Transition Networks J/VD-MRX-01 User manual

User’s Guide
J/VD-TX-01, J/VD-RX-01 and J/VD-MRX-01
Stand-Alone AM Video Copper-to-Fiber Video System
The J/VD-RX-01 standard size fiber receiver is a
companion to the J/VD-TX-01 series transmitter.
This receiver mounts into Transition’s E-MCR-04
12-position rack-mount shelf. This unit incorporates
two status LEDs: power status and fiber video RX.
It operates as a fiber receiver and a coax transmitter
to a monitor.
• Stand-alone version only
• One SC or ST fiber receiver port
• One 75-ohm BNC video transmitter port
The J/VD-MRX-01 small-form-factor fiber receiver is
a similar sized companion to the J/VD-TX-01 series
transmitter. This unit incorporates two status LEDs:
power and fiber video RX. It operates as a fiber
receiver and a coax transmitter to a monitor.
• Stand-alone version only
• One SC or ST fiber receiver port
• One 75-ohm BNC video transmitter port
Installation . . . . . . . . . . . . . . . . . .3
Operation . . . . . . . . . . . . . . . . . . .4
Cable Specification . . . . . . . . . . .4
Technical Specifications . . . . . . . .5
Troubleshooting . . . . . . . . . . . . . .6
Contact Us . . . . . . . . . . . . . . . . . .7
Compliance Information . . . . . . . .8
J/VD-RX-01
• AM Video
• NTSC, PAL, SECAM compatible
• Automatic gain control (AGC)
• Realtime full color video
• Plug-and-play design for easy installation
• CCTV video equipment compatible
• One-way signal transmission through the system
• Extended temperature rated for use in controlled
outdoor applications
J/VD-MRX-01
The J/VD-TX-01 fiber transmitter permits connecting a
video camera to a video monitor through multimode
(MM) or single mode (SM) fiber. Its small form factor
allows mounting directly to the camera’s coax video
output port. This unit incorporates two status LEDs:
power and coax video RX. It operates as a coax receiver
and a fiber transmitter.
• Stand-alone version only
• One SC or ST fiber transmitter port
• One 75-ohm BNC video receiver port
J/VD-TX-01

2
J/VD-TX-01, J/VD-RX-01, J/VD-MRX-01
24-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
75-Ohm BNC 2 75-Ohm coax cable, 30.5 m (100ft)
DescriptionConnector Type
The various fiber connections are available on separate models. Single mode and
multimode units come in the following configurations.
Number
The video transmitter/receiver system has the following copper connections.
Model Optic Fiber Distance Form Factors
J/VD-TX-01 ST, multimode, 850 nm 1km (0.62miles) Min*
J/VD-RX-01 ST, multimode, 850 nm 1km (0.62miles) Std*
J/VD-MRX-01 ST, multimode, 850 nm 1km (0.62miles) Min
J/VD-TX-01(SC) SC, multimode, 850 nm 1km (0.62miles) Min
J/VD-RX-01(SC) SC, multimode, 850 nm 1km (0.62miles) Std
J/VD-MRX-01(SC) SC, multimode, 850 nm 1km (0.62miles) Min
J/VD-TX-01(SM) ST, single mode, 1310 nm 10km (6.21miles) Min
J/VD-RX-01(SM) ST, single mode, 1310 nm 10km (6.21miles) Std
J/VD-MRX-01(SM) ST, single mode, 1310 nm 10km (6.21miles) Min
WMBS Wall-Mount Bracket, L 98.96 mm (3.896 in.) W: 25.4 mm (1 in.)
The WMBS wall-mount bracket is for the J/VD-RX-01 receiver only.
Part Number Description
Accessories
Additional Accessories
SPS-1872-CC Piggy back power supply 48 VDC in, 12VDC out
SPS-1872-SA Stand-alone power supply 48 VDC in, 12VDC out
E-MCR-04 Twelve (12) slots for Transition Networks’ stand-alone media converters
requiring an external power supply. Dimensions 3.0 in. high x 1.0 in.
wide x 4.7 in. deep (76 mm x 25 mm x 119 mm).
For the J/VD-RX-01 receiver only.
Part Number Description
WMBJ-V Wall-Mount Bracket, L 69.9 mm (2.75 in) W: 63.5 mm (2.5 in)
The WMBJ-V wall-mount bracket is for the J/VD-TX-01 transmitter and J/VD-MRX-01
receiver only.
Part Number Description
*Standard (Std), Miniature (Min)
J/VD-TX-01, J/VD-RX-01, J/VD-MRX-01
Installation
Connecting power
Transmitter and receiver back panels:
Note: J/VD-MRX-01 receiver has two ways to connect power: barrel connector and
a polarity sensitive 2-pin terminal block.
Note: The video transmitter and receiver must be matched: single mode TX/RX or
multimode TX/RX. If installed as a mixed pair, the system will not function.
Caution: Use 75 ohm BNC connectors on 75 ohm cable only. Failure to observe this
caution will result in signal degradation.
To install the video transmitter and receiver system cables, see installation diagram
below:
Video Camera
In
Out
In
Receiver Monitor
Fiber Optic Cable (SM/MM)
75-Ohm BNC Coax Cable
Out In
Transmitter
J/VD-RX-01 Receiver
J/VD-MRX-01 Receiver
J/VD-TX-01 Transmitter
Power ON LED
Power
Connector
Power
Connector
Video System Back Panels
DC Power, 2-Pin
Terminal Block
+-
Power ON LED
DC Power, 2-Pin
Terminal Block

