Lee Technology LTK-1100 User manual

Guest Paging System
LTK-1100
Operating Instructions
Questions? Comments?
Call
82-32-678-8605
lee technology korea.co.,ltd(LEETEK)
#24-2 Samjeong-dong, Ojeong-gu,
Puchon-city,Kyunggi-do, Korea
www.leetek.org
Please read these
instructions carefully
before setting up your
Guest Paging System!

GuestCall Coaster Paging System Instructions(LTK-1100)
Thank you for purchasing the GuestCall Paging System. The most advanced coaster paging
system on the market!
EQUIPMENT SET_UP
LTK-1100/ AC Adapter/Internal Antenna/manual
Keypad Sending Unit:
Unwrap all sending unit components. Lock the antenna into the hole in the upper right hand corner of
the sending unit. Plug the power supply with the large tip into a standard 110 outlet and plug it into the
back of the sending unit. We recommend some type of surge suppressor on the power supply for
protection. Power surges are not covered under system warranty!
Coaster Setup:
Locate the black charging base in a sturdy, out of the way location. Connect the charger bases
together using the included jumper wires. Use the power supply with the small tip and plug it into a
standard 110 outlet and into either open plug on the charger base. Be sure to plug the jumpers &
power supply jacks in all the way.
Stack the coasters on the black
charging base. The coaster number
will always face front and the red
charge indicator light will be on the left.
We recommend that you do not
stack coasters more than 15 high.
You should see a red light appear on each coaster. This light indicates proper charging is taking place.
NOTE: A wall mountable coaster holder is available for this system.
Coaster Numbers:
On the front of each coaster is your coaster number.
Surge Protection Recommended!!!
Power Supply
Jumper Wire
Charge Light
1
2
3
4
5
6
12v AC
1.5 amp
You should
stack a
maximum of
15 coasters
per charger.
LeetekTransmitter Coaster Power Supply
(Use 1 power supply per 60
coasters)
Transmitter
Power
Supply
Jumper wire

PLACEMENT & MOUNTING INSTRUCTIONS
DESKTOP:
You can use your transmitter with the 20 degree wedge attached or remove the wedge and lay the
transmitter flat.
WALL MOUNT
To mount your transmitter on a wall:
•Remove the plastic bracket (included) under the transmitter unit by unlocking the 2 latches.
•Place the plastic bracket against the wall and with the aid of a pencil, mark the position of the
mounting holes. (Refer to figure below). Mount the transmitter in a convenient location
where a power outlet is available.
•Drill a hole on the marked position. Install the 3 mounting screws (and use anchors where
necessary). Ensure that the screws are not fully tightened so that the unit can be easily
removed from the wall.
•Place the transmitter onto the wall (without the plastic bracket). Plug the 2-amp wall transformer
into any suitable AC outlet. Plug the power connector into the power jack on the top left hand
side of the unit. Transmitter is now ready for use. Be certain to mount the transmitter away from
phones, heat, moisture and exposed power circuits. These items can damage your system and
shorten transmission range.
System Configuration:
Your system was set at the factory and will function as soon as it is powered up.
Default setup is as follows:
Current time is set
Sleep shutdown on (battery operated pagers will be put to sleep at 1 am everyday)
Range Test is off. (Testing range is only necessary for very large properties)
Coasters are set to Flash & Vibrate when paged.
Duty Alert is off
Out of Range alert is off
*Some major points to remember when installing the equipment:
-Never install aerials near to overhead power lines or adjacent to telephone or public address or
Data communication lines.
-Avoid,where possible, running aerial feeder cables alongside other cables e.g.:telephone and
mains.
-Avoid mounting the transmitter in the immediate vicinity of telephones, exchanges or computer
equipment .
WALL
Mark these 3
holes on to the
wall

Operation Procedure
LTK-1100 allows and PC RS-232C control.
Step 1. Power on and entering Address
Connect the power Adaptor to AC outlet, and DC out put connector of the Adaptor to LTK-1100
Rear panel DC input connector. When the power is connected to LTK-1100 the system will
display the following.
Step 2.Sending Message
After entering the Pager Number (Message), press SEND to send the message. The call will
Now be transmitted to the receiver unit. Following display will appear on screen during the
Message transmission
Key Stroke Display
Pager # “28”
“Send” This stay on for less than 1 sec
Display go back to default display
After the page
Step 3.
To enter programming mode, press the “SETUP” button and enter the password “1379” followed by
“enter”. If the password is accepted, the display will show “use * to scroll to menu options”
1. Set the Current Time
HOUR DIGIT BLINKING
Press Numeric Hour, Press ENTER, automatically go
to minutes mode
Press Numeric Minutes
Press Enter, automatically go to AM/PM mode
INITIALIZING
READING SETUP
TRANSMITTER DUT
ROM VER: V1.00 A
ENTER PAGER NO.:
> 9:00 AM
ENTER PAGER NO.:
> 28 9:00 AM
Sending Message
Please Wait
ENTER PAGER NO.:
> 9:00 AM
SET CURRENT TIME
88:88 AM
SET CURRENT TIME
88:88 AM

