KS KitSound DIGGIT XL User manual

QA-MRK-FM-08-02 v1
REG02 – International – US and Canada Online
FRON COVER
DIGGI XL
OU DOOR BLUE OO H SPEAKER
User Manual
INNER LEAF
Please read this manual carefully before use.
WARNING
•Please don’t get the product wet
•Please don’t take the product apart. here are no user serviceable parts inside
•Please don’t modify or alter the product or accessories
•Please don’t expose the product to extreme temperatures or rapid changes of hot to cold or
vice versa
•Please don’t use damaged cables or plugs, or loose electrical sockets
•Please don’t touch the device, cables, plugs, or the electrical socket with wet hands or other
wet body parts
•Please don’t pull the cable excessively when disconnecting it if the cable is not fixed
•Please don’t bend or damage the cable
•Please don’t drop or cause an impact to the product or the device
•Please don’t place naked flame sources, such as lighted candles, on the product
Battery Information
•Batteries may malfunction if they are not used for extended periods
•Over time, unused devices will discharge and must be recharged before use
•Disconnect the charger from power sources when not in use
•Use the batteries only for their intended purposes
•Follow all instructions in this manual to ensure the longest lifespan of your device and battery.
Damages or poor performance caused by failure to follow warnings and instructions can void
your manufacturer’s warranty

QA-MRK-FM-08-02 v1
IP66
his speaker is rated IP66. he first 6 means that the KS Diggit XL is protected against dust and
contact. he second 6 means it protects from water jets from any direction, but is not impervious to
large amounts of water. Please do not directly immerse in water.
• o ensure that the KS Diggit XL is water resistant, please remove all cable connections and tightly
close the AUX/DC IN cap. Exposing the KS Diggit XL to liquids without doing so may result in
permanent damage to the speaker.
• Do not expose the KS Diggit XL to water while charging. his is very dangerous as doing so may
result in personal injury and permanent damage to the speaker or power source.
• IP66 rating is defined as the KS Diggit XL can withstand water spray (water-carrying capacity 100
L/min) for up to 3 minutes.
• We do not recommend leaving the KS Diggit XL outside at night in wet conditions or when it’s
raining. Store in a dry place while not in use, this will prolong the speaker’s life.
Box contents
•KitSound DIGGI XL
•Micro USB charge cable
•User manual
•Stake
•Stake tube
Functions
1. MFB (Multi-Function Button)
2. Volume+/Next rack
3. Volume-/Next rack
4. Multi-Pair Button
5. Micro USB Charge Port
6. Aux in
7. Stake
8. LED Light Indicator
9. Stake ube (Image needed)
10. Stake (Image needed)
Instructions for use
Getting started
harging the battery:
Give the speaker a full charge before its first use:
1. Connect the supplied USB charging cable to the Micro USB Charging Port (5) and plug into power
2. he LED Indicator (8) will slowly flash red whilst charging which will take up to 4 hours
3. Once fully charged the LED Indicator (8) will turn off

QA-MRK-FM-08-02 v1
Note: Allow up to 12 hours for the first charge.
You can play your speaker whilst it is being charged, but
this will affect the charging time.
Battery protection mode
•If you haven’t used the speaker for 90 days, the speaker will switch to battery protection mode
automatically. o cancel the battery protection mode, connect the DIGGI XL to power as per
Step 1 under ‘Charging the battery’
•o keep the rechargeable battery in good condition, please discharge and recharge speaker every
3 months, whether used during this time or not
Note: For best sound quality when the battery is below 30%, it is best to charge the DIGGI XL
Pairing the DIGGIT XL to your device
1. Long press MFB (1) to turn the speaker on and it will automatically enter pairing mode and the
LED Indicator (8) will slowly flash white
2. urn your iOS, Android, or Windows device’s Bluetooth ON and search for new devices
3. Select KS Diggit XL If asked for a passcode, enter ‘0000’, and the device will pair
4. Once connected an audio tone will sound and the LED Indicator (8) will be solid white
Re-pairing or pairing new devices
1. urn Bluetooth connectivity off on any previously paired devices
OR
2. Double tap the MFB (1) to re-enter pairing mode
3. Follow the ‘Pairing the DIGGI XL to your device’ instructions
Note: If a previously paired device is not present within the Bluetooth connectivity range then the
speaker will re-enter pairing mode.
Playing music on your speaker
Bluetooth
When connected via Bluetooth, play music on your device and the sound will play through the
speaker. Some devices may require you to select the audio output.
Auxiliary
1. Plug the Aux cable into the speaker’s Aux-in Port (6) and your device using the supplied
cable
2. he LED Indicator (8) will be solid white
Once connected to the DIGGI XL either wired or by Bluetooth, please follow the instructions on
next page:
Function
Bluetooth mode
Auxiliary mode
Volume+
Short press 2
Short press 2

