Kzyee KC501 Assembly instructions

OBDII /CAN SCAN TOOL

OBDII /CAN SCAN TOOL
Table of Contents
Safety...............................................1
Specifications .................................3
Overview.........................................3
Definitions......................................4
Control Modules ...........................4
I/M Monitors..................................5
Diagnostic Test Modes .................6
Diagnostic Trouble Code .............7
Setup - Before Use: ......................8
Operating Instructions ...............10
Connect Scan Tool .....................10
Setup ..........................................11
I/M Readiness Quick-Check ......15
Diagnostic Test Modes ...............16
Read Trouble Codes ..................17
DTC Lookup ..............................18
Erase Codes .............................19
View Live PID Data ...................20
Record Live PID Data..................... 22
Playback Live PID Data.................. 25
View Freeze Frame Data................ 26
I/M Readiness................................. 26
02 Monitor Test ............................... 27
On-Board Monitor Test ................... 28
Component Test ............................. 29
Vehicle Information ......................... 30
Modules Present............................. 31
ABS+SRS Testing........................... 32
Review Data ................................... 33
Ready Test...................................... 33
Print Data........................................ 34
Install/Update Software .................. 34
About . ................................................35
Maintenance..................................... 36
Troubleshooting .............................. 37
Parts List ............................................38
R WARNING SYMBOLS AND DEFINITIONS
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury .
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury .
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury .
Addresses practices not related to personal injury.

OBDII /CAN SCAN TOOL
- 1 -
Important Safety Information
To prevent personal injury or damage to vehicles and/or the Scan Tool, read this
instruction manual first and observe the following safety precautions, at a minimum,
whenever working on a vehicle:
1. Always perform automotive testing in a safe environment.
2. Wear safety eye protection.
3. Keep clothing, hair, hands, tools, test equipment, etc. away from all moving or hot
engine parts.
4. Operate the vehicle in a well ventilated work area. Exhaust gases are poisonous.
5. Put blocks in front of the drive wheels and never leave the vehicle unattended while
running tests.
6. Use extreme caution when working around the ignition coil, distributor cap, ignition
wires and spark plugs. These components create hazardous voltages when the
engine is running.
7. Put the transmission in PARK (for automatic transmission) or NEUTRAL (for manual
transmission) and make sure the parking brake is engaged.
8. Keep a fire extinguisher suitable for gasoline/ chemical/ electrical fires nearby.
9. Don't connect or disconnect any test equipment while the ignition is on or the engine
is running.
10. Keep the Scan Tool dry, clean, free from oil, water or grease. Use a mild detergent
on a clean cloth to clean the outside of the Scan Tool, when necessary.
Service
There are no user serviceable parts. Scan Tool service must be performed only by qualified
repair personnel.

OBDII /CAN SCAN TOOL
- 2 -
Specifications
Display Screen TFT Color (320 x 240)
Operating Temperature 32°F to 140°F
Storage Temperature -4°F to 158°F
Power 8V to 18V power provided by vehicle battery
Overview
OBD II On-Board Diagnostics
The first generation of On-Board
Diagnostics (called OBDI) was developed
by the California Air Resources Board
(ARB) and implemented in 1988 to monitor
some of the emission control components
on vehicles. As technology evolved and
the desire to improve the On-Board
Diagnostic system increased, a new
generation of On-Board Diagnostic system
was developed. This second generation of
On-Board Diagnostic regulations is called
"OBD II".
The OBD II system is designed to monitor
emission control systems and key engine
components by performing either
continuous or periodic tests of specific
components and vehicle conditions.
Vehicle Coverage
This Scan Tool is designed to work with all
OBD II compliant vehicles, including those
equipped with a CAN bus.
OBD II was installed in some 1994 and
1995 model year gasoline vehicles.
When a problem is detected, the OBD II
system turns on a warning lamp (MIL) on
the vehicle instrument panel to alert the
driver typically by the phrase of “Check
Engine” or “Service Engine Soon”.
The system will also store important
information about the detected malfunction
so that a technician can accurately find and
fix the problem. Here are three examples:
1. Whether the Malfunction Indicator
Light (MIL) is commanded 'on' or 'off';
2. Which, if any, Diagnostic Trouble
Codes (DTCs) are stored;
3. Readiness Monitor status.
To verify if a 1994 or 1995 vehicle is
OBD II compliant, check the Vehicle
Emissions Control Information label,
which is located in the engine
compartment.

