KT BESET 600 C User manual

140W 6” CEILING LOUDSPEAKERS
USER MANUAL
BESET 600 C

BESET600C®BESET600C® 2 3
INDEX PAGE NO.
INTRODUCTION 3
AUDIO CONNECTIONS 4
MOUNTING THE SPEAKER 5
SPEAKER PLACEMENT 6
PRODUCT SPECIFICATIONS 7
INCLUDED ITEMS 7
TABLE OF CONTENT
Thank You For Purchasing A KT Product
KT® Speakers feature an outstanding combinaon of performance and value in each of our products.
To ensure you get the most out of your new loudspeakers please take a moment to read this manual
before you get started.
You can get a digital copy of this manual Online. Simply visit our site
at www.ktwaves.com
A Few Words About Your New Ceiling Speakers
KT® Ceiling loudspeakers are designed using a sturdy cabinet that minimize resonance, distoron and
unwanted vibraon using a smart and easy to setup installinaon mounng brackets.
The Beset® 600c is designed to be used in a wide variety of applicaons like entertainment and Home
Theatre and is perfect for any home or commercial applicaon.
when using a wide array of In Ceiling Loudspeakers you get clear sound and even disparsion without
loosing any important space in your home or buisness space.
In Terms of being interior-design friendly, the grill and mounng bracket can be painted
to t any color scheme.
INTRODUCTION

BESET600C®BESET600C® 4 5
AUDIO CONNECTIONS
Never aach the speakers to a wall that might contain electrical wiring or plumbing.
IF YOU ARE UNSURE ABOUT ANY OF THESE INSTRUCTIONS,
PLEASE CONTACT A PROFESSIONAL CUSTOM AUDIO INSTALLER.
The below mounng procedure applies to drywalls, drywall ceiling and drop ceiling
or similar. You will have to cut a hall in a wall or ceiling, with the right tools and a
lile extra care and preparaon installing this speaker can be both quick and easy.
1. Carefully cut a hole drawn on the paper template (included).
2. Posion the template (now a border) where you have chosen to mount the speak-
er and draw a line on the wall or ceiling along the inside edge of the template.
3. Make your cuts along the line in the wall or ceiling. try to keep the cuts neat, how-
ever, the frame of the speaker will overlap the hole to hide any rough edges.
4. Run the speaker cables while leaving a 150cm (5 .) of extra cable at the hole.
5. Remove the speaker grill by pressing the mounng screws from the back of the
speaker.
6. Connect the speaker cables to the speaker’s terminal according to your setup..
7. With the grill removed, insert the speaker into the mounng hole.
8. Use a screwdriver to turn the mounng screws slowly clockwise.
9. The cut edges of the wall or ceiling will be caught rmly in between the mounng
clamps and the speaker frame.
MOUNTING THE SPEAKERS
Installaon of your KT ceiling speakers is designed to be simple
and intuive, it is largely advised to consult a professional installer.
Make sure the materials on which you plan to mount the speakers
can support the weight of the speakers.
The speaker terminal can accommodate up to 10 AWG speaker cables (some models can accommo-
date 14 AWG. 10 or 14 AWG speaker cables are connecon greater than 20 meters \ 66 . For shorter
length you can use 16 or 18 AWG speaker cable. it is recommended to leave about 150 cm (5 .) of
extra cable at the speaker end and to facilitate posioning and installaon of the speaker. Please be
advised not to use stables, nails or any other metalic objects to secure speaker cables. By separang
the speaker audio line from other cables such as electronic or communicaon lines you will diminish
the chances of geng Hums or distoron through the speaker.
When connecng the speaker it is very important the
you do not reverse the polarity of the sound the source.
please connect to the speaker’s input terminal Red (+)
with Red (+) and Black (-) with Black (-). before connecng
the speaker make sure your amplier is switched o.
please refer to you amplier’s instrucon manual for more informaon.
WARNING! Before connecng you amplier please make sure that your amplier is designed to work
with your specic KT speaker impedance requirements. you may cause a malfuncon in your ampli-
ers and speakers if they do not match. it may also void your warranty.
OTHER AUDIO CONNECTIVITY
AVAILABLE ONLY ON STEREO MODELS
CONNECT A SINGLE SPEAKER TO TWO AMPLIFIER SPEAKER OUTPUT TERMINALS. CONNECT ONE AMPLIFIER SPEAKERS
OUTPUT TERMINAL WITH ONE SPEAKER INPUT TERMINAL (RED (+) BLACK (-))
CONNECT THE OTHER AMPLIFIER SPEAKERS OUTPUT TERMINAL WITH THE
OTHER SPEAKER INPUT TERMINAL (RED (+) BLACK (-))
STEREO CONNECTION
CONNECT A SINGLE SPEAKER TO A SINGLE AMPLIFIER SPEAKER OUTPUT TERMINALS. CONNECT ONE AMPLIFIER SPEAK-
ERS OUTPUT TERMINAL WITH ONE SPEAKER INPUT TERMINAL (RED (+) BLACK (-))
USING A SHORT PIECE OF SPEAKER CABLE CONNECT ONE SIDE OF THE SPEAKER
INPUT TERMINAL TO THE OTHER SPEAKER INPUT TERMINAL. MAKE SURE YOU
CONNECT RED WITH RED AND BLACK WITH BLACK
MONO CONNECTION