QA-MRK-FM-08-02 v1
Volume
–
Short press 3
Short press 3
Next rack
Long press 2
N/A & use device
Previous rack
Long press 3
N/A & use device
Play/Pause rack
Short press 1
N/A & use device
urn Off/On
Long press 1
Long press 1
Please note
Your device will have an internal amplifier and if it is playing digital files like MP3s. It will also have
an integrated DAC (Digital Audio Converter). If you turn the volume up to 100%, your device will be
sending a distorted signal. o avoid this, and to get the best quality from the speaker, we
recommend that you do not run your device any higher than 95% volume. Some devices output
higher than others, so you may need to reduce the volume if you experience distortion.
Bluetooth Multi-Pairing
1. Follow the normal instructions on ‘
Pairing the Diggit XL to your device’ to pair your device to a
Diggit XL. his Diggit XL will act as the “master” speaker. his connection must be made before
attempting to Multi-Pair more speakers and use the feature
2. urn on any additional speakers you wish to use for Multi-Pairing by long pressing the MFB
(1). All the additional speakers will now automatically enter pairing mode
3.
Short press the Multi-Pair Button (4) on the initial “master” speaker. he LED Indicator (8) on this
speaker will now flash pink
4.
Short press the Multi-Pair Button (4) on each additional speaker and their LED Indicators (8) will
also flash pink
5.
he Diggit XL’s will now begin Multi-Pairing. he LED Indicator (8) on each additional speaker will
turn solid white to show they are all connected properly. he “master” speaker’s LED Indicator
(8) will flash pink for a couple of minutes to ensure it finds every speaker
6.
he audio will now play through every speaker, giving you an immersive sound experience
As soon as all speakers have been found, the “master” speaker’s LED Indicator (8) will turn solid pink to
show that all possible connections have been made. he solid pink notifies what speaker is now the
master. Each additional speaker will remain solid white when connected.
Note: Multi-Pair will not work when using the aux cable. he Diggit XL must be in Bluetooth mode.
To break pairing
1. o remove a speaker from the Multi-Pair chain, short press Multi-Pair Button (4) on any of the
additional speakers you want to disconnect
Note: Once a Multi-Pair connection is made, the Diggit XLs will find each other automatically when
turned on again.
Note:
We recommend that the below factory reset is performed on any Diggit XL that has been used
as an additional speaker within a multi-pairing chain, if you intend to use the same speaker again
individually or as a “master” speaker in a new multi-pairing chain.
To factory reset a Diggit XL speaker

QA-MRK-FM-08-02 v1
o factory reset any of the Diggit XLs and break its Bluetooth connection, long press the MFB (1) and
Multi-Pair Button (4) together for 10 seconds. he “master” Diggit XL will then re-enter pairing mode and
the LED indicator (8) will flash white.
Using the Stake
he Diggit XL Outdoor Bluetooth Speaker’s removable stake means that it can be used at all sorts of
outdoor locations without muffling sound, such as the beach, picnics, BBQs, festivals, garden parties,
camping, and more!
How to safely apply and use the removable stake
1. Pull the Stake (10) out of the Stake ube (9)
2. urn the Stake (10) 180 degrees and push back into the Stake tube (9) (see figure 1)
3. Push the assembled stake into the ground. Please ensure that you do this safely and
carefully and ensure that the stake is only pushed in by hand. (see figure 2). DO NOT use any
objects or the Diggit XL itself to hit it into the ground
4. Make sure the bottom of the speaker is a sufficient distance from the ground to allow easy
and safe removal. DO NOT push the entire stake into the ground
5. Carefully place the Diggit XL onto the Stake ube (9) (see figure 3)
How to safely extract and store the removable stake
6. When you have finished using the Diggit XL, carefully remove the Speaker from the Stake
ube (9)
7. Grab the lower end of the Stake ube (9) and the exposed part of the Stake (10) and
carefully pull out of the ground. DO NOT wiggle the stake or apply undue pressure when
removing to prevent damage to the product
8. If the Stake ube (9) or Stake (10) has dirt on it, clean with a damp cloth before returning the
Stake (10) into the Stake ube (9) for safe keeping
Note: Only apply the stake into ground suitable for use, such as soft grass, sand, or snow.