OBDII /CAN SCAN TOOL
- 3 -
Definitions
• EOBD: European On-Board
Diagnostics
Essentially the same as OBD II, with
the same Data Link Connector and
Communication Protocols.
• Communication Protocol: Allows
different systems and sensors in a
vehicle to communicate.
There are currently five Protocols:
CAN Bus
J1850 VPW
ISO 9141-2
J1850 PWM
ISO 14230 KWP
• CAN: Controller Area Network
Message-based Communication
Protocol serial bus.
• CAN Vehicle
2008 and newer.
• Pre-CAN Vehicle
2007 and older.
• DLC: Data Link Connector
The 16-cavity connector on the vehicle
that allows communication between the
computer system and the Scan Tool.
Control
Modules
• Drive Cycle
A set of driving procedures that,
when met, provide the Enabling
Criteria for the I/M Monitors to run
and complete their diagnostic tests.
• Enabling Criteria
Operating conditions that must
occur during a Drive Cycle to
cause the I/M Monitors to run and
complete their diagnostic tests.
• MIL: Malfunction Indicator Lamp
The vehicle’s “Check Engine”
warning light that activates
when a DTC is stored.
• DTC: Diagnostic Trouble Code
A code stored in the computer
system’s memory, which helps to
identify the fault condition that is
causing the MIL to activate.
• Freeze Frame Data
Operating conditions that are
stored when a DTC is stored.
• PID - Parameter Identification Data
Data returned by the vehicle’s
Control Modules to the Scan Tool.
Control Modules are individual computers that operate and monitor different
systems in the vehicle. Control Modules vary depending on manufacturer.
ID codes are assigned to each Control Module, which are
defined by the vehicle’s Communication Protocol.
For example, a vehicle may use ID code $7E8 for the PCM and $7E9 for the TCM.
Control Module Control Module Definition
PCM/ECU Powertrain Control Module/Engine Control Unit
TCM Transmission Control Module
Figure 1: Common Control Modules

OBDII /CAN SCAN TOOL
- 4 -
I/M Monitors
Inspection and Maintenance diagnostic tests that the Control Modules perform on specific
sub-systems of the vehicle.
There are two types of Monitors:
• Continuous: Monitors that
perform tests all the time while
the engine is running.
Gasoline Engine
Monitors
Continuous
MIS - Misfire
FUEL - Fuel System
CCM - Comprehensive Components
• Non-Continuous: Monitors that require
specific operating conditions to be met
during a Drive Cycle in order for the
Monitors to run their testing sequences.
Note: Not all Monitors are supported
by all vehicles.
Non-Continuous
CAT - Catalyst
HCAT - Heated Catalyst
EVAP - Evaporative System
AIR - Secondary Air System
O2S - Oxygen Sensors
HRT - Oxygen Sensor Heater
EGR - EGR System
Diesel Engine
Monitors
Continuous
MIS - Misfire
FUEL - Fuel System
CCM - Comprehensive Components
Non-Continuous
HCCAT - NMHC Catalyst
NCAT - NOx Aftertreatment
BP - Boost Pressure System
EGS - Exhaust Gas Sensor
PM - PM Filter
EGR - EGR System

