Legacy Super Magnum Coal Stoker Operating instructions

Installation & Owner's Manual
Care and Operation for Your Super Magnum Stoker
INSTALLER: Leave this manual with party responsible for use and operation.
O NER: Retain this manual for future reference. Call your dealer for questions on Installation, Operation, or Service.
To obtain a French tranlation of this manual, please contact your dealer or visit www.legacystoves.com
Pour obtenir une traduction française de ce manuel, s’il vous plaît contacter votre revendeur ou visitez
www.legacystoves.com
⚠CAUTIONS AND WARNINGS: RISK OF FIRE, INJURY OR DEATH
TESTED AND APPROVED FOR ANTHRACITE RICE COAL FUEL ONL . DO NOT USE
CHEMICALS OR FLUIDS TO START FIRE. BURNING OF AN OTHER T PE OF FUEL VOIDS
OUR WARRANT .
INSTALLATION MUST COMPL WITH LOCAL, REGIONAL, STATE AND NATIONAL CODES AND
REGULATIONS.
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS, INSTALLATION,
INSPECTION AND PERMITTING REQUIREMENTS IN OUR AREA.
MAXIMUM ALLOWED DRAFT IS -.08 INCHES OF WATER COLUMN.
DO NOT USE ABRASIVE CLEANERS ON STOVE GLASS.
DO NOT CLEAN STOVE GLASS WHEN HOT. NEVER ALLOW CHILDREN TO TOUCH GLASS OR
TO BE IN THE ROOM WITH THE STOVE UNSUPERVISED.
Report Number: 0536CS004S
Tested to: UL 1482-2011, UL 391-2010, ULC S627-00
Legacy Stoves, A Division of:
Alternate Heating Systems
2393 Little Egypt Rd
Harrisonville, PA 17228
WARNING!
Please read this entire manual
before installation and use of
this coal - burning room heater.
Failure to follow these
instructions could result in property
damage, bodily injury or even death.
SAVE THESE INSTRUCTIONS
Model(s): Super Magnum Coal Stoker


arnings and Cautions Continued
DO NOT OVERFIRE - IF AN EXTERNAL PART STARTS TO GLOW, OU ARE OVERFIRING.
REDUCE FEED RATE. OVERFIRING WILL VOID OUR WARRANT .
COMPL WITH ALL MINIMUM CLEARANCES TO COMBUSTIBLES AS SPECIFIED. DO NOT
PLACE FUEL WITHIN INSTALL CLEARANCES. FAILURE TO COMPL MA CAUSE HOUSE
FIRE.
KEEP CLOTHING, FURNITURE, DRAPERIES AND OTHER FLAMMABLE MATERIALS AWA .
HIGH TEMPERATURES MA IGNITE CLOTHING OR OTHER FLAMMABLE MATERIALS.
ALERT ADULTS AND CHILDREN TO HAZARDS OF HIGH TEMPERATURES.
DO NOT OPERATE WITH FUEL LOADING OR ASH REMOVAL DOORS OPENED.
INSPECT AND CLEAN CHIMNE CONNECTORS AND CHIMNE REGULARL . USE OF A UL
103 HT CHIMNE REQUIRED.
DO NOT BURN GARBAGE, FLAMMABLE LIQUIDS OR ENGINE OIL.
Introduction
Thank you for purchasing a Legacy StovesTM Super Magnum Coal Stoker Stove. The Super Magnum has been designed and built to last.
Please read this manual before attempting to install or use your new stove. If you have uestions regarding your new stove, contact
your dealer. Follow these instructions and you'll have years of warmth and comfort to enjoy your new coal stove.
If you are a coal burner for the first time, keep in mind that you will not have instant success with the maintenance of a fire. Nobody
does. Following these guidelines should help you with the basics.
Please copy your serial number label on the back of the stove to the box below.
-3-

