KTM 2010 690 SMC EU Manual

SETUP INSTRUCTIONS 2010
690 SMC EU
690 SMC AUS/UK
690 SMC USA
Art. no. 3211470en

INTRODUCTION 1
INTRODUCTION
The work described in these setup instructions must be performed before the vehicle is delivered to the customer.
Read the setup instructions in their entirety before beginning work.
Print out the current PDI form found on the KTM DEALER.NET.
These setup instructions were written to correspond to the latest state of this series. We reserve the right to make changes in the inter-
est of technical advancement without at the same time updating this manual.
We shall not provide a description of general workshop methods. Likewise, safety rules that apply in a workshop are not specified here.
It is assumed that the work will be performed by a fully trained mechanic.
All specifications are non-binding. KTM Sportmotorcycle AG in particular reserves the right to modify or delete technical specifica-
tions, prices, colors, forms, materials, services, designs, equipment, etc., without prior notice and without specifying reasons, to adapt
these to local conditions, as well as to stop production of a particular model without prior notice. KTM accepts no liability for delivery
options, deviations from illustrations and descriptions, as well as misprints and other errors. The models portrayed partly contain spe-
cial equipment that does not belong to the regular scope of delivery.
© 2010 KTM-Sportmotorcycle AG, Mattighofen Austria
All rights reserved
Reproduction, even in part, as well as copying of all kinds, is permitted only with the express written permission of the copyright
owner.
ISO 9001(12 100 6061)
According to the international quality management standard ISO 9001, KTM uses quality assurance processes that lead
to the maximum possible quality of the products.
Issued by: TÜV Management Service
KTM-Sportmotorcycle AG
5230 Mattighofen, Austria

MEANS OF REPRESENTATION 2
Symbols used
The symbols used are explained in the following.
Indicates an expected reaction (e.g. of a work step or a function).
Indicates an unexpected reaction (e.g. of a work step or a function).
Identifies a page reference (more information is provided on the specified page).
Formats used
The typographical and other formats used are explained in the following.
Specific name Identifies a proprietary name.
Name®Identifies a protected name.
Brand™ Identifies a brand in merchandise traffic.

SET‑UP 3
2.1Unpacking and setting up the vehicle
600643-01
–Remove the box and the plastic packaging.
Info
To avoid damaging the motorcycle during the setup, leave the protective foil
on the the vehicle until you have finished.
–Check the vehicle for transport damage.
–Unpack the separate enclosure and check its contents on the basis of the enclosure
list.
100303-01
–Remove the operating elements from the transport holder. Remove the screws and
handlebar clamps. Remove the transport holder.
100318-10
–Remove the M8 screw from the right hand guard.
100306-10
–Position the operating elements on the right half of the handlebar.
Info
The routing of cables and Bowden cables can be seen in the figure.
100305-10
–Position the handlebar.
The mark 1of the scale on the handlebar should be in the center of the han-
dlebar clamp.
–Position the handlebar clamps. Fit and evenly tighten the four screws.
Guideline
Screw, handlebar clamp M8 20 Nm
(14.8 lbf ft)
Loctite®243™
600645-01
–Position the operating elements on the left half of the handlebar. Fit the screws.

SET‑UP 4
600646-01
–Mount and tighten the rear mirror adapter and rear mirror on both sides.
–Position all operating elements exactly on the handlebar. Tighten all screws.
–Fit and tighten the M8 screw of the right hand guard.
100308-01
–Mount the footrests with the springs and bolts. Secure the bolts using the washers
and pins.
Plier for footrest spring (58429083000)
–Remove the protective plastic.
–Carefully loosen and remove the tensioning belt over the link fork.
Info
An assistant prevents the motorcycle from falling over.
–Carefully loosen and remove the tensioning belts around the lower triple clamp.
The vehicle is released at the front.
–Together with an assistant, take the vehicle off of the palette.
100277-12
–Recharge the battery. ( p. 7)
–Install the battery. ( p. 8)
100312-10
–Remove the rear fairing. ( p. 8)
–4 markings can be seen on the underside of the rear cover. At these positions,
drill holes in three steps of the prescribed size.
Guideline
Hole diameter for grap handles 14.50 mm (0.5709 in)
100313-10
–Remove screws .
–Fit the rear fairing. ( p. 9)
700217-01
–Mount the reflector.
Operation as 2-seater
–Fit the rear footrest bracket. ( p. 9)

