kuzco lighting THALIA User manual

THALIA CEILING FAN INSTRUCTION SHEET
MODEL CF91954
Scan this QR code with your phone to view our step by step installation video or visit
https://kuzcolighting.com/fan-resources.
TF. 1.855.855.8926 | T. 604 538 7162 | F. 604 538 7196
CANADA: 19054 28th Ave., - Surrey, BC V3Z 6M3
USA: 3035 E. Lone Mountain Rd. - Las Vegas, NV 89081
www.kuzcolighting.com
20230505

Page 2 of 16
1. To reduce the risk of electric shock, ensure electricity has
been turned off at the circuit breaker or fuse box before
beginning.
2. All wiring must be in accordance with the National
Electrical Code and local electrical codes. Electrical
installation should be performed by a qualified licensed
electrician.
3. CAUTION: Read all instructions and safety information
before installing your new fan. Review accompanying
assembly diagrams.
4. WARNING: To reduce the risk of electrical shock and fire,
do not use this fan with any solid-state fan speed control
device.
5. WARNING: To reduce the risk of fire, electric shock, or
personal injury, mount to UL Listed outlet box marked
“acceptable for fan support of 15.9 kg (35 lbs) or less”
and use mounting screws provided with the outlet box.
Most outlet boxes commonly used for the support of light
fixtures are not acceptable for fan support and may need
to be replaced. Due to the complexity of the installation
of this fan, a qualified licensed electrician is strongly
recommended.
6. The outlet box and support structure must be securely
mounted and capable of reliably supporting a minimum of
50 pounds.
7. The fan must be mounted with a minimum of 7 feet
clearance from the trailing edge of the blades to the floor.
The tip of the fan blade to the nearest wall/obstruction:
30 inches.
READ AND SAVE THESE INSTRUCTIONS.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK,
THIS FAN MUST BE INSTALLED WITH AN ISOLATING
WALL SWITCH.
8. Avoid placing objects in the path of the blades.
9. To avoid personal injury or damage to the fan and other
items, be cautious when working around or cleaning the
fan.
10. Do not use water or detergents when cleaning the fan
or fan blades. A dry dust cloth or lightly dampened cloth
will be suitable for most cleaning.
11. After making electrical connections, spliced conductors
should be turned upward and pushed carefully up into
outlet box. The wires should be spread apart with the
grounded conductor and the equipment- grounding
conductor on one side of the outlet box.
12. Electrical diagrams are for reference only. Light kits that
are not packed with the fan must be UL and cUL Listed
and marked suitable for use with the model fan you are
installing. Switches must be UL and cUL General Use
Switches. Refer to the Instructions packaged with the
light kits and switches for proper assembly.
13. Note: Suitable for use in damp locations. Use only with
light kits marked “Suitable for use in damp locations.”
14. Do not operate reversing switch while fan blades are
in motion. Fan must be turned off and blades stopped
before reversing blade direction.
WARNING: TO REDUCE THE RISK OF PERSONAL INJURY,
DO NOT BEND THE BLADE ARMS (ALSO REFERRED
TO AS FLANGES), WHEN INSTALLING THE BRACKETS,
BALANCING THE BLADES OR CLEANING THE FAN.
SAFETY INFORMATION

Page 3 of 16
• Safety
• Tools Needed
• Package Contents
• Hardware Included
• Fan Assembly
• Electrical Connections
• Fan Blade Installation
• Light Kit Installation
• Fan Operation
• Care and Cleaning
• Troubleshooting
• Warranty Information
TOOLS NEEDED
• Phillips screwdriver
• Flathead screwdriver
• Step ladder
• Wire cutter
HARDWARE INCLUDED
• Bracket Mounting Hardware
-wood screws (1a)
-screws (1b)
-wire nuts (1c)
-lock washers (1d)
-flat washers (1e)
• Blade to Motor Screws and Lock Washers (2a)
• Balance Kit (3a)
• Fan Mounting Hardware
-cotter pin (4a)
-clevis pin (4b)
PACKAGE CONTENTS
1a.
x3
1b.
x2
1c.
x3
1d.
x3
1e.
x3
2a.
x10
3a. 4a.
x1
4b.
x1

