LDA Audio Tech SiMax EP Series User manual

EQUIPMENT OF THE EP SERIES
Support Handbook
LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. 1
Tlf: [phone]. www.lda-audiotech.com
Button of balanced/unbalanced.
When pressing the button balanced/unbalanced, the attenuation of the signal will be lower, so the
power will suffer a great loss. For correct exit of signal, the button should be without pressing.
Standby mode.
The Standby mode in the high power stages (EP1000 / EP1500) if there is no input signal in the
equipment, it goes into energy saving mode. When the stage detects a input signal, it is activated
again.
When it doesn´t detect a signal in one minute, the light "Power"(1) will turn off. When there is
input signal again, then the light "Power" (1) turns on and the light "prot"(2) will also light up for a
second. Once the light "prot"(2) is off, the sound will start to come out.
1 2

EQUIPMENT OF THE EP SERIES
Support Handbook
LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. 2
Tlf: [phone]. www.lda-audiotech.com
Power on equipment.
When you power on the equipment you must activate the back button and after the button
frontal power.
Mode button.
Each pulse of MODE button changes the mode from Stand Alone to Master to Slave, indicated by
frontal leds. The connection between Master and Slave is made from the Link connector. If you are
in Master mode, controlling the volume of it will control the volume of those equipments that are
connected by the Link and are in Slave mode. The equipment that is in Slave mode can´t be
controlled with its own keypad.
(Link)

EQUIPMENT OF THE EP SERIES
Support Handbook
LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. 3
Tlf: [phone]. www.lda-audiotech.com
Connector Control/ Power Active.
This connector is intended for turning on and communications by RS485 protocol between MX218
/ CP2000 equipment and the connected stages.
Please contact with LDA Support Department for any information
[e-mail]