SET‑UP 5
Operation as 1-seater (at customer request only)
Warning
Forfeiture of homologation and insurance cover The vehicle is
homologated as 2-seater. If the heel protector is fitted instead of the
footrest bracket, the vehicle no longer conforms to the homologation and
must not be operated in this form without alterations to the registration
papers.
–Set up and operate the vehicle as a 2-seater or have changes made
to the registration papers.
–Fit the heel protector. ( p. 9)
–Refuel. ( p. 10)
–Print out the current PDI form found on KTM DEALER.NET and perform the delivery
inspection.
–Set kilometers or miles. ( p. 11)

WORK 6
3.1Removing the seat
100230-10
–Pull on strap and raise the rear of the seat at the same time.
–Pull back the seat and lift it off.
3.2Mounting the seat
100276-10
–Hook slot of the seat onto screw , press the rear downward and at the same
time push it forward.
–Push locking pin into lock housing and push the back of the seat down until
the locking pin locks in place with an audible click.
–Finally, check that the seat is correctly mounted.
3.3Removing the battery
Warning
Risk of injury Battery acid and battery gases cause serious cauterization.
–Keep batteries out of the reach of children.
–Wear suitable protective clothing and goggles.
–Avoid contact with battery acid and battery gases.
–Keep the battery away from sparks or open fire. Charge only in well ventilated rooms.
–In the event of skin contact, rinse with large amounts of water. If battery acid gets in the eyes, rinse with water for at least
15 minutes and contact a doctor.
–Switch off all power consumers and switch off the engine.
–Remove the seat. ( p. 6)
100277-10
–Disconnect the negative (minus) cable of the battery.
–Pull off the plug connector upwards.
–Remove screws .
–Pull the retaining bracket of the battery forward and remove it.
–Take off the positive pole cover .
–Disconnect the positive (plus) cable of the battery.
–Push the wiring harness to the side and pull the battery out of the battery rack.
Info
Never operate the motorcycle with a discharged battery or without a battery.
In both cases, electrical components and safety devices can be damaged.
The vehicle is therefore no longer roadworthy.

WORK 7
3.4Recharging the battery
Warning
Risk of injury Battery acid and battery gases cause serious cauterization.
–Keep batteries out of the reach of children.
–Wear suitable protective clothing and goggles.
–Avoid contact with battery acid and battery gases.
–Keep the battery away from sparks or open fire. Charge only in well ventilated rooms.
–In the event of skin contact, rinse with large amounts of water. If battery acid gets in the eyes, rinse with water for at least
15 minutes and contact a doctor.
Warning
Environmental hazard Battery parts and acid are harmful to the environment.
–Do not discard batteries with the household trash. Dispose of a defective battery in an environmentally compatible manner.
Give the battery to your KTM dealer or to a recycling center that accepts used batteries.
Warning
Environmental hazard Hazardous substances cause environmental damage.
–Oil, grease, filters, fuel, cleaners, brake fluid, etc., should be disposed of as stipulated in applicable regulations.
Info
Even when there is no load on the battery, it still loses power steadily.
The charge state and the type of charge are very important for the service life of the battery.
Rapid recharging with a high charging current shortens the battery's service life.
If the charging current, charging voltage and charging time are exceeded, electrolyte escapes through the safety valves. This
reduces the battery capacity.
If the battery is depleted from starting the vehicle repeatedly, the battery must be charged immediately.
If the battery is left in a discharged state for an extended period, it will become over-discharged and sulfate, destroying the
battery.
The battery is maintenance-free, which means that the acid level does not need to be checked.
–Switch off all power consumers and switch off the engine.
–Remove the battery. ( p. 6)
100151-10
–Connect the battery charger to the battery. Switch on the battery charger.
Battery charger (58429074000)
You can also use the battery charger to test rest potential and start potential of the
battery, and to test the alternator. With this device, you cannot overcharge the bat-
tery.
Info
Never remove lid .
Charge the battery with a maximum of 10% of the capacity specified on the
battery housing .
–Switch off and disconnect the charger after charging.
Guideline
The charge current, charge voltage and charge time must not be exceeded.
Charge the battery regularly when the
motorcycle is not in use
3 months
–Install the battery. ( p. 8)

