KSIX BXLAMP05 User manual
SMARTLED
LED LIGHT BARS
User manual
BXLAMP05
Technical information
Power: 5W
Luminous flux: 35 lm
Color: RGBIC
Voltage: 5V/1A
Dimensions: 30 x 3 x 3 cm (x2 bars)
Material: ABS+PC
Connection: Bluetooth + WiFi
Voice Assistant: Amazon Echo and Google Home
App: TuyaSmart and Smart Life
Box contents
2 x LED Bars
2 x Bases
2 x Brackets
1 x Remote
2 x Cables
2 x Stickers
1 x User manual
1. Installation
1. Place the light bars on either side of the table or mount them behind the TV screen,
computer, or any surface you prefer with the help of mounting brackets and stickers.
2. Connect the USB-C to USB-A cable to the main light bar and connect the two light bars
with the USB-C to USB-C cable.
3. Plug the main light bar into a power source with USB-A port and it will transmit signal to
the secondary light.
①Computer
②Power Bank
③Adapter
④Main light Bar
⑤Secondary light Bar
2. Download the app
• To download the app, scan the QR code.
• You can also search the app in the App Store or Google Play.
3. Register
1. If you do not have an account in the App, register and log in with the verification code.
2. Enter your email address and click on “Get verification code”. Enter the verification code
you will have received in your email.
3. Set the password and press “Finished” to complete registration.
3. Add your device
1. First, turn on Bluetooth and WiFi on your phone.
2. Open the app and tap “Add Device” or “+” in the top right corner.
3. Select your smart device from the list of devices or use the automatic scan to find it
directly.
4. Press and hold the power button for 10 seconds until the device starts flashing.
5. Next, select the 2.4 GHz WiFi network, enter the router password and wait while the app
finds the device. Add the device by tapping on the “+” symbol. Once it has been added,
tap “Finished”.
①
②
③
④ ⑤
Note
1. To ensure a correct synchronization with your mobile phone, it is necessary to accept all
the accesses requested by the app.
2. To connect for the first time, you must be connected to a Wifi network. Make sure that the
light is flashing quickly and that the WiFi password you have entered is correct. (The
connection process may take several minutes, please be patient).
3. After the first connection, you can use a new WiFi or mobile data network to control the
device at any time and from any location.
4. Only compatible with 2.4 GHZ WLAN, Android 4.1 and above and IOS 8.1 and above. Do
not use 5G WiFi.
5. The first connection should be made close to the router to ensure a faster connection.
6. When connecting multiple devices to the WiFi network, do not put them too close
together as this may cause signal interference.
4. Control your device
• After successful configuration, the device will be displayed on the "Devices" page. Tap on
the device icon to control its operation.
Colour mode
• This option allows you to choose from countless static colours and adjust their brightness
from 1 to 100% by simply swiping your finger.
Scene mode
• Choose from a wide variety of scene modes or create your own, selecting the dierent
options provided by the App. These eects are able to synchronize several colors at once,
creating unique colour sets.
Music Mode
• The incorporated sensitive microphone is able to synchronize the colours with the music.
• Accept all the accesses requested by the app and make your bars listen to the sound with
the rhythm of the music of your mobile phone, television or simply the ambient music.
Planner
• Enter the "Timer" section to set the operating time ranges of the bars. This will keep the
light in the ON or OFF position for a specific time.
6. Voice Assistants
• To set up your voice assistants through the app, you will need to tap on the top right corner
and then tap on the “Edit” icon.
• From here you can permit access to third parties to control the bulb, such as Alexa and
Google Home.
• You can adjust the brightness, change the colour, or simply turn the light on and o with
just a few words.
7. Remote control
① ⑥
⑦
⑧
⑨
⑩
⑪
②
③
⑤
④
More brightness
Less brightness
ON
OFF
RGBW
Static colour
DIY
Scene mode
Speed +/-
Timer
Music
Increase brightness
Decrease brightness
Switched on
Switched o
Selection of the dierent colors. R: red; G: green; B: blue; W: white
8 types of static colours
Click DIY1/DIY2/DIY3 Adjust the brightness of reds, greens and blues
4 scene modes available
Adjust the lighting speed
1-hour or 2-hour timing function to turn o the light
4 music modes available
①Brightness
②Static colour
③Click DIY1/DIY2/DIY3
④Adjust the brightness of reds, greens and blues
⑤Music Mode
⑥Power O / On
⑦Mode
⑧Speed +
⑨Speed -
⑩Scene mode
⑪Timer
8. Manual control from the Main Light Bar
①Music modes
②Switch light mode
③ON/OFF
④USB-C ports
① ② ③ ④
ON/OFF button: Press and hold the ON/OFF button for 5 seconds or more to synchronize
the bars.