Super Magnum Coal Stoker Label (top, not actual size)
-4-

Super Magnum Coal Stoker Label (bottom, not actual size)
-5-

-6-

Table of Contents - Super-Magnum Coal Stoker Stove
CAUTIONS AND WARNINGS: RISK OF FIRE, INJURY OR DEATH⚠.................................................1
Warn ngs and Caut ons Cont nued.................................................................................................................3
Introduct on....................................................................................................................................................3
Super Magnum Coal Stoker Label (top, not actual size)...............................................................................4
Super Magnum Coal Stoker Label (bottom, not actual s ze).........................................................................5
L st ng and Code Approvals...........................................................................................................................9
A. Appl ance Cert f cat on.........................................................................................................................9
B. Mob le Home Approved........................................................................................................................9
C. Glass Spec f cat ons..............................................................................................................................9
D. Electr cal Rat ng...................................................................................................................................9
E. BTU & Eff c ency Spec f cat ons..........................................................................................................9
Spec al Warn ngs and Not ces......................................................................................................................10
1.0 Some th ngs to keep n m nd.............................................................................................................10
1.1 Carbon Monox de.........................................................................................................................10
1.2 Wet Coal........................................................................................................................................10
1.3 Prevent Rust and Corros on..........................................................................................................10
F rst Steps.....................................................................................................................................................11
2.0 Gett ng Started...................................................................................................................................11
2.1 Appl ance Locat on.......................................................................................................................11
2.2 Room Sensor Locat on..................................................................................................................11
2.3 F re Safety.....................................................................................................................................11
2.4 Component Locat ons...................................................................................................................12
2.5 Pre-Use Check L st.......................................................................................................................13
2.6 D mens ons....................................................................................................................................14
2.7 Clearances.....................................................................................................................................15
2.8 Floor Protect on Requ rements.....................................................................................................15
Ch mneys and Vent ng..................................................................................................................................16
3.0 Ch mney Character st cs and Components........................................................................................16
3.1 Draft..............................................................................................................................................16
3.2 Ch mney Connectors.....................................................................................................................16
3.3 Wall Pass-Through........................................................................................................................17
3.4 The Ch mney n general................................................................................................................17
3.5 Ex st ng Masonry Ch mneys.........................................................................................................18
3.6 Vent ng to an Ex st ng Masonry F replace Ch mney....................................................................19
3.7 Install ng to a Prefabr cated Ch mney...........................................................................................20
3.8 Draft Test – Barometr c Damper Setup.........................................................................................21
Add t onal Setup...........................................................................................................................................22
4.0 Mob le Home Setup – USA Only......................................................................................................22
4.1 Outs de A r and secur ng stove.....................................................................................................22
4.2 Outs de A r Attachment.................................................................................................................23
4.3 Level ng the Appl ance.................................................................................................................23
4.4 Opt onal Heat Transfer K t............................................................................................................23
4.5 A r F lter........................................................................................................................................24
4.6 Opt onal Decorat ve T le K t.........................................................................................................24
4.7 Opt onal Door Tr m K t.................................................................................................................25
4.8 Room Sensor Installat on..............................................................................................................25
Operat on......................................................................................................................................................26
5.0 Operat ng Instruct ons.......................................................................................................................26
5.1 Fuel Spec f cat ons........................................................................................................................26
-7-

