Kyocera Sd-66k User manual

Iridium Adapter

SD-66K

Owner's Manual

English

Name Appearance Qty

AC Charger

(Bundled with cables

conforming to the country

standard)

Battery 2

Main unit

(Iridium Adapter) 1

■The components listed below are provided as standard accessories.

Separate vibrator

set

(Belt clip)

(Belt strap)

(Dry cell)

1 each

Thank you for purchasing the SD-66K Iridium Adapter.

Read this manual thoroughly first to ensure you use your phone with the

Iridium Adapter safely and correctly.

The screens and illustrations shown in this manual are for explanation purposes only. Note that

the actual product and screens may differ in some respects from the images depicted here.

■Notes on Use

●Iridium services are not available in some countries and regions

due to communications regulations.

●Even inside a service area, your phone may not work if you are in

a location that cannot be reached by radio waves, such as in a

tunnel, underground, in a building, close to a building wall, or in

mountains. Also, your call may be cut off if you move to a place

with poor radio conditions.

■Precautions Regarding Safety

●Do not use your phone while driving. Pull over and park in a safe

place before using the phone.

●Since your phone uses radio waves which can affect the

operation of electronic equipment, follow the instructions below:

• The use of mobile phones in an aircraft is prohibited. Switch

the phone off before boarding.

• When a mobile phone is used in some types of car, it may

affect the operation of automotive electronic components. Be

careful when using your phone in a car.

●To prevent radio waves from affecting electronic medical devices,

follow the instructions below:

• Switch the phone off before entering a place where the use of

mobile phones is prohibited, such as in a hospital or any other

medical facility, or around electronic medical equipment.

• If you use a pacemaker, consult your medical

institution/agency or the device manufacturer/supplier for

detailed information on the use of mobile phones and their

effects on the pacemaker.

Introduction Accessories

Before Using Your Phone with the Iridium Adapter

Grip Belt 1

Do not store this product in a very damp,

dusty, or hot location, as this could result in

faulty operation.

Keep this product out of the reach of small

children, as it could cause injury if used as a

toy.

Do not leave this product on an unstable or

sloping surface, as the product could fall,

causing damage or injury.

Only use the battery and AC charger specified

by KYOCERA for use with the Iridium Adapter.

The use of a battery or charger other than that

specified could result in the battery leaking

fluids, overheating, bursting, or igniting.

Do not subject this product to strong shocks or

vibrations, or throw or drop it, as this could

result in the battery leaking fluids, overheating,

bursting, or igniting, and could damage the

Iridium Adapter and cause faults or a fire.

Do not place the Iridium Adapter, battery, or

AC charger in a microwave oven or pressure

vessel, as this could result in the battery

leaking fluids, overheating, bursting, or

igniting, or could cause the Iridium Adapter or

AC charger to overheat, emit smoke, or ignite,

or could damage the circuitry inside the

device.

Do not use this product in places where there

are inflammable gases, as this could cause

the gases to ignite or result in device damage,

malfunction, or fire.

Safety Precautions

●Before using your phone with the Iridium adapter, read

these precautions carefully to use the phone safely and

correctly.

●The precautions listed here are intended to prevent injury

to the phone user and others, and to prevent unintended

damage to property.

■The designations below indicate the severity of the injury

or damage that may be incurred if the designated

precautions are not followed or the product is used

incorrectly.

Prohibited

Do not

disassembl

Essential

Unplug

This icon notifies the user that the action

indicated is prohibited.

■The icons shown below are used to indicate instructions

that should be observed.

This icon notifies the user that the action

indicated must be performed.

This icon indicates that the device must not be

disassembled.

This icon indicates that the device must be

unplugged from the power socket.

Essential

DANGER

WARNING

Prohibited

CAUTION

General Precautions When

Handling the Iridium Adapter,

Battery, and AC Charger

Indicates that, if this warning is ignored, improper

handling of the product is likely to result in death or

serious injury.

DANGER

Indicates that, if this warning is ignored, improper

handling of the product may lead to death or serious

injury.

WARNING

Indicates that, if this warning is ignored, improper

handling of the product could result in personal injury or

material damage.

CAUTION

Prohibited

Essential

Prohibited

Do not use your phone while driving, as this is

dangerous and could cause a traffic accident.

Pull over and park in a safe place before using

the phone.

Switch the phone off in places where the use

of mobile phones is prohibited, such as in an

aircraft or hospital. Mobile phones can

adversely affect the operation of electronic

instrumentation and medical equipment. For

information on using your phone in a medical

facility, refer to the directives provided by the

facility itself.

