Ledj Rubix RGB 3D Panel User manual

Order code: LEDJ476
Rubix RGB 3D Panel
User Manual

www.prolight.co.uk Rubix RGB 3D Panel User Manual 2
Safety advice
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL
CAREFULLY BEFORE YOUR INITIAL START-UP!
• Beforeyourinitialstart-up,pleasemakesurethatthereisnodamagecausedduringtransportation.
• Shouldtherebeanydamage,consultyourdealeranddonotusetheequipment.
• Tomaintaintheequipmentingoodworkingconditionandtoensuresafeoperation,itisnecessary
fortheusertofollowthesafetyinstructionsandwarningnoteswritteninthismanual.
• Pleasenotethatdamagescausedbyusermodicationstothisequipmentarenotsubjecttowarranty.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance
of this manual or any unauthorised modication to the equipment.
OPERATING DETERMINATIONS
Ifthisequipmentisoperatedinanyotherway,thanthosedescribedinthismanual,theproductmaysufferdamageand
thewarrantybecomesvoid.Incorrectoperationmayleadtodangere.g:short-circuit,burnsandelectricshocksetc.
Donotendangeryourownsafetyandthesafetyofothers!
Incorrectinstallationorusecancauseseriousdamagetopeopleand/orproperty.
CAUTION!
KEEP THIS EQUIPMENT
AWAY FROM RAIN,
MOISTURE AND LIQUIDS
CAUTION!
TAKE CARE USING
THIS EQUIPMENT!
HIGH VOLTAGE-RISK
OF ELECTRIC SHOCK!!
• Neverletthepowercablecomeintocontactwithother
cables.Handlethepowercableandallmainsvoltage
connectionswithparticularcaution!
• Neverremovewarningorinformativelabelsfromtheunit.
• Donotopentheequipmentanddonotmodifytheunit.
• Donotconnectthisequipmenttoadimmerpack.
• Donotswitchtheequipmentonandoffinshortintervals,
asthiswillreducethesystem’slife.
• Onlyusetheequipmentindoors.
• Donotexposetoammablesources,liquidsorgases.
• Alwaysdisconnectthepowerfromthemainswhen
equipmentisnotinuseorbeforecleaning!Onlyhandle
thepower-cablebytheplug.Neverpullouttheplugby
pullingthepower-cable.
• Makesurethattheavailablemainssupplyvoltageis
between100~240VAC,50/60Hz.
• Makesurethatthepowercableisnevercrimpedor
damaged.Checktheequipmentandthepowercable
periodically.
• Iftheequipmentisdroppedordamaged,disconnectthe
mainspowersupplyimmediatelyandhaveaqualied
engineerinspecttheequipmentbeforeoperatingagain.

• Iftheequipmenthasbeenexposedtodrastic
temperatureuctuation(e.g.aftertransportation),
donotconnectpowerorswitchitonimmediately.
Thearisingcondensationmightdamagetheequipment.
Leavetheequipmentswitchedoffuntilithasreached
roomtemperature.
• Ifyourproductfailstofunctioncorrectly,stopuse
immediately.Packtheunitsecurely(preferablyinthe
originalpackingmaterial),andreturnittoyourProLight
dealerforservice.
• Onlyusefusesofsametypeandrating.
• Repairs,servicingandpowerconnectionmustonlybe
carriedoutbyaqualiedtechnician.THISUNITCONTAINS
NOUSERSERVICEABLEPARTS.
• Thislightingxtureisforprofessionaluseonly-itis
notdesignedfororsuitableforhouseholduse.The
productmustbeinstalledbyaqualiedtechnicianin
accordancewithlocalterritoryregulations.Thesafetyof
theinstallationistheresponsibilityoftheinstaller.The
xturepresentsrisksofsevereinjuryordeathduetore
hazards,electricshockandfalls.
• Warning!RiskGroup2LEDproductaccordingto
EN62471.Donotviewthelightoutputwithoptical
instrumentsoranydevicethatmayconcentratethebeam.
• WARRANTY:Oneyearfromdateofpurchase.

www.prolight.co.uk Rubix RGB 3D Panel User Manual 3
Product overview & technical specications
UtilisingRGBSMD5050LEDscombinedwithretrostylingtheRubixoffersafreshapproachtoon-stage‘eye
candy’effects.Twentysevenpixels,arrangedinahexagonalchassisgenerateafullcolour,3Deffectasthe
coloursbringtheatpaneltolife.
Thechoiceofcontroloptionsincludesoundactive,master/slave,andauto,accessingalargenumberofbuiltin
macrosmakingtheseidealfornightclubs,entertainersoronstage.TheRubixalsofeaturesfullpixelmapping
capabilityforintegrationintolargersystems.
Rubix RGB 3D Panel
434mm 116mm
500mm
•108tri-colourSMD5050LEDs(RGB)
•Viewingangle:180°
•Pixels:27
•DMXchannels:9/14/17/81/83or98selectable
•Auto,soundactiveandmaster/slavemodes
•0-100%dimmingandvariablestrobe
•Suppliedwithquickreleaseomegaclamps
•4pushbuttonmenuwithLEDdisplay
•PowerCONinput/output
•3-PinXLRinput/output
•Convectioncooled
Specications Rubix RGB 3D Panel
Powerconsumption 35W
Powersupply 100~240V,50/60Hz
Fuse T1A250V
Dimensions 500x434x116mm
Weight 5.2kg
Ordercode LEDJ476

