KYMCO MXU 700i User manual

TABLE OF CONTENTS
- 1 -
FOREWORD ................................................................................................... i
PROTECT YOUR SPORT .................................................................................. i
IMPORTANT NOTICES ................................................................................... ii
SAFE RIDING INFORMATION ....................................................................... iii
PREFACE ...................................................................................................... iv
1. LOCATION OF THE WARNING AND SPECIFICATION LABELS*........1-1
1.1. LABELS FOR T3b MODELS ...........................................1-2
2. SAFETY INFORMATION ..................................................................2-1
3. DESCRIPTION AND MACHINE IDENTIFICATION.............................3-1
3.1. KEYS IDENTIFICATION NUMBER..................................3-1
3.2. IDENTIFICATION NUMBER RECORDS ..........................3-1
3.3. ENGINE SERIAL NUMBER ............................................3-2
3.4. ENGINE SERIAL NUMBER ............................................3-3
3.5. PARTS LOCATIONS* .....................................................3-4
4. CONTROL FUNCTIONS...................................................................4-1
4.1. IGNITION SWITCH .......................................................4-1
4.2. INSTRUMENTS AND INDICATOR..................................4-2
4.3. LEFT HANDLEBAR SWITCHES ....................................4-15
4.4. Winch switch............................................................. 4-18
4.5. EPS/ABS..................................................................... 4-19
4.6. TO JUMP START YOUR VEHICLE ................................4-20
4.7. RIGHT HANDLEBAR SWITCH .....................................4-21
4.8. THROTTLE LEVER.......................................................4-22
4.9. SPEED LIMITER..........................................................4-23
4.10. BRAKE........................................................................ 4-24
4.11. PARKING BRAKE ........................................................4-25
4.12. LOCKING STEERING...................................................4-26
4.13. DRIVE SELECT LEVER .................................................4-27
4.14. FUEL TANK CAP .........................................................4-28
4.15. SPARK PLUG INSPECTION..........................................4-29
4.16. BATTERY INSPECTION................................................4-29
4.17. SEAT........................................................................... 4-30
4.18. FLAG POLE BRACKET .................................................4-31
4.19. TRAILER HITCH* ........................................................4-31

TABLE OF CONTENTS
- 2 -
4.20. STORAGE COMPARTMENTS ......................................4-32
4.21. ACCESSORY SOCKET ..................................................4-34
4.22. TRAILER SOCKET*......................................................4-35
5. PRE-OPERATION CHECKS...............................................................5-1
5.1. DRIVE SELECT LEVER ...................................................5-2
5.2. FRONT AND REAR BRAKES ..........................................5-6
5.3. FUEL.............................................................................5-7
5.4. DRIVE SHAFT BOOTS ...................................................5-8
5.5. ENGINE OIL..................................................................5-9
5.6. REAR GEAR CASE OIL.................................................5-10
5.7. FRONT GEAR CASE OIL ..............................................5-10
5.8. THROTTLE LEVER .......................................................5-11
5.9. FITTINGS AND FASTENERS.........................................5-11
5.10. LIGHTS .......................................................................5-11
5.11. SWITCHES..................................................................5-11
5.12. BATTERY CUT OFF SWITCH* ......................................5-11
5.13. TIRES..........................................................................5-12
5.14. HOW TO MEASURE TIRE PRESSURE ..........................5-13
5.15. TIRE WEAR LIMIT ...................................................... 5-14
5.16. COOLANT .................................................................. 5-14
6. OPERATION ................................................................................... 6-1
6.1. STARTING A COLD ENGINE.......................................... 6-1
6.2. STARTING A WARM ENGINE .......................................6-3
6.3. DRIVE SELECT LEVER ...................................................6-4
6.4. ENGINE BREAK-IN .......................................................6-6
6.5. PARKING ......................................................................6-7
6.6. ACCESSORIES............................................................... 6-9
6.7. LOADING ................................................................... 6-10
7. RIDING YOUR ATV .........................................................................7-1
7.1. GETTING TO KNOW YOUR ATV ................................... 7-2
7.2. RIDE WITH CARE AND GOOD JUDGEMENT ................7-3
7.3. NOT RECOMMENDED FOR CHILDREN UNDER 16 YEAR OF
AGE. 7-4
7.4. NEVER CARRY PASSENGER ON THE CARGO RACKS.....7-4
7.5. APPAREL ......................................................................7-5
7.6. DO NOT OPERATE AFTER CONSUMING ALCOHOL OR

