KRK Full-line Speaker Monitor User manual

STUDIO MONITORING SOLUTIONS

KRK Systems is one of the world’s most respected manufacturers of studio
reference monitors. We achieved and have maintained this position by focusing
on accuracy, honesty and balanced spectral response with the goal of making
it possible for recording engineers to hear every nuance of the audio being
reproduced. KRK monitors are tools that are cherished by their owners as partners
in crafting great music and mixes.
For over a quarter of a century, we have been driven by a design philosophy of
precision, transparency, and at response. Our products deliver on this promise
through a combination of solid design and technical innovation. We were among
the rst manufacturers to take a quantum leap in woofer performance through
the use of Kevlar. Our VXT monitors are constructed from a remarkable material
that allows for its diraction-reducing shape while increasing internal cabinet
volume for better low frequency extension. The pinnacle of audio performance,
the KRK Expose E8B uses composite materials that provide the ultimate in detail
and accuracy. We were among the rst to introduce active (powered) monitors
that precisely match ampliers and electronics with the transducer elements.
These are all examples of innovations that produce tangible acoustic benets, not
a pursuit of the latest trends or fads. Our focus is your mix, and every monitor,
headphone and room correction system delivers on this commitment.
Whenyou chooseKRK, you join a family of elite producers, composers, performers
and engineers that rely on KRK products to deliver accurate sound reproduction
and acoustic precision, day in and day out. The signature yellow woofer of a KRK
monitor tells the world that you and your monitor are true to the mix and true
to your craft. KRK studio monitors enable you to condently make the critical
decisions that impact the music and audio program material the world listens to.
Our Focus.Your Mix.
Eric Clapton •Sting •Eddie Van Halen •Hans Zimmer •Billy Joel •Ozzy Osbourne •Metallica •Stevie Wonder •Timbaland •Boyz II Men
Jacquire King •Rodney “Darkchild” Jerkins •Daniel Porter •Cenzo Townshend •Mike Shipley •Ryan Hewitt •David Bascombe
Hit Factory •American Film Institute •Galaxy Studios •Sony Music •Fox Feature Film Division •Abbey Road Studios
Skywalker Sound •Jim Henson Studios
KRK®SYSTEMS
A SAMPLE OF USERS
Chestnut Studios, London

Using professional monitors in an acoustically correct studio is ideal for recording, mixing and mastering - but there are times when portability, sound isolation and
freedom from your environment’s acoustic limitations are the priority. At KRK, our passion is monitoring, whether the monitor is on the console or on your head.
Being able to discern the most subtle dierences in pitch, timbre and tone helps you to get it right every mix, every take, every performance. KRK Headphones
provide a precise listening experience that takes you from personal studio to commercial studio to on-the-go track evaluations and they allow you to evaluate and
enjoy your music with the consistent voicing philosophy and honest reproduction top producers, studio musicians, performers and engineers have come to trust.
Whether you are listening to some tracks, or tracking your next recording, the KNS series gives you the famous KRK sound in a closed-back around-the-ear design
with highly isolated surround pads. Having“One Voice”that consistently gives you accurate reproduction of your music or mix will help you achieve just what the
artist intended -- especially when the artist is you.
KNS SERIES
KNS8400 / KNS6400
Sensitivity / Eciency:
97 dB SPL @1mW / 95dB SPL @1mW
Freq Response:
5Hz-23 kHz / 10Hz-22 kHz
Total Harmonic Distortion: <0.1%
Rated Impedance: 36 ohms
Ambient Noise Isolation:
Up to 30 dBA / Up to 26 dBA
The KRK Exposé E8B is the agship of KRK’s product line. Dollar for dollar, mix for mix Exposé E8B blends technology and form to achieve a level of clarity and sonic
accuracy that is unprecedented.This mid-eld monitor utilizes two discrete high-power Class A/AB power ampliers — one each for the tweeter and woofer —
with symmetrical heat sinks built into the sides of the cabinet for cool, reliable operation. These two ampliers are perfectly mated to the exceptional transducer
complement.The high frequencies are reproduced using a revolutionary tweeter made of beryllium and aluminum (AlBeMet).This advanced composite material
deliverssmooth and incrediblydetailed highs, thanksto the strengthand ultra-lowmass of thisamazing tweeter.This high-frequency performance is teamed with
a signature KRK yellow multilayered Kevlar/Rohacell woofer. The Kevlar/Rohacell“sandwich”provides strength and stiness without excess mass, resulting in bass
and transients that are tight, punchy, and true to life and your mix. These components are housed in a stunning, highly functional enclosure that features thick,
non-parallel, internal walls that help eliminate standing waves, a non-slip, sound absorbing rubberized base, and magnetic shielding for use in close proximity
to video monitors.The Exposé E8B is the pinnacle of studio monitor performance and reinforces KRK’s reputation as a manufacturer of premium studio reference
monitors.