www.prolight.co.uk Rubix RGB 3D Panel User Manual 4
Technical specications
01-LEDdisplay
02-Functionbuttons
03-3-PinDMXinput
04-3-PinDMXoutput
05-PowerCONinput
06-PowerCONoutput
07-FuseT1A250V
08-Safetyeye
09-Omegaclampmounts
Inthebox:1 x xture, 1 x omega clamp,
2 x triangular connection omega clamp,
1 x connection omega clamp,
1 x PowerCON cable & 1 x user manual
www.prolight.co.uk
Rubix RGB 3D Panel
POWER INPUT:
100-240V~50/60Hz
POWER OUTPUT:
100-240V~50/60Hz
FUSE:
T1A 250V
POWER CONSUMPTION: 35W (max.)
DMX INPUT DMX OUTPUT
MENU ENTER UP DOWN
www.prolight.co.uk
Rubix RGB 3D Panel
POWER INPUT:
100-240V~50/60Hz
POWER OUTPUT:
100-240V~50/60Hz
FUSE:
T1A 250V
POWER CONSUMPTION: 35W (max.)
DMX INPUT DMX OUTPUT
MENU ENTER UP DOWN
01
02
08
09
05 06 07 03 04
www.prolight.co.uk
Rubix RGB 3D Panel
POWER INPUT:
100-240V~50/60Hz
POWER OUTPUT:
100-240V~50/60Hz
FUSE:
T1A 250V
POWER CONSUMPTION: 35W (max.)
DMX INPUT DMX OUTPUT
MENU ENTER UP DOWN
09

www.prolight.co.uk Rubix RGB 3D Panel User Manual 5
Operating instructions
MENU
F L. 0 0
F L. 9 9
C o. 0 1
C o. 5 0
Built-in programs
P r. 0 1
S p. 0 1
S p. F L
P r. 0 2
P r. 2 8
P r o
A U T O
Auto mode
S L A v
Slave mode
C o L r
Colour mix mode
r 1. 0 0
r 2. 0 0
r 3. 0 0
r 1. F L
r 2. F L
r 3. F L
g 1. 0 0
g 2. 0 0
g 3. 0 0
b 1. 0 0
b 2. 0 0
b 3. 0 0
g 1. F L
g 2. F L
g 3. F L
b 1. F L
b 2. F L
b 3. F L
d.001
d.512
d - - -
DMX address/channel settings
9. c h
1 4. c h
1 7. c h
8 3. c h
8 1. c h
9 8. c h

www.prolight.co.uk Rubix RGB 3D Panel User Manual 6
Operating instructions
MENU
uerInFo u - - -
Software version
Set
C u r
S y n c
- r S t
F A I L
C u - 1
C u - 4
Dimming curve selection
- O f f
H o L d
DMX signal failure
- - 0 n
- O f f
DMX sync setting
- - N O
- y E s
Reset factory settings
S U. 0 0
S U. 3 1
S o u d
Sound sensitivity