TABLE OF CONTENTS
- 3 -
DRUGS. 7-6
7.7. PRE-OPERATION CHECKS.............................................7-7
7.8. DO NOT OPERATE AT SPEEDS TOO FAST YOUR SKILLS OR
THE CONDITIONS. .........................................................................7-8
7.9. LOADING AND ACCESSORIES.......................................7-9
7.10. MODIFICATIONS ........................................................7-11
7.11. DURING OPERATION .................................................7-12
7.12. EXHAUST SYSTEM......................................................7-14
7.13. PRACTICING...............................................................7-15
7.14. TURNING YOUR ATV..................................................7-16
7.15. CLIMBING UP SLOPE .................................................7-17
7.16. RIDING DOWN SLOPE................................................7-23
7.17. PARKING ....................................................................7-25
7.18. WHAT TO DO IF..........................................................7-25
8. PERIODIC MAINTENANCE AND ADJUSTMENT..............................8-1
8.1. TOOL KIT/TOOL KIT COMPARTMENT...........................8-2
8.2. PERIODIC MAINTENANCE/LUBRICATION....................8-4
8.3. ENGINE OIL..................................................................8-7
8.4. REAR GEAR BOX OIL..................................................8-14
8.5. FRONT GEAR BOX OIL ...............................................8-16
8.6. SPARK PLUG INSPECTION..........................................8-18
8.7. SPARK ARRESTER.......................................................8-19
8.8. AIR FILTER CLEANING................................................8-21
8.9. AIR CLEANER HOUSING DRAIN TUBE........................8-23
8.10. IDLE SPEED INSPECTION ...........................................8-24
8.11. THROTTLE LEVER ADJUSTMENT................................8-25
8.12. VALVE CLEARANCE ADJUSTMENT.............................8-26
8.13. FRONT BRAKE PADS .................................................. 8-26
8.14. REAR BRAKE PADS.....................................................8-27
8.15. BRAKE FLUID INSPECTION......................................... 8-27
8.16. COOLING SYSTEM INSPECTION.................................8-29
8.17. ELECTRIC POWER STEERING SYSTEM (EPS)* ............8-31
8.18. ENGINE OVERHEATING .............................................8-32
8.19. WHEEL.......................................................................8-33
8.20. B AT T E R Y ....................................................................8-35
8.21. FUSE REPLACEMENT .................................................8-37

TABLE OF CONTENTS
- 4 -
8.22. HEADLIGHT BEAM ADJUSTMENT..............................8-39
8.23. DRIVE SHAFT BOOTS .................................................8-39
8.24. CABLE INSPECTION AND LUBRICATION.....................8-40
8.25. TROUBLESHOOTING..................................................8-41
9. CLEANING AND STORAGE .............................................................9-1
9.1. CLEANING YOUR ATV...................................................9-1
9.2. STORAGE .....................................................................9-5
9.3. SPECIFICATIONS...........................................................9-7
9.4. NOISE REGULATION...................................................9-13
9.5. MAINTENANCE RECORD ...........................................9-14

i
FOREWORD
Congratulations, and thank you for your purchase of a KYMCO All-Terrain Vehicle (ATV). Built with American engineering and global
manufacturing knowledge, it is designed to provide a superior ride, great comfort, and strong utility capabilities.
This Owner’s Manual was produced to ensure that you become aware of safe ATV operating procedures. It also includes information
about the general care and maintenance of your ATV.
Carefully read this manual. If you have any questions regarding your ATV, contact an authorized KYMCO ATV dealer for assistance.
Remember, only authorized KYMCO ATV dealers have the knowledge and resources to provide you with the best service possible.
PROTECT YOUR SPORT
Being able to use and enjoy your ATV requires you and your family to operate it in a responsible manner. Before riding your ATV you should:
Learn and adhere to all local and state off-road riding laws
Respect your ATV and its capabilities and limitations
Respect the environment and the rights of others
We advise you to strictly follow the recommended maintenance program for your ATV outlined in this manual. This preventative
maintenance program was designed to ensure that all of the critical components of your ATV are thoroughly inspected at various intervals.
The information in this manual is based on the latest product data and specifications available at the time of printing. KYMCO Inc.
reserves the right to make product changes and improvements which may affect illustrations or explanations without notice.

