LAUER EPC PM 1700tc Nautic User manual

CiS-Nr.:360.610.0120
Reg10509/0805
Version2/03.06
© Elektronik-Systeme LAUER GmbH & Co.KG
User manual
EPC PM 1700tc Nautic
EPC PM 1900tc Nautic
17“
19“
MT 217 Nautic
MT 219 Nautic
17“
19“
EPC PM box Nautic
Panel-PC:
TFT Monitor + PC-Box:
21“
21“
EPC PM 2100tc Nautic
MT 221 Nautic

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
2
Elektronik Systeme LAUER GmbH & Co.KG
P.O Box 1465
D-72604Nürtingen
Operatinginstructions: EPC PM Nautic devices
issue: 13.März 2006
editor: Jung
Operatinginstructions, manuals and software are copyrighted. All rights
are reserved. Copying, duplicating, translating, transcribing en bloc or
partially is prohibited.An exception is the making of a software back up
copy for private use.
• We reserve the right to make amendments to the manual without
priornotice.
• We can not guarantee the accuracy and correctness of the
programmesand data storedon the CD-ROM.
• Helpful suggestions, improvements as well as references to errors
are welcome at any time.
• Thestipulationsarealsovalid for any specialannexestothismanual.
Microsoft,Windows2000,WindowsXP andtheWindowsLogo are either
registered trademarks or trademarks of the Microsoft Corporation in the
USAand/or other countries.
The above terms in this documentation can be brands, whose use by
third parties can breach the rights of the proprietor.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
User tips
Please read the manual prior to using for the first time and keep it in a
safe place for future use.
Targetgroup Thedocumentedinformationin this manualrefers to theappliance, place
of use, transport, storage, assembly, use and maintenance.
This manual is directed to the following target groups:
• User
• Servicetechnicians/maintenance technicians
Especially observe the chapter „safety instructions and general
instructions“.
Knowledgeof PCand Microsoft-operatingsystems areassumed. Gene-
ralknowledge in thearea of automationtechnology is recommended.
Diagramconvention [Key] Key entries by the user are shown in squared brackets, for
example[CTRL] or[DEL]
italic Names of pushbuttons to be used, menus or other screen
elements as well as brand names are shown in italic letters.
Necessarybasic knowledge A solid Knowledge of the personal computer and Microsoft-operating
systems is assumed and a general knowledge in the area of automation
technologyis recommended.
Approbation’s&standards Youwillfind information intheannex,chapter„certificateand guide lines“.
Safety instructions Anywhereintheautomationequipment,wheredangerouserrorsmayoccur,
i.e.thatanoccurring error maycausemajor material or personaldamage,
additionalexternal precautions or facilities haveto bemade (for example
bymeansofindependentlimitswitches,mechanicalinterlocksetc.),which
incase of an error guarantee or enforce a secure operating condition.
The test and aptitude of the intended usage by the user res. the usage
under operational conditions is the responsibility of the user.Therefore
Elektronik-Systeme LAUER does not assume liability.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
4
UserTips
Icons The following icons are used in the manual to mark certain paragraphs:
Danger!
Meansthatdeathorsevereinjurywilloccurwhentherelevantprecautionary
measuresare nottaken
Caution!
Means that death or severe injury may occur when the relevant
precautionarymeasures are not taken.
Warning!
With warning triangle means that a light injury may occur when the rele-
vantprecautionary measuresare nottaken.
Attention!
Without warning triangle means that material damage may occur when
therelevant precautionary measures are nottaken.
Notice!
Means that an undesirable effect or situation may occur if the respective
advise is ignored.
The warning advise for the highest level is used if various danger levels
occur. When awarning advisewitha warningtrianglewarnsaboutperso-
naldamagethenanadditionalwarningformaterialdamagecanbeadded.
Qualifiedpersonnel Thedescribedappliancemayonlybeinstalledand operated inaccordance
withthisdocumentation.Onlyqualified personnel may putitintooperation
and operate this appliance. Qualified personnel are persons, who in
accordance with the safety regulations contained in this documentation,
areauthorised to put intooperation,earthandstamp appliances,systems
and circuits.
Intendeduse Theappliancecan only be usedforthedesignatedpurposes as described
in the catalogue and the technical write up and only in conjunction with
externaldevises i.e. componentsrecommended andauthorised by Elek-
tronik-SystemeLAUERGmbH & Co.KG.Theefficient and safeoperation
of the appliance presupposes appropriate transport, storage, assembly
andinstallation aswell as accurate handling and maintenance.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
Usertips 3
Contents 5
Preamble 6
Certificates and guide lines 7
1 Preparation 9
1.1 Listofsupplied equipment.................................................... 9
1.1.1 Organisationdriver-CD ............................................. 10
1.2 Preparingtheinstallation of the appliance .......................... 10
2 Description 11
2.1 Installation ......................................................................... 11
2.2 Display............................................................................... 13
2.3 Ports .................................................................................. 14
2.4 Motherboard–slots, memorymodule ................................ 15
3 Putting in to operation 17
3.1 Powersupply...................................................................... 17
3.1.1 How to handle ATX-powerpacks .............................. 17
3.2 Earthing system................................................................. 19
3.3 Assembly........................................................................... 19
3.4 Operatingsystem............................................................... 20
3.5 BIOS-settings .................................................................... 21
3.6 Importantitems regardingsoftware installation .................. 23
3.7 Touch installation 6.10Windows2000 / XP (only if required)24
3.8 Graphicboardinstallation ................................................... 28
3.9 InstallationLAN-/networkcard............................................ 29
4 Service 31
4.1 Changingthe fan ................................................................ 32
4.2 PCI-boardinstallation ......................................................... 34
4.3 Memoryexpansion,-change .............................................. 38
5 Technical data 41
5.1 Detaileddrawings ............................................................... 43
5.1.1 EPC PM 1700 Nautic ............................................... 43
5.1.2 EPC PM 1900 Nautic ............................................... 47
5.1.3 EPCPM2100 Nautic ................................................ 51
5.1.4 MT 217 Nautic ......................................................... 55
5.1.5 MT 219 Nautic ......................................................... 59
5.1.6 MT 221 Nautic ......................................................... 63
5.1.7 EPC PM Box Nautic ................................................ 67
Contents