www.prolight.co.uk Rubix RGB 3D Panel User Manual 7
DMX mode:
OperatinginaDMXcontrolmodeenvironmentgivestheuserthegreatestexibilitywhenitcomes
tocustomisingorcreatingashow.Inthismodeyouwillbeabletocontroleachindividualtraitof
thextureandeachxtureindependently.
ToaccesstheDMXaddressmode,pressthe“MENU”buttonandusethe“UP”and“DOWN”buttons
ontherearoftheunittoshowd001ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe
“UP”and“DOWN”buttonstosettherequiredDMXaddress.Pressthe“ENTER”buttontoconrmthe
setting. TheDMXchannelmodewillnowbedisplayed,usethe“UP”and“DOWN”buttonsontherearof
theunittoshowselectoneofthe9/14/17/81/83or98DMXchannelmodes.Pressthe“ENTER”
buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Operating instructions
Channel Value Function
1 000-255 Redsegment1dimmer(0-100%)
2000-255 Greensegment1dimmer(0-100%)
3000-255 Bluesegment1dimmer(0-100%)
4 000-255 Redsegment2dimmer(0-100%)
5 000-255 Greensegment2dimmer(0-100%)
6 000-255 Bluesegment2dimmer(0-100%)
7 000-255 Redsegment3dimmer(0-100%)
8 000-255 Greensegment3dimmer(0-100%)
9 000-255 Bluesegment3dimmer(0-100%)
9 channel mode:
Channel Value Function
1 000-255 Masterdimmer(0-100%)
2000-255 Reddimmer(0-100%)
3000-255 Greendimmer(0-100%)
4 000-255 Bluedimmer(0-100%)
5 000-255 Redsegment1dimmer(0-100%)
6 000-255 Greensegment1dimmer(0-100%)
7 000-255 Bluesegment1dimmer(0-100%)
8 000-255 Redsegment2dimmer(0-100%)
9 000-255 Greensegment2dimmer(0-100%)
10 000-255 Bluesegment2dimmer(0-100%)
11 000-255 Redsegment3dimmer(0-100%)
12 000-255 Greensegment3dimmer(0-100%)
13 000-255 Bluesegment3dimmer(0-100%)
14 000-010 Nofunction
011-255 Strobe(slow-fast)
14 channel mode:
Channel Value Function
1 000-255 Masterdimmer(0-100%)
2000-255 Reddimmer(0-100%)
3000-255 Greendimmer(0-100%)
4 000-255 Bluedimmer(0-100%)
5 000-255 Redsegment1dimmer(0-100%)
6 000-255 Greensegment1dimmer(0-100%)
7 000-255 Bluesegment1dimmer(0-100%)
8 000-255 Redsegment2dimmer(0-100%)
9 000-255 Greensegment2dimmer(0-100%)
10 000-255 Bluesegment2dimmer(0-100%)
11 000-255 Redsegment3dimmer(0-100%)
12 000-255 Greensegment3dimmer(0-100%)
13 000-255 Bluesegment3dimmer(0-100%)
14 000-255 Staticpatterns(seechartpage11)
15 000-255 Programs(seechartpage11)
16 000-255 Speed/soundsens(slow-fast/low-high)
17 000-010 Nofunction
011-255 Strobe(slow-fast)
17 channel mode:

www.prolight.co.uk Rubix RGB 3D Panel User Manual 8
Operating instructions
Value CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9 CH10
000-255
Pixel1
Red
(0-100%)
Pixel1
Green
(0-100%)
Pixel1
Blue
(0-100%)
Pixel2
Red
(0-100%)
Pixel2
Green
(0-100%)
Pixel2
Blue
(0-100%)
Pixel3
Red
(0-100%)
Pixel3
Green
(0-100%)
Pixel3
Blue
(0-100%)
Pixel4
Red
(0-100%)
Value CH61 CH62 CH63 CH64 CH65 CH66 CH67 CH68 CH69 CH70
000-255
Pixel21
Red
(0-100%)
Pixel21
Green
(0-100%)
Pixel21
Blue
(0-100%)
Pixel22
Red
(0-100%)
Pixel22
Green
(0-100%)
Pixel22
Blue
(0-100%)
Pixel23
Red
(0-100%)
Pixel23
Green
(0-100%)
Pixel23
Blue
(0-100%)
Pixel24
Red
(0-100%)
Value CH31 CH32 CH33 CH34 CH35 CH36 CH37 CH38 CH39 CH40
000-255
Pixel11
Red
(0-100%)
Pixel11
Green
(0-100%)
Pixel11
Blue
(0-100%)
Pixel12
Red
(0-100%)
Pixel12
Green
(0-100%)
Pixel12
Blue
(0-100%)
Pixel13
Red
(0-100%)
Pixel13
Green
(0-100%)
Pixel13
Blue
(0-100%)
Pixel14
Red
(0-100%)
Value CH11 CH12 CH13 CH14 CH15 CH16 CH17 CH18 CH19 CH20
000-255
Pixel4
Green
(0-100%)
Pixel4
Blue
(0-100%)
Pixel5
Red
(0-100%)
Pixel5
Green
(0-100%)
Pixel5
Blue
(0-100%)
Pixel6
Red
(0-100%)
Pixel6
Green
(0-100%)
Pixel6
Blue
(0-100%)
Pixel7
Red
(0-100%)
Pixel7
Green
(0-100%)
Value CH71 CH72 CH73 CH74 CH75 CH76 CH77 CH78 CH79 CH80
000-255
Pixel24
Green
(0-100%)
Pixel24
Blue
(0-100%)
Pixel25
Red
(0-100%)
Pixel25
Green
(0-100%)
Pixel25
Blue
(0-100%)
Pixel26
Red
(0-100%)
Pixel26
Green
(0-100%)
Pixel26
Blue
(0-100%)
Pixel27
Red
(0-100%)
Pixel27
Green
(0-100%)
Value CH41 CH42 CH43 CH44 CH45 CH46 CH47 CH48 CH49 CH50
000-255
Pixel14
Green
(0-100%)
Pixel14
Blue
(0-100%)
Pixel15
Red
(0-100%)
Pixel15
Green
(0-100%)
Pixel15
Blue
(0-100%)
Pixel16
Red
(0-100%)
Pixel16
Green
(0-100%)
Pixel16
Blue
(0-100%)
Pixel17
Red
(0-100%)
Pixel17
Green
(0-100%)
Value CH21 CH22 CH23 CH24 CH25 CH26 CH27 CH28 CH29 CH30
000-255
Pixel7
Blue
(0-100%)
Pixel8
Red
(0-100%)
Pixel8
Green
(0-100%)
Pixel8
Blue
(0-100%)
Pixel9
Red
(0-100%)
Pixel9
Green
(0-100%)
Pixel9
Blue
(0-100%)
Pixel10
Red
(0-100%)
Pixel10
Green
(0-100%)
Pixel10
Blue
(0-100%)
Value CH81
000-255
Pixel27
Blue
(0-100%)
Value CH51 CH52 CH53 CH54 CH55 CH56 CH57 CH58 CH59 CH60
000-255
Pixel17
Blue
(0-100%)
Pixel18
Red
(0-100%)
Pixel18
Green
(0-100%)
Pixel18
Blue
(0-100%)
Pixel19
Red
(0-100%)
Pixel19
Green
(0-100%)
Pixel19
Blue
(0-100%)
Pixel20
Red
(0-100%)
Pixel20
Green
(0-100%)
Pixel20
Blue
(0-100%)
81 channel mode:

www.prolight.co.uk Rubix RGB 3D Panel User Manual 9
Operating instructions
Value CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9 CH10
000-255
Master
dimmer
(0-100%)
Pixel1
Red
(0-100%)
Pixel1
Green
(0-100%)
Pixel1
Blue
(0-100%)
Pixel2
Red
(0-100%)
Pixel2
Green
(0-100%)
Pixel2
Blue
(0-100%)
Pixel3
Red
(0-100%)
Pixel3
Green
(0-100%)
Pixel3
Blue
(0-100%)
Value CH61 CH62 CH63 CH64 CH65 CH66 CH67 CH68 CH69 CH70
000-255
Pixel20
Blue
(0-100%)
Pixel21
Red
(0-100%)
Pixel21
Green
(0-100%)
Pixel21
Blue
(0-100%)
Pixel22
Red
(0-100%)
Pixel22
Green
(0-100%)
Pixel22
Blue
(0-100%)
Pixel23
Red
(0-100%)
Pixel23
Green
(0-100%)
Pixel23
Blue
(0-100%)
Value CH31 CH32 CH33 CH34 CH35 CH36 CH37 CH38 CH39 CH40
000-255
Pixel10
Blue
(0-100%)
Pixel11
Red
(0-100%)
Pixel11
Green
(0-100%)
Pixel11
Blue
(0-100%)
Pixel12
Red
(0-100%)
Pixel12
Green
(0-100%)
Pixel12
Blue
(0-100%)
Pixel13
Red
(0-100%)
Pixel13
Green
(0-100%)
Pixel13
Blue
(0-100%)
Value CH11 CH12 CH13 CH14 CH15 CH16 CH17 CH18 CH19 CH20
000-255
Pixel4
Red
(0-100%)
Pixel4
Green
(0-100%)
Pixel4
Blue
(0-100%)
Pixel5
Red
(0-100%)
Pixel5
Green
(0-100%)
Pixel5
Blue
(0-100%)
Pixel6
Red
(0-100%)
Pixel6
Green
(0-100%)
Pixel6
Blue
(0-100%)
Pixel7
Red
(0-100%)
Value CH71 CH72 CH73 CH74 CH75 CH76 CH77 CH78 CH79 CH80
000-255
Pixel24
Red
(0-100%)
Pixel24
Green
(0-100%)
Pixel24
Blue
(0-100%)
Pixel25
Red
(0-100%)
Pixel25
Green
(0-100%)
Pixel25
Blue
(0-100%)
Pixel26
Red
(0-100%)
Pixel26
Green
(0-100%)
Pixel26
Blue
(0-100%)
Pixel27
Red
(0-100%)
Value CH41 CH42 CH43 CH44 CH45 CH46 CH47 CH48 CH49 CH50
000-255
Pixel14
Red
(0-100%)
Pixel14
Green
(0-100%)
Pixel14
Blue
(0-100%)
Pixel15
Red
(0-100%)
Pixel15
Green
(0-100%)
Pixel15
Blue
(0-100%)
Pixel16
Red
(0-100%)
Pixel16
Green
(0-100%)
Pixel16
Blue
(0-100%)
Pixel17
Red
(0-100%)
Value CH21 CH22 CH23 CH24 CH25 CH26 CH27 CH28 CH29 CH30
000-255
Pixel7
Green
(0-100%)
Pixel7
Blue
(0-100%)
Pixel8
Red
(0-100%)
Pixel8
Green
(0-100%)
Pixel8
Blue
(0-100%)
Pixel9
Red
(0-100%)
Pixel9
Green
(0-100%)
Pixel9
Blue
(0-100%)
Pixel10
Red
(0-100%)
Pixel10
Green
(0-100%)
Value CH81 CH82 Value CH83
000-255
Pixel27
Green
(0-100%)
Pixel27
Blue
(0-100%)
000-010 Nofunction
010-255 Strobe(slow-fast)
Value CH51 CH52 CH53 CH54 CH55 CH56 CH57 CH58 CH59 CH60
000-255
Pixel17
Green
(0-100%)
Pixel17
Blue
(0-100%)
Pixel18
Red
(0-100%)
Pixel18
Green
(0-100%)
Pixel18
Blue
(0-100%)
Pixel19
Red
(0-100%)
Pixel19
Green
(0-100%)
Pixel19
Blue
(0-100%)
Pixel20
Red
(0-100%)
Pixel20
Green
(0-100%)
83 channel mode:

www.prolight.co.uk Rubix RGB 3D Panel User Manual 10
Channel Value Function
1 000-255 Masterdimmer(0-100%)
2000-255 Reddimmer(0-100%)
3000-255 Greendimmer(0-100%)
4 000-255 Bluedimmer(0-100%)
5 000-255 Redsegment1dimmer(0-100%)
6 000-255 Greensegment1dimmer(0-100%)
7 000-255 Bluesegment1dimmer(0-100%)
8 000-255 Redsegment2dimmer(0-100%)
9 000-255 Greensegment2dimmer(0-100%)
10 000-255 Bluesegment2dimmer(0-100%)
11 000-255 Redsegment3dimmer(0-100%)
12 000-255 Greensegment3dimmer(0-100%)
13 000-255 Bluesegment3dimmer(0-100%)
14 000-255 Pixel1Red(0-100%)
15 000-255 Pixel1Green(0-100%)
16 000-255 Pixel1Blue(0-100%)
17 000-255 Pixel2Red(0-100%)
18 000-255 Pixel2Green(0-100%)
19 000-255 Pixel2Blue(0-100%)
20 000-255 Pixel3Red(0-100%)
21 000-255 Pixel3Green(0-100%)
22 000-255 Pixel3Blue(0-100%)
23 000-255 Pixel4Red(0-100%)
24 000-255 Pixel4Green(0-100%)
25 000-255 Pixel4Blue(0-100%)
26 000-255 Pixel5Red(0-100%)
27 000-255 Pixel5Green(0-100%)
28 000-255 Pixel5Blue(0-100%)
29 000-255 Pixel6Red(0-100%)
30 000-255 Pixel6Green(0-100%)
31 000-255 Pixel6Blue(0-100%)
32 000-255 Pixel7Red(0-100%)
33 000-255 Pixel7Green(0-100%)
34 000-255 Pixel7Blue(0-100%)
35 000-255 Pixel8Red(0-100%)
36 000-255 Pixel8Green(0-100%)
37 000-255 Pixel8Blue(0-100%)
38 000-255 Pixel9Red(0-100%)
39 000-255 Pixel9Green(0-100%)
40 000-255 Pixel9Blue(0-100%)
98 channel mode:
Channel Value Function
41 000-255 Pixel10Red(0-100%)
42 000-255 Pixel10Green(0-100%)
43 000-255 Pixel10Blue(0-100%)
44 000-255 Pixel11Red(0-100%)
45 000-255 Pixel11Green(0-100%)
46 000-255 Pixel11Blue(0-100%)
47 000-255 Pixel12Red(0-100%)
48 000-255 Pixel12Green(0-100%)
49 000-255 Pixel12Blue(0-100%)
50 000-255 Pixel13Red(0-100%)
51 000-255 Pixel13Green(0-100%)
52 000-255 Pixel13Blue(0-100%)
53 000-255 Pixel14Red(0-100%)
54 000-255 Pixel14Green(0-100%)
55 000-255 Pixel14Blue(0-100%)
56 000-255 Pixel15Red(0-100%)
57 000-255 Pixel15Green(0-100%)
58 000-255 Pixel15Blue(0-100%)
59 000-255 Pixel16Red(0-100%)
60 000-255 Pixel16Green(0-100%)
61 000-255 Pixel16Blue(0-100%)
62 000-255 Pixel17Red(0-100%)
63 000-255 Pixel17Green(0-100%)
64 000-255 Pixel17Blue(0-100%)
65 000-255 Pixel18Red(0-100%)
66 000-255 Pixel18Green(0-100%)
67 000-255 Pixel18Blue(0-100%)
68 000-255 Pixel19Red(0-100%)
69 000-255 Pixel19Green(0-100%)
70 000-255 Pixel19Blue(0-100%)
71 000-255 Pixel20Red(0-100%)
72 000-255 Pixel20Green(0-100%)
73 000-255 Pixel20Blue(0-100%)
74 000-255 Pixel21Red(0-100%)
75 000-255 Pixel21Green(0-100%)
76 000-255 Pixel21Blue(0-100%)
77 000-255 Pixel22Red(0-100%)
78 000-255 Pixel22Green(0-100%)
79 000-255 Pixel22Blue(0-100%)
Operating instructions