5.2 General Operat ng Informat on.....................................................................................................26
5.3 ESP (Exhaust Sens ng Probe).......................................................................................................26
5.4 C rcu t Board.................................................................................................................................27
5.4.a C rcu t Board General Informat on.......................................................................................27
5.4.b Status L ght Error Messages.................................................................................................27
5.4.c C rcu t Board D psw tches:...................................................................................................27
5.4.d Feed Rate Adjustment...........................................................................................................28
5.4.e Mode Select on......................................................................................................................28
5.4.f Temperature D al....................................................................................................................28
5.4.g Blower Speed Adjustment.....................................................................................................28
5.5 Before Your F rst F re...................................................................................................................28
5.6 Start ng Your F rst F re..................................................................................................................28
5.7 F re Character st cs............................................................................................................................29
Troubleshoot ng............................................................................................................................................30
Serv ce & Ma ntenance................................................................................................................................31
6.0 Serv ce L fe Expectat ons..................................................................................................................31
6.1 Shutdown Procedure.....................................................................................................................31
6.2 Qu ck Reference Ma ntenance Chart............................................................................................31
6.3 Ma ntenance Procedures...............................................................................................................32
6.3.a Ash Removal.........................................................................................................................32
6.3.b Heat Exchanger Cha n Scraper..............................................................................................32
6.3.c F nes Tray Empty ng.............................................................................................................33
6.3.d Door Glass.............................................................................................................................33
6.3.e A r F lter................................................................................................................................34
6.3.f Hopper....................................................................................................................................34
6.3.g F rebox..................................................................................................................................34
6.3.g Ch mney Connector...............................................................................................................34
6.3.h Ch mney................................................................................................................................34
6.4 Spec f c Ma ntenance Items..........................................................................................................35
6.4.a Feed Motor............................................................................................................................35
6.4.b Blower Motor........................................................................................................................35
6.4.c D str but on Blower...............................................................................................................36
6.4.d ESP – Exhaust Sens ng Probe...............................................................................................36
6.4.e F nes Scraper – n Feeder......................................................................................................36
Reference Mater als......................................................................................................................................37
7.0 Serv ce Parts-1...................................................................................................................................38
7.0 Serv ce Parts-2...................................................................................................................................39
7.0 Serv ce Parts-3...................................................................................................................................40
7.0 Serv ce Parts-4...................................................................................................................................41
7.0 Serv ce Parts-5...................................................................................................................................42
Serv ce and Ma ntenance Log......................................................................................................................45
Serv ce and Ma ntenance Log......................................................................................................................46
-8-

Listing and Code Approvals
A. Appliance Certification
Model: Super Magnum Coal Stoker
Laboratory: OMNI-Test Laboratories, Inc
Report No. 0536CS004S
Type: Solid Fuel Room Heater / Coal Burning Type
Standard(s) UL 1482-2011, UL 391-2010, ULC S627-00
This appliance is also approved for installation in a shop
B. Mobile Home Approved
This appliance is approved for Installation in mobile/ manufactured homes in the US only. The structural integrity of the mobile home ?
oor, ceiling and walls must be maintained. The appliance must be properly grounded to the frame of the mobile home, and must never
be installed in a room designated for sleeping. The unit must have provisions for an outside air source when installed in a mobile home.
C. Glass Specifications
This appliance is e uipped with 5mm ceramic glass. Replace glass only with 5mm ceramic glass. Please contact your dealer for
replacement glass if needed.
D. Electrical Rating
115 VAC, 60 Hz, 3.1 Amps
E. BTU & Efficiency Specifications
Particulate Emissions Rating: Not Tested
*BTU Input: 5,000 – 103,000 / hr
Heating Capacity: 2,500 s ft or more
Hopper Capacity: 110 lbs
Fuel: Anthracite Rice Coal
Shipping Weight: 543 lbs
-9-