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
6
Preamble
Elektronik-Systeme LAUER GmbH & Co.KG
Kelterstraße 59
D-72669Unterensingen
Tel. [phone] / 9660-0
Fax [phone]
http://www.lauer-systeme.net
our philosophy Elektronik-SystemeLAUERisareliableinternationallyorientatedpartner.
From the text display LCA, the high-tech operating console PCS, to the
industrial computer we supply a complete range to:
• operate,observea nd control
Systeme LAUER stands for an almost unlimited product range and
competentservice,underthe umbrellaof AUGUSTATechnologie AG–a
globalgroup of companies.
Through active co-operation with our customers, persuasive concepts
are developed harmonising efficiently man, and interface. Proximity to
customers – the direct dialog – is the basis of our success.
Support contact Telephone: [phone]
eMail: [e-mail]
forsupportinquiriesalwayshavetheserialnumberofyour appliance
athand!
Upto datedriver units, software, driver units, manuals ...and innovations
canbe foundin ourdownload-forum:
http://forum.systeme-lauer.de/
Sales contact Telephone: [phone] / 9660 -0
eMail: [e-mail]
additionally on offer ... ... courses andtechnical trainingin our modernequipped trainingcentre
or alternatively at your place of business. Please ask your distribution
agent for the latest training course schedule.
...not onlydemo-appliances butalso specialistswho willpersonally ass-
ist you when you first take your appliance into operation..

