the menu options. In some
instances recommendations are made to hopefully enhance the results. However every installation
will be different and there will occasions when alternative solutions may be more suitable.
Leave setting on Manual as fixed board lens fitted
N/A
SHUTTER
AGC
SENS-UP
BRIGHTNESS
D-WDR
DEFOG
RETURN
AUTO-
1/25,1/50,FLK,1/200,1/400,1/1000,1/2000,1/5000,
1/10000,1/50000, x2/x4/x6/x8/x10/x15/x20/x25/x30
0 ~ 15
OFF –AUTO
x2,x4,x6,x8,x10,x15,x20,x25,x30
1 ~ 100
ON
LEVEL 0 ~ 8
RETURN
OFF –AUTO
POS / SIZE
GRADATION 0 ~ 2
DEFAULT
RETURN
SHUTTER Auto / Manual
AUTO-1/25,1/50,FLK,1/200,1/400,1/1000,1/2000,1/5000,
1/10000,1/50000, x2/x4/x6/x8/x10/x15/x20/x25/x30
Shutter speed changes allow you to freeze moving objects without ghosting but reduce the amount
of available light the faster the shutter operates. At night the slower the shutter speed the more light
is available. The Flicker option sets the shutter speed at 1/250 that synchronises with fluorescent
tubes so that the pulsing effect is minimised.
Recommendation is to leave this in Auto.
AGC 1 ~ 15 (Default = 15)
For better performance in low light conditions the AGC (Automatic Gain Control) can be increased.
This has the effect of making the picture brighter but it may also add more noise as it amplifies all
aspects of the video signal.
Recommend AGC is decreased below 15 if Sensup is increased over x2.
SENS-UP OFF –AUTO - x2,x4,x6,x8,x10,x15,x20,x25,x30
The Sens-Up option allows the shutter speed to be reduced allowing additional light to be captured.
Increasing brightness helps night time viewing (see BRIGHTNESS setting above). If set too high
and Sensup is slowing shutter speed down to a lower speed than any movement speed, ghosting can
occur. Recommend that Sensup is switched on to x8 or above in low light conditions.