Special arnings and Notices
1.0 Some things to keep in mind
1.1 CARBON MONOXIDE
Carbon monoxide, referred to as CO, is a colorless, odorless gas that is produced during combustion of coal and other fuels. CO fumes
are toxic and can be fatal.
•The Super-Magnum is a natural draft system which relies on a properly designed chimney to remove CO and other
combustion by-products from the stove.
•Even though this stove is designed to be as safe as possible, it is important that you install a CO detector. This is true for oil,
gas, or wood burning products as well.
•CO is not specifically heavier or lighter than air. Therefore, it is best to install the detector at table top level rather than on the
ceiling like a smoke detector.
•CO detectors are very sensitive and may sound an alarm for fumes other than CO or CO from sources other than the stove
such as car or lawn mower exhaust.
If the alarm sounds:
•Increase ventilation by opening windows or doors.
•Make sure the stove doors and hopper lid are closed and latched.
•Check stove for electrical power and normal operation.
•Check chimney for possible blockage or down-draft.
•Check for false alarm.
1.2 WET COAL
Freshly delivered coal is often watered down to eliminate dust when loading and unloading. Wet rice coal does not flow as well as dry
coal. We do not recommend burning wet coal; however, we realize if it's the only coal you have, it is better to burn it than to be cold. If
you must burn wet coal, the feed rate will likely need increased. Doing this once or twice a year will not damage your stove as long as it
is hot and burning. Damage is caused when the hopper is left with wet coal in it while the stove is cold. This will cause rust and
corrosion and it is totally the operator’s fault. After the coal dries for three or four days, depending on conditions, it will flow and feed
properly.
1.3 PREVENT RUST AND CORROSION
Always empty the hopper when not burning for more than a week. When left standing for long periods with wet coal, the feed system
will rust and corrode, causing it to seize. If the stoker is then turned "on", damage to the pusher assembly and feed motor could result.
This will be considered neglect and will void the warranty on those parts. Always check to see that moving parts are free before using, if
the unit has not been burned for a period of time. This can best be determined by running a "Test" cycle and watching the cam block
and pusher arm inside the right rear door.
SPECIAL NOTE: DUE TO ASH BUILDUP, IT IS STRONGLY RECOMMENDEDTO HAVE YOUR STOVE PROFESSIONALLY
CLEANED AND SERVICED ANNUALLY. THIS INCLUDES ALL PARTS OF THE STOVE, AND THE VENTING SYSTEM.
Installation and repair of this stove should be done by a ualified service person. We recommend that the stove be inspected before use
and at least annually by a ualified service person. Periodic cleaning is re uired throughout the heating season and at the end of each
winter for the stove to work efficiently.
-10-
NEVER SLEEP IN THE SAME ROOM WITH ANY COAL BURNING STOVE!
NEVER USE GASOLINE, LANTERN FUEL, KEROSENE, CHARCOAL LIGHTER FLUID, OR SIMILAR LIQUIDS TO START OR
“FRESHEN UP” A FIRE IN THIS HEATER. KEEP ALL SUCH LIQUIDS WELL AWAY FROM THE HEATER WHILE IT IS IN USE.
NEVER CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE.

First Steps
2.0 Getting Started
2.1 APPLIANCE LOCATION
Consideration must be given to safety, convenience, traffic flow, and the fact that the appliance will need a chimney and chimney
connector. It is a good idea to plan your installation on paper, using exact measurements for clearances and floor protection, before
actually beginning the installation.
Maintain specified vent clearance to combustible re uirements listed by the vent manufacturers instructions and all clearance to
combustibles listed in this manual.
Check with your local building code agency before you begin your installation. Be sure local codes do not supersede UL specifications
and always obtain the re uired permit so that insurance protection benefits cannot be unexpectedly canceled. If any assistance is
re uired during installation, please contact your dealer.
We recommend that a ualified building inspector and your insurance company representative review your plans before and after the
installation.
2.2 ROOM SENSOR LOCATION
The room sensor's location will have some effect on the appliance's operation. When the sensor is located close to the appliance, it may
re uire a higher setting to keep the rest of the house comfortable. If the sensor is located in an adjacent room, or farther away from the
stove, you will notice higher temperatures near the appliance.
2.3 FIRE SAFET
Maintain the designated clearances to combustibles. Insulation must not touch the chimney. You must maintain the designated air
space around the chimney. This space around a chimney is necessary to allow natural heat removal from the area. Insulation in this
space will cause a heat buildup, which may ignite wood framing.
NOTE: Clearances may only be reduced by means approved by the regulatory authority having jurisdiction.
To provide reasonable fire safety, the following should be given serious consideration:
•Install at least one smoke detector on each floor of your home. Detectors should be located away from the heating appliance
and close to sleeping areas. Follow the smoke detector manufacturer's placement and installation instructions, and be sure to
maintain regularly.
•Maintain a conveniently located Class A fire extinguisher to contend with small fires resulting from burning embers.
•Have a practiced evacuation plan, consisting of at least two escape routes.
•Form a plan to deal with a hopper fire as follows:
•In the event of a hopper fire:
✔Evacuate the house immediately.
✔Notify Fire Department.
-11-
DO NOT OPERATE BEFORE READING AND UNDERSTANDING THE INSTRUCTIONS.

