Skid Steer Wiring Installaon - Rocker Switches
Figure 9
Use these instrucons if the 8-Pin and 14-Pin connectors will not work on your skid loader.
The switches may be located in the provided switch plates, or in available switch knockouts in the skid steer. The below instrucons show a
typical skid steer installaon. Locaon details will vary between makes and models.
1. Insert two momentary switches (REDRS1093) into the upper cab panel (Figures 9 & 10).
2. Aach the one of the short red wires from RED56WIR-4 to the middle post of a momentary switches. (The momentary switches are idencal.)
Then aach the blue wire and the white wire of harness RED56WIR-3 to the same switch, one on either side of the red wire (Figure 11). This will
be your chute rotaon motor switch.
3. Aach the other short red wire from RED56WIR-4 to the middle post of the second momentary switch. Then aach the green wire and brown
wire of harness RED56WIR-3 to the switch, one on each side of the red wire (Figure 12). This will be your deector control switch.
4. Connect the free end of the Red wire (RED56WIR-4) to the power wire on the skid loader and the free end of the Black wire of harness
(RED56WIR-3) to a ground wire on the skid loader (Figure 13).
Figure 10
