Lacanche LAG 010 CKG Configuration guide

Page 1 sur 18– Ft010CKG – US – Date de mise à jour : 26/02/10 - Indice : 01
LAG 010 CKG
-Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
-WHAT TO DO IF YOU SMELL GAS.
•Do not try to light any appliance.
•Do not touch any electrical switch.
•Do not use any phone in your building.
•Immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions.
•If you cannot reach your gas supplier, call the fire
department.
-Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
WARNING :
THIS RANGE CAN TIP
INJURY TO PERSONS COULD RESULT
INSTALL ANTI-TIP DEVICE PACKED
WITH RANGE
SEE INSTALLATION INSTRUCTIONS
"OPTION GRILL "
WARNING : If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or death.

Page 2 sur 18– Ft010CKG – US – Date de mise à jour : 26/02/10 - Indice : 01

GENERAL MANUAL
LAG 010 CKG
Page 3 sur 18– Ft010CKG – US – Date de mise à jour : 26/02/10 - Indice : 01
Layout :
Cooktop option lava rock grill left or right of central hob (depending on model)
Description :
A 12,500 BTU/hr gas burner, a gas valve with thermocouple safety is located under de fire tray.
A 275 x 460 mm grill resting on pillars is located above the fire tray.
Electric ignition..
Pressures and hourly consumption :
Table 1
PRESSURE 6’’ WC 10’’ WC
GAS Natural gas G.P.L.
Btu / hr Btu / hr
12,500 12,500
Accessories
Cooking grill.
Ash-drawer
Bag of lava rock.

Page 4 sur 18– Ft010CKG – US – Date de mise à jour : 26/02/10 - Indice : 01

Page 5 sur 18– Ft010CKG – US – Date de mise à jour : 26/02/10 - Indice : 01
"OPTION GRILL"
INSTALLER'S MANUAL
Appliances must be installed in a workmanlike manner in
accordance with the instructions in this manual and locally
applicable regulations.
This manual will be handed over to the user after
installation.

Page 6 sur 18– Ft010CKG – US – Date de mise à jour : 26/02/10 - Indice : 01

INSTALLER’S MANUAL
LAG 010 CKG
Page 7 sur 18– Ft010CKG – US – Date de mise à jour : 26/02/10 - Indice : 01
SITTING
Cautions :
The purchaser undertakes to install or arrange for his/her equipment to be installed in a workmanlike manner and in
accordance with the applicable regulations and standards.
Any servicing or repair work on appliance must be performed by a qualified technician.
Recommendations :
Adjust this appliance by using the levelling feet. Allow a minimum clearance of 50 mm between the appliance and
any other surfaces (walls affected by heat).
If the appliance is to be built in between two surfaces, it is CRUCIAL to allow free circulation of air behind the
appliance (provide shielding at rear). Cooktops should NEVER be installed lower than adjacent worksurfaces. It is
also recommended to allow the unit front panel to protrude 50 mm relative to the adjacent units.
Must be installed under an exhaust hood.
Do not install this unit near combustible walls, partitions, pieces of furniture or decorative material unless these are
covered with adequate thermal insulation of the noncombustible type. Making sure the resulting installation meets
local fire regulations.
A shut-off valve must be installed and accessible close to the appliance in order to isolate it from the supply or to
facilitate cutting the gas supply :

INSTALLER’S MANUAL
LAG 010 CKG
Page 8 sur 18– Ft010CKG – US – Date de mise à jour : 26/02/10 - Indice : 01
Changing nozzle :
Replace the injector.
Lacanche ranges are supplied with the gas fi tting requested when the order is placed. The settings must
be fi ne-tuned when the range is installed.
IMPORTANT : Close the mains gas valve before carrying out any works.
GAS Pressure Ø
Natural gas 6" WC 1.40
L.P. propane 10" WC 0.95
IMPORTANT
In case of use with a gas other than that for which the appliance was initially set up, it is crucial
replace the injectors and modify the adjustments as defi ned below.
Adjusting the primary air of hob burners
Loosen the screw that secures the air ring D
Adjust the air ring.
Opening in mm /
inches
GAS Pressure Oven
Natural gas 6" WC 4 / 3/16
L.P. propane 10" WC 6 / 1/4