Page 4 of 16
Part Description Quantity
A Mounting bracket 1
B Canopy 1
C Canopy screw cover 1
D Hanger ball/downrod assembly 1
E Coupling cover 1
F Fan motor 1
G Blade 3
H Light kit pan 1
I LED Light kit assembly 1
J Glass shade 1
K Receiver 1
L Remote control 1
PACKAGE CONTENTS
A
B
C
D
E
F
G
H
I
J
KL

Page 5 of 16
Outlet Box Mounting Options
If there isn’t an existing UL Listed octagonal mounting box marked “Acceptable for Fan Support” follow the instructions below.
(REMINDER: an electrical junction box for use with luminaires is not acceptable for this application)
• Before you begin installing the mounting box, shut off the power at the circuit breaker of the fuse box.
• Secure the box directly to the building structure. The figures below show 3 example methods.
Cross brace
Outlet
box
Ceiling joist
Ceiling joist or Cross brace
Min 2”
Thick
Parallel
wood
brace
Ceiling joist
Hanger bar
Outlet
box
PREPARING THE MOUNTING HARDWARE
INSTALLING THE HANGING BRACKET
CAUTION: TO AVOID POSSIBLE ELECTRICAL SHOCK,
BE SURE ELECTRICITY IS TURNED OFF AT THE MAIN
POWER BOX BEFORE WIRING. ALL WIRING MUST BE IN
ACCORDANCE WITH NATIONAL AND LOCAL ELECTRICAL
CODES AND THE CEILING FAN MUST BE GROUNDED AS A
PRECAUTION AGAINST POSSIBLE ELECTRIC SHOCK. Outlet box
Mounting
bracket
1. Loosen the two mounting screws in the outlet box. Pass
the 120-Volt supply wires through the center hole in the
slide-on mounting bracket .
2. Slide the slide-on mounting bracket on to the mounting
screws and center the slide-on mounting bracket in
relation to the outlet box. If necessary, use leveling
washers (not included) between the slide-on mounting
bracket and the outlet box. The flat side of the slide-on
mounting bracket should face toward the outlet box, as
shown.
3. Securely tighten the two mounting screws.

Page 6 of 16
INSTALLING THE BLADES
1. Insert the blade through the slot cut-off in the center
flywheel, align the three screw holes in the blade with the
screw holes in the flywheel and secure with the screws
and lockwasher provided.
2. Repeat for the remaining blades.
Blade
Screw
PREPARING THE MOTOR
1. Loosen the collar set screws from the motor collar.
2. Take out the set screw located in the hanger ball, lower
the hanger ball and remove the cross pin. Remove the
hanger ball from the hanger ball/downrod assembly.
Set screw
Cross Pin
Downrod
Hanger ball
Collar set screws
Motor collar

Page 7 of 16
ASSEMBLING THE FAN
WARNING: Failure to properly install the cotter pin could
result in the fan becoming loose and possibly falling.
HANGING THE FAN
1. Carefully lift the fan motor assembly up to the mounting
bracket and seat the hanger ball/downrod assembly in
the mounting bracket socket. Make sure the tab on the
mounting bracket socket is properly seated in the groove
in the hanger ball/downrod assembly. This will help to
balance the ceiling fan.
WARNING: The tab in the ring must rest in the groove of
the hanger ball/downrod assembly. Failure to properly
seat the tab in the groove could cause damage to the
wiring. Mounting
bracket
Groove Tab
Downrod
Hanger
ball
Downrod
Coupling Cover
Canopy Screw
Cover
Safety cable
Cotter Pin
Clevis Pin
Collar set
screws
Motor collar
Hanger ball
Cross Pin
Set screw
Canopy
Reverse
switch
1. Carefully feed the motor wires and safety cable up
through the downrod. Thread the downrod into the collar
until the holes at the bottom of the downrod align with
the holes in the collar.
2. Carefully insert the clevis pin through the holes in the
collar and downrod. Insert the cotter pin through the
hole, near the end of clevis pin until it snaps into its
locked position.
3. Slip the coupling cover, the canopy screw cover, and the
canopy onto the downrod.
4. Carefully reinstall the hanger ball onto the downrod.
Being sure that the cross pin is in the correct position, the
set screw is tightened and wires are not twisted.

