L2 LRU14F3AWWC User manual

Instruction Manual
Upright Freezer
MODELS:
LRU14F3AWWC
LRU14F3ASTC

TABLE OF CONTENTS
2
1.SAFETY PRECAUTIONS …………………………………………………….......……..….3-4-5
2.INSTALLATION INSTRUCTIONS …………………………………………..........….…6-7-8
3.OPERATING YOUR APPLIANCE……………………………………….…........…..9-10-11
4.CARE AND MAINTENANCE …………………………………………….…..………. … .11-12
5.TROUBLESHOOTING GUIDE………………………………………….…….…………….….13
6.WARRANTY ……………………………………………………………………….….……… … …..14

IMPORTANT WARNING
WARNING - R600a GAS
This equipment contains a certain amount of ISOBUTANE (R600a) refrigerant gas,
an
environmentally compatible natural gas which, however, is combustible, even explosive.
Care must be taken during transport and installation to avoid damage to the cooling
system as
leaking gas may ignite or cause damage.
If a leak is detected, avoid any flames or other sources of heat and ventilate area
around
the appliance for several minutes.
Never operate a damaged appliance. If in doubt, consult the retailer where you
made
your purchase.
Any use not recommended by the manufacturer could result in fire, electric shock or
injury .
This appliance is intended to be used in household and similar applicaons such as staff kitchen
areas in shops, offices and other working environments; farm houses and by clients in hotels,
motels and other residenal type environments; bed and breakfast type environments; catering
and similar non-retail applicaons.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilies, or lack of experience and knowledge, unless they have been given
supervision or instrucon concerning use of the appliance by a person responsible for their
safety.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
Do not store explosive substances such as aerosol cans with a flammable propellant in this
appliance.
The appliance has to be unplugged aer use and before carrying out user maintenance on the
appliance.
WARNING: Keep venlaon openings, in the appliance enclosure or in the built-in structure, clear
of obstrucon.
WARNING: Do not use mechanical devices or other means to accelerate the defrosng process,
other than those recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
WARNING: Please abandon the refrigerator according to local regulators for it use flammable
blowing gas and refrigerant.
WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear
of the appliance.
WARNING: Risk of child entrapment. Before you throw away your old refrigerator or freezer:
• Take off the doors.
• Leave the shelves in place so that children may not easily climb inside.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
3

DANGER
IT IS DANGEROUS FOR ANY PERSON OTHER THAN AUTHORIZED SERVICE
PERSONNEL TO MAKE REPAIRS ON THIS APPLIANCE.
DO NOT ATTEMPT TO REPAIR THE APPLIANCE YOURSELF. IT IS DANGEROUS TO
MODIFY THE SPECIFICATIONS OF THIS PRODUCT OR CHANGE IT IN ANY MANNER.
ANY DAMAGE MAY RESULT IN A SHORT-CIRCUIT, FIRE OR ELECTRIC SHOCK.
WARNING: To avoid a hazard due to instability of the appliance, it must be fixed in accordance
with the instrucons.
Do not use extension cords or ungrounded(two prong)adapters.
The refrigerator must be disconnected from the source of electrical supply before aempng the
installaon of accessory.
Refrigerant and cyclopentane foaming material used for the appliance are flammable. Therefore,
when the appliance is scrapped, it shall be kept away from any fire source and be recovered by a
special recovering company with corresponding qualificaon other than be disposed by
combuson, so as to prevent damage to the environment or any other harm.
Children should be supervised to ensure that they do not play with the appliance.
14.
15.
16.
17.
18.
4

1. IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING YOUR APPLIANCE
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance. Read product labels for flammability and other warnings,
WARNING
CHILD SAFETY
Destroy carton, plastic bags, and any exterior wrapping material immediately after the unit is unpacked.
Children should never use these items to play. Cartons covered with rugs, plastic sheets or stretch wrap
may become airtight chambers and can quickly cause suffocation.
DISPOSING OF YOUR EQUIPMENT
PROPER DISPOSAL OF UNITS
Weathered, abandoned, or temporarily stored (even for a few days), units are dangerous and
attractive to children. Please take the precautions listed below.
We strongly encourage responsible appliance recycling/disposal methods.
BEFORE YOU THROW AWAY YOUR OLD APPLIANCE:
• Remove the door(s)
• Leave the shelves and baskets in place so children
may not easily climb inside.
WARNING
Please read all safety instructions before using your new unit.
5

2. INSTALLATION INSTRUCTIONS
TO ENSURE THAT YOU GET THE BEST RESULTS FROM YOUR NEW FREEZER/REFRIGERATOR, PLEASE TAKE
TIME TO FOLLOW THESE INITIALS STEPS.
A. ELECTRICAL CONNECTION AND CLEARANCE
We recommended to use a separate electrical circuit serving only this appliance. Do not use an
extension.
• This appliance is designed to be FREE STANDING ONLY, and should not be recessed or built-in.
Place your unit on a floor that is strong enough to support it when it is fully loaded.
• Allocate 4 inches (10 cm) of clearance space on each side of the unit, 4 inches (10 cm ) in the
back , and 12 inches (30 cm ) on top to allow the proper air circulation.
• Locate the appliance away from direct sunlight and sources of heat (stove, heater, radiator,
etc.). Direct sunlight may affect the acrylic coating and heat sources may increase electrical
consumption. Extreme cold ambient temperatures may also cause the unit not to perform
properly.
• Install the unit where the room temperature is between 0°C (32°F) and 43°C (110°F)
• Avoid locating the unit in moist areas.
• Plug the unit into a dedicated, properly installed-grounded wall outlet. Do not under
any circumstances cut or remove the third (ground) prong from the power cord. Any
questions concerning power and/or grounding should be directed toward a certified
electrician or an authorized Service Center.
•
Do not plug in this unit using an electric cord extension or adaptor.
6

B. UNPACKING AND CLEANING YOUR APPLIANCE
• Removetape and any labels from your fridge before using (except the rating label).
• Do not usesharp instruments, rubbing alcohol,flammable fluids, or abrasive cleaners to
removetape or glue. Theseproducts can damage the surfaceof your refrigerator.
• Clean your unit before usage: use a sponge, clothor paper towel and mild detergent in warm
water to clean outside and inside, door liner and gasket. Rinseand dry thoroughly.
• Do not switch on the fridge immediately after vertical placement. Turnit on after a 6 hours
period to ensure proper operation.
• If used as a freezer allow the unit to cool 2 to 3 hours before filling it with frozen food.
7

C.LEVELLING
If the unit is not leveled the doors may not close or seal properly, causing cooling, frost, or moisture
problems. It is very important of the fridge to be level in order to function properly.
To level your unit, turn the level leg clockwise to rise the side to the fridge or counter clockwise to lower it.
D.COMPONENTS
1. Outlet airflow gap
2. wire shelves
3. Inlet airflow gap
4. Wire cri s p e r
5. Lamp switch
6. Door trays
8

3. OPERATING YOUR UNIT
1.KEY
A. SET key; temperature setting button of unit
2.DISPLAY SCREEN/FUNCTIONS
1. COLDEST
2. COLDER
3. COLD
4. FREEZER/FRIDGE SWITCH BUTTON
3.DISPLAY
Once initially powered on,the display screen will be on full display for 3s. and then will run runs according to
COLDER /FRZ mode.
In freezer mode the temperature range is 10º to - 8 ºF (-12º to -22º C)
In refrigerator mode the temperature range is 35º to 45 ºF (2º-7º C)
Under normal circumstances the display will shows the actual temperature setting of the unit. ln case of
a failure, the corresponding LED will be displayed:
Fault Codes
Fault Description
Indicator 3 and 4
Refrigerator sensor circuit
Indicator 2 and 4
Freezer defrost sensor
indicator 1 and 4
Ambient temperature sensor
4. TEMPERATURE SETTING
Each time the temperature setting button “A”is pressed once, the temperature setting changes one
time. Once the temperature setting is complete, the refrigerator will operate in the selected mode
after 15 seconds.
The shift regulation is as such :
To set the temperature:
1. Press and hold button “A for 3 sec. to unlock the panel
2. Press “A”repeatedly to adjust the setting to “COLD”, “COLDER”or “COLDEST”as
needed.
①
②
③
④
A
9