WORK 8
3.5Installing the battery
100277-11
–Slide the battery into the battery rack.
Info
The battery terminals must be at the rear.
–Attach the positive cable and mount positive terminal cover .
–Position retaining bracket .
–Mount and tighten screws .
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
–Plug in connector .
–Attach the minus cable .
–Mount the seat. ( p. 6)
–Set the clock. ( p. 11)
3.6Opening filler cap
100227-10
–Lift the cover of the filler cap and insert the ignition key.
–Turn the ignition key 90° counterclockwise and remove the filler cap.
Info
The filler cap has a tank air vent system.
3.7Closing filler cap
100228-01
–Put the filler cap back on and turn the ignition key 90° clockwise.
–Remove the ignition key and fold down the cover.
3.8Removing rear fairing
–Remove the seat. ( p. 6)
100311-10
–Remove screws .

WORK 9
100314-10
–Remove screws .
–Open the filler cap. ( p. 8)
–Take off the rear fairing.
–Close the filler cap. ( p. 8)
3.9Fitting rear fairing
100315-10
–Position the license plate holder and cable harness.
–Open the filler cap. ( p. 8)
–Position the rear fairing and grab handles as shown in the figure. Fit and slightly
tighten the screws of the grab handles.
–Close the filler cap. ( p. 8)
–Fit and tighten the screws on the rear fairing.
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
100314-10
–Mount and tighten screws .
–Tighten the screws of the grab handles.
Guideline
Screw, handrail M8 20 Nm
(14.8 lbf ft)
–Mount the seat. ( p. 6)
3.10Fitting the rear footrest bracket
Info
The operations are the same for the left and right sides.
100316-10
–Position the footrest bracket . Mount and tighten screws .
Guideline
Screw, rear footrest bracket M8x16 25 Nm
(18.4 lbf ft)
3.11Fitting heel protector
Info
The operations are the same for the left and right sides.

WORK 10
100317-10
Warning
Forfeiture of homologation and insurance cover The vehicle is homologated
as 2-seater. If the heel protector is fitted instead of the footrest bracket, the
vehicle no longer conforms to the homologation and must not be operated in
this form without alterations to the registration papers.
–Set up and operate the vehicle as a 2-seater or have changes made to
the registration papers.
–Position the heel protector . Mount and tighten screws .
Guideline
Screw, heel protector M8x12 8 Nm (5.9 lbf ft)
3.12Refueling
Danger
Fire hazard Fuel is highly flammable.
–Never refuel the vehicle near open flames or burning cigarettes, and always switch off the engine first. Be careful that no
fuel is spilt, especially on hot vehicle components. Clean up spilt fuel immediately.
–Fuel in the fuel tank expands when warm and can escape if the tank is overfilled. See the notes on refueling.
Warning
Danger of poisoning Fuel is poisonous and a health hazard.
–Avoid contact of the fuel with skin, eyes and clothing. Do not inhale fuel vapors. If fuel gets into your eyes, rinse imme-
diately with water and contact a doctor. Wash affected skin areas immediately with soap and water. If fuel is swallowed,
contact a doctor immediately. Change clothing that has come into contact with fuel.
Warning
Environmental hazard Improper handling of fuel is a danger to the environment.
–Do not allow fuel to get into the ground water, the ground, or the sewage system.
Info
This motorcycle is equipped with a regulated catalyst. Leaded fuel will destroy the catalyst. You should therefore use unleaded
fuel only.
400405-10
–Switch off engine.
–Open the filler cap. ( p. 8)
–Fill the fuel tank with fuel up to measurement .
Guideline
Measurement of 20 mm (0.79 in)
Total fuel tank
capacity, approx.
12 l (3.2 US gal) Super unleaded (ROZ 95 / RON 95 /
PON 91) ( p. 14)
–Close the filler cap. ( p. 8)
400882-10
–Press the SET button for two seconds.
The fuel level warning lamp switches off. TRIP F is set to 0.0 and appears in
the previous display mode.
Info
If you do not press the SET button , the reset takes place automatically
after about three minutes.