Page 8 of 16
INSTALLATION OF THE SAFETY CABLE SUPPORT
1. Attach the wood screw and the flat washer to the ceiling
joist as shown (do not fully tighten). Slide the cable
clamp onto the safety cable from the fan. Loop the safety
cable around the wood screw that was just attached to
ceiling joist. Feed the end of the cable into the clamp and
pull as much cable through as possible. Firmly tighten
screw in the clamp. Cut off excess cable.
Wood ceiling joist
Safety Cable Clamp
Wood screw
and washer
Safety cable loop
Safety cable
INSTALLING THE RECEIVER
1. Position the house supply wires to one side of the
slide-on mounting bracket; position the fan wires to the
opposite side.
2. Insert the receiver (as shown, flat side toward ceiling) into
the slide-on mounting bracket until it rests on top of the
ball/downrod assembly.

Page 9 of 16
ELECTRICAL CONNECTIONS
1. Make wire connections from the fan to the receiver unit.
For this step use the bundle of 3 wires on the receiver.
• Connect the BLUE fan wire to the BLUE receiver wire.
• Connect the BLACK fan wire to the BLACK receiver
wire.
• Connect the WHITE fan neutral wire to the WHITE
receiver neutral wire.
2. Connect the wiring from the ceiling to the receiver unit.
For this step use the bundle of 2 wires on the receiver.
Secure with supplied wire nuts.
• Connect the BLACK building supply wire to the
BLACK receiver wire.
• Connect the WHITE receiver neutral wire to the
WHITE building neutral wire.
• Connect the COPPER building ground wire to the 2
GREEN ground wires from the fan.
WARNING: To avoid possible electrical shock, be sure
electricity is turned off at the main fuse box before
installation.
WARNING: Check to see that all connections are tight,
including ground, and that no bare wire is visible at the wire
nuts, except for the ground wire.
CAUTION: To reduce the risk of electric shock, this fan must
be installed with an isolating, general-use wall control/
switch.
NOTE: Control must be installed within 30 feet of fan.
Ceiling
Receiver
BLACK
WHITE
BLUE
BLK (AC IN)
WH (AC IN)
GROUND
Outlet box
WH
BLK
YELLOW / GRN (downrod)
YELLOW / GRN (hanger bracket)
BLACK
WHITE
BLUE

Page 10 of 16
Mounting bracket
Canopy mounting screw
Canopy
Canopy mounting screw
Canopy
Canopy
mounting
screw Canopy screw
cover
INSTALLING THE CANOPY
1. Align the locking slots of the canopy with the two
screws and alignment post (in the slide-on mounting
bracket).
2. Push up the canopy and turn it until the alignment post
engages to the round hole and the screws engage to the
key slots.
3. Firmly tighten the two mounting screws.
4. Align the oval shape on the canopy with canopy bottom
cover.
5. Push up the canopy bottom cover until the screw heads
engage to the slots on the canopy bottom cover so that
the magnetic canopy bottom cover can be attached to
the bottom of the canopy properly.
WARNING: When using the standard ball/downrod mounting,
the tab in the ring at the bottom of the mounting bracket
must rest in the groove of the hanger ball. Failure to properly
seat the tab in the groove could cause damage to the wiring.
NOTE: The magnet is pre-attached on the canopy bottom
cover for you to remove and install easily.

Page 11 of 16
INSTALLING THE LIGHT KIT PAN
1. Loosen but do not remove two of three mounting screws
from the fan motor assembly; Remove one mounting
screw.
2. Push the light kit pan up to the fan motor assembly so
that the two loosened screw heads fit into the keyhole
slots. Turn the light kit pan, tighten the screws.
3. Re-install the screw that was removed in step 1 and
tighten firmly.
CAUTION: To reduce the risk of electrical shock, disconnect
the electrical supply circuit to the fan before installing the
light kit.
INSTALLING THE LED ASSEMBLY
1. Remove one screw from the light kit pan and loosen, but
do not remove, the other two screws.
2. Connect the wires from the light kit fitter assembly to
the wires from the fan motor assembly by connecting the
molded adaptor plugs together. Carefully tuck all wires
and splices into the switch cap.
3. Push the light kit assembly up so that the two loosened
screw heads fit into the keyhole slots.
4. Turn the light kit assembly, tighten the screws. Reinstall
the screw that was removed in step 1 and tighten firmly.
CAUTION: To reduce the risk of electrical shock, disconnect
the electrical supply circuit to the fan before installing the
light kit.
Screw
LED assembly
LK pan
Screw
1. Place the glass shade into the light kit pan, aligning the
three flat areas on the top of the glass shade with the
three raised dimples in the light kit pan. Turn the glass
shade until it stops.
INSTALLING THE GLASS SHADE
Shade