Do not use your phone around electronic

devices that require precise control or use

weak signals. Radio interference can cause

malfunctions or other problems in electronic

devices.

Examples of affected devices:

Hearing aids, pacemakers and other electronic

medical aids, fire alarms, self-opening doors

and other automatic control devices, etc.

For more information on the effects of mobile

phones on pacemakers and other electronic

medical aids, check with the device

manufacturer or supplier.

Do not attempt to disassemble or modify the

Iridium Adapter as this could cause injury, an

electric shock, or malfunction.

Prohibited

Do not

disassemble

Essential

Prohibited

WARNING

Precautions When Using Your

Phone with the Iridium Adapter

Precautions When Using Your

Phone with the Iridium Adapter

Prohibited

Precautions When Using the Battery

CAUTION DANGER

When the phone (with or without the Iridium

Adapter) is used in some types of automobile,

it may affect the operation of electronic

components in the car. Do not use the phone

if it adversely affects the safe operation of the

vehicle in any way.

Do not use your phone in crowded places as

the antenna could strike someone and cause

injury.

Keep the Iridium adapter away from electro-

magnetic cards. Emissions from the phone

can erase the information stored on floppy

disks and cash cards or credit cards.

Keep the Iridium Adapter dry. Water or other

fluids entering the Adapter could cause

overheating, an electric shock, or damage.

Do not dispose of the battery by throwing it in

a fire, as this could cause the battery to ignite

or burst.

If you are having difficulty connecting the

battery to the phone unit, do not use force as

this could cause the battery to leak fluids,

overheat, burst, or ignite.

Do not short-circuit the battery terminals, and

do not touch the terminals with metal objects

such as paper clips or wire. Also, do not carry

or store the battery with objects such as metal

necklaces. Any of these could cause the

battery to leak fluids, overheat, burst, or

ignite.

Do not solder the terminals as this could cause

the battery to leak fluids, overheat, burst, or

ignite.

Any fluid from inside the battery coming into

contact with the eyes could cause loss of

vision. If this occurs, flush the affected eye

with clean water without rubbing and seek

immediate medical treatment.

Do not attempt to disassemble or modify the

battery as this could cause the battery to leak

fluids, overheat, burst, or ignite.

Do not use or leave the battery in hot places

such as near a fire or heating appliance. This

could cause the battery to leak fluids,

overheat, burst, or ignite.

Prohibited

Do not

disassemble

Essential

Prohibited

If there are any noticeable changes in the

battery while being used, charged, or stored

(overheating, discoloration, deformation, etc.),

remove the battery from the phone unit and

discard it. Continued use of the battery in

such conditions could cause the battery to leak

fluids, overheat, burst, or ignite.

Any battery fluid coming into contact with your

skin or clothing could cause skin damage.

Wash the fluid off immediately with clean

water.

If the battery is leaking fluid or producing any

odor, keep it away from any naked flames as

this could cause the leaking fluid to ignite,

resulting in a fire or in the battery bursting.

Prohibited

Essential

WARNING

CAUTION

Keep the battery dry. Moisture on the battery

could cause the battery to overheat, emit

smoke, or corrode.

Do not use or leave the battery in direct

sunlight or in hot places such as in a car on a

hot day. This could cause the battery to leak

fluids or overheat, and could impair

performance or reduce the lifetime of the

battery.

Prohibited

Precautions When Using the AC Charger

DANGER

Always use the AC charger with a standard

household power supply. The use of other

voltages could cause an electric shock, fire, or

faults.

Never short-circuit the DC plug, as this could

cause device faults, an electric shock, smoke,

or fire.

Do not use the AC charger if the power cord is

damaged (core wiring exposed or cut, etc.) as

this could cause a fire or electric shock.

Clean off any dust on the power plug as this

could cause a fire.

Do not place any container of water (such as

an aquarium or jug) near the AC charger.

Water or other fluids on the charger could

cause overheating, an electric shock, or

damage.

If any water or other liquid gets into the AC

charger, immediately unplug the power cord.

Failure to do so could cause the charger to

overheat or catch fire, or cause an electric

shock or faults.

Do not attempt to disassemble or modify the

AC charger, as this could cause injury, an

electric shock, fire, or faults.

Do not use the AC charger in places with

condensing of water vapor, such as a

bathroom, as this could cause an electric

shock.

Do not touch the AC charger, power cord, or

power socket with wet hands, as this could

cause an electric shock.

Essential

Prohibited

Essential

Prohibited

Do not

disassemble

Unplug

Prohibited

CAUTION

Do not place heavy objects on the power cord

or attempt to modify the power cord as this

could cause an electric shock or fire.