www.prolight.co.uk Rubix RGB 3D Panel User Manual 11
Operating instructions
Channel Value Function
80 000-255 Pixel23Red(0-100%)
81 000-255 Pixel23Green(0-100%)
82 000-255 Pixel23Blue(0-100%)
83 000-255 Pixel24Red(0-100%)
84 000-255 Pixel24Green(0-100%)
85 000-255 Pixel24Blue(0-100%)
86 000-255 Pixel25Red(0-100%)
87 000-255 Pixel25Green(0-100%)
88 000-255 Pixel25Blue(0-100%)
89 000-255 Pixel26Red(0-100%)
98 channel mode cont.:
Value Function
000-005 Nofunction
006-010 Staticpattern1
011-015 Staticpattern2
016-020 Staticpattern3
021-025 Staticpattern4
026-030 Staticpattern5
031-035 Staticpattern6
036-040 Staticpattern7
041-045 Staticpattern8
046-050 Staticpattern9
051-055 Staticpattern10
056-060 Staticpattern11
061-065 Staticpattern12
066-070 Staticpattern13
071-075 Staticpattern14
076-080 Staticpattern15
Value Function
000-015 Nofunction
016-023 Program2(Fade1)
024-031 Program3(Fade2)
032-039 Program4(Fade3)
040-047 Program5(Fade4)
048-055 Program6(Change1)
056-063 Program7(Change2)
064-071 Program8(Change3)
072-079 Program9(Change4)
Static patterns
Programs
080-087 Program10(Change5)
088-095 Program11(Change6)
096-103 Program12(Change7)
104-111 Program13(Change8)
112-119 Program14(Change9)
120-127 Program15(Change10)
128-135 Program16(Change11)
136-143 Program17(Change12)
144-151 Program18(Change13)
152-159 Program19(Change14)
160-167 Program20(Change15)
168-175 Program21(Change16)
176-183 Program22(Change17)
184-191 Program23(Change18)
192-199 Program24(Change19)
200-207 Program25(Change20)
208-215 Program26(Change21)
216-223 Program27(Change22)
224-231 Program28(Change23)
232-255 Soundactive
90 000-255 Pixel26Green(0-100%)
91 000-255 Pixel26Blue(0-100%)
92 000-255 Pixel27Red(0-100%)
93 000-255 Pixel27Green(0-100%)
94 000-255 Pixel27Blue(0-100%)
95 000-255 Staticpatterns(seechartbelow)
96 000-255 Programs(seechartbelow)
97 000-255 Speed/soundsens
(slow-fast/low-high)
98 000-010 Nofunction
011-255 Strobe(slow-fast)
081-085 Staticpattern16
086-090 Staticpattern17
091-095 Staticpattern18
096-100 Staticpattern19
101-105 Staticpattern20
106-110 Staticpattern21
111-115 Staticpattern22
116-120 Staticpattern23
121-125 Staticpattern24
126-130 Staticpattern25
131-135 Staticpattern26
136-140 Staticpattern27
141-145 Staticpattern28
146-150 Staticpattern29
151-155 Staticpattern30
156-160 Staticpattern31
161-165 Staticpattern32
166-170 Staticpattern33
171-175 Staticpattern34
176-180 Staticpattern35
181-185 Staticpattern36
186-190 Staticpattern37
191-195 Staticpattern38
196-200 Staticpattern39
201-205 Staticpattern40
206-210 Staticpattern41
211-215 Staticpattern42
216-220 Staticpattern43
221-225 Staticpattern44
226-230 Staticpattern45
231-235 Staticpattern46
236-240 Staticpattern47
241-245 Staticpattern48
246-250 Staticpattern49
251-255 Staticpattern50