4
J/VD-TX-01, J/VD-RX-01, J/VD-MRX-01
24-Hour Technical Support: 1-800-260-1312 -- International: 00-1--952-941-7600
Operation
• Make sure that power is supplied to the transmitter, receiver, and camera, with the
monitor turned ON.
• The system is operational when what the camera sees appears on the monitor.
Cable specifications
Coax cable
RG Type: RG-59, RG-6
Gauge: 18–25, single conductor
Impedance: 75 ohms
Distance: 30.48 M (100 ft) Max
Fiber
Single Mode 9/125µ
Multimode 62.5/125µ
Multimode
Wavelength: 850 nm
Link Budget: 6.0 db
Single Mode
Wavelength: 1310 nm
Link Budget: 10.0 db
Technical Specifications
Use 75 ohm BNC connectors on 75 ohm cable only.
Transition Networks models J/VD-TX-01, J/VD-RX-01, J/VD-MRX-01 video system
specifications for all three models.
Video formats: NTSC, PAL, SECAM
Video spec
Input Video: 0.5 to 2-volt pk-pk (75 ohms)
Bandwidth: 5 Hz - 10 MHz
Differential gain: < 5 %
Differential phase: < 5°
Tilt: <1%
Signal/Noise Ratio: 60dB
Regulatory compliance
Emissions: EN55022 class A
Immunity: EN55024
Safety compliance: Unit: CE Mark
Power supply: UL listed
Power consumption: 2 watts
Power input range: 9 – 40VDC; 9 – 24VAC (TX)
9 – 16 VAC/VDC (RX)
Power supply: External wall-mount AC/DC; 12VDC @ 0.5A
Operating temperature: 0°C to 50°C (32°F to 140°F) with included AC/DC power
supply
-40°C to 75°C (-40°F to 176°F) DC voltage input
Storage temperature: -25°C to 85°C (13°F to 185°F )
Humidity: 5% to 95%, non-condensing
Altitude: 0 to 10,000 feet
Dimensions: TX: 2.0” x 2.2” x 1.0” (50.8 mm, 55.88 mm, 25.4 mm)
RX: 3.0” x 3.896” x 1.0”(76.2 mm, 98.96 mm, 25.4 mm)
MRX: 2.0” x 2.2” x 1.0” (50.8 mm, 55.88 mm, 25.4 mm)
Warranty: Lifetime
The information in this user’s guide is subject to change. For the most up-to-date
information on the J/VD-TX-01, J/VD-RX-01, J/VD-MRX-01 video system, view the
user’s guide on-line at: www.transition.com.
J/VD-TX-01, J/VD-RX-01, J/VD-MRX-01