Always unplug the AC charger before

performing any cleaning or maintenance.

Failure to do so could cause an electric shock.

Always grasp the plug itself when you unplug

the AC charger. Pulling on the power cord can

damage the cord and cause an electric shock

or fire.

Prohibited

Essential

General Notes on Cleaning and Maintenance

Do not splash water on the Iridium Adapter, phone unit,

battery, or AC charger.

Although the phone unit, battery, and charger are water

resistant, you should avoid using them in places where

there is a lot of water vapour, such as a bathroom, and

take care to protect them from rain.

Use a soft dry cloth to clean the Iridium Adapter, phone

unit, battery, and AC charger.

Wiping them with a wet cloth could cause faults. Also,

solvents such as alcohol, thinner, benzine, or detergent

may remove the printed lettering on the device or cause

discoloration.

Notes on the Phone Unit

Use your mobile phone as far away as possible from

equipment such as conventional phones, TVs, radios, and

electronic office equipment, as the mobile phone can

affect the operation of such equipment.

KYOCERA guarantees this product according to the

guarantee specifications described in the Warranty

Booklet. However, KYOCERA will assume no

responsibility for any incidental damages resulting from

any inability to transmit or receive calls or messages due

to breakdown, malfunction or any other failure of this

product. If your phone needs to be repaired, any data

stored within it may be lost or corrupted. Keep backup

copies of all important data to prevent loss.

Notes on the Battery

Store the battery in a cool, well-ventilated location that is

not exposed to direct sunlight.

If you leave the battery uncharged, it may be impossible to

recharge it later. If the battery is left unused for extended

periods, recharge it occasionally.

The battery has a limited life.

KYOCERA lithium ion batteries use the latest low power

consumption technology and can be used for far longer

periods than conventional batteries. However, the life of

any battery is limited, and the amount of time for which a

battery can be used between recharges gradually

decreases. if repeated recharging fails to restore the

battery's functionality, the battery has failed and should be

replaced with a new battery of the specified type.

Do not dispose of used batteries with ordinary household

garbage.

Apply insulating tape to the battery terminals before

disposing of the battery. Check with the relevant local

authorities for the correct method of disposing of your

battery.

Do not expose your phone to extremely low or high

temperatures.

Use the phone at temperatures between -30˚C and 60˚C.

The lifetime may vary with the circumstances the phone is

used.

Notes on the AC Charger

Do not charge the battery in the following places:

• In direct sunlight.

• In ambient temperatures below -20˚C or above 50˚C.

• In humid or dusty locations or places subject to

vibrations (this could cause malfunctions).

• Near an appliance such as a TV or radio (this could

impair picture or sound quality).

Your Phone and its Environment

Inadequately protected electronic equipment may be

affected by radio waves. This interference can lead to

accidents. Listed below are the most dangerous situations

in which this can occur. Do not hesitate to inquire whether

or not your phone can affect surrounding equipment.

Vehicles

Check with the vehicle manufacturer that electronic

equipment used in your vehicle will not be affected by

radio energy.

Aircraft

• Switch off your phone when in an aircraft. The use of

phones while airborne is illegal in some countries. It

may disrupt the operation of the aircraft or of the Iridium

network. Failure to observe these warnings may lead to

suspension or denial of access to the network or to

legal action.

• Check with a member of the aircraft crew before you

use your telephone in or around an aircraft on the

ground.

Blasting Areas

Switch off your phone in any areas where you are

requested to turn off radio transmission devices, such as

quarries or other areas where blasting is in progress.

Explosive Environments

It is dangerous to use your phone in potentially explosive

environments.

• Switch off your phone in any area with a potentially

explosive atmosphere. This includes areas in which

petrol or other inflammable chemicals are handled

(service stations, fuel depots, chemicals plants, etc.)

and areas where the air contains dust particles, such as

metal powders or seeds.

• If you wish to use your phone in a vehicle used for

transporting flammable substances (even when parked)

or vehicle powered by liquefied petroleum gas (LPG),

check first that the vehicle complies with the applicable

safety regulations.

Medical Equipment and Hospitals

• Switch off your phone in hospitals, clinics and other

health care facilities where you are requested to turn off

radio transmitting devices. These establishments may

use equipment that is sensitive to radio emissions.

• If you have any questions about the radio wave

shielding on electronic medical devices that you

yourself use (pacemakers, hearing aids, etc.), contact

the manufacturer of the medical device.

Using Your Phone Efficiently and Safely

Using your phone in the most efficient manner will improve

the performance of your phone, reduce radio emissions

and reduce battery consumption.