2.4 COMPONENT LOCATIONS
-12-

2.5 PRE-USE CHECK LIST
Place the appliance in a location near the final installation and
follow the procedures below:
1. Open the appliance and remove all articles packed inside.
Inspect all items for shipping damage. Notify dealer of
any missing or damaged goods.
2. All safety warnings have been read and followed
precisely.
3. This Owner's Manual has been read in its entirety.
4. Floor protection re uirements have been read and
followed.
5. The flue connector has been installed in accordance with
the instructions herein.
6. The proper clearances from the appliance and chimney
connector to combustibles have been met.
7. The masonry chimney has been cleaned and inspected by
a professional.
8. The chimney meets the minimum height re uirements.
9. All labels and hang tags have been removed from the
glass.
10. All plated surfaces have been wiped clean as applicable.
11. The room sensor and any additional cable has been
installed properly.
12. A properly grounded electrical receptacle is available
within reach of the unit's power cord.
-13-
WARNING!
Inspect appliance and
components for damage.
Damaged parts may impair safe
operation.
•Do NOT install damaged components.
•Do NOT install incomplete
components.
•Do NOT install substitute components.
•Report damaged parts to dealer.
WARNING!
Fire Risk: Alternate Heating
Systems disclaims any
responsibility for, and the
warranty will be voided by, the following
actions:
•Installation and use of any damaged
appliance.
•Modification of the appliance.
•Installation other than as instructed by
Alternate Heating Systems.
•Operating appliance without fully
assembling all components.
•Operating appliance without legs
attached.
•Overfiring.
•Any action that may cause a fire
hazard.

2.6 DIMENSIONS
-14-

2.7 CLEARANCES
2.8 FLOOR PROTECTION REQUIREMENTS
Floor protection must be of a non-combustible material. It must be located
under the appliance and extend beyond the appliance according to the
measurements below. Floor protection must also extend under any horizontal
sections of chimney connector and 2" (50.8mm) beyond each side of the
connector.
DANGER: The appliance legs may not be removed for installation.
Minimum Size floor protection is 49½" Deep By 42¾" Wide.
Alternate floor protector dimension may be used as long as they satisfy the
measurement re uirements shown above.
Minimum size floor protection for a corner installation hearth pad is 54" x 54"
(USA ONLY).
-15-
Parallel Installation Inches Millimeters
ABack all to Unit (Hopper) 2 51
BSide all to unit 24 610
CBack all to Flue Connector 17 432
DSide all to Flue Connector 34 864
Corner Installation Pouces Millimeters
Ealls to Unit Body 15 381
Falls to Flue Connector 24 610
Inches Millimeters
GSides – USA/Canada* 8 203
HFront – USA/Canada* 18 457
JRear – USA 12 305
Floor Protection
Requirements
CAUTION! DO NOT STORE FUEL INSIDE INSTALLATION CLEARANCES!