EXPOSÉ E8B
Exposé E8B
1”AlBeMET (aluminum/beryllium) Inverted Dome Tweeter
8”Dual Layer Kevlar/Rohacell Woofer
Class A/AB Power Ampliers / 240 watts
Freq Response: 40Hz – 30kHz
Max Peak SPL: 115 dB
“With KRK Expose I was looking for a pair of speakers that were
consistent, and were easy to carry with me, that had enough
power to allow me to turn them up and be able to fill the control
room with music, but also a speaker that I could turn down and
get musical balances, and know that what I was hearing in the
studio I was also taking home. And it was a speaker I just bonded
with right away.”
Ed Cherney
Grammy andTEC award winning producer and engineer
The first thing I noticed was the comfort...just great. Then I was extremely impressed with the sound quality...clear and
natural. What struck me was how they didn’t sound as much like headphones, but more like KRK studio monitors. The more
I use KRK, from the headphones to my V8s to my E8s...what I have come to expect and enjoy is the extremely accurate and
consistent reproduction of sound. Just fantastic!” Johnny A.
Guitar Virtuoso/ Blues Artist of the Year 2010
EXPOSÉ TECH NOTE:
The E8B’s massive woofer construction is that of a
multi-layered sandwich, consisting of two layers
of Kevlar with a layer of Rohacell in between. The
woofer’s construction reduces distortion for greater
signal reproduction accuracy.
KNS TECH NOTE:
An innovative headphone acoustical system brings a
new level of headphone performance. Replaceable
components for long life.
KNS8400 features a detachable / replaceable sleek prole in-line high quality
volume control, and ear cushions with acoustic memory foam.

Professional recording studios, broadcast studios, serious project studios... these are demanding applications for any monitor. If you need more power, more
accuracy, more precision, more mounting options, look no further than KRK’sVXT line. Drawing upon the design characteristics of our Exposé E8B, theVXT product
family consists of the VXT8 near/mid-eld, theVXT6 neareld, and the VXT4 neareld, with bass response that is remarkable for such a compact cabinet.
All three models have a visually striking enclosure made out of structural foam. This material increases speaker performance by reducing cabinet resonance while
improving structural integrity. Due to its rigidity, this material allows the VXT to have more interior volume than other similarly sized speakers, which results in
extended low-frequency response.The VXT’s sleek curvature provides excellent imaging and a wider sweet spot giving engineers greater freedom to accurately
work their mix across the whole desk. Integrated in the front, the slotted bass port eectively minimizes port turbulence.The domed tweeter is made from true
silk for fast transient response.The low distortion woofer design features a sti and lightweight cone with a robust motor to control high dynamic peak excursion,
while delivering tight and accurate bass. Both transducers have vented formers to remove heat and reduce the eects of power compression — enabling these
monitors to maintain their sonic signature hour after hour, day after day. With uncompromising attention to detail that includes tamper resistant switch covers,
integrated mounting support, optional front grills and more, theVXT Series is an outstanding choice for a broad range of monitoring applications.
VXT SERIES
VXT 4
1”Silk Dome Ferrite Tweeter
4” Woven Kevlar Woofer
Class A/B Power Ampliers / 45 watts
Freq Response: 66Hz - 22kHz
Max Peak SPL: 107dB
VXT 6
1”Silk Dome Ferrite Tweeter
6” Woven Kevlar Woofer
Class A/B Power Ampliers / 90 watts
Freq Response: 49Hz - 22kHz
Max Peak SPL: 111dB
VXT 8
1”Silk Dome Ferrite Tweeter
8” Woven Kevlar Woofer
Class A/B Power Ampliers / 180 watts
Freq Response: 37Hz - 22kHz
Max Peak SPL: 114 dB
“What I like about the KRK VXT is two-fold: The Kevlar woofer is a wonderful thing; it gives and takes as
demanded by the music. The silk tweeter gives you a little more separation between the minute frequencies.
I monitor at whisper-quiet levels to downright loud, and there’s no ear-fatigue at all. I don’t know how you can make that
accurate of a speaker at the price range you do!” Dan Spitz
Executive Recording & Mix Engineer / Lead Guitar - Anthrax
VXT TECH NOTE:
High density / low resonance CAD optimized enclosure
with complex shapes and non-parallel walls for
improved structural integrity and rigidity resulting in
an extended low-end response.

Just because your budget is smaller than that of a mega-studio doesn’t mean you don’t deserve a great set of monitors. For years, KRK Rokit
monitors have provided accurate sound for small personal, project as well as pro studios. The Rokit family brings KRK quality monitoring to
the masses.
All Rokits feature curved edges to prevent problems caused by early sound wave reflections of a traditional box enclosure. This results in a
better image in a wider area so even with small head movements you are always getting the best sound-staging. Rokit G2s also feature a
great looking cabinet with a front-firing bass port and a glass-aramid composite woofer for tight, punchy bass. The soft-domed tweeters
provide silky-smooth high-frequency response that does not fatigue. Dual high-power amplifiers in each speaker and active crossovers
provide solid power and crystal-clear detail. And Rokits are easy to connect in any desktop or studio environment by offering the flexibility
of RCA/Phono, ¼” and XLR inputs.This latest evolution in the Rokit series features an incredibly accurate response curve , and delivers
professional level studio monitor performance at an incredibly affordable price.