• Always extended the antenna fully before using the

phone.

• For your own safety as well as for the satisfactory

operation of the phone, you are advised to use the

phone only in the normal operation position (with the

antenna extended over your shoulder and the earpiece

to your ear).

• For best performance, avoid touching the antenna while

a call is in progress.

• Do not use your phone if the antenna is damaged.

Touching a damaged antenna could inflict a minor skin

burn. Have a damaged antenna replaced by a qualified

technician. Make sure that it is replaced only with the

antenna recommended by KYOCERA.

• Avoid low reception areas (such as in a tunnel or

between tall buildings). In low reception areas, the

symbol on the LCD panel shows fewer than 3 bars. If

possible, move to a more favorable location.

• Do not use a battery charger other than those specified

in the KYOCERA catalog. Use of any other type of

charger may be dangerous and will invalidate the

phone’s warranty.

• Do not allow metal objects (keys in your pocket, etc.) to

short-circuit the battery contacts.

• The radio equipment must be connected to the antenna

via a non-radiating cable (e.g.coaxial).

The antenna must be mounted in a position such that

no part of the human body will normally rest close to

any part of the antenna unless there is an intervening

metallic screen, for example, a metallic roof.

Using Your Phone Responsibly

Safe use of the phone is your responsibility. Careless

handling of the phone can result in harm to others and

damage to the phone itself. To avoid such problems, read

and follow all the security instructions presented here and

make them known to anyone borrowing your phone. To

prevent unauthorized use of your phone:

• Keep your phone in a safe place and keep it out of the

reach of small children.

• Avoid writing down your PIN code. Try to remember it

instead.

• Switch off the phone if you are going to leave it unused

for an extended period.

• Use the Security menu to restrict the calls that can be

made from your phone.

• Use the Security menu to change the security code

after you purchase the phone.

CAUTION!

Your phone is not a toy. Keep it in a safe place and out of

the reach of small children. Children could hurt

themselves or others and could damage the phone.

Using Your Phone While Driving

• Avoid using your phone while driving, except in an

emergency.

CAUTION!

Using your phone and driving at the same time can be

dangerous as it lowers your concentration.

• You should always concentrate solely on driving.

Whenever possible, pull off the road and park before

using your phone.

• If you want to use your phone while driving, install the

hands-free kit that is available for that purpose.

• Respect the local regulations in countries where you

drive and use your phone.

• Check with the manufacturer of your car that the

electronic equipment used in your car will not be

affected by the radio waves emitted by your phone.

CAUTION!

The use of an alarm system to operate a vehicle's lights

or horn to indicate an incoming call is prohibited on public

roads in some countries. Check the local regulations.

Overview of Features and Controls

■

This section identifies each part of the Iridium Adapter.

Extendable antenna

Extend this antenna when calling.

Phone release levers

You can remove your phone from the

Iridium Adapter by pushing these two

levers at the same time.

Interface terminal

Exchanges information between adapter

and telephone set.

I/O and charging socket

Accepts a connector for data transfer or

charging the battery.

Charging LED indicator

Blinks while the battery is charging. It

remains lit when the battery is fully

charged.

Mounting screw hole for Grip Belt

Use this hole to attach the Grip belt.

Battery lock lever

Slide this lock lever before you can remove

the battery.

Battery

Battery catch

To remove the battery, slide this battery

catch to the right after unlocking the battery

using the battery lock lever.

Grip belt hole

Use this hole to attach the Grip belt.

SIM Card

■About the SIM Card

• The Iridium Adapter uses a "plug-in" SIM card.

• The Iridium Adapter cannot use credit-card-sized SIM cards.

To use the Iridium Adapter, you must insert a valid SIM card into the Adapter.

The SIM card is supplied by your Iridium service provider.

The SIM card contains Iridium Network subscription information and your

personal information such as your subscription ID number and your phone

number. It also contains the authentication commands required to access the

Iridium Network. The SIM card usually cannot be read unless a valid password

(PIN1 or PIN2) is entered.

■Removing the SIM Card

Be sure to switch off your phone before removing the battery.

Failure to do so may cause the phone to malfunction.

Slide the battery release lever

in the direction of an arrow.

Slide the battery up and then lift it

off the Adapter.

Slide the battery lock lever on top

of the Iridium Adapter.

Slide the card holder lock down in

the direction indicated.

This will unlock the card holder.

Lift up the card holder and pull out

the SIM card.

■Inserting the SIM Card

Insert the SIM card into the card

holder.

Close the card holder and slide the

card holder lock up in the direction

indicated.