ii
IMPORTANT NOTICES
KYMCO and the ATV Safety Institute recommend that all
ATV operators ride an ATV appropriate for their age.
Age (Years) Engine Size (cc) Speed Limitations (MPH)
6-11 Up to 70 10 - Governed
15 - Maximum
12-15 Up to 90 15 - Governed
30 - Maximum
16 and Older Over 90 According to Local
Regulations
READ THIS MANUAL CAREFULLY
Your owner’s manual contains important information on safety, operation, and maintenance. Anyone who operates this ATV should
carefully read and understand the contents of this manual before riding the vehicle.
AGE RECOMMENDATION
The minimum recommend age for this ATV model is 16. Children under age 16 should never operate this vehicle.
RIDER TRAINING
Anyone who operates this vehicle should get proper instruction.
Use ATV
Please check your local riding law and regulations before operating this machine.

iii
SAFE RIDING INFORMATION
KYMCO provide many important many safety messages both in this manual and on the vehicle. For your safety and the safety of
others, pay special attention to all warning preceded by this alert symbol . Failure to follow the warnings contained in this
manual can result in SEROUS INJURY or DEATH.
The SAFETY ALERT symbol with the exclamation point in the triangle means
ATTENTION! BE ALERT! YOUR SAFETY CAN BE AFFECTED.
Failure to follow instructions associated with a WARNING symbol could result in severe
injury or death to the operator, a passenger, a bystander, or a person inspecting or
repairing the vehicle.
A CAUTION symbol indicates that special precautions must be taken to avoid damaging
the vehicle.
NOTE
The NOTE symbol indicates key information about a procedure or to clarify an operation.
The owner’s manual should be considered a permanent part of your vehicle. It should remain with the vehicle at all times
and stay with the ATV if it is sold.

iv
PREFACE
Congratulations on your purchase of the KYMCO ATV. KYMCO take pride in a worldwide reputation for quality-in research, design,
production and service.
For replacement parts and accessories, we recommend genuine KYMCO products. They've been specially designed for your
vehicle and manufactured to meet KYMCO's demanding standards.
This manual will provide you with a good basic understanding of the features and operation of this machine. This manual includes
important safety information. It provides information about special techniques and skills necessary to ride your machine. It also
includes basic maintenance and inspection procedures. If you have any questions regarding the operation or maintenance of your
machine, please consult a KYMCO dealer.
We wish you many years of safe and enjoyable riding.
While reading this manual, remember:
The warning symbol indicates a strong possibility that serious injury or death may result if instructions are not followed.
All information in this publication is based on the latest product information available at the time of approval for printing. KWANG
YANG MOTOR CO., LTD Reserves the right to make changes at any time without notice and without incurring any obligation.

1-1
1.
LOCATION OF THE WARNING AND SPECIFICATION LABELS*
WARNING INFORMATION
Anyone who rides the vehicle should read and understand this information before riding. They contain important information for safe
and proper operation of your ATV.
The labels should be considered as permanent parts of the vehicle. If a label comes off or becomes hard to read, contact your
KYMCO dealer for replacements.
* The following illusts may differ slightly from your vehicle.

1-2
1.1. LABELS FOR T3b MODELS
*
*FOR PASSENGER SEAT ONLY

1-3
MXU700i MXU550i

1-4

1-5

2-1
2.
SAFETY INFORMATION
AN ATV IS NOT ATOY AND CAN BE HAZARDOUS TO OPERATE.
An ATV handles differently from other vehicles including motorcycles and cars. A collision can occur quickly, even during routine
maneuvers, if you fail to take proper pre-cautions.
SEVERE INJURY OR DEATH can result if you do not follow these instructions:
Read this manual and all labels carefully and follow the operating procedures described.
Never operate an ATV without proper training or instruction. Beginners should receive training from a certified instructor.
Always follow the age recommendation:
A child under 16 years old should never operate an ATV with engine size greater than 90cc.
Never allow a child under age 16 to operate anATV without adult supervision, and never allow continued use of anATV by a
child if he or she does not have the abilities to operate it safely.
Never operate an ATV without wearing an approved motorcycle helmet that fits properly. You should also wear eye protection
(goggles or face shield), gloves, boots, long-sleeved shirt or jacket, and long pants.