LOCK/UNLOCK
When the temperature control panel is locked , you ned to press temperature setting key
for 3 long seconds to unblock, all LEDs will blink for 2 seconds then the panel will unlock.
When the temperature control panel is unlocked and there is no operation (no key
pressed) for 15 seconds, it will automatically lock itself.
5. FRIDGE/FREEZER CONVERSION
The conversion can be made only when the temperature control panel is unlocked.
Press and hold form 3 sec. “A”settting , this icon will lit and the unit will
run as a freezer.
Re-press and hold form 3 sec. “A”to convert back the unit to a refrigerator
mode .
FREEZER USAGE
When using the unit as a freezer for the first time or after defrosting, turn the temperature control to
set MAX for at least two to three hours before introducing the food to be stored. Let the freezer cool
overnight before adding large amounts of unfrozen food. Never add more than 2-3 pounds of unfrozen
food per cubic foot of freezer space.
All frozen food products you purchase should be placed in the freezer as soon as possible to avoid the
frozen food from defrosting.
To obtain the best possible results from your unit , it is important that you know how the mechanism
works:
• This unit is designed for long-term frozen food storage. However, we recommend a storage
period not exceeding three months.
• The shelf life of frozen food varies and recommended storage time should not be
exceeded.
• Pre-packaged frozen food commercially should be retained in accordance with the
recommendations of the manufacturer.
• Place the frozen food in the freezer as soon as possible after purchase. Carefully follow the
instructions on the package for the storage time.
Please note that if you switch from freezer mode to refrigerator mode, you’ll have to
completely unfreeze the appliance and wait for the temperature to be back to cooling
settings before using it again.
10

DEFROSTING
This appliance is equipped with a “Frost Free”type cooling system, which means it never has to be
manually defrosted. Defrosting is done automatically by means of a defrost heating element and a defrost
timer that will cycle on and off as the appliance operates. The defrost water is routed into a defrost pan
located beside the compressor, where it then evaporates.
4. CARE AND MAINTENANCE
CLEANING YOUR UNIT
Upon installation of your new appliance, it is recommended that it be cleaned thoroughly.
1. Remove all contents and unplug the appliance
2. Use a clean sponge or soft and a mild detergent in warm water.
3. Do not use abrasive or harsh cleaners. Hand wash, rinse and dry all surfaces thoroughly. Do not
use cleaning waxes, concentrated detergents, bleaches or cleaners containing petroleum on plastics
and rubber parts. Never use paper towels, window sprays, scouring cleansers or flammable fluids on
plastic parts as these can scratch or damage material. Clean with a cloth soaked in this solution and
then dry with a soft cloth.
4. It is recommended that the unit be cleaned each time it is defrosted to help keep the unit odor
free and running efficiently.
VACATION TIME
Short vacations: Leave the unit operating during vacations of less than three weeks.
Long vacations: If the appliance won’t be used for several months
1.Remove all food.
2.Disconnect power cord from electrical outlet.
3.Clean the appliance thoroughly.
4.Leave door open to avoid possible formations of condensation, mold or odors
POWER FAILURE
If a power failure occurs, frozen foods will stay frozen for at least 24 hours if the door is kept closed. This
will help food to stay fresh or frozen.
If service is to be interrupted longer than 24 hours remove all frozen food and find an alternate solution
MOVING YOUR UNIT
• Remove all the food.
• Securely tape down all loose items inside.
• Remove the rollers to prevent damage.
• Tape the doors shut.
• Be sure the unit stays in the upright positionduring transportation.
11