Chimneys and Venting
3.0 Chimney Characteristics and Components
3.1 DRAFT
Draft is widely misunderstood. It is important that you, the stove operator, realize that draft is a variable effect, not a given uantity.
Stoves and chimneys do not have draft, yet draft is the key to your stove’s performance.
Draft is a force, produced by an operating stove and the chimney to which it is attached. It is created by hot gases rising up the
chimney, creating a pressure difference between the inside of your home and the outside air. It continually moves fresh combustion air
into the stove, and hot exhaust gases out of the stove; without this constant flow, the fire will go out.
Other factors, such as barometric pressure, winds, the airtight nature of the home, the total inside chimney volume, chimney height and
the presence of venting devices such as exhaust fans also play a role in maintaining an ade uate draft. In some cases, a window may
need to be left open, or some other source of fresh air provided, to keep the appliance operating properly. Low barometric pressures,
super insulated homes and exhaust fans can reduce draft; winds can play havoc with draft; and too large or too small a chimney volume
can cause reduced draft due to the excessive cooling or not enough room to vent exhaust gases uickly.
Some signs of inade uate draft are smoking, odor, difficulty in maintaining the fire, and low heat output. Overdraft can be caused by a
very tall chimney even if it is the recommended size, and can cause over firing of your stove. Signs of an overdraft include rapid fuel
consumption, inability to slow the fire, and parts of the stove or chimney connector glowing red. It is important that you follow the
chimney guidelines in this manual, including size, type, and height to avoid draft problems.
When installed and operated according to this manual, the this unit will produce enough hot gases to keep the chimney warm so that
ade uate draft is maintained throughout the burn cycle. See later in this section for installation of a barometric damper to limit
maximum draft.
When solid fuels are burned completely, they produce water and carbon dioxide. However, in long slow burns, a substantial amount of
carbon monoxide may be produced. If allowed to build up, carbon monoxide (which is odorless) can prove fatally poisonous. Proper
ventilation and draft will prevent this from happening. If you smell smoke, thoroughly ventilate your dwelling, and contact your dealer
for service. Retest the draft and properly set the barometric damper. Other causes of poor ventilation or draft are icing, exhaust fans, a
blocked outside air inlet, and room air starvation. If your stove is sluggish and you get occasional odor, check these possibilities and
increase the airflow in your home.
3.2 CHIMNE CONNECTORS
In general, following these guidelines will ensure compliance with all national and provincial codes; prior to beginning your
installation, check with your local building code official to check on additional local regulations which may influence the design and
placement of your venting system.
The Legacy Super Magnum Coal Stoker may be installed with 24 MSG, 6 inch diameter (150mm) chimney connector pipe. Size of the
connector should correspond to the size of the flue collar opening. Do not use makeshift compromises. No part of the chimney
connector may pass through an attic or roof space, closet or other concealed space, or through a floor or ceiling. Whenever possible,
avoid passing the connector through a combustible wall; if you must, use an approved wall pass-through, described later in this section.
Assemble the connector beginning at the flue collar, with the crimped ends pointing towards the stove (to keep debris and creosote
flakes inside the system). Each joint, including the one to the stove’s flue collar and the one to the chimney itself should be secured with
at least three sheet metal screws. Screws may be a maximum of 3 inches apart. A 1-1/4" (30 mm) overlap is re uired at each joint,
including the flue collar attachment. No more than two 90 degree elbows should be used, and the total length of connector should not
exceed 10 feet (3 m). All horizontal runs of connector must have a minimum upward slope of 1/4"(6 mm) per foot (20 mm per meter).
-16-
WARNING! CHIMNEY AND CHIMNEY CONNECTORS MUST BE KEPT CLEAN AND IN GOOD CONDITION!