2-2
Never consume alcohol or drugs before or while operating this ATV.
Never operate at speeds too fast for your skills or the conditions. Always go at a speed that is proper for the terrain, visibility and
operating conditions, and your experience.
Never attempt wheel, jump, or other stunt.
Always inspect your ATV each time you use it to make sure it is in safe operating condition. Always follow the inspection and
maintenance procedures and schedules described in this manual.
Always keep both hands on the handlebars and both feet on the footboards of theATV during operation.
Always go slowly and be extra careful when operating on unfamiliar terrain. Always be alert to changing terrain conditions when
operating theATV.
Never operate on excessively rough, slippery or loose terrain.
Always follow proper procedures for turning as described in this manual. Practicing turns at low speeds before attempting to turn
at faster speeds. Do not turn at excessive speed.

2-3
Never operate the ATV on hills.
Always follow proper procedures for climbing slopes as described in this manual. Check the terrain carefully before you start up
any slope. Shift your weight forward. Never open the throttle suddenly. Never go over the top of a slope at high speed.
Always follow proper procedures for going down slopes and for braking on slopes as described in this manual. Check the terrain
carefully before you start down any slope. Shift your weight backward. Never go down a slope at high speed. Avoid going down
slope at an angle that would cause the vehicle to lean sharply to one side. Go straight down the slope where possible.
Never attempt to turn theATV around on any slope until you have mastered the turning technique described in this manual on
level ground. Avoid crossing the side of a steep slope if possible.
Always check for obstacles before operating in a new area. Never attempt to operate over large obstacles, such as large rocks or
fallen trees. Always follow proper procedures when operating over obstacles as described in this manual.
Always be careful when skidding or sliding. Learn to safely control skidding or sliding by practicing at low speeds and on level,
smooth terrain. On extremely slippery surfaces, such as ice, go slowly and be very cautious in order to reduce the chance of
skidding or sliding out of control.

2-4
Never operate an ATV in fast flowing water or in water that deeper than recommended in this manual. Remember that wet brakes
may have reduced stopping ability. Test your brakes after leaving water. If necessary, apply them several times to let friction dry
out the linings.
Always use the size and type tires specified in this manual. Always maintain proper tire pressure as described in this manual.
Never modify an ATV through improper installation or use of accessories.
Never exceed the stated load capacity for an ATV. Cargo should be properly distributed and securely attached. Reduce speed
and follow instructions in this manual for carrying cargo. Allow greater distance for braking.

2-1
POTENTIAL HAZARD
Improper handling of gasoline.
WHAT CAN HAPPEN
Gasoline can catch fire and you could be burned.
HOW TO AVOID THE HAZARD
Always turn off the engine when refueling.
Do not refuel right after the engine has been running and is still
very hot.
Do not spill gasoline on the engine or exhaust pipe/muffler
when refueling.
Never refuel while smoking, or while in the vicinity of sparks,
open flames, or other sources of ignition such as the pilot lights
of water heaters and clothes dryers.
When transporting the machine in another vehicle, be sure it is
kept upright and that the fuel cock is in the "OFF" position.
Otherwise, fuel may leak out of the carburetor or fuel tank.
POTENTIAL HAZARD
Improper handling of gasoline.
WHAT CAN HAPPEN
Gasoline is poisonous and can cause injuries.
HOW TO AVOID THE HAZARD
If you should swallow some gasoline or inhale a lot of gasoline
vapor, or get some gasoline in your eyes, see your doctor
immediately.
If gasoline spills on your skin, wash with soap and water. If
gasoline spills on your clothing, change your clothes.

2-2
POTENTIAL HAZARD
Starting or running the engine in a closed area.
WHAT CAN HAPPEN
Exhaust fumes are poisonous and may cause loss of
consciousness and death within a short time.
HOW TO AVOID THE HAZARD
Always operate your machine in an area with adequate
ventilation.

3-1
3.
DESCRIPTION AND MACHINE IDENTIFICATION
3.1. KEYS IDENTIFICATION NUMBER
The keys identification number is stamped on itself or a tag as
shown in the following illustration.
Functions

Ignition Switch

Right Storage open and lock
3.2. IDENTIFICATION NUMBER RECORDS
Record the keys identification number, frame serial number and
engine serial number information for assistance when order
replacement parts.
KEY No.
__________________________________________________
FRAME No.
__________________________________________________
ENGINE No.
__________________________________________________