Battery lock lever

SIM card holder

CAUTION!

About the antenna

Grasp the top of the antenna.

■To ensure optimum communication performance when using your

phone, extend the antenna as described below.

Bend the top of the antenna to the right or left until it stops.

If you bend it to the right, the antenna will lock in position.

When using the phone, keep the antenna vertical to the ground.

Bending to the left.

To ensure optimum communication performance, make sure there are

no obstacles above or around you.

Be sure to bend the top of the antenna so that it is vertical to the

ground.

When extending or replacing the antenna, always hold the top of the

antenna. Holding the lower part may damage it.

Extend the top half of the antenna.

Bending to the right.

• Do not use excessive force. Doing so may damage the antenna.

• When replacing the antenna, first bring the top section back in line,

then grip the top and reverse the procedure used for extending the

antenna. Holding the bottom section of the antenna and then trying

to replace it may damage it.

Using the phone on the right side Using the phone on the left side

CAUTION!

Extend the rest of the antenna.

Attaching Your Phone

■Attaching the Phone Unit

Remove the terminal cover at the bottom of the phone and attach it to

the adapter terminal connector.

Insert the phone into the adapter.

The phone unit is connected to the Adapter at the interface terminal.

Be careful not to touch the terminal when attaching your phone.

■Removing the Phone Unit

Push the phone release levers on both sides of the Iridium Adapter at

the same time, then lift the phone unit off the Adapter.

Slide the phone in the

direction of an arrow

until you hear a click.

Keep the removed terminal cover

safe and be sure not to lose it.

CAUTION!

Phone

Removing the Battery

■Removing the Battery

Slide the battery catch on the

back of the Iridium Adapter.

Slide the battery up and then

lift it off the Iridium Adapter.

Always switch off your phone before removing the battery. Failure to do

so may cause the phone to malfunction.

The battery has a limited life. While the lifetime of the battery will

depend on how frequently you use your phone with the Iridium Adapter,

you should replace the battery once a year. When you replace the

battery, always purchase a new KYOCERA lithium-ion battery of the

same type.

Release the battery lock lever on

top of the Iridium Adapter.

■Inserting the Battery

Align the battery with the Iridium Adapter and push the battery in the

direction of the arrow to secure.

Place the battery lock lever (on top of the Iridium Adapter) to the lock

position.

Battery lock lever

CAUTION!

Charging the Battery

If you charge the battery in a foreign country, check the voltage in that

country and adjust the voltage of your AC charger as required before

charging.

Insert the battery firmly in the Iridium Adapter.

Plug the AC charger connector into the charging socket in the base of

the Iridium Adapter.

Plug the AC charger cable into an AC power outlet.

• Do not handle the AC charger with wet hands.

• Do not use any device other than the AC charger bundled with the

Iridium Adapter to charge the battery.

• If the battery is left unused for extended periods, the battery may be

so discharged that it cannot be recharged as quickly as usual by

the AC charger.

Battery lock lever

CAUTION!

Connector

Charging socket

Cap

Unlock

Lock

• When several batteries are to be charged, the phone installed in the

adapter and batteries installed in the adapter will be charged first.

The spare batteries installed in the AC charger will be charged last.

• If the indicator quickly blinks, check the battery for proper

connection.

Power outlets vary from country to country. Use the plug

provided for use in the particular country.

AC Charger

●This indicator shows the charging status when the

battery mounted on the AC charger is to be charged

(charging requires 3 to 4 hours).

Lamp blinking: charge in progress

Lamp lit: charge completed

●This indicator shows the charging status when the battery

mounted on the phone is to be charged (charging requires 3 to

4 hours).

Lamp blinking: charge in progress

Lamp lit: charge completed

Spare battery

CAUTION!

Remove by pressing the lock release buttons

on either side of the socket and pulling out.

Separate Vibrator

●The battery (AAA size) for the separate vibrator has a limited life.

Although the battery life depends on how frequently the phone unit is

used, you should replace the battery with a new one when the vibration

has weakened. As the new battery, use an alkaline cell.

●This separate vibrator works with Iridium phones only. Since no ID is

required to use the separate vibrator, it may detect incoming or

outgoing calls to or from other Iridium phones in the vicinity.

■Loading the battery

Remove the battery housing

cover.

Check the + and – polarities

of the battery and insert it.

■Attaching the belt clip

■Removing the belt clip

●Insert the hook of the belt clip in the slot and push the clip in the direction of

the arrow while squeezing it at qfrom both sides.

●Squeeze the clip at qfrom both

sides and pull it toward you. If the

clip won't come off easily, squeeze

the clip in the same way and pull it

toward you while turning it left and

right.