The newest addition to the family, the Rokit RP10-3, is a Mid-field 3-way monitor system in a compact form factor and at a breakthrough
price that delivers loud and accurate sound reproduction to satisfy professional needs. The RP10-3 will suit commercial facilities in need
of more capable mid-fields as well as space and budget conscious private studios. The high SPL output makes it capable of handling
challenging high dynamic tracks for all genres of music. The Rokit RP10-3 offers location flexibility by placing the tweeter and midrange
in a unique rotatable housing.Whether they are vertical, placed on their side or wall mounted – the proper orientation of the acoustic axis
can be maintained!
Need Rokit Powered performance in a passive configuration? Check out the KRK R6 at www.krksys.com
ROKIT®POWERED
Rokit 5 G2
1” Soft Dome Tweeter
5”Glass Aramid Composite Woofer
Class A/B Power Ampliers / 45 watts
Freq Response: 52Hz - 20kHz
Max Peak SPL: 106 dB
Rokit 6 G2
1”Soft Dome Tweeter
6”Glass Aramid Composite Woofer
Class A/B Power Ampliers / 68 watts
Freq Response: 48Hz - 20kHz
Max Peak SPL: 107 dB
Rokit 8 G2
1”Soft Dome Tweeter
8”Glass Aramid Composite Woofer
Class A/B Power Ampliers / 90 watts
Freq Response: 44Hz - 20kHz
Max Peak SPL: 109 dB
Rokit 10-3
1”Soft Dome Tweeter
4”Glass Aramid Composite Midrange
10”Glass Aramid Composite Woofer
Class A/B Power Ampliers / 140 watts
Freq Response: 35Hz - 20kHz
Max Peak SPL: 113 dB
“KRK Rokit 5’s are true and consistent -- not hyped sounding. They also make you work for a great result which I like.
When the mix is sounding huge on them -- then I know I’m finished.”
Jacquire King
Record Producer, Mixer, and Engineer
ROKIT TECH NOTE:
Front-ring port provides low freq extension without
boundary coupling. Radically curved front plate
design virtually eliminates diraction distortion. The tweeter and midrange housing rotates for horizontal placement.

Surround sound mixing and today’s bass-heavy music demand accurate sound reproduction in the bass frequencies. Subwoofers allow you to use smaller main
monitors, make it possible to monitor the essential low frequency range and can be a great solution for space-challenged control rooms or mixing environments.
When dealing with subsonic frequencies -- if they cannot be heard accurately they cannot be mixed accurately.
The KRK12sHO powered subwoofer is the perfect High Output choice for professional studios, where ultra-accurate bass extension and maximum sound levels
are required. Powered by a massive 400 watt amplier and a strengthened version of our signature Kevlar woofer with ultra dense rigid multilayer dust cap, the
KRK12sHO is the no-compromise way to hear what is happening in the depths of your mix, capable of generating 123dB of SPL.
The KRK12s powered subwoofer is an ideal complement to KRKVXT series, KRK Rokit series, or any other 6”-10”studio monitor. The KRK12s is designed to extend
the response of an existing monitor system so that the low-frequency portion of the mix can be engineered. The KRK12s features the powerful accurate and low
distortion sound that is the hallmark of all KRK monitor systems. An ecient and low distortion 240-watt amplier makes the KRK12s perfect for project and
professional studio applications that require increased signal pressure.
The KRK10s powered subwoofer has a smaller form factor than the 12”models and is a great addition in a studio running KRK Rokit,VXT or any other 4”-8”studio
monitor. The KRK10s subwoofer also features a great looking cabinet that echoes the curved edges of the Rokit and VXT monitors. The front-ring bass port and
KRK’s signature yellow glass-aramid composite woofer ensure accurate and powerful low-end punch.
POWERED SUBWOOFERS
KRK10s
10”Glass Aramid Composite Woofer
150 Watts RMS powered subwoofer for studio use
Freq Response: 34Hz – 50Hz to 130HzVariable
Max Peak SPL: 113 dB
Class A/B Power Amplier / 150 Watts Continuous
KRK12s
12”Kevlar Woofer
240 Watts RMS powered subwoofer for studio use
Freq Response: 32Hz - 139Hz (left / right inputs)
Max Peak SPL: 119.5 dB
Class A/B Power Amplier / 240 Watts Continuous
KRK12sHO
12”woven Kevlar High Performance woofer
400 Watts RMS powered subwoofer for studio use
Freq Response: 29.2Hz - 60Hz - 160Hz (left / right inputs), 29.1Hz - 211Hz (LFE input)
Max Peak SPL: 123 dB
Class A/B Power Amplier / 400 Watts Continuous
“I’ve always loved having a sub to wow record companies or artists when playing back a song or mix. The truth is, most subs
are only good for that purpose and are not accurate enough to work with when making a record. The KRK12s changed that.
It’s very accurate and actually makes my Expose’s sound even better!”