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
Certificates and guide lines
The following applies for the products described in this documentation:
EMV-directives Alternating - AC supply
The appliances running on AC supply comply with the EC-directive „89/
336/EEC electromagnetic compatibility“ and are according to the CE-
markingdesigned for followingapplications:
Application Standard
Emittedinterference interference resistant
industrial EN61000-6-4: 2001 EN 61000-6-2: 2001
Directcurrent –DC supply
The appliances running on DC supply comply with the EC-directive „89/
336/EEC electromagnetic compatibility“ and are according to the CE-
markingdesigned for followingapplications:
Application Standard
Emittedinterference interference resistant
industrial EN61000-6-4: 2001 EN 61000-6-2: 2001
lowvoltage directive 230V The appliances running on AC supply comply with the EC-directive 73/
23/EEC,low voltage directive. Compliance with this standard was tested
inaccordance withEN 60950.
Declarationof conformity The EC-declaration of conformityandthe associated documentationand
are kept at the disposal of the responsible authorities.Your distribution
agentcan make these available on demand.
Assembly directives Please note the assembly directives and safety instructions mentioned
inthis documentation, when putting intooperation andduring operation.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
8
Certificates and guide lines
The following certifications apply from summer 2005 for the products
describedin thisdocumentation:
• GermanischerLloyd(GL)
• LloydsRegisters (LR)
• Bureauveritas (BV)
• Detnorske veritas(DNV)
• AmericanBureau of Shipping (ABS)
Theseproductsarealsotestedinaccordance with EN 60945for„Bridges“!

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
1 Preparation
1.1 List of supplied equipment
The transport cardboard box contains the following parts and materials:
CD with operating system.
Driver software CD for all pre-installed components like mother board,
touch, key board etc. Further information will be found in chapter
„installation“.
Usermanual
Notice!Separatedocumentationofthird partycomponentsis included on
the enclosed CD.This manual only describes specific information about
LAUER products – not about third party components.
The LAUER appliance pass is supplied with every appliance.It contains
important information for the user.Ready to hand are important address
data,serial number,thenthere are thecomponents andtype designation
correspondingwith the companyinternal appliance designation.
Also shown are all components contained in the system – therefore the
CPUand hard disktype or the operation systemare easily identifiablefor
theuser.
Youradvantages:
• all important contact data for a fast and uncomplicated handling for
desiredimprovements, general queries or for service purposes.
• complete configuration of your system including serial number.
Fixing kit
8Stainlesssteelscrewswithwashers/nutsandO-ringsealsarecontained
inthe parcelof eachEPC PM 1700,1900, 2100 Nautic,MT 217, 219and
MT 221 Nautic.
Documents

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
10
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Cable set, consisting of VGA- and USB-cable (Length 3m)
Only supplied with MT 217 or MT 219 (optional) .
1standard power cable/cooling device cable
(EuropeanorUS standard)-Length approx.3m
Only supplied with MT 217 or MT 219 .
Tip!Power-cable is NOT contained with the DC-version.
1.1.1Organisation driver-CD
Onthe supplied driverCD you willfind the availabledrivers necessaryfor
yourinstallation.
• AUDIO (OnboardSound)
• CHIPSET
• Graphic (Graphic cards driver for a resolution up to
1600 x 1200 for a 21" Display)
• LAN (Onboardnetwork)
1.2 Preparing the installation of the appliance
Openthe package andcheck, whether thecontents matchthe list above.
The cardboard box should be kept for an eventual future safe transport.
After removing the appliance from the parcel, lay the parts on a suitable
clean and open surface (for example a table. Workbench etc.). Follow
exactly the instructions described in the following chapters.
1 Preparation

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
2 Description
2.1 Installation
Compactsolution The installation of the EPC PM Nautic is independent of the displaysize,
shown as follows:
1 front unit
2 PC-unit
1
2

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
12
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Monitorsolution Theinstallation of theMonitors is independent of thedisplay size, shown
as follows:
1 front unit
2 PC-unit
1
2
2 Description

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
2.2 Display
Display sizes of 17" and 19" are available.
FrontwithUSB-port, ON/OFF-switchesanddimmerswitchestoregulate
thebrightness.
2 Description

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
14
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
2.3 Ports
PC-Module
2 Description

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
2.4 Motherboard – slots, memory module
Thepanel-PCandthePC-modulehave2DIMMslotsforthemainstorage,
2 PCI-slots.
Further details on the motherboard can be found in the manual with the
suppliedmaterials.
Notice!
Individual slots may be part of the supply depending on configuration
andcustomer requirements!
The quality of the memory module may influence the system stability.
Please only use memory modules cleared by Systeme LAUER.
Memory modules are electrostatic sensitive components. Relevant
protective measures (earth) have to be considered during assembly/
disassembly.
ESD-protective measures to be considered when opening and working
onthe appliance.
2 Description