.
Press “# “ to change (AM to PM) Press ENTER
2. Set the Sleep Shutdown Time (Factory Default : ON – 1 AM)
This system has an “ALL SLEEP” function that turns off all battery pagers (for example,
manager pagers)at once automatically.
To turn this feature off:
•Press “#/Select” key to turn the sleep shutdown “OFF”
•Press enter to go back to the main menu.
To change the shutdown time:
•Press “#/Select” key to turn the sleep shutdown “OFF”
•Set the hour then press “ENTER”key.
•Set the minutes and press “ENTER” key.
•Use the “# /Select” key to select AM or PM.
•After the correct time is set, press the “ENTER” or “∗/ Menu” key to return to the main
menu or press the “CANCEL” key 2 times to exit the system programming menu.
3. Range Test (Factory Default : OFF)
With this feature you can determine what distance your transmitter will cover.
•Remove a couple of coasters from the charging stack.
•At the range test menu, press “#/Select” key to turn range test “ON”.
•Press “ENTER” to start the range test. As soon as range test is activated you’ll notice
the coasters flash once every 10 seconds (if you use pagers they will vibrate). Walk
around your property. When you reach the point where the coasters do not flash
consistently, this is your maximum range
•Press the “CANCEL” key to stop the range test. Press the “CANCEL” key again to exit
the system programming menu.
NOTE : The transmitter has an auto shut off feature that will stop the range test after 15 minutes.
4. Set Pager Alert (Factory Default: Flash & Vibe)
With this feature you have the option of changing the way your coasters alert the guest.
Be sure that all coasters are returned before performing this procedure.
To change the alert mode of your coasters follow these instructions:
•Remove all the coasters from the charging unit or unplug the power supply that is
connected to the charging bases.
•At the “Set Pager Alert ” menu, press the “#/Select” key to scroll through the different
alert options.
•After making a selection, press the “enter” key 3 times. After sending the code, the
coasters will now respond with your new selection.
•Press “CANCEL” key to exit the system programming menu
•Return all the coasters to the charging base or plug the power supply. The coasters are
ready to receive the page with the new alert.
5. Setting the Duty Alert (Factory Default: OFF)
SET CURRENT TIME
88:88 AM

This feature enables your transmitter to send a page, at a preset time, to a certain pager to
remind them of a duty required of them. For example, a busser can receive a page every 60
minutes to remind him to check the restrooms.
You can assign up to 3 different pagers to be duty alert pagers.
PROGRAMMING THE DUTY PAGER
•At the “Duty Alert” menu, press “#/Select” key to turn the duty cycle “ON” and press the
“ENTER” key.
•Enter the duty pager number and press “ENTER” key.
•Enter the cycle time (in minutes) and press the “ENTER” key.
Press ENTER Key
6. Setting the “Out of Range” (for coasters only) (Factory Default: OFF)
With this feature, the coasters will play a melody when taken out of range of the transmitter
to inform the guest that they are out of range and will miss their page. The melody will only
stop, when they return back within range.
Be sure that all coasters are returned before turning out of range on or off.
TURNING THE OUT OF RANGE ON
To test the coasters with out of range on, unplug the power supply, that is connected to
the transmitter. After 45 – 60 seconds, all the coasters will play a melody since they are
not receiving a signal from the transmitter. Plug in the power supply back into the
transmitter. After a few seconds, all coasters will stop playing the melody. Return all the
coasters to the charging base or plug the power supply. The coasters are ready to
receive the page with the out of range feature turned on.
Press ENTER
Press ENTER
Set Pager No:
Cycle Time
>Min
Enter Message
>
Duty o1 Saved
Cancel:to Exit
Enter:Next PG
R
Out of range>On
#to turn ON?OFF:
Are All Pagers
Returned ??

Press Enter
Press Enter
After message is sent, display go to back to Main Menu
Main Menu
TURNING THE OUT OF RANGE OFF
•Remove all the coasters from the charging unit or unplug the power supply that is
connected to the charging base
•At the “Out of Range” menu, press “#/Select” key to turn the out of range OFF.
•Press “ENTER” key 3 times. After sending the signal, all the coasters will light up once to
tell you that they received the new code.
•Press “CANCEL” key to exit the system programming menu.
To test the coasters with out of range off, unplug the power supply, that is connected to the
transmitter. After 30 - 45 seconds, all the coasters should not play the melody since the out
of range were turned off. If all or some of the coasters are playing the melody, repeat the
procedure above. If none of the coasters are playing the melody, return all the coasters to
the charging base or plug the power supply. Plug the power supply of the transmitter. The
coasters are ready to receive the page with the out of range feature turned off.
Press ENTER
Press ENTER
Press Enter
Press Enter
After message is sent, display go to back to Main Menu
Main Menu
Unplug All
Coasters
Message sent
Plug in pagers
Press * to scroll
Menu options
Out of range>OFF
#to turn ON?OFF:
Are All Pagers
Returned ??
Unplug All
Coasters
Message sent
Plug in pagers
Press * to scroll
Menu options

Specification
Model:LTK-1100 (Pager transmitter)
Pocsag code
Carrier frequency:
457.5750Mhz + /- 200Hz
Frequency Range:450.3250MHz – 467.7500Mhz
Effective Range: Up to 1/2 mile with standard aerial
Stability: +/- 1.5ppm –100 C to 50 0C, +/- 1.0ppm /year Aging
FM Modulation
Deviation: 4.5khz
FM Accuracy: +/- 5% 4.275< 4.5 < 4.725
Data rate : 1200BPS, 600Hz +/-5Hz
Residual FM:Less than 5Hz, 300Hz HPF and 3kHzLPF
RF Out put: 27dbm +/- 1db Maximum (0.5W)
Message: Numeric, 12digit Maximum
Address Range:0001 to 1249
Frequency and data rate setting: Through RS-232 connector.Computer program is included.
Address Abbreviation :Pager Addresses are shortened to 3 digit through RS-232C connector.
Computer program is included.
RF ON/OFF:RF is ON only during the Pager No( message) transmission, Number/ ADDRESS
entered and SEND key pressed.
Power: DC 9V, 1A, AC Adapter
Dimension: W(185 ) x D( 190 ) x H ( 51.5 )
Weight: 0.8kg