3.3 WALL PASS-THROUGH
Occasionally it is necessary to pass the chimney connector through a combustible wall to reach the chimney. Depending on your local
building codes, and the pertinent provincial or national codes, there are several choices for accomplishing this safely. Before beginning
your installation, contact local officials, and also the chimney connector and chimney manufacturer for specific re uirements.
Canada: Three methods are approved by the Canadian Standards Association. The diagram shows one method re uiring an 18"
(450mm) air space between the connector and the wall. It allows use of one or two covers as described in the diagram. The two other
methods are described in detail in the current issue of CAN/CSA B365, the national standard.
United States: In the U.S., the national code is NFPA 211. While many localities adopt this standard, be sure to check with local
authorities before beginning your installation.
The NFPA (National Fire Protection Association) permits four methods for passing through a combustible wall. A commonly used
method to pass through a wall directly to a masonry chimney is to clear a minimum 12"(300 mm) around the entire chimney connector,
and fill it with brick masonry which is at least 3.5"(90 mm) thick. A fireclay liner, minimum 3/8" (9 mm) wall thickness must run
through the brick wall to the chimney liner (but not beyond the inner surface of the liner). It must be cemented in place with refractory
cement. This method is illustrated. For details on the other three options, refer to the most recent edition of the NFPA 211 code.
3.4 THE CHIMNE IN GENERAL
This unit must be installed into a chimney approved for use with solid-
fuel appliances. In the U.S., it must be connected to (1) a prefabricated
chimney complying with the re uirements for Type HT chimneys in
the Standard for Chimneys, Factory-Built, Residential Type and
Building Heating Appliances, UL 103, or (2) a code-approved masonry
chimney with a flue liner.
In Canada, this unit is listed for use with prefabricated chimneys tested
and listed to the high temperature (650 degrees C) chimney standard,
ULC S-629, or with a code approved masonry chimney.
For mobile homes, (US only) it must only be installed with
prefabricated chimney systems, including the installation components,
tested to use in mobile homes; the diameter should match the diameter
of the flue collar opening
The minimum recommended height for any chimney is 16 ft. (4.8 m)
above flue collar height. For non-mobile home installations, a round
flue (either masonry or approved prefabricated), of either 6" (150 mm),
7" (180 mm) or 8" (200 mm) may be used. For s uare or rectangular
masonry chimneys, nominal sizes of 8" x 8" or 8" x 12" (200mm x 200
mm, 200 mm x 300 mm) may be used.
-17-

Codes re uire that solid-fuel chimneys extend 3 ft. (0.9 m) above the highest point at which they exit from the roof. Then, the chimney
must extend 2 ft. (6 m) above the highest point within a 10 ft (3 m) radius. Thus, the 3 foot, 2 foot, 10 foot rule:
•3ft. - Above roof exit point
•2ft. - Higher than anything within-
•10ft. of the chimney.
NOTE: The restriction of not venting more than one appliance to the same flue applies to the U.S. specifically. While it is not
recommended that you use the same chimney for more than one appliance, in Canada certain exceptions may be made. Be sure to
contact your building code inspection official to see if this option is allowed in your area, and to find out the specific re uirements for
such an installation.
Building codes re uire that solid-fuel chimneys extend 3 ft (0.9 m) above the point at which they exit from the roof, provided that no
part of any structure is within the top of the chimney, then the chimney must extend 2 ft (6 m) above the highest point with the 10 ft (3
m) radius top height. If there is not ten feet of clearance from the top of the chimney, then the chimney must extend 2 ft (6 m) above the
highest point with the 10 ft (3 m) radius.
3.5 EXISTING MASONR CHIMNE S
If you plan on using a preexisting masonry chimney, have it thoroughly
inspected and cleaned. Any faults which make the chimney unsafe and
unusable must be repaired prior to use. These can include improper
height, structural defects, blockages, inade uate clearance to
combustibles, unsealed openings into other rooms of the house, signs of
creosote or smoke leakage, a loose or absent clean-out door, or absence of
a liner.
When connecting to a masonry chimney, several provisions are standard.
First, whether the chimney connector is vented to the chimney through a
thimble or a breech pipe, neither must pass beyond the inner surface of
the chimney liner, and both must be firmly cemented in place with
refractory cement. (A thimble is a masonry pipe which is inserted through
the chimney wall, and is fre uently the preferred method; a breech pipe is
a piece of steel pipe used the same way.) In Canada, a breech pipe has
ridges or protrusions to lock it firmly into the refractory cement. In either case, the chimney connector vents to the chimney through
the thimble or breech pipe.
Masonry Chimney with Wall Pass-Through
-18-
DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE
SERVING ANOTHER APPLIANCE.
WARNING ! DO NOT INSTALL IN SLEEPING ROOM!