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
16
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
2 Description

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
3 Putting in to operation
3.1 Power supply
The Panel-PC,TFT Display and the PC-Box are available as DC-24V- or
AC-115/230V-powersystem.
Power supply system The Panel-PC and PC-Box can be operated with extra-low- voltage in
accordancewith EN60950!
The controlling transformer has to comply with EN60742!
Checkthe power supply system with the relevant data on the type plate.
All cable connections have to be checked prior to putting the system in
tooperation.
It has to be ensured that all voltages and signals comply with the rele-
vant specifications.
1fuse 6,3 A
2powersupply 24V
3earth screw
4ATX switch
5Powerremoteterminal
6powersupply 230V
Thepowersupply24Vis carried out viaadouble-poleconnector(Phoenix
MST BT 2,5/2).
3.1.1How to handle ATX-power packs
Powerpacks,mainboardsand operationsystems are used in the Panel-
PC and the PC-Box, using up to date PC-technologies like „ATX“ and
„ACPI“. Switching on the appliances is done in accordance with ATX-
specification via the ATX-Power-switch (red button underneath the
appliance).
Should a correct automatic booting not function then this can have the
followingreasons.
Inthe BIOS the option ACPWR Loss Restarti.e.PWRONAfterPWRFail
must be set to Enable i.e. On .
The operating system must be ended correctly via the button abandon –
shut down, so that the operating system of the VPC is shut down.The
computer must not be switched while with the operating system is still
running!
6
3
4 5
1
2
3
4 5

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
18
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
The power pack now has to be separated for at least 15 seconds from
thepowersupply, priortoa re-start.Duringthebooting process themains
voltage may not fall (not even for a short time) below the permissible
value.
A manual actuation of the ATX-Power-switch becomes necessary i.e.
the BIOS-menu starts automatically to check and confirm correctness
of settings, if the system registers an error during shut down or booting.
This is not a malfunction but a safety feature!!
Supplybuild up
Powersupply Monitor
1 Supplyconnection 24VDC
2 Earthscrew
3 VGA-connection
4 2x USB, Power Remote
connection
1 Supply connection 115/230VAC
2 Earth screw
3 VGA-connection
4 2x USB, Power Remote
connection
3 Putting in to operation
2
134
2
134
VAC
+ 24 V
VAC
0V
24V DC

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
3.2 Earthing system
The following items have to be observed to guarantee a safe dissipation
ofelectronic interference:
• Appliance and switch board have to be connected to the nearest
possiblecentralearthing point.
• makesureof a possiblylow inductive connectionbetween appliance
andswitch board.
• All data cables connected to the appliance have to be the screened
type.
• The screens have to be earthed on both sides.There has to exist a
lowohmconnectionbetweentheconnectedsystems.Highequalising
currents through the cable screen due to voltage fluctuations are to
beavoided.
• The earthing connection is to be carried out with min. 4 mm² cross
section.
3.3 Assembly
Assembly To dissipate the heat generated in the appliance a free space for air
circulation, of 100 mm has to be provided around the appliance!
The installation is done by means of screws.
Notice!
Possibility of damage to the appliance!
Protection class IP65 to the front panel is only guaranteed with a perfect
fitting seal.
Pay attention to the torque when fixing the front panel!
3 Putting in to operation

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
20
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
3.4 Operating system
Supply incl. operating system hard disk version:
We offer our appliances with installed operating system software. In this
case we opt for following installation concept.The respective operating
system and other programmes are installed on C: drive. D: drive is a
completefreepartitionandcanforexamplebeusedforyourdata(beneficial
for example for data back up). On E: drive are all the data required for a
newinstallation (driversandoperationsystem).Thispartition alwaysuses
a FAT 16-data system.
At present the following operating systems are available:
Windows2000 German,English andmulti-language pack
(C: and D: NTFS)
WindowsXP professional German and English
(C: and D: NTFS)
depending on the configuration, the respective user interface of the
installed operating system appears, once the EPC has booted from the
hard disk.
3 Putting in to operation