OBDII /CAN SCAN TOOL
- 5 -
Diagnostic Test Modes
Diagnostic Test Modes as described in the latest OBD II standard SAE J1979.
Note: Not all Modes are supported by all vehicles.
Mode $01 – Identifies the Powertrain
information and shows current data
available to the Scan Tool. This data
includes: DTC set, status of on-board tests,
and vehicle data such as engine RPM,
temperatures, ignition advance, speed, air
flow rates, and closed loop status for fuel
system.
Mode $02 –Displays Freeze Frame Data.
Same data as in mode 1, but it was
captured and stored when a malfunction
occurred and a DTC was set. Some of the
PIDs for Mode $01 are not implemented in
this mode.
Mode $03 –Displays the type of
Powertrain or emission related DTCs
stored by a 5 digit code identifying the
faults. There may be more than one
response message if there are more
trouble codes than will fit in the data bytes
of the response message, or if there are
more than one ECU computer responding.
Mode $04 –Used to clear DTCs and
Freeze Frame Data. This clears all DTCs
that may be set including freeze frame
data and Readiness Monitors.
Mode $05 –Oxygen Sensor Test Results.
This mode displays the oxygen sensor
monitor screen and the test results
gathered about the oxygen sensor.
Mode $06 –Non-Continuously Monitored
Systems test results. There are typically a
minimum value, a maximum value, and a
current value for each non-continuous
monitor. This data is optional, and it is
defined by a given vehicle maker if it's used.
Mode $07 –Request for DTCs (pending)
from Continuously Monitored Systems
after a single driving cycle has been
performed to determine if repair has fixed
aproblem. This is used by service
technicians to verify repair was performed
properly and after clearing DTCs.
Mode $08 –This special Control Mode
requests control of the on-board system,
test, or component bi-directionally (where
applicable). This mode is manufacturer
specific.
Mode $09 –Reports vehicle information.
This information includes vehicle VIN number
and calibration information stored in the
vehicle ECUs.
Mode $0A –Request Emission-Related
Diagnostic Trouble Codes with Permanent
Status. This mode is required for all
emissions-related DTCs. The presence of
permanent DTCs at an inspection without the
MIL illuminated is an indication that a proper
repair was not verified by the on-board
monitoring system.

OBDII /CAN SCAN TOOL
- 6 -
Diagnostic Trouble Code
A five digit alphanumeric identifier for a fault condition identified by the OBD II system.
There are three types of DTCs:
1. Pending - When a fault condition is
identified during a Drive Cycle, but
does not meet enough criteria to
activate the MIL.
If the fault condition occurs during two
consecutive Drive Cycles, it will turn
into a Stored DTC and the MIL will
activate.
2. Stored - A DTC is stored when a fault
condition has occurred that meets
enough criteria to activate the MIL.
3. Permanent - A stored DTC that can
only be cleared by the OBD II system,
after repairs are made, and a set
number of Driving Cycles have been
completed.
Example: P0212 - Injector Circuit / Open Cylinder 12
Systems
B - Body
C - Chassis
P - Powertrain
U - Network
Code Types*
0 - Generic
1 - Manufacturer Specific
2 - Generic Powertrain/Manufacturer Specific
3 - Generic Powertrain/Manufacturer Specific
Sub-Systems
1 - Fuel and Air Metering
2 - Fuel and Air Metering
(injector circuit malfunction only)
3 - Ignition Malfunction or Engine Misfire
4 - Auxiliary Emission Controls
5 - Vehicle Speed or Idle Controls
6 - Computer Output Circuits
7 - Transmission Controls
8 - Transmission Controls
12 - Cylinder 12
P 0 2 1 2
*The Scan Tool supports the following Code Types:
Generic (SAE):
B0, B3
C0, C3
P0, P2, P34-P39
U0, U3
Manufacturer Specific:
B1, B2
C1, C2
P1, P30-P33
U1, U2
Figure 2

OBDII /CAN SCAN TOOL
- 7 -
Setup - Before Use:
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the
beginning of this document including all text under subheadings therein
before set up or use.
Functions
Figure 3

OBDII /CAN SCAN TOOL
- 8 -
1. OBD II Cable
Connects the Scan Tool to the
vehicle’s DLC.
2. LCD Screen
3. Red LED !
Indicates there is a problem in one or
more of the vehicle's systems. The
RED LED is also used to show that
DTCs are present. DTCs are shown
on the Scan Tool's display. In this case,
the MIL on the vehicle's instrument
panel will light steady on.
4. Yellow LED !
Indicates there is a possible problem. A
“Pending” DTC is present and/or some
of the vehicle's emission monitors have
not run their diagnostic testing.
5. Green LED √
Indicates that engine systems are
running normally (The number of
monitors on the vehicle which are
active and performing their diagnostic
testing is in the allowed limit, and no
DTCs are present).
6. Cancel/Go Back
Cancels a selection from a menu or
returns to the previous screen.
7. Left Button
Moves to previous screen if information
covers more than one screen.
8. Help Button ?
View detailed information, if available.
9. USB Connector
Connects the Scan Tool to a PC for
updating software and printing.
10. I/M Button
Quick-checks emissions test readiness
and Drive Cycle verification.
11. Up Button
Moves up through menu and submenu
items in menu mode. When more than
one screen of data is retrieved, moves
up through the current screen to the
previous screens for additional data.
12. Select Button OK
Confirms a selection.
13. Right Button
Moves to next screen if information
covers more than one screen.
14. Down Button
Moves down through menu and
submenu items in menu mode. When
more than one screen of data is
retrieved, moves down through the
current screen to next screens for
additional data.