QA-MRK-FM-08-02 v1
Specifications
Bluetooth® technology v
4.0
Bluetooth connectivity distance
up to
3
0 m
Bluetooth Frequency
2402
–
2480 MHz
ransmission power
6
dB
m
(conducted)
Frequency response
60
Hz
–
2
0 kHz
Drivers
2
x
45
mm
Output RMS
2
x
1
5
W
Battery
Li
-
ion
Play time
up to
24
hours
Charging time
up to
4
hours
IP rating
IP
66
Working temperature
40
°C ~
-
10
°C
Dimensions (mm)
H
193
x W
81
xD
81 mm
Weight
614
g
Troubleshooting
We hope you've now got all the information you need to get started, but if you're having problems
with anything, please feel free to contact us at: support@kitsound.co.uk
‘Hereby, Kondor Ltd declares that the
radio equipment type
, KSDIGXLnn
is in compliance with
Directive 2014/53/EU. he full text of the EU declaration of conformity is available at the
following internet address: http://kondor.co.uk/product-documents.’
F ID: 2ADFF- KSDIGXL
his device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Warning: Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
NO E: his equipment has been tested and found to comply with the limits for a Class B digital
device and ISM equipment, pursuant to part 15 of the FCC Rules respectively. hese limits are
designed to provide reasonable protection against harmful interference in a residential installation.
his equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be

QA-MRK-FM-08-02 v1
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/ V technician for help
I : 23562 – KSDIGXL
his device complies contains licence-exempt transmitter/receiver that comply with Innovation
Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the
following two conditions: (1) his device may not cause interference; and (2) his device must accept
any interference, including interference that may cause undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR
d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) L’appareil ne doit
pas produire de brouillage; (2) L’appareil doit accepter tout brouillage radioélectrique subi, même si
le brouillage est susceptible d’en compromettre le fonctionnement.
aution: Radio Frequency Exposure
his device comply with applicable FCC and ISED radio frequency exposure requirement, must be
installed with a separation distance between the user and/or bystander and the device greater
than 20cm.
Exposition aux radiofréquences : Cet équipement est conforme aux limites d’exposition par
rayonnements définies par l’industrie du Canada pour une utilisation dans un environnement non
clos. Cet équipement doit être utilisé à une distance minimale de 20 cm entre l’émetteur de
radiation et votre corps. Cet émetteur ne doit pas être situe au même endroit qu’un autre émetteur
et ne doit pas être connecté à une antenne différente.
he use and operation of this product is beyond our control. Warranty of the KSDIGXLnn is limited to
defects caused by faulty manufacture or defects in materials only. No warranty whatsoever is given
or implied for damage caused by the user under any circumstances.
his does not affect your statutory rights.
Please do not attempt to open this product. here are no user serviceable parts inside. If your
product has an embedded, non-replaceable battery, do not attempt to access or remove the
battery. his may cause personal injury and will damage the product.
Making any attempt to open the product or carry out repair voids any and all warranties.
We are sorry for any inconvenience caused by minor inconsistencies in these instructions, which
may occur as a result of product improvement and development.
BACKCOVER
kitsound.co.uk

QA-MRK-FM-08-02 v1
he Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc.
and any use of such marks by Kondor Ltd. is under license. Other trademarks and trade names are
those of their respective owners.
All trademarks are acknowledged as the property of their respective owners. Unless otherwise
stated their use does not imply that the trademark owner is affiliated with KitSound or endorses the
products herein.
Products showing the ‘Crossed hrough’ wheelie bin symbol must be recycled separately from
household waste at the end of their useful life. Please DO NO dispose of this appliance in normal
household waste. Your local appliance retailer may operate a ‘take-back’ scheme when you are
ready to purchase a replacement product, alternatively contact your local government authority for
further help and advice on where to take your appliance for recycling.
Please recycle this packaging responsibly.
JB. 6716_a/REG02/KSDIGXL/Made in China. © KitSound is a trademark of Kondor Limited, 2019.
Christchurch, Dorset, BH23 4FL, UK
Table of contents
Other KS KitSound Speakers manuals