INSTALLER’S MANUAL
LAG 010 CKG
Page 9 sur 18– Ft010CKG – US – Date de mise à jour : 26/02/10 - Indice : 01
Adjusting reduced flow of hob burners :
After connection or change of gas, it is crucial to modify this adjustment :
►Remove the knob.
►Light the appropriate burner.
►Adjust to minimum setting.
►Use a small screwdriver to set the adjusting screw E.
N.B : Flame is reduced to ¼ of its size in the minimum setting, the burner must remain lit when changing
from maximum setting to minimum setting.
Adjusting the safety devices for each thermocouple of the hob :
If the burner goes out, having kept the control knob pushed in for roughly twenty seconds, check that :
- The magnetic head grip the valve moderately.
- The flame touches the point of thermocouple F.
- The thermocouples and magnetic heads are absolutely clean.

INSTALLER’S MANUAL
LAG 010 CKG
Page 10 sur 18– Ft010CKG – US – Date de mise à jour : 26/02/10 - Indice : 01
IMPORTANT
THE APPLIANCE MUST BE INSTALLED IN
ACCORDANCE WITH THE LOCAL CODES OR
National Fuel Gas Code, ANSI Z223.1 or latest edition.
Manual shut-off valve should be installed in an accessible
location in the gas piping external to the appliance for the
purpose of turning on or shutting off gas to the appliance.
Must be installed under an exhaust hood.
Do not install this unit near combustible walls, partitions,
pieces of furniture or decorative material unless these are
covered with adequate thermal insulation of the
noncombustible type.
Making sure the resulting installation meets fire
regulations.
IMPORTANT
IMPORTANT

INSTALLER’S MANUAL
LAG 010 CKG
Page 11 sur 18– Ft010CKG – US – Date de mise à jour : 26/02/10 - Indice : 01
ELECTRICITY
REPARATIES
All work on or repair of an appliance must be carried out by a qualified installer.
Refer to data sheet of basic appliance.
THE APPLIANCE WHEN INSTALLED, MUST BE
ELECTRICALLY GROUNDED IN ACCORDANCE
WITH THE LOCAL CODES OR The National Electrical
Code, ANSI/NFPA 70-1996 or latest edition.
ALL WORK ON OR REPAIR OF AN APPLIANCE
MUST BE CARRIED OUT BY A QUALIFIED
INSTALLER.

INSTALLER’S MANUAL
LAG 010 CKG
Page 12 sur 18– Ft010CKG – US – Date de mise à jour : 26/02/10 - Indice : 01
GAS CIRCUIT DIAGRAMME
GAS CIRCUIT DIAGRAMME
Designation Part number
oven burner 65.062010
Injector holder 65.51764
Oven burner 65.080012
Screw 65.51085
Burner body 65.062011
+ 4 screws 65.129101
+ 4 disc 65.30932

Page 13 sur 18– Ft010CKG – US – Date de mise à jour : 26/02/10 - Indice : 01
« LACANCHE»
USER'S MANUAL
IMPORTANT
Provide adequate air supply during use of the
appliance.
Provide adequate clearances for servicing and
proper operation by not obstructing front or
side of appliances.
WARRANTY
The warranty is stated on the sales contract.
Please contact your approved Dealer if any work
has to be carried out under warranty.
This warranty excludes damage resulting from
incorrect installation, improper use or inadequate
servicing.

Page 14 sur 18– Ft010CKG – US – Date de mise à jour : 26/02/10 - Indice : 01

USER’S MANUAL
LAG 010 CKG
Page 15 sur 18– Ft010CKG – US – Date de mise à jour : 26/02/10 - Indice : 01
SAFETY INSTRUCTIONS
If the range is to be installed on an area covered with linoleum or any
other floor covering, make sure that the floor covering can withstand 90 F
(65°C) above room temperature without warping, shrinking or discoloring.
Do not install the range over carpeting.
Never store anything in the oven or the cooktop. Flammable materials can
catch fire, plastic items may melt or ignite and other types of items could
be ruined.
This appliance is for cooking. Based on safety considerations, never use the
oven or cooktop to warm or heat a room. Doing so may result in carbon
monoxide poisoning and overheating of the oven. Also, such use can
damage the cooktop or oven parts.
Never corver any slots, holes or passages in the oven bottom or cover an
entire rack with materials such as aluminium foil. Doing so blocks air flow
through the oven and may cause carbon monoxide poisoning.
Aluminium foil linings may also trap heat, causing a fire hazard.
Do not obstruct the flow of combustion or ventilation air to the appliance.
Be sure a fresh air supply is available.
When using the cooktop, do not touch the burner grates or the immediate
surrounding area. Areas adjacent to the burners may become hot enough
to cause burns.
Do not hang articles from any part of the appliance or place anything
against the oven. Some fabrics are quite flammable and may catch on fire.
However, children should not be left alone in the kitchen while the range is
in use. Do not store items of interest to children over the unit. Children
climbing to reach items could be seriously injured.
Do not use aluminum foil to line any part of the oven or cooktop.
When using the oven, do not touch the interior surfaces of the oven, the
exterior area immediately surrounding the door or the backtrim.
Disconnect from power supply before servicing.

