LC-POWER LCCD-A1 User manual

USER MANUAL
LCCD-A1
Solar Controller+LED Driver+Built-in Timer
20120314 VERSION 1

Page 2/8
Please read the instructions carefully and thoroughly before using the product. It comes with a number of outstanding
features, such as:
 Build-in LED driver, maximum output voltage up to 70V, maximum efficiency up to 96%.
 Automatic recognition of system voltage 12/24 V
 Protection degree:IP68 -- in1.5m water depth 72hours
 External high precision temperature sensor, high precision temperature compensation.
 Advanced four stage charging (main, boost, equalization, float) effectively prolong the battery life.
 4 stages PWM dimming function.
 Professional LED driver chip, with little current ripple, which extends the LED span life.
 Built-in intelligent learning function easily realizing automatically lights on in the morning.
 With electricity protection data-saving function.
 Complete protections on reverse polarity (battery or solar panel), over-charge, over-discharge, over load, short circuit,
TVS lightening;
 Imported good-quality components contributing to high reliability;
Installation
Attentions
 The solar panel voltage may exceed human body safety voltage when wiring 24V system. So it is better to shade the
solar panel and use insulating tools;
 Output voltage of load may exceed human body safe voltage; please connect LED before load open during
installation.
 Battery may permanent damage if short circuit, one fuse recommended between battery and controller;
 Good ventilation area recommended for heat dissipation;
 Make sure the wire length between battery and controller is as short as possible

Page 3/8
12V system 24V system
LED driver output voltage range 16V~70V 32V~70V
Recommended series LED lamp qty. 5~20PCS 10~20PCS
LED load max. power 30W 60W
 Recommended minimum wire size: 2.5mm²;
 Controller be with Reverse Current Protection by MOSFET which inspects the current direction regularly;
Installation steps & connection diagram
 Firstly connect load with controller and then wire battery and solar panel to controller respectively; please pay
attention to the distinction of negative and positive; After connecting the battery, controller will automatically
recognize system voltage and display on the nixie tube. (“12” stands for 12V system, “24” stands for 24V system.)
Accepted LED load
User should make sure the LED load can meet following standards

Page 4/8
Symbol Equipment Status Description
on battery working
off no battery connected
slow flash low voltage
quick flash over voltage
on daytime
off nighttime
slow flash charging
quick flash over tempreture, stop charging
off load off
on load work with 100% power
flash for 3 times load work with 75% power
flash for 2 times load work with 50% power
flash 1 time load work with 25% power
battery
solar panel
load
LED display
Remark: Slow flash frequency is about 2 times/s, quick flash frequency is about 2 times/s.
Output mode
The controller can automatically detect day/night through testing the open circuit voltage of the solar panel, no
setting of a clock is required. It gets the dawn light start time through learning to daytime and nighttime in different
area or season.
There are 4 output modes available:
 Light control “on” and time control “off” (1-4.): Load starts working when controller detects night and stop
working as set time (the load stops working if controller detects “daytime” no matter the set time is achieved or
not);

Page 5/8
 Morning Mode (4~5): The load would be turned on automatically in the morning, the output power is
adjustable.
 Manual mode (6): can switch output performance manually no matter daytime or night; the power is adjustable.
 Debug mode ( ): used for debugging and installation;
Remark: if the battery is over charge or discharge, the controller will cut off the load not matter under which
mode.
Imag e on tens dig it Model Imag e on un it dig it P arameter
L oad work with 100% power ~ Work period (0~14hours)
L oad work with 75% power ~ Work period (0~14hours)
L oad work with 50% power ~ Work period (0~14hours)
T he fourth period of time ~ Work period (0~14hours)
1 dawn light power 25%
2 dawn light power 50%
3 dawn light power 75%
4 dawn light power 100%
0 load off
1 load work with 25% power
2 load work with 50% power
3 load work with 75% power
4 load work with 100% power
Demo model
~
~Manual mode
Morning mode
Remark: the dot behind units digit on nixie tube stands for 10; (eg. 3. Stands for 13)

Page 6/8
Keys and settings
Skip Press: press the button within 2 seconds
Confirm Press: press the button within 2 to 4 seconds.
Configure Press: press the button over 4 seconds
Browse Mode: nixie tube tens digit is “on” (except ).
Setting mode: nixie tube unit digit is twinkling.
Configure mode: nixie tube tens digit is showing symbol “ ”
1. Under browse mode, user can “Skip Press” to view status of each output mode. When it goes to the expected output
mode(1-5), “Confirm Press” to enter setting mode, nixie tube unit digit would flash; “skip press” to chose the expected
output mode parameter; “confirm press” to confirm and exit the setting mode.
2. Under browse mode and nixie tube tens digit showing “6”, “confirm press” to enter manual output mode, nixie tube
unit digit would flash, “skip press” to chose the expected output power. When you want to exit the manual mode,
“confirm press” to enter browse mode.
3. Under browse mode and nixie tube tens digit showing (1-5), “configure press” to enter configure mode,. When you
want to exit the configure mode, “configure press” or wait for 3 minutes to enter browse mode.

Page 7/8
System voltage 12/24 V auto recognition
Max. charge/load current 10A
Output current 300mA~3300mA
Float Charge 13.8V/27.6V(25℃)
Mai n Charge 14.4/28.8 V (25 °C), 30 min. (daily)
Boost charge 14.4/28.8 V (25℃ ), 2 hAcvaon: baery voltage < 12V/24V
Equlization charge 14.8/29.6V
Deep discharge protecon:Cut-off voltage 11V/22V
Deep discharge protecon:Reconnect voltage 12V/24V
Overvoltage protection 16V/32V
Max. panel voltage 55V
Temperature compensation -4mV/℃·2V
Self cons umption 5 ~ 10mA
Day/night detect voltage Day:>9V; night: <7V
Day/night detect delay 3min
Working temperature -40~+50℃
Maximum above sea level 4000m
Size 82x59x20mm
Weight 160g
Protection degree IP68(1.5m, 72h)
Technical data
Remark:
1. The two voltage levels before/after the slash are valid for 12V and 24V systems respectively.
2. only solar panel or load can full load running if environment temperature is over 55 ℃

Page 8/8
Phenomenon Problem Solution
Battery indicator off Battery working problem Make sure the wiring between controller and
battery is correct.
Battery indicator slowly flash,
without output
Battery under over discharge protection Charge to recover voltage
Battery indicator quick flash,
without output Battery under overvoltage protection Cut off output for protecting load, auto working after recovering voltage
Solar indicator “off” in daytime Solar panel wiring problem Make sure the wiring between controller and
solar panel is correct.
Solar indicator “on” in
nighttime, without load output System cannot detect night
System detects “night” when solar voltage drops
less than 7V; Solar indi cator be “off” and with
load output; make sure solar panel not shone
by light if no output 3 min. later.
Solar indicator quick flash No charging
Over temperature, solar charging “off” system
auto recovered when temperature return to
normality.
Others - Check the wiring
Common problems & Solutions
SUBJECT TO CHANGE WITHOUT NOTICE
VERSION 20130301
MADE IN CHINA