OBDII /CAN SCAN TOOL
- 9 -
Operating Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the
beginning of this document including all text under subheadings therein
before set up or use of this product.
TO PREVENT SERIOUS INJURY AND DEATH:
Exhaust gases are poisonous. Operate the vehicle in a well ventilated work area.
Wear ANSI-approved safety goggles during use.
Connect Scan Tool
CAUTION: Do not connect or disconnect
the Scan Tool while the ignition
is on or the engine is running.
Note: The Scan Tool is powered
by the vehicle’s battery.
1. Turn the engine and ignition OFF.
2. Connect the OBD II Cable
to the Scan Tool.
3. Connect the other end of the
Cable to the 16-cavity DLC.
The DLC is normally located under
the dashboard on the driver’s
side. (Refer to vehicle’s owner’s
manual for location of DLC.)
4. Turn the vehicle’s ignition ON
with the engine OFF .
Note: If Linking Error! message displays:
• Press the ESC button
• Verify the ignition is ON
• Verify the vehicle is OBD II compliant
5. If the message does not go away,
have the Scan Tool inspected
by a qualified technician.
Note: To quick-check Emissions
Test Readiness, see page 17.
Note: To read Diagnostic Trouble
Codes, see page 19.
Figure 4: DLC

OBDII /CAN SCAN TOOL
- 10 -
Setup
From the Main Menu, use the Up/ Down/ left/ Right button to select Setup, then press OK.
Note: Setup is not required to operate the Scan Tool.
System Setup 1/7
Language
Main Menu
Configure Monitors ?
Unit of Measure
Key Beep Set
Status Beep Set
Tool Self-test
Update Mode
Figure 5
Set Language
1. From System Setup, use the Up/ Down
button to select Language, then press
OK.
2. Select desired language, then press OK.
o English
o Español
Language 1/3
?
o Français
Figure 6

OBDII /CAN SCAN TOOL
- 11 -
Configure Monitors
Note: Configuring the Monitors is
not required to operate the Scan Tool.
BEFORE CONFIGURING MONITORS:
• Run “I/M Readiness Quick-Check” on
page 17 to determine which Monitors
are not supported on the vehicle.
• Refer to EPAguidelines for acceptable
incomplete monitor limits.
1. From System Setup, use the Up/ Down
button to select Configure Monitors,
then press OK.
Configure Monitors 1/4
Spark IGN Required Mon.
Compression IGN Required Mon.
Allowed INC Monitors ?
Reset Factory Default
Figure 7
2. Select a configuration, then press OK.
a. Spark IGN Required Mon.
For gasoline engines.
b. Compression IGN Required Mon.
For diesel engines.
c. Allowed INC Monitors to
Set how many incomplete
Monitors are acceptable.
d. Reset Factory Default
3. Custom Data Set screen shows
which buttons can be used to
configure the monitors. Press any
button to move to the next screen.
……………Custom Data Set…………..
[ ] –Select/Deselect
[ ] –Select/Deselect all
[OK] –Confirm
[ESC] –Cancel
Press any key to con.
Figure 8
4. For Spark IGN Required Mon. and
Compression IGN Required Mon.,
deselect Monitors that are not supported
on the vehicle, see “I/M Readiness
Quick-Check” on page 17.
………Sppark IGN Monitors 1/10
√MIS
√FUEL
CCM ?
√CAT
HCAT
√EVAP
Figure 9
5. For Allowed INC (incomplete)
Monitors, select the number of
incomplete Monitors allowed. Refer
to EPAguidelines for acceptable
incomplete monitor limits.
………
Alllowed INC Monitors 1/4
0
1
2 ?
3
Figure 10