Belt clip

Hook

Slot

■

The separate vibrator will vibrate when it detects incoming or outgoing

calls. It also vibrates when the phone is accessing the network, for

example when settings are being updated. To ensure you can feel it

clearly, always carry the vibrator on your belt or another location in close

contact with your body.

■Attaching the belt strap

ONON OFFOFF

ON OFF

CAUTION!

How to attach the Grip Belt

■Before using the separate vibrator

ON OFF

Stop button

Press this button to stop vibration.

Power switch

Switch on the separate vibrator before use.

●The separate vibrator can be used with any Iridium phone.

●Place the separate vibrator so that you can feel the vibration directly,

for example, on your belt. You will feel less vibration if the separate

vibrator is not in close contact with your body, for example, in the

pocket of your jacket.

●Since the separate vibrator uses a small current, it may not vibrate or

may vibrate late depending on the place and other conditions such as:

• When the phone unit is in a metal or thick bag

• When the separate vibrator is 1.5 m or more away from the phone

unit

• When there is a metal wall or a person standing between the

separate vibrator and the phone unit

• When the separate vibrator and the phone are moving apart

●Use the separate vibrator as far away as possible from devices such

as radios.

●Do not drop the vibrator or let it get wet, as this may damage it.

Fasten the grip belt screw on the top of the adapter using a coin.

■Using a grip belt can help you hold the phone.

Place the belt through the hole, as shown below.

Adjust the length of the strap to fit your hand.

CAUTION!

Specifications

Optional Accessories

Iridium Adapter

Dimensions

Height (excluding the antenna) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146 mm

Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 mm

Thickness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64 mm

Weight (Main unit) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 390 g (approx.)

Battery voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DC 7.4V 1500 mAh

AC Charger (AC-S100)

Dimensions

Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 mm

Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127 mm

Depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 mm

Weight (Main unit) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220g (approx.)

Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .AC 100 V~240 V, 50~60 Hz

Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8.4V±0.05 V

Charging time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180 min. (approx.)

■Design and specifications are subject to change without notice due to ongoing

product improvement.

■The following optional accessories are available for use with this product.

Accessory names and designs are subject to change without notice.

Two-Way Cable (TW-S100)

DC Charger (DC-S100)

Battery (BP-S100)

Solar Power Supply (SP-S100)

AC Charger (AC-S100)

(Cables are included which comply

with the country standard)

Quick Reference for Troubleshooting

■If you are having trouble with your phone with the Iridium Adapter, check the following list of symptoms. If you cannot solve the problem yourself, contact

Service Information Window.

Symptom

No power

Battery does not recharge

SIM error (displayed on LCD panel on phone unit)

PIN error (displayed on LCD panel on phone unit)

PUK error (displayed on LCD panel on phone unit)

Cannot make any calls

Cannot make international calls

Cannot answer calls

Ringer muted

Cannot forward calls

Message memo feature does not work

Cannot record messages

Cannot create new Phone Book entry

Possible cause

• Battery low

• Battery loaded incorrectly

• Battery not correctly connected to AC charger

• Battery expired

• SIM card inserted incorrectly

• SIM card dirty

• SIM card damaged

• PIN code entry failed 3 times in succession

• PUK code entry failed 10 times in succession

• Wrong number

• Antenna not extended

• Outgoing calls barred

• Maximum cumulative time-charge exceeded

• Weak signal

• Defective SIM card

• Phone number with no leading "+" and country

code

• Weak signal

• Incoming calls barred

• Ringer disabled

• No phone number entered as destination.

• Too many or long messages recorded

• Phone Book full

User response

• Charge battery immediately

• See page 10 to click battery into place

• See page 12 to connect battery correctly

• Replace with new battery

• Check your SIM card

• Refer to the owner's manual for your phone

• Dial correct phone number

• Extend antenna

• Refer to the owner's manual for your phone to

cancel outgoing call barring

• Refer to the owner's manual for your phone to

reset maximum cumulative time-charge

• Check signal strength icon on LCD panel

• Check SIM card

• Enter "+" and country code (See page 18).