Martin Harrington
Writer / Producer
SUBWOOFER TECH NOTE:
KRK Subwoofers oer high dynamic range
ampliers for stereo and surround applications. KRK
12”models are equipped with low-frequency eect
(LFE) capabilities. All are suitable for any music
genre, game development and motion picture
soundtracks.
All KRK subwoofers allow use of an
external footswitch to bypass the
subwoofer.

A great mix starts with a great recording room. But when it comes to achieving the most accurate mix, your room may have the upper hand. Like any room, your
studio’s acoustics include oending frequencies and room reections, and none of these are helping your mix. Getting a handle on these problems has traditionally
meant the installation of soft foam or fabrics, and that’s a great start. But now you can get even closer to a perfect room, and a perfect mix, because the future
of studio sound is here, and it’s called ERGO.
HEAR THE DIFFERENCE
KRK, long known for highly accurate studio monitors brings you ERGO (Enhanced Room Geometry Optimization). ERGO is an audio recording interface / room
correction system designed to measure and analyze phase/frequency problems within a listening environment. The powerful digital signal processor in the ERGO
unit processes audio to correct for the oending issues. So, you can stop worrying about your studio’s acoustics and start focusing on your mix! ERGO’s high-end
sound quality makes it perfect for the discriminating audio professional, while the aordable price puts it within reach of the typical recording hobbyist. Every
studio needs an ERGO, because even the most accurate monitor in an imperfect room isn’t going to solve mixing problems, but ERGO will. ERGO also makes your
mix translate from the studio to dierent environments.
THE BEST APPROACH
While many conventional room correction systems utilize simple analysis and limited bands of EQ (often fewer than 8), ERGO uses multiple measurements and
proprietary algorithms to create a 3D image of the room, and then applies 1024 dynamic lters to control the audio environment. Our 3D model allows users
to preserve the“good”characteristics of the room, while correcting the bad... ERGO doesn’t color the sound or produce an articially sterile environment. ERGO
produces the best mix for a given room; a mix that will translate better to other listening environments, since it was mixed in a“perfect”room.
ERGO
“Adding the ERGO to our setup has just further improved our experience with KRK by balancing our brand new studio without
having to discover and correct our rooms flaws through trial and error. It also helps to untie us from the studio by enabling
us to partially control any makeshift recording space we may end up in. I have a feeling that will be very useful with the
amount of time we spend on the road.” Manchester Orchestra
The sophisticated room analysis and correction system within ERGO, called“RoomPerfect” was developed by
Lyngdorf Audio in Denmark after many years of R&D work. The patented algorithm in the system compares
many measurements and corrects for phase and frequency problems using thousands of lters, not just a few.
The result is the most accurate mix. ERGO, analyze this!
Lyngdorf Audio utilizes some of the best audio engineers in the world to develop superior technology. Lyngdorf
Audio is the industry leader and cutting-edge digital audio company and we are proud to exclusively license
their technology.
While conventional room correction systems utilize simple analysis and limited bands of EQ (often fewer than 8), ERGO
uses multiple measurements and proprietary algorithms to create a 3D image of the room, and then applies 1024
dynamic filters to control the audio environment. Our 3D model allows users to preserve the “good” characteristics
of the room, while correcting the bad... ERGO doesn’t color the sound or produce an artificially sterile environment.
ERGO produces the best mix for a given room; a mix that will translate better to other listening environments, since
it was mixed in a“perfect” room
No Room Correction The Competition’s Room Analysis ERGO’s Room Analysis ERGO’s Room Correction
ROOMPERFECT™TECHNOLOGY

KRK USER PROFILES
THE AMERICAN FILM INSTITUTE: FILM PRESERVATION & EDUCATION HOT CHELLE RAE: POP ROCK BAND
DANIEL LEVITIN: RESEARCH JACQUIRE KING: PRODUCER
RON FAIR: RECORD LABELS
SONY ELECTRONICS, INC.: INNOVATORSRODNEY“DARKCHILD”JERKINS: SONGWRITER/PRODUCER
BOYZ II MEN : R&B LEGENDS
KRK monitors are used worldwide in small project studios and world-class mixing rooms. KRK’s are also found in numerous applications outside of recording,
including broadcast, corporate facilities and video post production. Whether you are a producer, engineer, musician or broadcaster -- KRK has products that t your
style and your commitment to great sound.
TheAmerican Film Institute(AFI),foundedin1967,hasbeenaquintessentialforceinspiringtheexchange
of ideas between the entertainment and technology communities, especially in terms of“digital media”.
Intrinsic to “digital media” is high quality sound production, and this starts with quality monitoring
systems. Recently, AFI equipped 15 of their Editing Suites with 15 pairs of KRK Systems’VXT4 studio
monitors after receiving a number of complaints from AFI Fellows about their previous speakers not
translating from one environment to the next. Editing Fellows at the AFI Conservatory are responsible to
post the sound on more than 80 lms per year.