USER’S MANUAL
LAG 010 CKG
Page 16 sur 18– Ft010CKG – US – Date de mise à jour : 26/02/10 - Indice : 01
USE LAVA ROCK GRILL
Before use, it is mandatory to remove all the internal and external plastic packing pieces, failure to do so will
cause irreversible damage to the steel walls
Remove the cooking grill and cover only the stone rack in the tray with the 3 kg of lava rock supplied.
Initial usage will cause some smoke and is no cause for alarm.
CAUTION potential users that temperatures may exceed 300°C.
Using the burner :
→Push and turn the burner control knob anticlockwise as far as the symbol.
Simultaneously push ignition pushbutton several times .
→Keep the control knob pushed in for roughly 20 seconds in order
to activate the safety cut-out.
→A reduced flowrate position identified by the mark produces the
preset minimum burner power (low flame).
→To turn off, turn the control knob clockwise to the «OFF» position.
Useful hint :
CAUTION :
→Use no oils or fats when cooking over lava rock as these may burn and
smoke.
→Untrimmed fat may burn and smoke; simply move the cut away from the fl
ame.
→The grill can be fi xed in a higher or lower position for fast or slow
cooking.
After any use, to close the valve of stopping gas
High level
Low level

USER’S MANUAL
LAG 010 CKG
Page 17 sur 18– Ft010CKG – US – Date de mise à jour : 26/02/10 - Indice : 01
Broiled meat tips :
→Do not score or «spear» the cut or it will lose its juices.
→Use tongs not a fork to turn.
Recommended temperatures :
Very hot : Use for thin cuts or for rare and red cuts.
Hot : For thin or medium-thick cuts cooked medium.
Medium : Thick cuts (e.g., ribs of beef) should not be seared too quickly to avoid a well-browned
outside and a raw inside.
Broiling lengthwise and crosswise :
Cuts can be broiled length- and crosswise once or twice; twice will more evenly distributed the juices
and produce a tender piece dripping less when served.

USER’S MANUAL
LAG 010 CKG
Page 18 sur 18– Ft010CKG – US – Date de mise à jour : 26/02/10 - Indice : 01
CLEANING
Do not use a steam cleaner to clean the appliance.
Before any cleaning work, isolate from the mains supply
Wait until the fire tray has at least partially cooled.
Cooking grill :
After use, remove food rests with a metal brush from grill while still hot.
The lava rock rests on a rack which itself rests on the bottom of the fire tray. The rack may be removed to clean
the tray.
Ashes fall into the ash-drawer A, which may be pulled out completely for emptying.
Replace lava rock as a function of use but at least once a year.
Railing of recovery (rep.A) - Tub with juice (rep.B) - Drawer with
Burner :
The deflector D detachable (removable) protecting the distiller can clean itself easily in the
dishwasher.
Use a metal brush to clean the burner after use.
Body panels :
You can use special-purpose products for stainless steel (e.g. SUMAINOX ®, JOHNSON
STAINLESS STEEL
®, PPZ STAINLESS STEEL ®). Never use abrasive products.
CAUTION
Use NO chlorinated cleasers to clean this unit.
Carefully read the precautions and recommendations for applying the products
you use to
clean and maintain the range. Follow the instructions for use.
DANGER : Wait for the cooling of the device before any manipulation of the drawer with residues
(rep. C) and to use an adequate protection so required by manipulation of the tub(ferry,high school
diploma) with juice (rep. B) during the service.
Warn users of the potential hazards.
A B C
D