3.6 VENTING TO AN EXISTING MASONR FIREPLACE CHIMNE
In some situations, a code compliant chimney originally used for a masonry fireplace
may be used to install your Super Magnum Coal Stoker stove. In addition to the
re uirements found in the previous paragraphs, it is important to be aware that all
clearances must be met, including those from the chimney connector to combustibles —
18" (360 mm) to sides and 18" (450 mm) to ceiling. Do not forget to include floor
protection in your plans. (See Clearances and Floor Protection in a previous section.)
Since many fireplaces have exposed wooden mantels and trim, pay special attention to
the clearances necessary to these materials.
If your fireplace chimney is behind a combustible wall, you must use an approved wall
pass-through system to gain access to the masonry chimney. The chimney connector
must enter the chimney at a place where it is lined, and the fireplace must be made
inoperable. For example, you might remove the damper, replacing it with a secure,
airtight, noncombustible seal (removable for inspection); this also satisfies the
re uirement that no room air must be allowed to enter the chimney.
-19-
DO NOT BURN ANY FUEL OTHER THAN COAL. NEVER
USE HIGHLY VOLATILE SUBSTANCES IN YOUR STOVE,
SUCH AS GASOLINE, WHICH COULD CAUSE AN
EXPLOSION.

3.7 INSTALLING TO A PREFABRICATED CHIMNE
When venting your Super Magnum Coal Stoker Stove using a
prefabricated chimney, be sure to contact local building code
authorities, and to follow the manufacturer’s instructions exactly. Use
only the manufacturer’s parts; do not use makeshift installation
techni ues. All prefabricated chimneys must be tested to either the
U.S. or Canadian high-temperature standards, UL 103 or ULC-629.
Your manufactured chimney may contain more parts than is shown at
right. Include all re uired items in your installation. A chimney cap
(A) serves to keep rain and snow from entering the chimney. An
approved Class A chimney (B) is re uired for the Super Magnum
Stoker. Wall Bands (C) must be deployed for support per
manufacturer’s recommendations. A manufacturer’s Wall Support Kit
(D) will contain re uired items for supporting the chimney. Such kits
will cost less than individual items purchased separately. A Bottom
Cap (E, location marked, but actual cap not shown) allows for
cleaning. A Finishing Collar (F) provides inside wall protection. A
Wall Thimble (G) provides for re uired clearance between the
chimney pipe passing through a flammable wall. The Chimney
Connector (H) must be approved single wall, or a low clearance pipe,
installed with re uired clearances in place. A Roof Brace
(I) is re uired for chimneys that extend more than a certain distance,
as referenced by the manufacturer’s instructions, from the roof.
Manufactured chimneys may feature a built in “twist lock” at each
joint, but a Joint Band (J) is still normally re uired to secure pipe at
the joint. An approved Chimney Pipe Adapter (K) is re uired. A
Ceiling Support (L) will provide structural support for the chimney
and is typically part of a kit that includes items that maintain re uired
clearances to flammables. A Storm Collar (M), and Adjustable
Flashing (N) prevent water from entering the home by running down
the outside of the chimney. Additional items or a kit (O) provide
additional mounting support or fire protection to the roof joists or
other roof components.
-20-
Table of contents
Other Legacy Stove manuals
Popular Stove manuals by other brands

wiking
wiking Bazic 3 Mounting

Regency
Regency FG38-LPG Owners & installation manual

Savoie
Savoie FRANCO BELGE 174 08 02 Technical manual

Breckwell
Breckwell Luxury P2000I owner's manual

Regency
Regency FIREGENIE FG39-LPG Owners & installation manual

Flame Energy
Flame Energy XTD 1.9 FL045W Installation and operation manual

Simpson
Simpson DirectVent Pro installation instructions

HETAS
HETAS FARROW 5.0kW user guide

Wolf Steel
Wolf Steel Napoleon Haliburton GDS28-1NSB Installation and operation manual

MCZ
MCZ KLIN COMFORT AIR 8 M1 installation guide

Harman
Harman XXV installation manual

Extraflame
Extraflame COMFORT IDRO user manual