Currently riding a massive wave of millions of views on YouTube for the single “Tonight, Tonight,” the
band Hot Chelle Rae is destined for star status. Peaking on the Billboard Hot 100 chart at number seven
and now platinum “Tonight, Tonight,” oers bold, swaggering vocals, monster sing-along choruses,
crunching rock guitar and a propulsive rhythm section that just won’t quit. For on-the-go band member
Nash Overstreet (lead guitar/vocals), KRKVXT4s monitors save the day with accurate, portable reference
monitoring for projects in any acoustic environment or situation. According to Overstreet, “Having an
accurate mix/reference is crucial. Having monitors as small as the KRKVXT4s, which deliver great sound
WHILE being small enough to set up as studio reference monitors in a hotel room, green room or back
lounge of the bus is ideal.”
DanielJ. Levitinrunsthe Laboratoryfor MusicalPerception,Cognition,and expertiseat McGill University,
where he holds the James McGill Chair and the Bell Chair in the Psychology of Electronic Communication.
Before becoming a neuroscientist, he worked as a session musician, sounds engineer, and record
producer with artists such as Stevie Wonder and Blue Öyster Cult. He has published extensively in
scientic journals and music magazines such as Grammy and Billboard.
Talent, devotion and determination, you’ll nd all three in Jacquire King. Born in Washington D.C., he
knew by the age of 18 that recording and mixing music was the only thing he wanted to do. Now he’s
worked in cities around the world and is a multiple Grammy-winning record producer and mix engineer
working with some of the biggest names in music business. Most recently he shared in a 2009 Grammy
Award for Record of theYear with producer Angelo Petraglia for the Kings of Leon’s“Use Somebody”from
the band’s release Only By the Night. He’s also worked with Tom Waits, Modest Mouse, Mutemath, Cold
War Kids, Norah Jones and Buddy Guy to name a few.
Over the past ve years the Geen Records Chairman has produced hits for Mary J. Blige, The Pussycat
Dolls, The Black Eyed Peas, and Keyshia Cole listening exclusively to KRKs. Fair tells us, “KRKs are the
benchmark for me. In production, in nal mixes, in casual listening sessions: it all leads back to KRKs.
I have brought them to mix rooms, mastering rooms and living rooms in order to establish that what
I’m hearing — I’m hearing.” KRKs are rened, pristeen, and analytical, while at the same time kick
serious ass, impress the hell out of artists, dazzle the promotion sta and deliver an unforgettable sonic
impression.”
Sony Electronics, Inc. exhibits at key industry trade shows and events throughout the year. To best
showcase its concepts, products and technologies to customers, Sony relies on KRK VXT8 powered
monitors to provide accurate audio to properly demonstrate its latest products. In the past year, Sony
has depended on the superb quality of the VXT8’s at the CEDIA, CinemaCon and NAB shows in its HD
theater demonstration room for the SRX-R320 4K Digital Cinema Projector. Pristine performance is
critical at these events because those in attendance are the most discerning engineers from their elds,
inuencing purchasing decisions. Accurate audio playback, sound quality, reliably and ruggedness of the
KRK VXT8’s allows Sony to portray its products’capabilities in the most positive light.
Rodney“Darkchild”Jerkins has worked with some of the biggest names in the music industry including
Britney Spears, Lady Gaga, Alicia Keys, Jennifer Lopez, and Beyonce to name a few. By the age of ten,
“Darkchild” knew he wanted to be a producer and began landing garage-style production gigs. He
entered a professional studio at the age of sixteen working with Patti LaBelle, and hasn’t looked back. In
1999, Jerkins won a Grammy with Destiny’s Child for “Say My Name”. He has produced music in a variety
of genres, from hip-hop and dance to country and gospel, and was a producer and mentor on season 10
of American Idol.
Celebrating their 20th Anniversary this year, legendary R&B group Boyz II Men redened and
revolutionized the genre. The group has created some of the most celebrated songs and timeless classics
of the past two decades, and stands as one of the last truly iconic bands in the business.Their 13 Grammy
Awards are just the tip of the iceberg: throughout their 20-year career, Boyz II Men have also won a
whopping 16 American Music Awards, 9 Soul Train Awards, 3 MTV Awards, 3 Billboard Awards, and a
long-awaited 2012 star on the Hollywood Walk of Fame. Composed of Nate Morris,Wanya Morris, and
Shawn Stockman, Boyz II Men remains the best-selling R&B group of all time, with an astounding 64
million albums sold. And for Boyz II Men the hits just keep on coming—the group will release an
exclusive 20th Anniversary Album and continues to tour across the world.

TECHNICAL SPECIFICATIONS
KRK Systems uses state of the art tools to design and test its products. Additional technical information can be found in the product datasheets at www.krksys.com (Support/Product Documentation). Passion for audio is intrinsic in our culture and pushing the levels of performance each time we develop a new product is what drives our team. Some of the most advanced software applications
are used to model, analyze and predict the performance of every component or assembly used in our loudspeaker system. Highly complex virtual models of mechanical, electrical and acoustic
performance are evaluated, adapted and optimized. Prototypes are assembled and analyzers are used to evaluate the performance of the drivers, identify linear and non-linear parameters as well
as distortion and thermal anomalies. Acoustic measurement tools are used to perform time, energy, frequency and wavelet analysis to allow visibility into the entire performance characteristics of
the systems.