OBDII /CAN SCAN TOOL
- 12 -
Unit of Measure
1. From System Setup, use the Up/
Down button to select Unit of
Measure, then press OK
Unit of Measure
1/2
2. Select English or Metric,
then press OK.
o English
o Metric ?
Figure 11
Key Beep Set - Control Sound When Buttons are Pressed
1. From System Setup, use the
Up/ Down button to select
Key Beep Set, then press OK.
Key Beep Set 1/2
2. Select Beep ON or Beep OFF,
then press OK.
o Beep ON
o Beep OFF ?
Figure 12
Status Beep Set - Control Notification Sounds
1. From System Setup, use the Up/
Down button to select Status
Beep Set, then press OK.
Status Beep Set 1/2
2. Select Beep ON or Beep OFF,
then press OK.
o Beep ON
o Beep OFF ?
Figure 13

OBDII /CAN SCAN TOOL
- 13 -
Tool Self-test
From System Setup, select Tool Self-test, then press OK.
Display Test
1. From Tool Self-test, use the
Up/ Down button to select
Display Test, then press OK.
Tool Self-test 1/3
2. To verify that the LCD screen is
functioning properly, a color test will run.
3. Press ESC to exit the test.
Display Test
Keyboard Test
LED Test ?
Figure 14
Keyboard Test
1. From Tool Self-test, use the
Up/ Down button to select
Keyboard Test, then press OK.
Keyboard Test
Press any key to
start test
key:
Double [ESC] to return
Figure 15
2. Press each button to make sure they are
functioning properly. If functioning
properly, the correct name for each
button will display after the word “key:”.
3. Press ESC twice to exit the test.
LED Test
1. From Tool Self-test, use the Up/
Down button to select LED Test,
then press OK.
LED T es t 1/3
RED LED ON
YELLOW LED ON
GREEN LED ON
Figure 16
2. To verify that the LEDs are functioning
properly, select each LED then
press OK. If functioning properly,
the selected LED will light up.
3. Press ESC to exit the test.

OBDII /CAN SCAN TOOL
- 14 -
I/M Readiness Quick-Check
To check emissions readiness
prior to having a vehicle inspected for a
state Emissions Test.
To determine which Monitors to configure.
CAUTION: Do not connect or disconnect
the Scan Tool while the ignition is on or
the engine is running.
1. Connect the Scan Tool according to
“Connect Scan Tool” on page 12.
2. Turn the vehicle’s ignition ON with the
engine OFF .
3. Wait until the Scan Tool has stablished
communication.
4. Press the I/M button on the keyboard.
5. View results and interpret data as
described below.
Figure 17
Note: You may need to complete
a Drive Cycle before performing an I/M
Readiness Test if the battery has been
disconnected or DTCs have been erased
recently.
Icon Interpretations
MIL - “Check Engine” light status
IGN - Ignition type
DTC - Number of stored DTCs
PdDTC - Number of pending DTCs
Symbol Interpretations
Each Monitor’s readiness is indicated
by one of the following symbols:
The Monitor has completed its
diagnostic routine and is ready.
The Monitor has not completed its
diagnostic routine and is not ready.
• Perform a Drive Cycle,
then repeat the test.
The Monitor is not supported on the
vehicle and may be deselected according
to “Configure Monitors” on page 14.
Keyboard LED Interpretations
1. Green LED - Ready
Indicates that engine systems are
running normally and no pending
DTCs are present.
2. Yellow LED - Might be Ready
Indicates there are pending DTCs or
there are Monitors that have not
finishing running.
• Perform a Drive Cycle, then
repeat the test.
3. Red LED - Not Ready
Indicates there is a fault condition in
one of the vehicle’s systems and stored
DTCs are present.
• Have the vehicle serviced.

