Laser AO-DPF-12ELBK User manual

AO-DPF-12ELBK USER MANUAL
1
Please read carefully before use

AO-DPF-12ELBK USER MANUAL
2
TABLE OF CONTENTS
IMPOR AN SAF EY INS RCU IONS AND PRECAU IONS ........................................................ 3
FEA URES .................................................................................................................................. 3
WHA ’S IN HE BOX .................................................................................................................. 4
GE ING O KNOW YOU PRODUC .......................................................................................... 4
GE ING S AR ED ..................................................................................................................... 5
PIC URE PLAYBACK ................................................................................................................... 5
Using the Zoom feature ......................................................................................................... 6
Inserting Memory Cards ........................................................................................................ 6
FREQUE LY ASKED QUES IONS ................................................................................................. 7
ROUBLE SHOO ING ................................................................................................................. 7
ECHNICAL SPECIFICA IONS ..................................................................................................... 8
AVAILABLE ACCESSORIES .......................................................................................................... 8
CON AC INFORMA ION .......................................................................................................... 8

AO-DPF-12ELBK USER MANUAL
3
IMPORTANT SAFTEY INSTRCUTIONS AND PRECAUTIONS
- Read all instructions carefully before use.
- Retain manuals for future reference.
- Use this product only in the manner described.
- Only use a water-dampened soft-cloth to clean the surface of this product.
- Use electronic devices in well ventilated areas and ensure that ventilation holes are
clear. his product is designed for indoor use only.
- Do not expose to excess vibration.
- Do not use in direct sunlight.
- he following will damage this product: any liquid such as water or moisture,
extreme heat; cold; humidity, dusty or sandy environments.
- Only place this device on stable surfaces and ensure that any attached cables are
secure and will not cause the device to fall.
- If wall mounting this product please ensure that all fittings are rated for the weight
of this product and is installed correctly.
- When positioning for wall mounting please consider length of power cord and
location of nearest power outlet.
- his product and the AC adaptor may become warm when in use.
- here are no user serviceable parts in this product.
- Un-authorized attempts to dismantle or repair this product will void product
warranty and may result in dangerous electric shock.
- Remove any power or data cords by pulling them from the plug and not the cord.
- Using this device near other electronic devices may cause interference.
- Please turn this product off at the power outlet when not in use.
- Images in the document are representative only and may differ from actual product.
- We reserve the right to make changes to this product without notification.
FEATURES
• 12” viewable display.
• Simple to operate-plug and play.
• Display digital pictures (JPEG) without a computer.
• Compatible memory cards include Secure Digital Card (SD), Multimedia Card (MMC),
Memory stick, Memory stick Pro/Duo, &USB Disk.
• Displays digital camera’s stored JPEG images.
• Supports up to 16 Mega pixel image files (JPEG Format).
• Slide show for JPEG photos.
• Support photo zoom function: 150%, 200%, 250%.

AO-DPF-12ELBK USER MANUAL
4
WHAT’S IN THE BOX
1 x Laser AO-DPF-12ELBk Digital Picture frame
1 x Stand
1 x AC power adaptor
1 x user manual
GETTING TO KNOW YOU PRODUCT
Descripti n
Descripti n
1
Zoom Button
7
Up Button
2
Play/Pause Button
8
USB 2.0 Host Port
3
On/Off Power Switch
9
DC Input Jack
4
Next
Button
10
Wall Mount Holes
5
Previous
Button
11
Stand Mount Keyway
6
Down Button
12
SDHC/MS/MMC Card Slot.

AO-DPF-12ELBK USER MANUAL
5
GETTING STARTED
Identify each item from the box.
Insert the stand so that the lug line up with the keyway (11) on the back of the Digital
Picture Frame.
Rotate the Stand a ¼ turn clockwise until it locks in place.
Check the power switch to ensure that it is in the OFF position.
Plug the AC adaptor in to the input Jack on the side of the Digital Picture frame (9) and then
plug the power pack in to the wall outlet.
urn the wall outlet on.
Place the storage card containing your JPG images in to the SDHC/MS/MMC slot (12) or a
USB drive in to the USB port (8).
urn the Power Switch on the Digital Picture frame to the on position.
he Picture frame will detect the images on the storage device and begin playback.
PICTURE PLAYBACK
he Laser Digital picture frame will automatically begin playback of files detected on storage
card or USB drives connected to the frame.
he following buttons are used to control playback.
ICON
TITLE DESCRIPTION
Play/Pause Starts or stops picture slide show.
Next Button Displays next image
Previous Button Displays previous image
Zoom Zooms in on current image. Supports 150%, 200% & 250%
zoom. Please see further for more information.
Please note that Pressing the Previous or Next button while slide show is paused will resume
slide show. Please press pause again to pause the next image.
Slide Show playback is fixed and duration of image may be affected by size of image files
being displayed.