The most important tool however, is our ears! All the science in the world won’t replace the value of human hearing as an integrated phase in the voicing process. A panel of accomplished producers,
engineers and artists are part of every product we develop. Each panelist has undergone rigorous testing of their hearing so that subjective perception is closely tied to objective analysis. Their
combined expertise in the technology of acoustics and the art of music is what makes KRK products exceptional.
Model Exposé E8B VXT 4 VXT 6 VXT 8
Conguration 2-Way 2-Way 2-Way 2-Way
System type Active Studio Monitor Active Studio Monitor Active Studio Monitor Active Studio Monitor
Low-Frequency Driver 8" Dual Layer Kevlar/Rohacell woofer 4" Woven Kevlar woofer 6" Woven Kevlar woofer 8" Woven Kevlar woofer
Mid-Frequency Driver N/A N/A N/A N/A
High-Frequency Driver 1" AlBeMET (aluminum/beryllium) inverted dome tweeter 1" silk dome tweeter 1" silk dome tweeter 1" silk dome tweeter
Frequency Response 40Hz - 30kHz 66Hz - 22kHz 49Hz - 22kHz 37Hz - 22kHz
Max Peak SPL 115 dB 107 dB 111 dB 114 dB
Amplier Class Class A-B Class A-B Class A-B Class A-B
PowerOutput 240W 45W 90W 180W
High Frequency 120W 15W 30W 60W
Mid Frequency N/A N/A N/A N/A
Low Frequency 120W 30W 60W 120W
Input Impedance (Ohms) 10 K Ohm balanced 10 K Ohm balanced 10 K Ohm balanced 10 K Ohm balanced
HF Level Adjust -2dB, -1.5dB, -1dB, -0.5dB, 0dB, +0.5dB,+1.0dB LF N/A +1dB shelf / Flat / -1dB shelf +1dB shelf / Flat / -1dB shelf
HF Shelf -2dB, -1.5dB, -1dB,-0.5dB, 0dB, +0.5dB, +1.0dB N/A N/A N/A
LF Level Adjust -3dB @ 45Hz, -3dB @ 50Hz, -3dB @ 65Hz N/A whole, half,quar ter whole, half, quarter
SystemVolume (-30dB - +6dB) (-30dB - +6dB) (-30dB - +6dB) (-30dB - +6dB)
Auto Mute N/A (on / o) (on / o ) (on / o)
Indicators Power Power, Clip, Limit Power, Clip, Limit Power, Clip, Limit
Indicator Control N/A Clip Indicator (On / O / Limit) Clip Indicator (On / O / Limit) Clip Indicator (On / O / Limit)
Input Connectors:
RCA N/A N/A N/A N/A
1/4" N/A Balanced 1/4"/XLR Combo Balanced 1/4"/XLR Combo Balanced 1/4"/XLR Combo
XLR Balanced XLR Balanced 1/4"/XLR Combo Balanced 1/4"/XLR Combo Balanced 1/4"/XLR Combo
Ground Lift N/A On / O On / O On / O
AC Power Input Selectable 100V, 120V, 230V, 240V (50Hz - 60Hz) Selectable 110V-120V / 220V-240V (50Hz - 60Hz)or
100V (50Hz - 60 Hz)
Selectable 110V-120V / 220V-240V (50Hz - 60Hz) or
100V (50Hz - 60 Hz)
Selectable 110V-120V / 220V-240V (50Hz - 60Hz) or 100V
(50Hz - 60 Hz)
Enclosure Construction 25mmMDF Structural Foam Structural Foam Structural Foam
Finish Black Textured Paint Black Textured Paint BlackTextured Paint BlackTextured Paint
Port Conguration Front ring slot port Front ring slot port Frontring slot por t Front ring slot port
Grille N/A Optional Optional N/A
Mounting Bottom Bottom Bottom Bottom
Compatable OmniMount 120.0WBX 20.5WBX 30.0 WBX 60.0 WBX
Dimensions (H x W x D) 19.3" (491mm) x 14.6" (370mm) x 14" (355mm) 10" (254mm) x 7.34" (186mm) x 7.48" (190mm) 14.36" (365mm) x 10.35" (263mm) x 9.66" (245mm) 17.06" (433mm) x 12.51" (318mm) x 11.66" (296mm)
Weight 67 Lbs. (30.4 Kg.) 14 Lbs. (6.36 Kg.) 27 Lbs. (11.6 Kg.) 41 Lbs. (16.5 Kg.)