Light modes button (C): Press the “C” button to choose from the 10 scene modes
available.
Music Button (M): Press the “M” button to choose between the 4 available music modes.
USB-C ports (x2): Connect the main bar to the current and to the other bar through these
USB ports.
9. More about the App
You can adjust the dierent functions from the menu button at the top right corner of the
App.
1. The device name can be changed as desired.
2. Device information.
3. Tap-to-Run and Automation allows you to check the Intelligent Automation to which
your device is linked.
4. Supported third-party control provides information on how to connect your device with
Amazon Alexa, Google Assistant.
5. Disconnection notice: allows you to alert yourself when your device is oine.
6. Create “Group” to control another smart device at the same time.
7. FAQ & Feedback allows users to report issues and obtain assistance.
8. Add to Home Screen allows you to add the smart device to your smartphone's home
screen.
9. Check the network of the device to check the status of the network connection.
10. Firmware information allows you to check the software or install updates on the device.
11. Restore factory settings: Allows you to reset the factory settings of the smart device.
Maintenance recommendations
• Regularly clean the product with a dry cloth.
• The product must be disconnected or switched o when cleaned.
• Keep the connectors and/ or ports free from dust, lint, etc. to prevent improper
connections.
• Avoid breaking the device. Do not put objects over it or bend it too strong.
• If the product includes a cable do not bend it too strong and do not pull from it to
unplug the product.
• Do not wet the product.
• Keep it always in a dry place, away from humidity.
• When not using the product, store it in a place free from dust, dirt, lint, liquids, etc.
• If water enters the product interior, unplug it immediately from any attached power
source or device it is connected to.
• Avoid dropping or hitting the product. That might damage it.
• Do not use the product for anything other than its intended use.
• Please recycle the product in accordance with local environmental laws and regulations.
Safety information
Please read the following instructions before using the device for the first time:
• When you use device keep it away from heat sources (fire) and from humidity sources
(water and other liquids).
• Do not use the product if it is wet or damaged.
• Do not use the product with wet hands.
• Do not leave the product in contact with flammable materials.
• Do not expose the product to high temperatures (for example: inside a car during hot
weather).
• Do not throw the product into fire.
• Keep the product away from children.
• Disconnect or switch o the product if you are not going to use it for a long period of
time.
• Do not use the product if you perceive any visible defects.
• Do not attempt to open or puncture the product. You might damage it.
• Do not use the product with incompatible devices.
• Do not disassemble or modify the product. These actions will invalidate the Warranty.
Legal Note
Hereby, Atlantis Internacional S.L. declares that this product is in compliance with the
essential requirements and other relevant provisions of Directive 2014/53/EC. The features
and functions described in this manual are based on tests made by Atlantis Internacional
S.L. It is the user’s responsibility to examine and verify the product after its purchase.
Atlantis Internacional S.L. is not responsible and will never be liable for any personal loss or
injury, economical loss, material loss or any damage due to misuse, abuse or improper
installation of the product. Atlantis Internacional S.L. is not responsible and will never be
liable for any function, communication and connection failure between the product and
Bluetooth enabled devices.
Electronic and electrical devices disposal
This symbol indicates that electrical and electronic equipment is to be collected separately.
• This product is designated for separate collection at an appropriate collection point. Do
not dispose of as household waste.
• If the equipment uses batteries, they must be removed from the equipment and disposed
in an appropriate collection center. If the batteries cannot be removed, do not attempt to
do it yourself since it must be done by a qualified professional.
• Separate collection and recycling helps conserve natural resources and prevent negative
consequences for human health and the environment that might result from incorrect
disposal.
• The final price of this product includes the cost necessary for the correct environmental
management of the generated waste.
• For more information, contact the retailer or the local authorities in charge of waste
management.
Warranty: The 3-year warranty does not apply to products with consumable parts or parts
subject to wear, except for defects in materials or manufacturing.
CE Declaration of Conformity
We hereby declare that the product (s) listed below satisfies the provision for CE-marking
according to the following European directive(s):
EN IEC 55015:2019+A11:2020
EN IEC 61000-3-2:2019/A1:2021
EN 61000-3-3:2013/A2:2021
EN 61547:2009
Article: BXLAMP05
EAN: 8427542125954
Manufacturer:
ATLANTIS INTERNACIONAL, S.L.
Address:
Carrer del Crom, 53, 08907 L'Hospitalet de Llobregat, Barcelona (Spain)
Place and date of the declaration:
L’Hospitalet de Llobregat, September, 1st 2022
Nico Broder
General Manager