AO-DPF-12ELBK USER MANUAL
6
Using the Z m feature
Press in the zoom button at any time will zoom in to the centre of the current image 150%.
Press again to zoom in to 200% and again to 250%. Use the Previous/Next/Up/Down
buttons to scroll the image across and up and down the screen to show the edges of the
image.
Press the Zoom button again to resume normal viewing.
he Slide show will pause while in zoom mode and resume when exited or the Play/Pause
button is pressed.
Inserting Mem ry Cards
his Digital Picture frame is compatible with following memory cards or USB disks. Adaptors
may be required to use some card types (not supplied).
• Secure Digital Card
M
(SD)
• Secure Digital Card High Capacity
M
(SDHC) Up to 16GB
• MultiMedia card
M
(MMC)
• Memory Stick®, Memory stick PRO®, Memory stick DUO®(MS)
• USB flash drives up 16GB (FA /FA 32 files system only)
Please turn the Digital Picture Frame OFF before connecting you card or Drive.
Do not force card in to the slots.
he Digital Picture frame will only recognise images in JPEG (JPG) format. Digital images
stored in other formats may not be recognised and ignored by the Digital Picture frame.

AO-DPF-12ELBK USER MANUAL
7
FREQUETLY ASKED QUESTIONS
QUESTIONS
ANSWERS
What picture formats are
supported?
Photo DCF JPEG and Photoshop®’s Baseline JPEG
What is the maximum size
picture the Digiframe can
display?
he Digital picture frame can display images up to 16
Megapixels.
Can I adjust the picture
settings like colour and
brightness?
No. he colour, contrast and brightens settings are all preset
in the factory for your screen.
Can I have a USB drive and a
Memory card inserted at the
same time?
You can, but a card and a USB drive is plugged in to the
Digital Picture frame at the same time it will default to the
USB drive only. You will need to remove the USB drive and
restart to read the card.
Can I alter the slideshow
settings?
he slideshow settings in are preset at the factory and
cannot be changed.
Can the Digital Picture Frame
be set to show images in
portrait rather than
landscape?
he Digital Picture frame can only be set to show images in
the Landscape format. Images taken in the portrait mode
will be displayed in the “pillar box’ format.
TROUBLE SHOOTING
PROBLEM
SOLUTION.
No Picture • Power not connected or turned on
• Power switch in off position
Will not read card • Card in wrong files system. Cards and drives should
be in FA /FA 32 only. Reformat card/drive if
required.
• Card not seated correctly. Remove and replace.
Will not read image files Files in wrong format. Convert format to JPEG
Slideshow/forward/next
buttons are slow to respond.
Large images files can affect the performance of the Digital
Picture Frames. Copy & Reduce image resolution. Lower
resolution will also reduce size required for each file
allowing more images on your card or Flash drive.

AO-DPF-12ELBK USER MANUAL
8
TECHNICAL SPECIFICATIONS
echnical Specifications*
Dimensi ns * 320MM X 240MM X 56MM Viewing Angle 50/60/70/70(CR=10)
Weight* 1300 grams Resp nse Time 30 ms
*Dimensions without stand Supp rt F rmat JPG
Display 12” Colour F LCD (Diagonal) AC input 110-240VAC 50/60Hz
Res luti n 800 X 600 P wer Requirement 12V DC
C ntrast 500:1 P wer C nsumpti n 24W
Brightness 300 cd/m Operati n Temperature -20°C to 65°C
Aspect Rati n 4:3 St rage Temperature -30°C to 75°C
* As continual improvements are made to this product, slight operational differences may occur. For the most
up-to-date manual please visit our website.
AVAILABLE ACCESSORIES
USB Flash Drives
http://www.laserco.net/products/media-storage-devices/usb-flash-drives
F r ther access ries and pr ducts
http://www.laserco.net
CONTACT INFORMATION
For more information on this product and technical support please visit
H P://WWW.LASERCO.NE
