KZ RV Sportsmen 2020 User manual

Owner’s
MANUAL
GUIDEBOOK TO ENJOYMENT
OF YOUR KZRV
RECREATIONAL VEHICLE
SPORTSMEN
CONNECT
CONNECT SE

2
THE PURPOSE OF THIS OWNER’S MANUAL IS TO PROVIDE THE
MOST CURRENT INFORMATION AVAILABLE FOR YOUR
RECREATIONAL VEHICLE CONCERNING CARE AND USAGE.
MINOR MAINTENANCE AND CRITICAL SAFETY WARNINGS ARE
INCLUDED AND MUST BE READ AND OBEYED.
ADDITIONAL MAINTENANCE INFORMATION IS FOUND IN THE
“MAINTENANCE MANUAL”, SUPPLIED WITH YOUR RECREATIONAL
VEHICLE. FAILURE TO PROVIDE PROPER CARE FOR YOUR RV
COULD RESULT IN LOSS OF WARRANTY COVERAGE.
ADDITIONAL MANUALS MAY BE SUPPLIED AND AVAILABLE BY THE
MANUFACTURER OF THE COMPONENT AND/OR APPLIANCE. SEE
THE INFORMATION PACKET IN YOUR COACH.
Conventional Travel Trailer
Travel Trailer Toy Hauler
Conventional Fifth Wheel
Fifth Wheel Toy Hauler
Hybrid Travel Trailer
© 2020 KZRV
LITHO U.S.A.
11-2019

3
TABLE OF CONTENTS
Chapter 1 –Information to RV Ownership ...................................7
Safety Considerations..............................................................8
Reporting Safety Defects...................................................8
Safety When Emergency Stopping....................................9
Additional Safety Considerations.......................................9
Extended or Cold Weather Use...............................................9
Condensation ..........................................................................10
Causes...............................................................................10
Solutions............................................................................10
Interior Ventilation....................................................................10
Chapter 2 –Service Procedures ...................................................12
Basic Service Procedures........................................................12
Dealer ................................................................................12
Factory...............................................................................13
Parts ..................................................................................13
Owner’s Responsibility.......................................................13
Seasonal Sites...................................................................14
Towable Limited Warranty.......................................................14
Chapter 3 –Using your RV............................................................17
Equipment ...............................................................................17
Tow Vehicle .......................................................................17
Hitches –Travel Trailer......................................................17
Hitches –Fifth Wheel.........................................................18
Hitch Height Specifications –Travel Trailer .......................18
Hitch Height Specifications –Fifth Wheel ..........................18
Hook up –Travel Trailer ....................................................18
Hook up –Fifth Wheel .......................................................19
Safety Chains –Travel Trailer............................................19
Front Landing Jacks...........................................................19
Traveling..................................................................................20
Weights..............................................................................20
Weighing Vehicle - Loaded or Unloaded............................20
Loading Procedures...........................................................21
Tires...................................................................................22
Understanding Tire Pressure and Load Limits................23
Tire Size..........................................................................24
Tire Tread .......................................................................24
Tire Balance and Wheel Alignment.................................24
Tire Repair......................................................................24
Tire Fundamentals..........................................................24
Tire Speed Rating...........................................................25
Cargo Capacities ...............................................................25
How Overloading Affects your RV and Tires......................25
How to Change a Tire........................................................26
Wheel Bearings..................................................................26
Wheel Lugs........................................................................26

4
Brakes –Electrical.............................................................27
Breakaway Switch..............................................................28
Towing ...............................................................................28
Setting Up and using you Recreational Vehicle.......................29
Travel Trailer Un-Hook.......................................................29
Fifth Wheel Un-Hook..........................................................30
General Detector Information ..................................................31
Safety Detectors ................................................................31
Fire Extinguisher.............................................................31
Propane/Carbon Monoxide Detector...............................31
What is Carbon Monoxide?.............................................31
Dual Sensor Technology.................................................32
Operation........................................................................32
Gas Alarm.......................................................................32
Simultaneous CO and Gas Alarm...................................32
Lower Power Options......................................................32
Visual and Audible Alarm Signals ...................................33
CO Alarm........................................................................33
Propane Gas Alarm ........................................................33
Malfunction Service Signal..............................................33
End of Life Signal............................................................34
Smoke Alarm ..................................................................34
Operation........................................................................34
Testing............................................................................34
Steps .......................................................................................35
Windows..................................................................................36
Doors.......................................................................................36
TV Antenna (nonmoving).........................................................37
Slideouts..................................................................................38
Trailer Set-up Requirements –General.............................38
Below Floor Slide System..................................................38
Above Floor Slideout (All Brands and Types) ....................39
Bedroom Slideout ..............................................................39
Power for Operation...........................................................39
Operational Switch.............................................................40
Electrical Components.......................................................40
Manual Override......................................................................41
Below Floor Slideout..........................................................41
Above Floor Slideout..........................................................41
Bedroom Slideout....................................................................41
Schwintec Wall Slide ...............................................................41
Blinds.......................................................................................42
Ladder, Exterior.......................................................................42
Murphy Bed .............................................................................43
Chapter 4 –Systems......................................................................45
Water and Drainage Plumbing.................................................45
Fresh Water System................................................................45
Tanks.................................................................................45

5
Filling Fresh Water System................................................45
12-volt Demand Pump.......................................................46
Faucets..............................................................................47
Bath and Shower ...............................................................47
Outside Shower .................................................................47
Fresh Water Lines..............................................................48
Low Point Drains................................................................48
Sanitizing and Filling the Potable Water System................49
Drainage (Fresh Water) .....................................................49
Sanitation System....................................................................50
Toilets ................................................................................50
Using Toilets and Tank System .........................................50
Vent ...................................................................................50
Holding Tanks....................................................................51
Draining the Tanks.............................................................51
Flush System.....................................................................52
Maintenance for Holding Tanks .........................................52
Heated Holding Tanks .......................................................53
Winterizing your Recreational Vehicle ...............................53
Bypass Kit..........................................................................54
Propane Fuel System..............................................................54
Propane Container.............................................................55
Servicing and Filling Propane Containers..........................55
Installing Propane Containers............................................57
Regulator ...........................................................................59
High Pressure Hoses with Acme Connectors ....................60
Main Supply –Low Pressure .............................................60
Operation...........................................................................60
Checking for Leaks ............................................................61
Propane Gas Consumption................................................62
Electrical System.....................................................................63
General Information...........................................................63
Changes and Modifications................................................63
120-volt System.................................................................63
Power Cord –30 Amp or 50 Amp...................................63
Circuit Breakers and Box ................................................64
50 Amp (Optional)...........................................................64
DP/DT Switch..................................................................66
GFCI Protection..............................................................67
12-volt System...................................................................67
Converter........................................................................67
Auxiliary Battery (Optional) .............................................68
Battery Cut-Off Switch.....................................................69
Circuit Breakers and Fuses (12-volt)...............................69
Exterior Light and Connector, 12-volt..............................70
Porch Lights....................................................................70
Brake Wiring ...................................................................70
Solar Panel Receptacle...................................................71