WORK 11
3.13Setting the clock
Condition
The motorcycle is stationary.
400838-01
–Switch on the ignition by turning the ignition key to position ON .
–Press the MODE button repeatedly until the ODO mode is active.
–Keep the MODE button and the SET button pressed simultaneously.
The time display begins to flash.
–Press the MODE button to set the hour.
–Press the SET button to set the minute.
–Keep the MODE button and the SET button pressed simultaneously.
The time is set.
3.14Setting kilometers or miles
Info
If you change the unit, the value ODO is retained and converted accordingly.
Making the setting according to the country.
Condition
The motorcycle is stationary.
400839-01
–Switch on the ignition by turning the ignition key to position ON .
–Press the MODE button repeatedly until the ODO mode is active.
–Keep the MODE button pressed until the display mode changes from km/h to mph or
from mph to km/h.

TECHNICAL DATA - TIGHTENING TORQUES FOR CHASSIS 12
Screw, license plate holder, bottom EJOT 3 Nm (2.2 lbf ft) –
Screw, SLS valve EJOT 2 Nm (1.5 lbf ft) –
Spoke nipple, front wheel M4.5 4 Nm (3 lbf ft) –
Bolt, foot brake lever stub M5 6 Nm (4.4 lbf ft) Loctite®243™
Remaining screws, chassis M5 4 Nm (3 lbf ft) –
Screw, electrical holder M5 3 Nm (2.2 lbf ft) –
Screw, exhaust heat shield M5 8 Nm (5.9 lbf ft) –
Screw, fuel level sensor M5 3 Nm (2.2 lbf ft) –
Screw, fuel pump M5 6 Nm (4.4 lbf ft) –
Screw, headlight mask M5 5 Nm (3.7 lbf ft) –
Screw, seat lock M5 3 Nm (2.2 lbf ft) Loctite®222
Screw, side cover M5 2 Nm (1.5 lbf ft) –
Screw, side stand switch M5 3 Nm (2.2 lbf ft) –
Screw, starter cable on starter M5 3 Nm (2.2 lbf ft) –
Spoke nipple, rear wheel M5 4 Nm (3 lbf ft) –
Nut, foot brake cylinder screw M6 10 Nm (7.4 lbf ft) –
Remaining nuts, chassis M6 15 Nm (11.1 lbf ft) –
Remaining screws on fuel tank M6 6 Nm (4.4 lbf ft) –
Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –
Screw, ball joint of push rod on foot
brake cylinder
M6 10 Nm (7.4 lbf ft) Loctite®243™
Screw, brake fluid reservoir of rear
brake
M6 5 Nm (3.7 lbf ft) –
Screw, front brake disc M6 14 Nm (10.3 lbf ft) Loctite®243™
Screw, ignition lock M6 10 Nm (7.4 lbf ft) Loctite®243™
Screw, magnetic holder on side stand M6 10 Nm (7.4 lbf ft) Loctite®243™
Screw, radiator bracket M6 5 Nm (3.7 lbf ft) –
Screw, rear brake disc M6 14 Nm (10.3 lbf ft) Loctite®243™
Screw, voltage regulator M6 8 Nm (5.9 lbf ft) –
Nut, manifold on cylinder head M8 25 Nm (18.4 lbf ft) Copper paste
Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft) Loctite®243™
Remaining nuts, chassis M8 30 Nm (22.1 lbf ft) –
Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –
Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft) –
Screw, connection lever on frame M8 30 Nm (22.1 lbf ft) –
Screw, exhaust clamp on main silencer M8 25 Nm (18.4 lbf ft) –
Screw, fork stub M8 15 Nm (11.1 lbf ft) –
Screw, front footrest bracket M8 25 Nm (18.4 lbf ft) –
Screw, fuel tank, bottom M8 20 Nm (14.8 lbf ft) –
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) Loctite®243™
Screw, handrail M8 20 Nm (14.8 lbf ft) –
Screw, heel protector M8x12 8 Nm (5.9 lbf ft) –
Screw, license plate holder, top M8 20 Nm (14.8 lbf ft) –
Screw, main silencer holder M8 25 Nm (18.4 lbf ft) –
Screw, main silencer holder on fuel
tank
M8 25 Nm (18.4 lbf ft) Loctite®243™
Screw, rear footrest bracket M8x16 25 Nm (18.4 lbf ft) –
Screw, side stand bracket M8 25 Nm (18.4 lbf ft) –
Screw, spring holder on side stand
bracket
M8 25 Nm (18.4 lbf ft) Loctite®243™
Screw, steering stem M8 20 Nm (14.8 lbf ft) Loctite®243™
Screw, top triple clamp M8 17 Nm (12.5 lbf ft) –
Upper fuel tank screw M8 20 Nm (14.8 lbf ft) –