ENERGY SAVING TIPS
The unit should be located in the coolest area of the room, away from heat producing appliances or
heating ducts, and out of the direct sunlight.
Let hot foods cool to room temperature before placing in the unit. Overloading forces the
compressor to run longer. Foods that need to freeze may lose quality, or spoil.
Be sure to wrap foods properly, and wipe containers dry before placing them in the unit. This cuts down
on frost build-up inside.
Storage bins or shelves should not be lined with aluminum foil, wax paper, or paper towels. Liners
interfere with cold air circulation, making the unit less efficient.
Organize and label food to reduce door openings and extended searches. Remove as many items as
needed at one time, and close the door as soon as possible.
12

5.TROUBLESHOOTING
You can solve many common problems easily. Try the suggestions below to see if you can solve the issue, if the
problem persists contact the store where the unit was purchased.
PROBLEM(S)
POSSIBLE CAUSE (S)
Unit does not operate.
• Unit is not correctly plugged in.
• The circuit breaker tripped or has a blown fuse.
• The temperature control is set at "0/OFF".
Compressor turns on and off frequently.
• The room temperature is hotter than normal.
• A large amount of food has been added .
• The door is opened too often.
• The door is not closed completely.
• The temperature control is not set correctly.
• The door gasket does not seal properly.
• The unit does not have the correct clearances.
• The unit has recently been disconnected for a
period of time. Four hours are required for the
freezer to cool down completely.
Temperature inside the unit is too warm.
• Temperature control is set too warm. Turn the
control to a cooler setting and allow several hours
for the temperature to stabilize.
• Door is kept open too long or is opened too
frequently. Warm air enters every time the door is
opened. Open the door less often.
• The door is not closed completely.
• The door gasket does not seal properly.
• A large amount of warm or hot food might have
been stored recently. Wait until the unit has had a
chance to reach its selected temperature.
• The unit has recently been disconnected for a
period of time. Four hours are required for the
• freezer to cool down completely.
Temperature inside the unit is too cold.
• Temperature control is set too cold. Turn the
control to a warmer setting and allow several hours
for the temperature to stabilize.
Popping or cracking sound when compressor
comes on.
• Metal parts undergo expansion and contraction, This
is normal. Sound will level off or disappear as unit
continues to run.
Bubbling or gurgling sound, like water boiling.
• Refrigerant (used to cool ) is circulating
throughout the system. This is normal.
IF AFTER CONSULTING THE TROUBLESHOOTING GUIDE YOUR PROBLEM IS STILL NOT RESOLVED,
PLEASE CONTACT THE STORE WHERE YOUR PURCHASE WAS MADE.
13

6.WARRANTY INFORMATION
Refrigerator Warranty
14

Manuel D’Utilisation
Congélateur Vertical
MODÈLES:
LRU14F3AWWC
LRU14F3ASTC

TABLE DES MATIÈRES
16
1.AVERTISSEMENTS & PRÉCAUTIONS IMPORTANTES……………………..…………... 17-18-19
2.INSTRUCTIONS D’INSTALLATION …............................................................... 20-21-22
3.FONCTIONNEMENT......................................................................................23-24-25
4.NETTOYAGE ET ENTRETIEN............................................................................... 26-27
5.GUIDEDE DÉPANNAGE..............................................................................……. 28-29
6.GARANTIE………………........................................................................…...………….….30

