Lanoptik MV60 User manual

MV60
LANOPTIK TECHNOLOGIES LTD
www.lanoptik.com
5G WiFi Multi-Viewing Workstation
User’s Manual

Content
www.lanoptik.com
CHAPTER 1 SOFTWARE FOR WINDOWS
CHAPTER 2 APP FOR SMART DEVICES
- 1 -
1.1 Software operating environment requirements - 1 -
- 10 -
2.1 APP operating environment requirements - 10 -
1.2 Software installation steps - 1 -
1.3 Operation description of software interface and functional modules - 3 -
1.3.1 User Number section - 4 -
1.3.2 Lecturing section - 4 -
1.3.3 Commonly-used toolbar - 5 -
1.3.4 Image property adjustment tool - 6 -
1.3.5 Measuring tool - 7 -
1.3.6 System settings section - 9 -
2.2 APP download, install and connect microscopic images - 10 -
2.3 APP function introduction - 11 -
2.4 Screen Live Preview Window Function Buttons Introduction - 11 -
2.5 File manager - 12 -
2.5.1 Photo folder - 12 -
2.5.2 Video folder - 12 -
2.5.3 Use APP for calibration and measurement - 13 -

User's Manual | 5G WiFi Multi-Viewing Workstation MV60
www.lanoptik.com
- 1 -
System
CPU
Hard Disk
Memory
Graphics Card
Network Card
Windows 7, 10, 11
i7 8th-generation
or later version
512GB
or more
16GB
or more
Discrete graphics card
(NVIDIA GeForce)
10/100/1000M
Self-adaptive
Chapter 1 Software for Windows - KoPa WiFi Lab
1.1 Software Operating Environment Requirements
Note: The language of the installation wizard is independent of the language used in the software interface.
Software installation requires registry files, which may be blocked by some anti-virus software, such
as the pop-up prompt whether to allow installation, must be allowed and continue.
The software may be blocked by some anti-virus software during operation, so it can't be used
normally. It is recommended to close all anti-virus software first or add this software as a trusted
option when using this interactive system.
Note:Make sure the workstation is powered on and properly connected before running the software.
1.2 Software Installation Steps
Step 1: Start the computer and Prepare the software "KoPa WiFi Lab Install" which to be installed.
Step 2: Double-click the "KoPa WiFi Lab Install" file. When the following window appears, select the
required installation wizard language and press the "OK" button.
Step 3: Click the "Next" button when the" Welcome to KoPa WiFi Lab "installation wizard appears.

www.lanoptik.com
- 2 -
Step 4: When the "Select Destination Location" window appears, click "Browse" to select the path of the
file you want to install, usually you don't need to change it, click "Next".
Step 5: When the screen as shown below appears, select the shortcut you need and click the "Next"
button.
Step 6: Confirm information such as "Destination location" of the software installation.After
confirmation, please click the "Install " button.
User's Manual | 5G WiFi Multi-Viewing Workstation MV60

www.lanoptik.com
- 3 -
Step 7: The installation progress bar will appear during the installation process. During the installation
process of the software, some necessary library files need to be registered. If it may be blocked by
some anti-virus software, such as the pop-up prompt whether to allow installation, it must be allowed
and continue to run.
Step 8: When the following window appears, the software has been installed successfully. Click "Finish"
button to complete the installation.After the window closes, check the buttons on your desktop.
If you cannot find it, go from “Start”
→
”All Programs” to find it.
1.3 Operation Description of Software Interface and Functional Modules
User's Manual | 5G WiFi Multi-Viewing Workstation MV60

www.lanoptik.com
- 4 -
1.3.1 User Number Section
1.3.1.1 Function description:
Quickly scan connections and view the current number of connections to the Multi-Viewing
Workstation.
1.3.1.2 Function details:
The smart terminal can scan the connection QR code in the software interface to connect to the
Multi-Viewing workstation to observe microscopic images in real time.
The "User Number section" on the left side of KoPa WiFi Lab can view the total number of current
connections to the Multi-Viewing workstation (the figure on the left is 35),The system
automatically detects the number of refreshed microscopes online, midway join or leave and
return can view in real time.
1.3.2 Lecturing Section
1.3.2.1 Function description:
Windows screen or operation process pushed to the smart terminal users simultaneously; Smart terminal users can
display microscopic images and computer operation screens under Windows in real time,displaying lesson plans, PPT,
videos and other lesson plans in real time for smart terminal users.
User's Manual | 5G WiFi Multi-Viewing Workstation MV60