BESET600C®BESET600C® 6 7
PRODUCT SPECIFICATIONS
Speaker design Indoor In Ceiling
Power Rang 140W RMS | 280W PEAK
Impedance Ω 8 Ohms
Frequency Response 40Hz to 20Khz
High Frequency Driver 2 X 19mm (0.75”)
Woofer 165mm (6.5”) Kevlar woofer with silk dome
Connector Type Terminal
Color White, Paintable
Minimum Mounng Depth 70mm
Weight 1.8 Kg (1 pcs.)
INCLUDED ITEMS
CUTOUT PAPER TEMPLATE
MOUNTING BRACKET
USER MANUAL
SPEAKER PLACEMENT
We strongly suggest that you take the me to consider the best speaker placement for your specic
applicaon. once installed it is not easily moved or reposion. although each space has it’s own acousc
response there are some general guidelines you can safely follow.
Placing the speakers close to the walls will lead to some increase in bass frequencies. in some cases it
may result in a “boomy” or “muddy” sound.
place the speakers at least 60 cm (2 .) away from corners and other surfaces which may interfere or
reect sound.
For Crical Listening
Place the le and right speakers at an equal distance from your listening posion.
Place the speakers no more that 300 cm (10 .) apart from each other and no less than 150 cm (5 .)
For Entertainment listening or background music
in rectangular smaller rooms (below 30 square meters or 320 square .) in most cases 1 or 2 speakers
should suce and provide good coverage. if you use 2 units place them near opposite corners. If you
use one speaker it is advised to place it in the center.
in irregular or larger rooms use more than 2 speakers and place them evenly across the space for good
sound dispersion.
FOR HOME THEATRE SETUP 5.0\5.1\6.0\6.1\7.0\7.1
FRONT SPEAKERS
Place the le and right speakers at an equal distance from your listening posi-
on. in front of your TV and about 60-90 cm (2-3 .) away from the wall. Place
the speakers no more that 300 cm (10 .) apart from each other and no less
than 150 cm (5 .)
CENTER SPEAKERS
Place the speakers in the middle of the front le and right speakers.
6.0\6.1 systems - place the second center speaker (rear center) behind your
listening posion, in line with the front center speaker.
SURROUND SPEAKERS
place the right and le surround on the right and le of your listening posion
as far apart as your front le and right speakers.
7.0\7.1 systems - place the rear right and le surround speakers behind your
listening posion at equal distance from your posion. they should be located
at half the distance at the right and le surround speakers posioned on the
sides.

BESET600C® 8