Model Rokit 5 G2 Rokit 6 G2 Rokit 8 G2 Rokit 10-3
Conguration 2-Way 2-Way 2-Way 3-Way
System type Active Studio Monitor Active Studio Monitor Active Studio Monitor Active Studio Monitor
Low-Frequency Driver 5"Aramid Glass Composite woofer 6" Aramid Glass Composite woofer 8" Aramid Glass Composite woofer 10" Aramid Glass Composite woofer
Mid-Frequency Driver N/A N/A N/A 4" Aramid Glass Composite Midrange
High-Frequency Driver 1" soft dome tweeter 1" soft dome tweeter 1" soft dome tweeter 1" soft dome tweeter
Frequency Response 52Hz - 20kHz 48H z - 20kHz 44Hz- 20kHz 31Hz - 20kHz
Max Peak SPL 106 dB 107 dB 109dB 113 dB
Amplier Class Class A-B Class A-B Class A-B Class A-B
Power Output 45W 68W 90W 140W
High Frequency 15W 18W 20W 30W
Mid Frequency N/A N/A N/A 30W
Low Frequency 30W 50W 70W 80W
Input Impedance (Ohms) 10 K Ohm balanced 10K Ohm balanced 10 K Ohm balanced 10 K Ohm balanced
HF Level Adjust -2dB, -1dB, 0, +1dB -2dB, -1dB, 0, +1dB -2dB, -1dB, 0, +1dB -2dB, -1dB, 0, +1dB
HF Shelf N/A N/A N/A N/A
LF Level Adjust N/A N/A N/A -2dB, -1dB, 0, +1dB
SystemVolume (-30dB - +6dB) (-30dB - +6dB) (-30dB - +6dB) (-30dB - +6dB)
Auto Mute N/A N/A N/A N/A
Indicators Power Power Power Power
Indicator Control N/A N/A N/A N/A
Input Connectors: N/A
RCA Unbalanced RCA Unbalanced RCA Unbalanced RCA Unbalanced RCA
1/4" Balanced 1/4" TRS Balanced 1/4" TRS Balanced 1/4" TRS Balanced 1/4" TRS
XLR Balanced XLR Balanced XLR Balanced XLR Balanced XLR
Ground Lift N/A N/A N/A N/A
AC Power Input Selectable 110V-120V / 220V-240V (50Hz - 60Hz) or 100V
(50Hz - 60 Hz)
Selectable 110V-120V / 220V-240V (50Hz - 60Hz) or 100V
(50Hz - 60 Hz)
Selectable 110V-120V / 220V-240V (50Hz - 60Hz) or 100V
(50Hz - 60 Hz)
Selectable 110V-120V / 220V-240V (50Hz - 60Hz) or
100V (50Hz - 60 Hz)
Enclosure Construction MDF MDF MDF MDF
Finish Black vinyl wrap Black vinyl wrap Black vinyl wrap Black vinyl wrap
Port Conguration Front ring slot port Front ring slot port Front ring slot port Frontring slot por t
Grille N/A N/A N/A N/A
Mounting N/A N/A N/A N/A
Compatable OmniMount N/A N/A N/A N/A
Dimensions (H x W x D) 11.1" (282mm) x 7.28" (185mm) x 9.06" (230mm) 13" (330mm) x 8.82" (224mm) x 10.87" (276mm) 15.5" (394mm) x 10.83" (275mm) x 11.73" (298mm) 21.2" (540mm) x 12.7" (325mm) x 14.3" (365mm)
Weight 14 Lbs. (6.4 Kg.) 19 Lbs. (8.8 Kg.) 26 Lbs. (12 Kg.) 46 Lbs. 21 Kg.)

Model ERGO
Processing 400MHz Blackn DSP
RoomPerfect Algorithm Sample Rate - 96kHz
Room Correction Frequencies 20-500Hz
1024 tap FIR lter for room correction
Audio Spec A/B Speaker Select and Control / Stereo Audio-In
Freq Response: 20Hz-20kHz
Signal to Noise Ratio: 118dB @ Fs=48kHz
THD+N: 0.0056% @ 1kHz, 20Hz-20kHz
S/PDIF In: 32kHz-96kHz
FireWire Spec CoreAudio,WDM, and ASIO Driver support
FireWire Recording Interface Capable
Simultaneous 4 in, 6 out
Mechanicals Illuminated Controls
Measurement Microphone
Headphone Output
Dimensions ERGO: (H x W x D) 2.36”x 7.20” x 4.20”
60mm x 183mm x 107mm
Microphone Length: 197mm (7.75”)
Weight 610g (21.5 oz)
Ear Cushion for KNS8400 (pair)
CUSK00003
KNS Protective Bag for travel/storage
BAGK00009
1.5m headphone cable for laptop or portable
use
CBLK00032
VXT 4 Wall Adapter
KRKSTDX4W1
8-16654-00203-7
VXT 6/8 Wall Adapter
KRKSTDX68A1
8-16654-00205-1
VXT 35mm Pole Adapter
KRKSTDX4A1
8-16654-00201-3
VXT6GRL
8-16654-00134-4
VXT4GRL
8-16654-00133-7
Printed in China
2.5m coiled headphone cable
CBLK00027
KNS In-Line volume control
CBLK00031
1/8”to1/4”Screw-in adapter
CONK00007
10m straight headphone extension
cable
CBLK00030
3m straight headphone extension cable
CBLK00029
2.5m straight headphone cable
CBLK00028
Ear Cushion for KNS6400 (pair)
CUSK00001
Head Cushion for KNS8400
CUSK00004
Head Cushion for KNS6400
CUSK00002
Model KRK10s KRK12s KRK12sHO