www.lanoptik.com
- 5 -
1.3.2.2 Electronic whiteboard
In the lecturing mode, click the "Electronic Whiteboard" button in the upper right corner of the software to
display the tutor's computer desktop to the smart terminal users and make annotations on the computer desktop and
other courseware.
"Electronic Whiteboard" tools, from left to right are: Pen, Arrow, Enter Text, Undo, Redo, Eraser, Delete Object, Line
Width, Line Type, Color, Screenshot, Screen Record, Mouse Penetrate (this tool allows to retrieve file from computer
disk), and return to the interface of the software. It is helpful to annotate courseware or video displayed on the desktop
and display them to all smart terminal users in real time.
1.3.3 Commonly-used Toolbar
Open Retrieve the image from the local disk into the software.
Save After annotating the picture and adding text, click "Save" button to save the
current annotation and text.
Preview When a static image is displayed on the window, clicking this button will restore
the window to the dynamic preview
Select Select objects to facilitate the next operation,such as moving,deleting. Support
single selection and regional selection.
Move Use the mouse to drag a static screen
Undo Undo the last operation on the “object”.
Redo Redo the last operation on the “object”.
Delete Make a one-click deletion or eraser of the selected “object”.
Multi-screens
Comparison Full screen / Home screen / Dual screen comparison / Four screen comparison.
Mirror Mirror the image on the currently selected screen.
Flip Flips the image in the currently selected screen.
Take Picture Take a picture of the screen currently selected.
Screen Shot Take screenshot of the entire desktop.
Record Video recording of the screen currently selected.
Screen Record Video recording of the entire desktop.
Advanced Image
Process Combine channels--Images can be assigned color channels quickly and
reliably. Combined color images--Easy overlay of fluorescence microscopy
images.
User's Manual | 5G WiFi Multi-Viewing Workstation MV60

www.lanoptik.com
- 6 -
1.3.4 Image Property Adjustment Tool
The image properties tool is activated when the software displays only dynamic images of a
single window. Depending on your needs, you can adjust the corresponding parameters to
achieve the desired preview and scanning effect.
Staining type
The Staining type is chosen according to the actual situation.
Brightness
Manually drag the adjustment bar to adjust the image brightness.
Exposure
When checked, the camera will automatically be exposed according to the
environment used. When not checked, manual exposure can be carried out
through the adjustment bar, and directly input the value in the box is
supported.
White balance
When checked, the camera will automatically white balance according to
the use environment. When not checked, manual white balance
adjustment can be carried out through the adjustment bar, and directly
input the value in the box is supported.
Gain
Manually drag the adjustment bar to adjust the image gain.
Contrast
Manually drag the adjustment bar to adjust the image contrast.
Hue
Manually drag the adjustment bar to adjust the image hue.
Saturation
Manually drag the adjustment bar to adjust the image saturation.
Sharpness
Manually drag the adjustment bar to adjust the image sharpness.
Gamma
Manually drag the adjustment bar to adjust the image gamma.
Export image properties
Export the value of the current image property parameter.
Import image properties
Import image property parameter values.
Restore default values
Restore the default value of image properties.
User's Manual | 5G WiFi Multi-Viewing Workstation MV60

www.lanoptik.com
- 7 -
1.3.5 Measuring Tools
1.3.5.1 Calibration and measurement function operations
Step 1: Acquire benchmark image.
Place a scale ruler in the filed of view. Please use the same conditions (i.e. same objective lens,
same camera resolution) as the target observation objects.If a magnification reduction lens is
used to measure the target observation objects, then a magnification reduction is also needed
to measure the scale bar. This is what we called acquire benchmark image.As figure follows:
Step 2: Click "Calibration" in the left measurement tools toolbar, calibration table will shown as
below figure.
Step 3: Set the scale and draw a straight line with the mouse on the benchmark image.When setting the ruler length,
you can get a more accurate result by selecting a longer scale length.If 10 small scale lengths are selected, the
accuracy will be higher than that of only 1 scale length.) As shown in the figure :(the image value drawn with the mouse
will be automatically updated at the "pixel number")
Enter the name of the calibration table created and the selected ruler length (the actual length). Assuming that the unit
of dividing scale in the benchmark picture is µm, fill in the corresponding information at the designated place, as shown
in the figure below: Click "Add" to add the benchmark defined in the benchmark picture to the calibration table in the
software for subsequent operation.
User's Manual | 5G WiFi Multi-Viewing Workstation MV60