TECHNICAL DATA - TIGHTENING TORQUES FOR CHASSIS 13
Engine carrying screw M10 45 Nm (33.2 lbf ft) Loctite®243™
Remaining nuts, chassis M10 50 Nm (36.9 lbf ft) –
Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –
Screw, bottom shock absorber M10 45 Nm (33.2 lbf ft) Loctite®243™
Screw, engine bearer on frame M10 45 Nm (33.2 lbf ft) –
Screw, foot brake lever M10LH 25 Nm (18.4 lbf ft) Loctite®243™
Screw, handlebar support M10 40 Nm (29.5 lbf ft) –
Screw, side stand M10 35 Nm (25.8 lbf ft) Loctite®243™
Screw, top shock absorber M10 45 Nm (33.2 lbf ft) Loctite®243™
Screw, front brake caliper M10x1.25 45 Nm (33.2 lbf ft) Loctite®243™
Lambda sensor M12x1.25 24.5 Nm (18.07 lbf ft) Copper paste
Screw, swingarm pivot M12x1.75 80 Nm (59 lbf ft) –
Nut, linkage lever on swingarm M14x1.5 100 Nm (73.8 lbf ft) –
Nut, linkage lever to rocker arm M14x1.5 100 Nm (73.8 lbf ft) –
Screw, bottom steering head M20x1.5 60 Nm (44.3 lbf ft) Loctite®243™
Screw, top steering head M20x1.5 10 Nm (7.4 lbf ft) –
Screw, front wheel spindle M24x1.5 40 Nm (29.5 lbf ft) –
Nut, rear wheel spindle M25x1.5 90 Nm (66.4 lbf ft) –

SUBSTANCES 14
Super unleaded (ROZ 95 / RON 95 / PON 91)
According to
–DIN EN 228 (ROZ 95 / RON 95 / PON 91)

*3211470en*
3211470en
KTM-Sportmotorcycle AG
5230 Mattighofen/Austria
http://www.ktm.com
02/2010
Photo: Mitterbauer