• Check signal strength icon on LCD panel

• Refer to the owner's manual for your phone to

cancel outgoing call barring

• Refer to the owner's manual for your phone to

enable ringer

• Refer to the owner's manual for your phone to set

destination phone number

• Refer to the owner's manual for your phone

• Edit Phone Book, e.g., by deleting, to free up more

entry space

Country Codes for International Calls

Alaska.....................................................................+1

Albania................................................................+355

Armenia, Republic of...........................................+374

Algeria.................................................................+213

American Samoa ................................................+684

Andorra...............................................................+376

Angola.................................................................+244

Anguilla...................................................................+1

Antigua and Barbuda..............................................+1

Argentine Republic................................................+54

Aruba ..................................................................+297

Ascension Island.................................................+247

Australia................................................................+61

Austria...................................................................+43

Azerbaijan...........................................................+994

Azores Islands ....................................................+351

Bahamas.................................................................+1

Bahrain................................................................+973

Bangladesh.........................................................+880

Barbados.................................................................+1

Belarus, Republic of............................................+375

Belgium.................................................................+32

Belize..................................................................+501

Benin...................................................................+229

Bermuda Islands.....................................................+1

Bhutan.................................................................+975

Bolivia .................................................................+591

Bosnia and Herzegovina.....................................+387

Botswana............................................................+267

Brazil.....................................................................+55

British Virgin Islands ...............................................+1

Brunei Darussalam .............................................+673

Bulgaria...............................................................+359

Burkina Faso.......................................................+226

Burundi................................................................+257

Cabo Verde.........................................................+238

Cameroon...........................................................+237

Canada ...................................................................+1

Canary Islands......................................................+34

Cayman Islands......................................................+1

Central African Republic.....................................+236

Chad ...................................................................+235

Chile......................................................................+56

China.....................................................................+86

Cocos Islands .......................................................+61

Colombia...............................................................+57

Comoros .............................................................+269

Congo .................................................................+242

Congo (Rep.) ......................................................+243

Cook Islands.......................................................+682

Costa Rica ..........................................................+506

Cote d'Ivoire........................................................+225

Christmas Island...................................................+61

Croatia ................................................................+385

Cuba .....................................................................+53

Cyprus.................................................................+357

Czech Republic...................................................+420

Democratic Kampuchea......................................+855

Democratic People's Republic of Korea .............+850

Denmark ...............................................................+45

Diego Garcia.......................................................+246

Djibouti................................................................+253

Dominica.................................................................+1

Dominican Republic................................................+1

Ecuador...............................................................+593

Egypt.....................................................................+20

El Salvador..........................................................+503

Equatorial Guinea...............................................+240

Eritrea .................................................................+291

Estonia (Rep.).....................................................+372

Ethiopia...............................................................+251

Faroe Islands......................................................+298

Fiji .......................................................................+679

Finland................................................................+358

Falkland Islands..................................................+500

France...................................................................+33

French Polynesia................................................+689

Gabonese Republic ............................................+241

Gambia ...............................................................+220

Georgia...............................................................+995

Germany...............................................................+49

Ghana.................................................................+233

Gibraltar..............................................................+350

Greece..................................................................+30

Greenland...........................................................+299

Grenada..................................................................+1

Guadeloupe Island..............................................+590

Guam......................................................................+1

Guatemala ..........................................................+502

Guiana ................................................................+594

Guinea ................................................................+224

Guyana ...............................................................+592

Haiti.....................................................................+509

Hawaii.....................................................................+1

Honduras ............................................................+504

Hong Kong..........................................................+852

Hungarian People's Republic................................+36

Iceland ................................................................+354

India......................................................................+91

Indonesia ..............................................................+62

Iran........................................................................+98

Iraq......................................................................+964

Ireland.................................................................+353

Israel...................................................................+972

Italy .......................................................................+39

Jamaica...................................................................+1

Japan....................................................................+81

Jordan.................................................................+962

Kazakhstan.............................................................+7

Kenya..................................................................+254

Kiribati.................................................................+686

Korea ....................................................................+82

Kuwait.................................................................+965

Kyrgyzstan..........................................................+996

Lao People's Democratic Republic.....................+856

Latvia ..................................................................+371

Lebanon..............................................................+961

Lesotho...............................................................+266

Liberia.................................................................+231

Libya ...................................................................+218