OBDII /CAN SCAN TOOL
- 15 -
Diagnostic Test Modes
CAUTION: Do not connect or disconnect
the Scan Tool while the ignition
is on or the engine is running.
1. Connect the Scan Tool. according to
“Connect Scan Tool” on page 12.
Access Diagnostic Menu
1. From the Main Menu, use the Up/
Down/ Left/ Right button to select
OBDII/EOBD (Diagnostic Menu),
then press OK.
2. Turn the vehicle’s ignition ON
with the engine OFF.
Note: Not all vehicles return the
same data, results may vary from
the examples given herein.
3. Control Module will display.
In Figure S below, the example
vehicle uses the CAN Protocol and
has the following Control Modules:
$7E8 - PCM ID
$7E9 - TCM ID
(See Control Modules on
page page 6 for
more information.)
Control Module 1/2
Main
Menu
2. System Status will display momentarily .
System Status
MIL Status OFF
Codes Found 2
Ignition Type Spark
Monitors N/A 4
Monitors OK 4
Monitors INC 2
$7E8
$7E9 ?
Figure 19
4. Press OK to go to Diagnostic Menu.
Diagnostic Menu 1/11
Figure 18 Read Codes
Erase Codes
Live Data ?
View Freeze Frame
I/M Readiness
02 Monitor Test*
On-Board Mon. Test
Figure 20
Note: If vehicle is 2008 or newer, the
02 Monitor Test* will not be present.

OBDII /CAN SCAN TOOL
- 16 -
Read Trouble Codes
Modes $03, $07 and $0A Request Emission-Related DTCs
1. From Diagnostic Menu, use the
Up/ Down button to select
Read Codes, then press OK.
Diagnostic Menu 1/11
Read Codes
Erase Codes
Live Data ?
View Freeze Frame
I/M Readiness
02 Monitor Test
On-Board Mon. Test
Figure 21
Read Codes
1. From Read Codes, select from:
a. Stored Codes - Mode $03
b. Pending Codes - Mode $07
c. Permanent Codes - Mode $0A
This mode is available on
some vehicles starting in
2010 and is required on all
2012 and newer vehicles.
2. If there are no DTCs, the
message “No codes are stored
in the module” will appear.
3. View the DTC.
DTC Control
Module
2/8
P0122 $10 Generic
Throttle / Pedal Position
Sensor / Switch A Circuit Low
DTC Description
Figure 22
4. See “DTC Lookup” on page 20
to view likely causes for DTCs.
Note: To view operational data stored when
the DTC was stored, see
View Freeze Frame Data on page 28.

OBDII /CAN SCAN TOOL
- 17 -
DTC Lookup
Search the DTC library for code definitions.
From the Main Menu, use the Up/ Down/
Left/ Right button to select DTC Lookup,
then press OK.
P0212
Injector Circuit/ Open
Cylinder 12
1/1
Main
Menu
1. Input the DTC by using the
buttons to highlight and change
digits, then press OK.
DTC Lookup
P0212
Left
Right
Change digit
OK Confirm
ESC Exit
Figure 24
2. Press the ? button to view
likely causes for the DTC.
3. If a DTC is manufacturer
specific, a screen will prompt
the choice of vehicle make.
4. If a DTC is not found, the
Scan Tool will refer you to the
vehicle’s owner’s manual.
Note: DTC definitions can
also be found online.
Figure 23

OBDII /CAN SCAN TOOL
- 18 -
Erase Codes
Mode $04 Clear/Reset Emission-Related Diagnostic Information
WARNING! Do not clear any DTCs before
the vehicle has been repaired and the
system has been checked completely by
a qualified technician.
As long as there is a fault
condition, the DTCs will continue
to set and turn on the MIL.
Note: If the vehicle stores permanent
DTCs, they cannot be erased by the
Scan Tool. They can only be erased
by the OBD II system, after repairs are
made, and a set number of Driving
Cycles have been completed.
1. Turn the vehicle’s ignition ON
with the engine OFF .
2. From Diagnostic Menu, use the Up/
Down button to select Erase Codes,
then press OK.
Diagnostic Menu 2/11
Read Codes
Erase Codes
Live Data ?
View Freeze Frame
I/M Readiness
02 Monitor Test
On-Board Mon. Test
Figure 25
3. Choose whether or not to erase codes.
Erase Codes
Erase trouble codes!
Are you sure?
YES NO
Figure 26
4. When DTCs have been erased, the
following message will appear .
Erase Codes
Erase Done!
Press any key to con.
Figure 27
Note: Erasing codes will reset the Monitors
to incomplete status. A Drive Cycle will
need to be completed before performing
an Emissions Readiness Test.
Clearing the error code will not
repair the car. Repair the car,
then clear the error code.