ATTENTION GAZ - R600a
Si vous détectez une fuite, évitez absolument toute flamme ou autres sources de chaleur et aérez
le local où se trouve l’appareil pendant plusieurs minutes.
Ne jamais mettre en marche un appareil présentant des dommages. En cas de doute, consultez le
détaillant là où vous avez effectué votre achat.
Toute utilisation non recommandée par le manufacturier pourrait entraîner un incendie, des chocs
électriques ou des blessures.
Cet appareil est desné à être ulisé dans des applicaons domesques et similaires telles que
les zones de cuisine du personnel dans les magasins, les bureaux et autres environnements de
travail; les maisons de ferme et par les clients dans les hôtels, motels et autres environnements
de type résidenel; les environnements de type chambre d’hôtes; restauraon et applicaons
similaires non détaillants.
Cet appareil n’est pas desné à être ulisé par des personnes (y compris des enfants) ayant des
capacités physiques, sensorielles ou mentales réduites, ou manquant d’expérience et de
connaissances, à moins d’avoir été supervisées ou instruites concernant l’ulisaon de l’appareil
par une personne responsable de leur sécurité.
Si le cordon d’alimentaon est endommagé, il doit être remplacé par le fabricant, son agent de
maintenance ou des personnes de qualificaon similaire afin d’éviter un danger.
Ne stockez pas de substances explosives telles que les contenants d’aérosol avec gaz propulseur
inflammable dans cet appareil.
L’appareil doit être débranché après usage et avant de procéder à l’entreen par l’ulisateur sur
l’appareil.
AVERTISSEMENT: Gardez les ouvertures de venlaon, dans l’enceinte de l’appareil ou dans la
structure intégrée, sans d’obstrucon.
AVERTISSEMENT: N’ulisez pas de disposifs mécaniques ou des autres moyens d’accélérer la
décongélaon, autres que ceux recommandés par le fabricant.
AVERTISSEMENT: Ne pas endommager le circuit de réfrigérant.
AVERTISSEMENT: Ne pas uliser d'appareils électriques dans les comparments de stockage des
aliments de l'appareil, à moins qu'ils ne soient du type recommandé par le fabricant.
AVERTISSEMENT: Veuillez abandonner le réfrigérateur conformément aux réglementaons
locales pour l'ulisaon de gaz inflammable et de réfrigérant.
AVERTISSEMENT: Lors du posionnement de l'appareil, assurez-vous que le câble d'alimentaon
n'est pas coincé ou endommagé.
AVERTISSEMENT: Ne placez pas plusieurs douilles portaves ou disposifs d'alimentaon
d’énergie portafs à l'arrière de l'appareil.s avec l’appareil.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Cet équipement conent une certaine quanté de gaz réfrigérant ISOBUTANE (R600a), un gaz naturel
compable avec l’environnement qui, cependant, est combusble, voire explosif. Des précauons
doivent être prises pendant le transport et l’installaon pour éviter la détérioraon du circuit de
refroidissement car le gaz, en s ’échappant, peut s’enflammer ou causer des dommages.
17

1. IMPORTANTES CONSIGNES DE SÉCURITÉ (suite)
DANGER
IL EST DANGEREUX QUE QUICONQUE QU’UN PERSONNEL DE SERVICE AUTORISÉ
D’EFFECTUER DES RÉPARATIONS SUR CET APPAREIL.
NE TENTEZ PAS DE RÉPARER L'APPAREIL VOUS-MÊME. IL EST DANGEREUX
D'ALTÉRER LES SPÉCIFICATIONS DU PRODUIT OU DE LE MODIFIER DE QUELQUE
MANIÈRE QUE CE SOIT. TOUT DOMMAGE PEUT REPRÉSENTER UN RISQUE DE
COURT-CIRCUIT, D'INCENDIE OU D'ÉLECTROCUTION.
AVERTISSEMENT:Risque d’enfermer les enfants. Avant de jeter votre vieux réfrigérateur ou
congélateur :
• Rerer les portes.
• Laisser les tablees en place de façon à empêcher l’accès aux enfants.
AVERTISSEMENT : Pour éviter un danger dû à l'instabilité de l'appareil, celui-ci doit être fixé
conformément aux instrucons.
Ne pas ulisez de rallonges ou d'adaptateurs sans mise à la terre (deux broches).
Le réfrigérateur doit être déconnecté de la source d'alimentaon électrique avant de tenter
l'installaon de l'accessoire.
Les matériaux moussant de réfrigérant et de cyclopentane ulisé pour le réfrigérateur est
inflammable. Par conséquent, lorsque le réfrigérateur est raclé, il doit être gardé à l'écart de
toute source de feu et récupéré par une société de récupéraon spéciale avec une qualificaon
correspondante autre que la combuson, de manière à éviter tout dommage à l'environnement
ou autre.
Enfants doivent être surveillés pour s’assurer qu’ils ne jouent pas avec l’appareil.
13.
14.
15.
16.
17.
18.
18