Page 12 of 16
INSTALLING THE REMOTE CONTROL HOLDER
1. Remove the remote control holder cover from the remote
control holder.
2. Attach the remote control holder with the two remote
control holder mounting screw provided.
3. Replace the remote control holder cover into remote
control holder.
Remote control
holder cover
Remote control
holder
Screws

Page 13 of 16
OPERATION
Install battery (included). To prevent damage to transmitter,
remove the battery if not used for long periods of time.
IMPORTANT: If you have two or more fans, please follow
steps below to control each fan independently. Also follow
steps below to re-pair the remote and the receiver when
needed.
1. 1, 2 and 3 buttons:
These three buttons are used to set the fan speed as follows:
1 = minimum speed
2 = medium speed
3 = high speed
2. button:
This button turns the fan off.
3. button:
This button turns on “breeze” option.
4. button:
This button controls the light “ON/OFF” and “Dimmable”
options.
5. 2H, 4h and 8H buttons:
These three buttons are used to set the fan timer as follows:
2H = 2 hour timer
4H = 4 hour timer
8H = 8 hour timer
SET code setting button:
Follow the below steps to set the remote control:
• With the fan’s power off, press and release the “Learn”
button located in the remote’s battery compartment within
30 seconds of turning the electrical power to the fan on.
If pairing is successful, the fan’s light kit will flash, the blades
will begin to spin and the fan and light kit will turn off within 30
seconds.
NOTE:If the self calibration test failed, turn the AC power off;
restore power and process the self calibration test again.

Page 14 of 16
OPERATION (continued)
NOTE: The learning frequency function and self calibration test will continue to retain the last set frequency and calibration
set even when the AC power is shut off. If the frequency is changed the self calibration test will occur again.
Summer Mode and Winter Mode Operation
The fan shipped from the factory with the reversing switch positioned to circulate air downward. If airflow is desired in the
opposite direction, turn your fan off and wait for the blades to stop turning, then slide the reversing switch (located at the top of
the motor housing, refer to page 7) to opposite position, and turn fan on again. The fan blades will turn in the opposite direction
and reverse airflow.
Speed settings for warm or cold weather depend on factors such as room size, ceiling height and number of fans.
Summer Mode (forward):
A DOWNWARD airflow creates a cooling effect. This allows
you to set your air conditioner on a warmer setting without
affecting your comfort.
Winter Mode (reverse):
A UPWARD airflow moves warmer air off the ceiling area.
This allows you to set your heating unit on a cooler setting
without affecting your comfort.
OPERATING CEILING FAN WITH THE BOND APP
NOTE: Confirm that your smart device (phone/tablet) is
connected to your WiFi network before proceeding.
• Using your smart device, navigate to the application
store (Apple App Store or Google Play). Download the
free BOND Home app and create an account.
1. Download the BOND HOME app
• Ensure the fan and receiver are receiving power from the
house supply by using the remote control to turn the fan
and light on and off.
• Open the BOND Home app on your smart device and
follow the instructions included in the app to add your fan.
2. Connect to the BOND receiver