www.lanoptik.com
- 8 -
“Add”: Add the right side calibration information to the list on the left.
“Edit”: Revise or edit selected calibration item on the left.
“Delete”: Delete selected calibration item on the left.
“Apply”: Activate selected calibration item as benchmark for current image.
User's Manual | 5G WiFi Multi-Viewing Workstation MV60
Step 4: Import the target image to be measured, select the calibration value on the left in the calibration table, click
"Apply", and set the baseline saved in the previous step as the baseline of the target image, as shown below:
Note:
Step 5: Select the corresponding measurement tool for actual measurement. The measured data will be displayed in
the display bar on the right side of the software.
Note: The software provides the following measurement tools:
Step 6: Export the measured results.
Click the export tool in the upper right display bar to export data and images
to PDF, Word, Excel, printer and mail (Outlook only).Export to PDF, printer and mail
functions are only available for static images
Select Export to Word, as shown below: Enter file name, select path, and click Save"

www.lanoptik.com
- 9 -
User's Manual | 5G WiFi Multi-Viewing Workstation MV60
The exported documents are as follows:
1.3.5.1 Scale bar tool
1.3.6 System Settings Section
Click the Settings button in the upper right corner of the software to enter the system settings.
Save path
Photo file type
Sound of snapshot
Language
Recording time

www.lanoptik.com
- 10 -
User's Manual | 5G WiFi Multi-Viewing Workstation MV60
Chapter 2 App for Smart Devices - KoPa WiFi Lab
KoPa WiFi Lab is dedicated to smart devices (mobile phones, tablets).
KoPa WiFi Lab is available for download from official website or the Google play store and APP store by
following instructions.
KoPa WiFi Lab can be downloaded repeatedly from the Google play store or APP store.
Note:
System
System Version
CPU
RAM
ROM
Protocol
Android
5.0 or later version
Dual-core 1.7GHz or later version
3GB or more
32GB or more
5G WiFi
IEE802.11ac
iOS
11.0 or later version
Dual-core 1.8GHz or later version
2GB or more
32GB or more
2.1 App Operating Environment Requirements
Note: Please confirm that the hardware of the smart device must support 5G WiFi IEE802.11ac protocol,
otherwise it will not be able to acquire image correctly.
2.2 APP Download, Install and Connect Microscopic Images
Step 1: Scan the QR code on the right to download and install the APP. (Please use
the browser code scanning function to download)
Note: After the APP is downloaded, please follow the instructions to allow the
installation and allow all licenses, if you click "No", it will not work.
Step 2:Connecting and acquiring images using the APP.
Note: Please run KoPa WiFi Lab for Windows to make sure your PC is getting images properly before using the APP. After the
APP is installed, use the built-in QR code scanner of the smart terminal to scan the "Connection QR Code" on the interface of
KoPa WiFi Lab for Windows to get the image directly.

www.lanoptik.com
- 11 -
User's Manual | 5G WiFi Multi-Viewing Workstation MV60
2.3 APP Function Introduction
Preview
Click to go to the image preview window.
File Manage
Click to check the photos/videos/assignment folder.
Scan QR Code
Scan the connection QR code of the KoPa WiFi Lab interface for Windows to get an image.
Settings
APP settings
Operation Guide (Upper right corner)
Retrieve/hide user instructions.
2.4 Screen Live Preview Window Function Buttons Introduction

www.lanoptik.com
- 12 -
User's Manual | 5G WiFi Multi-Viewing Workstation MV60
2.5 File Manager
2.5.1 Photo Folder
2.5.2 Video Folder
Image and video files can be renamed. Click on the file name to bring up the file renaming dialog box, as follows.

www.lanoptik.com
- 13 -
(1) Place the calibration ruler under the microscope.
(2) Click
→
Add
(3) Enter a name, the actual length of the calibration ruler, select a unit, and draw on the ruler, the pixels are
automatically entered, as shown below.Click “OK” to complete the calibration.
User's Manual | 5G WiFi Multi-Viewing Workstation MV60
2.5.3 Use APP for Calibration and Measurement
(4) Select a calibration value. (5) Use the measurement tool at the top of the window.

LANOPTIK TECHNOLOGIES LTD
No. 72 Hongjing Street, Lejia Road, Baiyun District, Guangzhou, China. 510400
Phone: +86 20 3898 6017 | Fax: +86 20 3847 6076
Website: http://www.lanoptik.com | Email: info@lanoptik.com
Specifications are subject to change without any obligation on the part of the manufacturer.
Table of contents
