Ksenia Matrix User manual

code R30040.110en www.kseniasecurity.com
ed.09/2020
matrix
Universal Transmitter
Installation guide
INTRODUCTION
matrix module is a bi-directional universal radio interface for connecting third-party low power
consumption motion detectors to the lares 4.0 platform, at 868 MHz frequency band, and it is compatible
with OPTEX sensors series:
• BXS (PIR or PIR+AM/ curtain coverage right and left sides);
•VXS(PIR+AM/PIR+AM+MW/ 90° coverage);
• WXI (PIR/ PIR+AM/ 180° coverage right and left sides);
• WXS (PIR+AM/ PIR+AM+MW/ 180° coverage right and left sides);
• QXI (PIR/ PIR+MW/ 120° coverage right and left sides);
allowing their remote management (configuration data and detailed alarm signalling).
matrix directly feeds the connected motion detector with its own standard CR 123A batteries, from 1 to 3
batteries (second and third are optional) dependently on the consumption of the connected motion
detector. Through the supervision function, the control panel verifies the persistence of the radio
communication with all the wireless devices. Two dedicated inputs (alarm and sabotage) detect any
disappearance and/or sabotage of the connected detector. matrix itself has a tamper protection vibration
sensor (accelerometer), which allows, for example if it is mounted on a joint, to detect even a simple
rotation or change of position. To connect third-party motion detectors it provides a connection terminal on
board (If programmed as UNIVERSAL) and, alternatively, a serial port that is compatible with OPTEX sensors
(if programmed as OPTEX).
WARNING! OPTEX sensors series WXI, WXS, QXI are compatible with matrix device whose serial number is
equal or higher than 004000.

code R30040.110en www.kseniasecurity.com
ed.09/2020
TECHNICAL DATA
• Operating frequency: 868MHz
• Inputs: no. 1 alarm NC - NA type / no. 1 sabotage NC type
• Serial interface compatible with OPTEX detectors
• Lithium batteries power supply CR-123A (from 1 to 3)
• 3-axis mems accelerometer for sabotage
• Range in open air: up to 300m
• Operative Temperature Range: -10 / + 55°C
• Humidity: 95%
• Dimensions: 100x43x17mm (h x w x d)
DESCRIPTION OF THE PRODUCT
LEGEND
Ppower supply output voltage (3V, 50mA max)
–negative power supply (3V, 50mA max)
TAMP tamper terminal blocks (T/-)
ALL alarm terminal blocks (A/-)
UART port compatible with OPTEX* sensors for exchanging
communication and configuration data via RS-232
SW1 Enroll / Test radio button
J6 jumper closed: tamper ( ) not used
jumper closed: tamper ( ) used
BATTERIES - 3 slots for lithium batteries CR-123A
(code KSI7203015.000**)
(battery powered device from 1 to 3 batteries (second and
third are optional) it depends on the power consumption of
the connected motion detector)
WARNING! DO NOT connect external power sources to matrix power
supply outputs ( Pand –on screen-printing).
It could cause damage to your device.
* Use only the cable supplied for serial connection with OPTEX.
** WARNING! Risk of explosion if the battery is replaced by an
incorrect battery type.

code R30040.110en www.kseniasecurity.com
ed.09/2020
INSTALLATION
matrix can be installed in the special housing inside the sensor that will be used.
Remember that OPTEX sensors WXI, WXS, QXI series are compatible with matrix device whose serial
number is equal or higher than 004000.
Programmed as UNIVERSAL to connect third-party motion detectors (not OPTEX), matrix provides a
connection terminal on board to connect the outputs of the third-party sensors on TAMPER and ALARM
inputs (TAMP and ALL on screen-printing).
Power to the sensor is supplied by connecting the outputs indicated on screen-printing with [P and -].
Programmed as OPTEX to connect BXS, VXS, WXI, WXS, QXI sensors, connect one side of the cable supplied
to the serial port (indicated with no.5 at paragraph “DESCRIPTION OF THE PRODUCT” page 2) and the other
side to the OPTEX serial port (for further information, please consult the manual of the sensor itself).
Thanks to this serial link, installers avoid the terminal block wiring and the configuration of OPTEX sensors
can be performed via Ksenia SecureWeb or APP Ksenia PRO; the OPTEX switch manual settings are
completely avoided.
WARNING! JUST in case you are installing matrix inside OPTEX series QXI, follow the instructions below.
Due to the small size of the OPTEX QXI series, to allow the OPTEX tamper to function correctly and to avoid
damaging the matrix or the OPTEX sensor itself, pay particular attention when installing matrix inside the
case.
1 After having mounted the OPTEX QXI case and connected
the cable supplied for serial connection, insert the matrix
into the sensor base by placing it on the right side, with
the batteries in contact with the OPTEX base and the
terminal block facing upwards.
OPTEX base matrix+OPTEX main unit

code R30040.110en www.kseniasecurity.com
ed.09/2020
2 Make sure that matrix PCBA does not cover the support
highlighted in the next image, the space left will be
occupied by the sensor tamper.
3 Be careful not to compress the cable when repositioning
the OPTEX QXI main unit.
4 Close the sensor cover in a way that is close-fitting.

code R30040.110en www.kseniasecurity.com
ed.09/2020
CONFIGURATION
Starting from the configuration program of lares 4.0 control panel, it is possible to customize the type of
functioning requested to the wireless sensor -> matrix, by choosing between UNIVERSAL (for third-party
motion detectors) or OPTEX (for Optex BXS, VXS, WXI, WXS, QXI motion detectors).
In case of UNIVERSAL operation, the configuration is limited to general information about matrix (serial
number, supervision and tamper protection).
In case of OPTEX operation, the customization involves the connected OPTEX sensor so that, in addition to
the general information written above, the configuration also includes enabling/disabling PIR sensor,
tamper/accelerometer, switch on board, alarm notification with LED, inhibition time, anti-masking, PIR
settings (PIR sensitivity and PIR pulse number) and micro-wave settings (micro-wave sensitivity and micro-
wave immunity).
For more details, please refer to "Lares 4.0 Programming Manual".
COMPLIANCE
Europe - CE, Rohs
Technical specification, appearance, functionality and other product characteristics may change without notice.