Page 15 of 16
CARE AND CLEANING
• Periodically it may be necessary to re-tighten blade to blade arm screws or blade arm to motor screws to prevent clicking
or humming sound during operation. This is especially true in climates with broad temperature and humidity ranges.
• When dusting the blades, you must support the blade to prevent bending - no pressure should be applied to the blades. If
you experience any flaws in the operation of your fan, please check the following points.
TROUBLESHOOTING
PROBLEM SOLUTION
FAN WILL NOT START 1. Check circuit fuses or breakers.
2. Check wall control LED indicator light. If LED is not illuminated when pushing a button, it is
not transmitting a signal. Please check battery, power to wall control/circuit breaker and all
electrical connections.
3. Assure there are no more than 2 fans operating on a circuit through the wall control. Assure that
there are no more than 12 fans operating on a circuit through an on/off wall switch or a breaker
(not through a wall control).
4. Assure that the fan is within range of the wall control (30 ft.).
FAN SOUNDS NOISY 1. Allow a 24-hour “breaking-in” period. Most noise associated with a new fan will disappear during
this time.
2. Make sure all motor housing screws are securely fastened.
3. Make sure the screws that attach the fan blade to the fan are tight.
4. Make sure your ceiling box is secure and rubber isolator pads are used between the mounting
bracket and outlet box.
FAN WOBBLES 1. Check that all blade to motor and blade arm screws are secure.
2. If the blade wobble is still noticeable, interchanging two adjacent (side by side) blades can
redistribute the weight and possibly result in smoother operation.
3. Make sure the mounting plate is securely fastened to the ceiling outlet box.
4. Make sure ceiling box is secure.

Page 16 of 16
PART RESIDENTIAL USE COMMERCIAL/HOSPITALITY USE
Motor Lifetime Lifetime
Integrated LED Components 1 year 3 year
LED Bulbs 1 year 1 year
Blades, Controls, Switches, Capacitors, Hardware 1 year 1 year
KUZCO GROUP CEILING FAN LIFETIME LIMITED WARRANTY
Below is a detailed list of items warranted:
What is covered?
• Parts that arrive damaged
• Parts missing from the box
• Parts that do not function properly
• Parts that have ceased proper functioning within warranty limits
What is not covered?
• Installation costs
• Parts worn down with regular usage
• Parts damaged in installation
• Modified parts
• Parts out of warranty
WARRANTY APPLIES ONLY TO ORIGINAL PURCHASER FROM AN AUTHORIZED KUZCO GROUP DISTRIBUTOR.
Kuzco Group products are warranted against defects in materials and construction, subject to conditions and exclusions, for a
period of one (1) year from the date of product shipment to the customer. Kuzco Group warrants the original owner that the motor
in the fan will be free from defects for the lifetime of the fan. This warranty does not apply to fans which have been damage
because of improper installation, removed from the original installation or subjected to use for which the fan was not designed.
The customer is responsible for any cost of removing the old fan, installing a new fan or any other costs. This limited lifetime
warranty is in lieu of all other expressed warranties. Kuzco Group shall not be liable for any incidental or consequential damages.

Using your smart device, scan the QR code below
to go to the application Store to download the
free Bond Home app.
Step 1
Check that your fan and receiver are
securely connected to the house supply:
Using your fan's remote control, turn the
fan and the light on and off.
Test your ceiling fan
according to the app's
prompts to toggle the
fan and lights.
ČūŠǶƑŞîƥĿūŠDžĿŕŕ
appear on-screen to let
you know that your
ceiling fan has been
successfully connected
to the Bond Home App.
Click CONTINUE to
proceed with setting up
your ceiling fan.
Step 2
Step 6
Step 5
Name your ceiling fan:
Step 7
Open the Bond Home App on your mobile device
and follow the step-by-step instructions in the
app to add your ceiling fan.
Create an account or login to your existing
account.
You will be prompted to allow permissions to
the Bond Home App. These permissions are
needed to set up new devices.
Step 3 Step 4
ĺūūƙĚîŕūČîƥĿūŠIJƑūŞƥĺĚƎƑĚēĚǶŠĚēŕĿƙƥūƑ
add your own location.
Choose a device name.
This name will be used for integrations and
voice commands, so we recommend choosing
a simple and descriptive name.
Connect to Wi-Fi:
If you need assistance at any time during the
setup process, please visit the Help section of the
Bond Home App, located in Settings. Select from
either "Open a Ticket" or "Live Chat" to connect
with a member of the Bond Support Team.
Step 8
Setup complete! Your fan should
appear in the app. Sit back, relax, and
enjoy your new ceiling fan!
Step 9
Select your desired Wi-Fi network and enter
password if necessary.
Once the connection is made, select DONE.
If your fan does not appear, try swiping down
to refresh.
Follow the prompt to go to your device’s settings
îŠēČūŠŠĚČƥƥūƥĺĚūŠē ūŠǶijØĿɠGĿŠĚƥDžūƑŒɍ
If you do not see the Bond Config Wi-Fi network
listed, press and hold the power button on your
ceiling fan’s remote control for 10 seconds.
Additionally, you can try refreshing your Wi-Fi list.
Go back to the Bond Home app.
Welcome
How to
on a Android device
Activate your
Smart Fan
Select the "Smart
by Bond" ceiling
fan option.
Select "+" to add
a new device
In the bottom