www.prolight.co.uk Rubix RGB 3D Panel User Manual 12
Operating instructions
Auto mode:
Toaccesstheautomode,pressthe“MENU”buttonandusethe“UP”and“DOWN”buttonsontherear
oftheunittoshowAUTOontheLEDdisplay.Pressthe“ENTER”buttontoconrmthesetting.The
unitwillnowrunthroughallthebuilt-inprograms.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Built-in program mode:
Toaccessthebuilt-inprogrammodepress“MENU”untilthedisplayshowsProontheLEDdisplay.
Pressthe“ENTER” buttonandusethe“UP”and“DOWN”buttonstoselectaprogramfrom
Pr.01~Pr.28.TochangethespeedofprogramsPr.02~Pr.28pressthe“ENTER” buttonand
thenusethe“UP”and“DOWN”buttonstoselectanyvaluefromSP.01~SP.FL.Pressthe“ENTER”
buttontoconrmthesetting,thenusethe“UP”and“DOWN”buttonstoselecttheashspeedvalue
fromFL.00~FL.99.Pressthe“ENTER” buttontoconrmthesetting.InPr.01youareableto
setaspecicstaticpattern.WheninPr.01pressthe“ENTER” buttonandthenusethe“UP”and
“DOWN”buttonstogothroughthestaticpatterns.Pressthe“ENTER” buttontoconrmthesetting,then
usethe“UP”and“DOWN”buttonstoselecttheashspeedvaluefromFL.00~FL.99.Pressthe
“ENTER” buttontoconrmthesetting.Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Master/slave mode:
Tosetthemasterunit,pressthe“MENU”buttonontherearofthemasterunitthenselectyourdesired
program(soundactive,auto,staticpatternoroneofthebuilt-inprograms).Tosettheotherunitsin
slavemode,pressthe“MENU”buttonontherearoftheunittoshowSLAuontheLEDdisplayand
pressthe“ENTER”buttontoconrmthesetting.Theunitswillnowruninsequencewiththemaster
unit.Ifyouwouldrequirefullysynchronisedpatterns/colourspleaseensurethe‘DMXsyncsetting’
(page13)issetto--On.Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
PleaseensurethatallslaveunitsaresettothesameDMXchannelmodeasthemasterunit.
Colour mix mode:
Toaccessthecolourmixmodepress“MENU”buttonuntilCoLrshowsontheLEDdisplay.
Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstoselectthebrightnessof
segmentoneredbetweenr1.00~r1.FL.Pressthe“ENTER” buttonandrepeatforsegmentone
green(g1),segmentoneblue(b1),segmenttwored(r2),segmenttwogreen(g2),segmenttwo
blue(b2),segmentthreered(r3),segmentthreegreen(g3)andsegmentthreeblue(b3).
Value: 00 - FL (00 = low brightness, FL = high brightness)
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Sound sensitivity:
Toaccessthesoundsensitivitysetting,pressthe“MENU”buttonandusethe“UP”and“DOWN”
buttonsontherearoftheunittoshowSoudontheLEDdisplay.Pressthe“ENTER” buttonand
thenusethe“UP”and“DOWN”buttonstoselectanyvaluefromSU.00~SU.31.Pressthe
“ENTER”buttontoconrmthesetting. Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.

www.prolight.co.uk Rubix RGB 3D Panel User Manual 13
Operating instructions
Dimming curve selection:
Toaccessthedimmingcurvesetting,pressthe“MENU”buttonandusethe“UP”and“DOWN”
buttonsontherearoftheunittoshowSetontheLEDdisplay.Pressthe“ENTER” buttonand
thenusethe“UP”and“DOWN”buttonstoselectCur.Pressthe“ENTER” buttonand
thenusethe“UP”and“DOWN”buttonstoselecttherequireddimmingcurvefromCu-1~Cu-4.
Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
DMX signal failure:
ToaccesstheDMXsignalfailuresetting,pressthe“MENU”buttonandusethe“UP”and“DOWN”
buttonsontherearoftheunittoshowSetontheLEDdisplay.Pressthe“ENTER” buttonand
thenusethe“UP”and“DOWN”buttonstoselectFAIL.Pressthe“ENTER” buttonand
thenusethe“UP”and“DOWN”buttonstoselecteither-OFF(blackout)~HoLd(holdDMXsignal).
Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
DMX sync setting:
ToaccesstheDMXsyncsetting,pressthe“MENU”buttonandusethe“UP”and“DOWN”
buttonsontherearoftheunittoshowSetontheLEDdisplay.Pressthe“ENTER” buttonand
thenusethe“UP”and“DOWN”buttonstoselectSync.Pressthe“ENTER” buttonand
thenusethe“UP”and“DOWN”buttonstoselecteither--On(fullysynchronisedpatterns/
colours)~-Off(patterns/coloursrununsynchronised).Pressthe“ENTER”buttontoconrmthe
setting. Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Reset factory settings:
ToaccesstheDMXsyncsetting,pressthe“MENU”buttonandusethe“UP”and“DOWN”
buttonsontherearoftheunittoshowSetontheLEDdisplay.Pressthe“ENTER” buttonand
thenusethe“UP”and“DOWN”buttonstoselect-rSt.Pressthe“ENTER” buttonand
thenusethe“UP”and“DOWN”buttonstoselecteither--NOor-yES.
Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Software version:
Toaccessthesoftwareversion,pressthe“MENU”buttonandusethe“UP”and“DOWN”
buttonsontherearoftheunittoshowInFoontheLEDdisplay.Pressthe“ENTER” buttonand
thenusethe“UP”and“DOWN”buttonstoselectuer.Pressthe“ENTER” buttonand
thesoftwareversionwillbedisplayed.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Cu-3-InverseSquareLaw Cu-4-S-curveCu-1-Linear Cu-2-SquareLaw