Liechtenstein.........................................................+41

Lithuania .............................................................+370

Luxembourg........................................................+352

Macao.................................................................+853

Macedonia ..........................................................+389

Madagascar........................................................+261

Madeira Islands...................................................+351

Malawi.................................................................+265

Malaysia................................................................+60

Maldives..............................................................+960

Mali .....................................................................+223

Malta...................................................................+356

Marshall Islands..................................................+692

Martinique Island.................................................+596

Mauritania...........................................................+222

Mauritius .............................................................+230

Mexico...................................................................+52

Micronesia (Federated States of Micronesia).....+691

Moldova ..............................................................+373

Monaco...............................................................+377

Mongolian People's Republic..............................+976

Montserrat...............................................................+1

Morocco..............................................................+212

Mozambique .......................................................+258

Myanmar (Union of the Myanmar)........................+95

Namibia...............................................................+264

Nauru..................................................................+674

Nepal...................................................................+977

Netherlands...........................................................+31

Netherlands Antilles............................................+599

New Caledonia and Dependencies.....................+687

New Zealand.........................................................+64

Nicaragua............................................................+505

Niger ...................................................................+227

Nigeria.................................................................+234

Niue.....................................................................+683

Norfolk Island......................................................+672

Norway..................................................................+47

Oman..................................................................+968

Pakistan................................................................+92

Palau...................................................................+680

Panama...............................................................+507

Papua New Guinea.............................................+675

Paraguay.............................................................+595

Peru ......................................................................+51

Philippines.............................................................+63

Poland...................................................................+48

Portugal...............................................................+351

Puerto Rico.............................................................+1

Qatar...................................................................+974

Reunion...............................................................+262

Romania................................................................+40

Rossian Federation.................................................+7

Rwandese Republic............................................+250

Saint Christopher and Nevis...................................+1

Saipan.....................................................................+1

San Marino..........................................................+378

Sao Tome and Principe ......................................+239

Saudi Arabia .......................................................+966

Senegal...............................................................+221

Seychelles...........................................................+248

Sierra Leone .......................................................+232

Singapore..............................................................+65

Slovakia ..............................................................+421

Slovenia..............................................................+386

Solomon Islands .................................................+677

Somali Democratic Republic...............................+252

South Africa ..........................................................+27

Spain.....................................................................+34

Spanish North Africa.............................................+34

Sri Lanka...............................................................+94

St. Vincent and the Grenadines..............................+1

St. Helena Island.................................................+290

St. Lucia..................................................................+1

St. Pierre and Miquelon Islands..........................+508

Sudan..................................................................+249

Suriname.............................................................+597

Swaziland............................................................+268

Sweden.................................................................+46

Switzerland ...........................................................+41

Syrian Arab Republic..........................................+963

Tadzhikistan............................................................+7

Taiwan ................................................................+886

Tanzania.............................................................+255

Thailand................................................................+66

Togo....................................................................+228

Tonga..................................................................+676

Trinidad and Tobago...............................................+1

Tunisia ................................................................+216

Turkey...................................................................+90

Turkmenistan......................................................+993

Turks and Caicos Islands........................................+1

Tuvalu.................................................................+688

Uganda ...............................................................+256

Ukraine................................................................+380

United Arab Emirates..........................................+971

United Kingdom of Great Britain and Northern

Ireland...................................................................+44

United States of America........................................+1

Uruguay ..............................................................+598

Uzbekistan..............................................................+7

Vanuatu...............................................................+678

Vatican..................................................................+39

Venezuela.............................................................+58

Viet Nam...............................................................+84

American Virgin Islands..........................................+1

Western Samoa..................................................+685

Yemen.................................................................+967

Yugoslavia ..........................................................+381

Zambia................................................................+260

Zimbabwe ...........................................................+263

To prefix a plus sign "+" to a phone number, hold

down the 0 key.

"+" will appear on the screen.

5KKTP29DEGXB

Iridium, and Iridium World Service are registered trade-mark of Iridium LLC.

0499DP

Printed in Japan C

Table of contents

Popular Adapter manuals by other brands

TRENDnet

TRENDnet TEW-806UBH Quick installation guide

Tektronix

Tektronix Keithley 237-TRX-BAR manual

Sling Media

Sling Media Slinglink quick start guide

Bosch

Bosch Rexroth Fe PROFIBUS-DP Bus Adapter instruction manual

Belkin

Belkin F5D4081 Quick installation guide

Exsys

Exsys EX-6011 manual

Belkin

Belkin F8T001 user manual

Devolo

Devolo dLAN 1000 mini manual

Extron electronics

Extron electronics ASA 100 Series Brochure & specs

Accessory Power

Accessory Power ReVIVE series instruction manual

Chung Nam Electronics

Chung Nam Electronics WLANTUBGM user manual

Cisco

Cisco WUSB54GS Product data

Pro Intercom

Pro Intercom BP2 operating instructions

NETGEAR

NETGEAR PowerLINE 1000 Series user manual

VOLTCRAFT

VOLTCRAFT SNG-600N-OW-L operating instructions

Eldes

Eldes EWM1 user guide

Rocom

Rocom Doormaster 4 quick guide

Atlona

Atlona AT-HDAIR Specifications

Kyocera SD-66K User manual

Popular Adapter manuals by other brands