Using your smart device, scan the QR code below
to go to the application Store to download the
free Bond Home app.
Step 1
Check that your fan and receiver are
securely connected to the house supply:
Using your fan's remote control, turn the
fan and the light on and off.
Test your ceiling fan
according to the app's
prompts to toggle the
fan and lights.
ČūŠǶƑŞîƥĿūŠDžĿŕŕ
appear on-screen to let
you know that your
ceiling fan has been
successfully connected
to the Bond Home App.
Click CONTINUE to
proceed with setting up
your ceiling fan.
Step 2
Step 6
Step 5
Name your ceiling fan:
Step 7
Open the Bond Home App on your mobile device
and follow the step-by-step instructions in the
app to add your ceiling fan.
Create an account or login to your existing
account.
You will be prompted to allow permissions to
the Bond Home App. These permissions are
needed to set up new devices.
Step 3 Step 4
ĺūūƙĚîŕūČîƥĿūŠIJƑūŞƥĺĚƎƑĚēĚǶŠĚēŕĿƙƥūƑ
add your own location.
Choose a device name.
This name will be used for integrations and
voice commands, so we recommend choosing
a simple and descriptive name.
Connect to Wi-Fi:
If you need assistance at any time during the
setup process, please visit the Help section of the
Bond Home App, located in Settings. Select from
either "Open a Ticket" or "Live Chat" to connect
with a member of the Bond Support Team.
Step 8
Setup complete! Your fan should
appear in the app. Sit back, relax, and
enjoy your new ceiling fan!
Step 9
Select your desired Wi-Fi network and enter
password if necessary.
Once the connection is made, select DONE.
If your fan does not appear, try swiping down
to refresh.
Follow the prompt to go to your device’s settings
îŠēČūŠŠĚČƥƥūƥĺĚūŠē ūŠǶijØĿɠGĿŠĚƥDžūƑŒɍ
If you do not see the Bond Config Wi-Fi network
listed, press and hold the power button on your
ceiling fan’s remote control for 10 seconds.
Additionally, you can try refreshing your Wi-Fi list.
Go back to the Bond Home app.
Select the "Smart
by Bond" ceiling
fan option.
Select "+" to add
a new device
In the top-right corner
Welcome
How to
on a iOS device
Activate your
Smart Fan

The Factory Reset will erase all fan settings,
schedules, and disconnect from your Wi-Fi
network. However, the fan will remain paired
with the remote control.
If your fan is already connected to WiFi, the Bond
ūŠǶijŠĚƥDžūƑŒDžĿŕŕēĿƙîƎƎĚîƑɍ¹ūČîƭƙĚĿƥƥū
reappear, hold down the Power button on the
remote control for 10 seconds and refresh your
WiFi network list on your phone or tablet.
To perform a Factory Reset:
Bond Config network does not
show up in my WiFi list
Troubleshooting
Turn off the breaker or wall switch.
Turn the breaker/switch back on.
Immediately press and hold the Fan Speed 1
button on your ceiling fan’s remote control for
ȃȁƙĚČūŠēƙɈūƑƭŠƥĿŕƥĺĚČĚĿŕĿŠijIJîŠŕĿijĺƥǷîƙĺĚƙ
ǶDŽĚƥĿŞĚƙɍɚsūƥĚɇÞūƭŞƭƙƥƙƥîƑƥĺūŕēĿŠijƥĺĚ
button within 15 seconds of turning the
breaker or wall switch back on.)
1.
2.
3.

FAN SLOPE CEILING ADAPTOR INSTALLATION SHEET
MODEL: X-ADP 34 FAN
CANADA: 19054 28th Ave. - Surrey, BCV3Z 6M3
USA: 3035 E. Lone Mountain Rd. - Las Vegas, NV 89081
www.kuzcolighting.com
20230802
TF. 1.855.855.8926 | T. 604.538.7162 | F. 604.538.7196