Conguration Front loaded, vented subwoofer Front loaded,vented subwoofer Front loaded, vented subwoofer
System type Active Subwoofer Active Subwoofer Active Subwoofer
Low-Frequency Driver 10" glass aramid composite woofer 12"woven Kevlar woofer 12" woven Kevlar High Performance woofer
Frequency Response 34Hz – 50Hz to 130Hz Variable 32Hz - 139Hz (left / right inputs) 29.2Hz - 60Hz - 160Hz (left / right inputs), 29.1Hz - 211Hz (LFE input)
Max Peak SPL 113 dB 119.5 dB 123 dB
Amplier Class Class A-B Class A-B Class A-B
Power Output 150 WattsContinuous @ 1% THD+N @ 100Hz 240 Watts Continuous @ 1% THD+N @ 100Hz 400 Watts Continuous @ 1% THD+N @ 100Hz
SNR (signal to Noise Ratio) 98dB 102dB 92dB
Amplier Distortion (THD+N) ≤ 0.1% @-3dB of Maximum Power Output 20Hz - 200Hz ≤ 0.1% @-3dB of Maximum Power Output 20Hz - 200Hz ≤ 0.01% @-3dB of Maximum Power Output 20Hz - 200Hz
Input Impedance (Ohms) 10 kΩ Balanced or unbalanced 10 kΩ Balanced or unbalanced 10 kΩ Balanced
Ground Lift On / O On/ O  On / O
Low Pass Frequency 50H z to130Hz 55Hz to 170Hz 60Hz to 160Hz
HPF bypass with footswitch only with footswitch only with footswitch only
Footswitch Optional Optional included
Phase 0 or 180 degrees 0 or 180 degrees Rotatable Phase + Polarity Switch
SystemVolume -30dB to +6dB -30dBto +6dB -30dB to +6dB
Indicators Power Power, protection Power, protection, limiter
Input Connectors Stereo RCA for left and right, Stereo balanced TRS for left and right, stereo
balanced XLR for left and right
Stereo RCA for left and right, Stereo balancedTRS for left and right, stereo
balanced XLR for left and right
Balanced XLR for Left and Right Inputs
LFE input N/A Balanced TRS Balanced XLR
Output Connectors Stereo RCA for left and right, stereo balanced XLR for left and right Stereo RCA for left and right, Stereo balancedTRS for left and right, stereo
balanced XLR for left and right
Stereo Balanced XLR for left and right, full range with foot switch engaged, 80Hz
HP without foot switch engaged.
AC Power Input Selectable 110V-120V / 220V-240V Selectable 110V-120V / 220V-240V Selectable 110V-120V / 220V-240V
Enclosure Construction 15mm reinforced MDF 18mm reinforced MDF 18mm and 36mm reinforced MDF
Finish black vinyl wrap Textured Paint Textured Paint
Port Conguration Front ring slot port Front ring slot port Front Firing Quad Concentric Slot Ports
Grille Metal Mesh Metal Mesh N/A
Dimensions (H x W x D) 15" (382mm) x 14" (355mm) x 16.06" (408mm) 18.11" (460mm) x 15.94" (405mm) x 22.64" (575mm) 20" (508 mm) x 20" (508 mm) x 22.48" (571mm)
Weight 39 Lbs. (17.7Kg.) 66.44 Lbs. (30.14 Kg.) 109.7 Lbs. (49.7 Kg.)
Model KNS6400 KNS8400
Conguration Closed back, circumaural Closed back, circumaural
System type Monitor Headphones Monitor Headphones
Cable 2.5 m, (8.2 ft.), 99,99% OFC detachable 2.5 m, (8.2 ft.), 99,99% OFC detachable
Ear Cushion type Acoustic cellular foam Acoustic memory foam
Headpad Finish Leatherette Premium leatherette
Nominal Headband Pressure 4 N (based on average head size) N/A
Ambient Noise Isolation Up to 26 dBA Up to 30 dBA
Tranducer 40mm, neodymium 40mm, neodymium
Power Handling Full Range 1000mW 1000mW
Nominal Impedance 36 ohms 36 ohms
Frequency Response 10Hz to 22KHz 5Hz to 23KHz
Sensitivity (1mW) 95 dB SPL 97 dB SPL
Calculated Max SPL 122 dB SPL 124 dB SPL
Connectors Gold Plated Stereo 1/8th inch Gold Plated Stereo 1/8th inch
Volume control N/A In cord, detachable
Finish Black impact resistant plastic Black impact resistant plastic
Dimensions (H x W x D) 3.7" (94mm) x 10.5" (267mm) x 9.6" (244mm) 3.7" (94mm) x 10.5" (267mm) x 9.6" (244mm)
Weight 0.46 Lbs. (0.21Kg) 0.5 Lbs. (0.23Kg)
ACCESSORIES

USA: Telephone [phone] •Fax [phone]
Europe: Telephone [phone] •Fax [phone]
www.krksys.com
LITK00065