1. PRÉCAUTIONS IMPORTANTES
VEUILLEZ LIRE TOUTES LES INSTRUCTIONS AVANT D’UTILISER L’APPAREIL
POUR VOTRE SÉCURITÉ
N’entreposez pas ou n’utilisez pas de l’essence ou tout autre vapeur ou liquide inflammable près de cet
appareil ou de tout autre appareil électroménager. Lisez les étiquettes du produit concernant les
avertissements d’inflammabilité et autres dangers.
AVERTISSEMENT
SÉCURITÉ
Risque d’emprisonnement pour les enfants.
Détruisez le carton, les sacs en plastique et tout matériau d’emballage immédiatement après le déballage.
Les enfants ne devraient jamais jouer avec ces éléments. Les cartons, plastiques et film étirables peuvent
devenir étanches à l’air et rapidement provoquer la suffocation.
Mise au rebut
Un appareil, jeté au rebut, représente un attrait dangereux pour les enfants. Enlevez-la ou les portes de
tout appareil qui n’est pas utilisé, même s’il est jeté au rebut que pour quelques jours.
Nous encourageons les méthodes responsables de recyclage et de mise au rebut des appareils
électroménagers.
Avant de recycler ou de mettre au rebut votre appareil :
•Enlevez les portes
•Laissez les tablettes et les paniers en place de sorte que les enfants ne puissent pas grimper
facilement à l'intérieur.
IMPORTANT
Veuillez lire toutes les consignes de sécurité avant d'utiliser votre nouveau réfrigérateur/congélateur.
19

2.INSTALLATION
AVANT DE METTRE VOTRE APPAREIL EN MARCHE, LIRE ET SUIVRE CES ÉTAPES INITIALES
IMPORTANTES .
A.ÉLECTRICITÉ, MISE À LA TERRE ET DÉGAGEMENT
Il est nécessaire de brancher l’appareil à un circuit unique, mise à la terre, ne desservant que cet
appareil.
Ne jamais utiliser de rallonge électrique.
• Cet appareil doit être installé de façon indépendante SEULEMENT. (Ne pas
encastré) Il doit être placé sur une surface solide qui en supportera le poids une
fois rempli.
• Afin de permettre une circulation d’air adéquate assurez-vous d’avoir un
dégagement d’au moins 10 cm (4 pouces) sur chaque côté, de 10cm (4 pouces)
à l’arrière et de 30 cm (12 pouces) au- dessus de votre appareil.
• Placez l’appareil à l’abri des rayons du soleil et de sources de chaleur
(four, radiateur). Une exposition directe à la lumière du soleil peut affecter le
revêtement acrylique de l’appareil et les sources de chaleur peuvent en faire
augmenter la consommation d’électricité.
• Des températures ambiantes extrêmement froides peuvent aussi causer des
problèmes de fonctionnement. Installez l’appareil dans un endroit où la
température ambiante se situe entre 0° C (32°F) et 43 °C (110°F).
Branchez l’appareil seul dans une prise murale mise à la terre. Le cordon d'alimentation
de l'appareil est muni d'une fiche à trois broches avec mise à la terre pour vous protéger
contre les chocs électriques. L’unité doit être branchée directement dans une prise
électrique à 3 broches avec mise à la terre.
20