6
J/VD-TX-01, J/VD-RX-01, J/VD-MRX-01
24-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Troubleshooting
If there are problems with the system setup or a system failure occurs, isolate and
correct the problem by determining the answers to the following questions and then
taking the indicated action:
1. Are the power LEDs ON in the transmitter and receiver?
NO
• Are the power adapters the proper type (voltage and frequency) for the AC
outlet?
• Are the power cords properly plugged/installed into the transmitter and
receiver, and plugged into an active electrical outlet?
• Contact Technical Support: US/Canada: 1-800-260-1312, International: 00-1-
952-941-7600.
YES
• Proceed to step 2.
2. Are the RX LEDs lit on the transmitter and receiver?
NO
• Check that the fiber cable SM/MM matches the transmitter and receiver set
SM/MM.
• Check the fiber-cable connections and condition of the fiber cable.
• Check for video signal at the transmitter coax port.
• Check the coax cable connection.
• Contact Technical Support: US/Canada: 1-800-260-1312, International: 00-1-
952-941-7600.
Yes
• Contact Technical Support: US/Canada: 1-800-260-1312, International: 00-1-
952-941-7600.
J/VD-TX-01, J/VD-RX-01, J/VD-MRX-01
Declaration of Conformity
Name of Mfg: Transition Networks
6475 City West Parkway, Minneapolis MN 55344 U.S.A.
Model: J/VD-TX-01, J/VD-RX-01, J/VD-MRX-01 Video
Transmitter and Receivers
Part Number(s): J/VD-TX-0X, J/VD-RX-01, J/VD-MRX-01
Regulation: EMC Directive 89/336/EEC
Purpose: To declare that the J/VD-xxx-01 to which this declaration refers is in
conformity with the following standards.
CISPR 22:1997+A1:2000; EN 55024:1998+A1:2000 Class A; FCC part 15 subpart B; CFR
21 subpart J
I, the undersigned, hereby declare that the equipment specified above conforms to the above
Directive(s) and Standard(s).
Contact Us
Technical support
Technical support is available 24 hours a day.
US and Canada: 1-800-260-1312
International: 00-1-952-941-7600
Transition now
Chat live via the Web with Transition Networks Technical Support.
Log onto www.transition.com and click the Transition Now link.
Web-based seminars
Transition Networks provides seminars via live web-based training.
Log onto www.transition.com and click the Learning Center link.
E-Mail
Ask a question anytime by sending an e-mail to our technical support staff.
Address
Transition Networks
6475 City West Parkway, Minneapolis, MN 55344, U.S.A.
telephone: 952-941-7600, toll free: 800-526-9267, fax: 952-941-2322
OCT 7, 2005
Stephen Anderson, Vice-President of Engineering Date

8
Trademark notice
All trademarks and registered trademarks are the property of their respective owners.
Copyright restrictions
© 2003, 2005 Transition Networks.
All rights reserved. No part of this work may be reproduced or used in any form or by any means -
graphic, electronic, or mechanical - without written permission from Transition Networks.
Printed in the U.S.A 33349.A
J/VD-TX-01, J/VD-RX-01, J/VD-MRX-01
Compliance Information
CISPR22/EN55022 Class A
CE Mark
FCC regulations
This equipment has been tested and found to comply with the limits for a class A digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference, in which
case the user will be required to correct the interference at the user's own expense.
Canadian regulations
This digital apparatus does not exceed the Class A limits for radio noise for digital apparatus set out
on the radio interference regulations of the Canadian Department of Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables
aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage
radioélectrique édicté par le ministère des Communications du Canada.
European regulations
WARNING: This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
ACHTUNG! Dieses ist ein Gerät der Funkstörgrenzwertklasse A. In Wohnbereichen können bei
Betrieb dieses Gerätes Rundfunkstörungen auftreten. In diesem Fäll ist der Benutzer für
Gegenmaßnahmen verantwortlich.
ATTENTION! Ceci est un produit de Classe A. Dans un environment domestique, ce produit
risque de créer des interférences radioélectriques, il appartiendra alors à l'utilsateur de prende les
measures spécifiques appropriées.
In accordance with European Union Directive 2002/96/EC of the European Parliament
and of the Council of 27 January 2003, Transition Networks will accept post usage returns
of this product for proper disposal. The contact information for this activity can be found
in the 'Contact Us' portion of this document.
CAUTION: RJ connectors are NOT INTENDED FOR CONNECTION TO THE
PUBLIC TELEPHONE NETWORK. Failure to observe this caution could result in
damage to the public telephone network.
Der Anschluss dieses Gerätes an ein öffentlickes Telekommunikationsnetz in den EG-
Mitgliedstaaten verstösst gegen die jeweligen einzelstaatlichen Gesetze zur Anwendung der
Richtlinie 91/263/EWG zur Angleichung der Rechtsvorschriften der Mitgliedstaaten über
Telekommunikationsendeinrichtungen einschliesslich der gegenseitigen Anerkennung ihrer
Konformität.
This manual suits for next models
2
Table of contents