www.prolight.co.uk Rubix RGB 3D Panel User Manual 14
Setting the DMX address:
TheDMXmodeenablestheuseofauniversalDMXcontroller.Eachxturerequiresa“startaddress”
from1-511.Axturerequiringoneormorechannelsforcontrolbeginstoreadthedataonthechannel
indicatedbythestartaddress.Forexample,axturethatoccupiesoruses7channelsofDMXandwas
addressedtostartonDMXchannel100,wouldreaddatafromchannels:100,101,102,103,104,105
and106.Chooseastartaddresssothatthechannelsuseddonotoverlap.E.g.thenextunitinthe
chainstartsat107.
DMX 512:
DMX(DigitalMultiplex)isauniversalprotocolusedasaformofcommunicationbetweenintelligent
xturesandcontrollers.ADMXcontrollersendsDMXdatainstructionsformthecontrollertothexture.
DMXdataissentasserialdatathattravelsfromxturetoxtureviatheDATA“IN”andDATA“OUT”
XLRterminalslocatedonallDMXxtures(mostcontrollersonlyhaveadata“out”terminal).
DMX linking:
DMXisalanguageallowingallmakesandmodelsofdifferentmanufacturestobelinkedtogether
andoperatefromasinglecontroller,aslongasallxturesandthecontrollerareDMXcompliant.
ToensureproperDMXdatatransmission,whenusingseveralDMXxturestrytousetheshortest
cablepathpossible.TheorderinwhichxturesareconnectedinaDMXlinedoesnotinuencethe
DMXaddressing.Forexample;axtureassignedtoaDMXaddressof1maybeplacedanywherein
aDMXline,atthebeginning,attheend,oranywhereinthemiddle.Whenaxtureisassigneda
DMXaddressof1,theDMXcontrollerknowstosendDATAassignedtoaddress1tothatunit,
nomatterwhereitislocatedintheDMXchain.
DATA cable (DMX cable) requirements (for DMX operation):
ThisxturecanbecontrolledviaDMX-512protocol.TheDMXaddressissetonthebackoftheunit.
YourunitandyourDMXcontrollerrequireastandard3-pinXLRconnectorfordatainput/output,
seeimagebelow.
Note: DMX cable must be daisy chained and cannot be split.
DMX setup
FurtherDMXcablescanbe
purchasedfromallgoodsound
andlightingsuppliersor
ProLightConceptsdealers.
Pleasequote:
CABL10 – 2m
CABL11 – 5m
CABL12 – 10m

www.prolight.co.uk Rubix RGB 3D Panel User Manual 15
Notice:
Besuretofollowthediagramsbelowwhenmakingyourowncables.Donotconnectthecables
shieldconductortothegroundlugorallowtheshieldconductortocomeincontactwiththeXLRs
outercasing.Groundingtheshieldcouldcauseashortcircuitanderraticbehaviour.
Special note:
Line termination:
Whenlongerrunsofcableareused,
youmayneedtouseaterminatoron
thelastunittoavoiderraticbehaviour.
Using a cable terminator will decrease
the possibilities of erratic behaviour.
(3-pin - Order ref: CABL90, 5-pin - Order ref: CABL89)
5-pin XLR DMX connectors:
Somemanufacturesuse5-pinXLRconnectorsfordatatransmissioninplaceof3-pin.5-pinXLRxtures
maybeimplementedina3-pinXLRDMXline.Wheninsertingstandard5-pinXLRconnectorsintoa
3-pinlineacableadaptormustbeused.Thediagrambelowdetailsthecorrectcableconversion.
Terminationreducessignaltransmission
problemsandinterference.Itisalways
advisabletoconnectaDMXterminal,
(resistance120Ohm1/4W)betweenpin2
(DMX-)andpin3(DMX+)ofthelastxture.
5-pin XLR (female)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
3-pin XLR (female)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
3-pin XLR (male)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
5-pin XLR (male)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
DMX setup

www.prolight.co.uk Rubix RGB 3D Panel User Manual 16
WEEE notice
Correct Disposal of this Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries
with separate collection systems)
Thismarkingshownontheproductoritsliterature,indicatesthatitshouldnotbedisposed
withotherhouseholdwastesattheendofitsworkinglife.Topreventpossibleharmtothe
environmentorhumanhealthfromuncontrolledwastedisposal,pleaseseparatethisfromother
typesofwastesandrecycleitresponsiblytopromotethesustainablereuseofmaterialresources.
Householdusersshouldcontacteithertheretailerwheretheypurchasedthisproduct,ortheir
localgovernmentofce,fordetailsofwhereandhowtheycantakethisitemforenvironmentally
saferecycling.
Businessusersshouldcontacttheirsupplierandcheckthetermsandconditionsofthe
purchasecontract.Thisproductshouldnotbemixedwithothercommercialwastesfordisposal.
